mxr M102 DYNA COMP User manual

92503016097revB
M102 DYNA COMP

SAMPLE SETTINGS
M102 DYNA COMP®COMPRESSOR
DESCRIPTION
•In-linecompressor“evens
out”yoursignal
•Especiallyusefulforincreased
sustainwithstabledynamics
•Nashvillestudiostandard
CONTROLS
 OUTPUTknobcontrolsoverall
effectvolume
 SENSITIVITYknobsets
compressionratio
 FOOTSWITCHtoggleseffecton/
bypass(redLEDindicateson)
SPECIFICATIONS
InputImpedance 1MΩ
OutputImpedance 10kΩ
NominalInputLevel -5dBV
NominalOutputLevel -12dBV
NoiseFloor* 95dBV
T.H.D 0.2%Typ.at-20dBV,1kHz
MaxCompression 36dB
AttackTime 5ms
ReleaseTime 1s
Bypass TrueHardwire
CurrentDraw 3.3mA
PowerSupply 9voltsDC

*A-weighted
NASHVILLE NASTY
BOTTLENECK
NEW WAVE SQUASH
DIRECTIONS
•Runacablefromyourguitar
totheDynaComp’sINPUTjack
andrunanothercablefromthe
DynaComp’sOUTPUTjackto
youramplier.
•Startwithallcontrolsat
12o’clock.
•Turntheeffectonbydepressing
thefootswitch.
•RotateOUTPUTknobclockwise
toincreaseoverallvolumeof
effectorcounterclockwiseto
decreaseit.
•RotateSENSITIVITYknob
clockwisetoincreasesensitivity
(morecompression)orcounter-
clockwisetodecreaseit(less
compression).
DUNLOP MANUFACTURING, INC.
P.O. BOX 846 BENICIA, CA 94510 U.S.A.
TEL: [phone] FAX: [phone]
POWER
TheDynaCompispoweredbyone
9-voltbattery(removebottomplate
toinstall),a9-voltACadaptersuch
astheDunlopECB003/ECB003E,
oraDCBrick™powersupply.
