mxr UNI-VIBE M68 Manual

92503016632revA
M68 UNI-VIBE® CHORUS/VIBRATO

SAMPLE SETTINGS
M68 UNI-VIBE®CHORUS/VIBRATO
STAR SPANGLED
BANNER
YOUR SETTING
MACHINE GUN
DUNLOP MANUFACTURING, INC.
P.O. BOX 846 BENICIA, CA 94510 U.S.A.
TEL: [phone] FAX: [phone]
CONTROLS
SPEED knob controls sweep
rate of effect
VIBE button toggles between
default Chorus Mode and
Vibrato Mode
LEVEL knob controls overall
volume of effect
DEPTH knob controls overall
intensity of effect
5FOOTSWITCH toggles effect on/
bypass (white LED indicates on)
DESCRIPTION
• Legendary effect in a
smaller housing
• Chorus mode sounds rich, lush
• Vibrato mode delivers a deep,
shimmering texture
• True bypass
DIRECTIONS
• Run a cable from your guitar
to the Uni-Vibe’s INPUT jack
and run another cable from
the Uni-Vibe’s OUTPUT jack
to your amplier.
• Start with all controls
at 12 o’clock.
• The Uni-Vibe’s default setting
is Chorus Mode (dry signal mixed
with pitch-shifted signal). Push
VIBE button to engage Vibrato
Mode (pitch-shifted signal only—
indicated by red LED).
• Turn the effect on by depressing
the footswitch.
• Rotate LEVEL knob clockwise
to increase overall volume or
counterclockwise to decrease it.
• Rotate SPEED knob clockwise
to increase sweep rate of effect or
counterclockwise to decrease it.
• Rotate the DEPTH knob
clockwise to increase intensity
of effect or counterclockwise to
decrease it.
SPECIFICATIONS
Input Impedance 1 MΩ
Output Impedance 5 kΩ
Max Input 0 dBV
Max Output 8 dBV
Noise Floor* -94 dBV
Speed Control 0.5 Hz to 10.5 Hz
Bypass True Hardwire
Current Draw 5 mA
Power Supply 9 volts DC
*A-weighted, all controls at mid position
POWER
The MXR Uni-Vibe®Chorus/ Vibrato
is powered by one 9-volt battery
(remove bottom plate to install),
a 9-volt AC adapter such as the
Dunlop ECB003/ECB003E, or a
DC Brick™power supply.
