My Child Pinto User manual

Pinto Travel System
Travel system with seat unit, infant carrier, hood
and raincover
Instructions: Please read carefully and keepfor future
reference. Your childs safetymay be affected if you do not
follow these instructions
Seat unit is suitable from 6months upto 15kg
Group 0+ infant carrier suitable from birth to 13kg
Confroms to ECE R44.04
This product is testedto: BSEN1888:2003 (A1-A3:2005)

Parts
Car seat x 1
2
Chassis x 1
1
Front wheels x 2 Basket x 1
2
3
Rear wheels x 2
4 5 6
Raincover x 1 Bumper bar x 1 Footmuff x 1
7 8 9
Seat unit x 1
NOTE: check the chassis for the parts listed above as
some parts may already be fitted to the chassis.
Hood x 1
10 11 12
Head hugger x 1 Insert cushion x 1
Thank you for purchasing the MyChild Pinto. Please read the instructions and warnings carefully before
use to ensure safe and satisfactory operation of this product.
Your child’s safety is your responsibility. If you have a query with this product or require replacement
parts, please contact your MyChild retailer.
Lay out the parts on a soft level surface and compare to the part/fixings checklist below. Do not discard
any packaging until you are sure that you have all the parts.
Keep children clear during assembly as pack contains parts and plastic bags which may present a
choking or entrapment hazard.

A.1
3
B.
Opening the stroller
B. Make sure both locks snap into place on both sides of the stroller.
Assembling the wheels
C.1. Push front wheel axle into front wheel housing until they click into place.
C.2. Push rear wheel axle into rear wheel housing until they click into place.
A. Release the storage latch by pulling the storage latch release lever, then lift the handle to open the stroller.
C.1 C.2
Operating the swivel wheels and brake
D.1 D.2
D.1. Push down swivel/lock slider to lock the front wheel. Lift the swivel lock slider to release the lock.
D.2. Push down the brake bar with your foot to apply the brake. Lift up the brake bar to release the brake.
A.3
A.2
Adjusting the handle height
E. The handle has 3 height settings. Press down both buttons on the top of the handle to adjust the height
of the handle up or down.
E.

4
Folding the stroller
NOTE: remove child from stroller and lock the brake so the stroller is secure.
G. Push slider button G.1 to the left, then squeeze the large lever G.2. Keep pressure on the large lever
G.2, and let go of the slider G1.
H. While you are still pressing the large lever G.2, pull up safety lock H with two fingers. Push down on the
handle to fold stroller. Fold the handle down until the carrying latch automatically engages. You should hear
it ‘CLICK’ into place.
F . Release the carrying latch. See page 3 (A and B) for instructions
IMPORTANT NOTE: be careful not to mistake the 1-finger carrying latch with the 2-finger safety
lock lever (H).
G.1
G.2
H
K
I.2
Assembling the hood
L
I.1
CLICK
Attaching bumper bar
J
Removing bumper bar
K - L. To assemble the hood, place over fixing mounts and slide down. To release the hood press the
release tab (located on the end of the hood mounting bracket) and slide the hood up.
I.1 + I.2 To assemble the bumper bar, place over fixing mounts and push prong into holes.
J Press button under bumper bar mounting bracket and pull out the bumper bar.
G

5
O.
O. (+Q carrycot is optional extra) To attach the seat, carrycot or the infant carrier to the stroller frame place
onto the two adapters found on each side of the chassis, make sure both locks click into place.
P. Pull the silver release levers on the adaptors to take out the seat, carrycot or the infant carrier.
IMPORTANT NOTE: before putting a child inside - lift the pushchair up by the seat unit/ carrycot/ carseat to
ensure it is firmly connected to the chassis.
Fitting and removing the carrycot and infant carrier
Q
*Carrycot is optional extra
*
R.1.
R.2.
P.
R.1 R.3
To remove the seat, grip the seat unit on both sides. Use your forefinger to lift the release
button on the outside of the adaptor. Lift the seat unit off the adaptors.
To fit the seat in forward facing mode, hold the seat unit so that it is facing forward. Locate the seat
joints above the adaptors and push the seat downwards until it CLICKS into place.
R.3.
To fit the seat in parent facing mode, hold the seat unit so that it is facing the handle. Locate the
seat joints above the adaptors and push the seat downwards until it CLICKS into place.
WARNING: never remove the seat unit when a child is in the seat. Always remove your child before
turning the seat unit around.
ATTENTION: lift up the seat unit to ensure it is firmly connected to the adaptors.
Removing and positioning the seat unit
R.2

Adjusting the Harness
Seat unit
Undo the harness as shown in the section above, operating the harness.
The shoulder straps can be adjusted by locating the buckle underneath the back of the seat unit as shown. Twist
the buckle and feed though the harness button hole.
Once the buckle is fully out of the hole, reposition into the desired height setting and thread the buckle back
through so it is underneath the seat unit.
To ensure the strap is fitted correctly and secure, pull the strap up sharply.
T.1
T.2
T.3
T.4
T.1 T.2 T.3 T.4
Fitting the footmuff
12
3 4
5
34
5
12
U.1 U.2
U.1 - Unclip the harness. See section T.
U.2 - Thread the harness straps through the back of the footmuffs button holes. Pull the harness straps
through and check the buckle locks into postion.
Note: please make sure the harness shoulder straps are placed through the same height holes.
Operating the harness
T o secure the harness, snap each side of the waist belt into the centre buckle. Adjust shoulder straps and
waist band to fit child by adjusting the sliders . T o release press tabs inwards on the quick release fastener
and pull apart (
S.2).
S.1.
S.1
S.2
Warning: the shoulder straps can be completely removed from the stroller when adjusting the position.
Please ensure it is secure before use.
6

7
Safety Information when using the seat unit and car seat with the pushchair chassis
This seat unit is suitable for children from 6months to 15kg.
Warning: to avoid injury ensure that your child is kept away when unfolding and folding this product.
Warning: do not let your child play with this product.
Warning: it may be dangerous to leave your child unattended
Warning: always use the crotch strap in combination with the waist belt
Warning: parcels, accessories and other items (eg hand bags, shopping bags, etc) that are placed on the
pushchair may cause the unit to become unstable
Warning: do not lift and carry the pushchair while open with a child in it
Warning: do not use the pushchair on steep slopes, stairs, escalators, beaches, mud, etc
Warning: check that the pram body or seat unit attachment devices are correctly engaged before use
Warning: do not allow your child to climb unassisted into the pushchair
Warning: use the D rings provided for the attachment of a separate safety harness approved to BS6634
Warning: never leave rain covers, hoods and aprons on indoors and in hot weather
Warning: do not use replacement parts or accessories other than those approved by manufacturer or retailer
Warning: the basket weight must not exceed 2kg
Warning: always apply the brakes when the pushchair is stationary
Warning: taking children up or down stairs, escalators, steps, steep slopes and muddy/rough terrain could be
dangerous and should not be attempted. Any resulting damage will not be covered under the warranty.
Remove your child from the pushchair and fold up for easy carrying to negotiate such hazards, or simply avoid
them.
Warning: do not allow children to play with the stroller
Warning: never assume a driver can see you or your child
Warning: if your stroller is to be used by someone unfamiliar with it, e.g grandparents then show them how it
works before letting them use it
Warning: this pushchair is not suitable for running or skating.
Warning: hold onto your stroller when close to moving vehicles and trains as the draught from the vehicles
may move the stroller even with the brakes on.
Care and maintenance:
Fabrics and chassis can be cleaned with non-abrasive cloth and mild detergent.
Do not use bleach or use strong detergents.
Inspect parts regularly. Contact retailer or manufacturer for servicing.
MyChild M34 3QA
email: [email protected]

8
Safety advice when using the car seat in a vehicle
Warning: the correct fitting of the car seat belt (following the red guide markings) is of vital importance
for the safety of your child. See the labels on the seat itself.
Warning: keep these instructions with the seat for future reference.
Warning: never leave your child unattended.
Warning: NEVER use the child seat on a passenger seat that is fitted with a front airbag. THIS CAN BE
VERY DANGEROUS.
- The product is only safe if it is used in strict accordance with these instructions.
- The product must only be used on forward facing passenger seats which are fitted with automatic.
3-point safety belt which are approved to ECE R16 or equivalent.
- The product may be used on a front or rear passenger seat but we recommend that it is fitted on the
rear passenger seat.
- The product must be replaced if it is involved in an accident as it may have unseen damage.
- Do not use this product second hand as you do not know its history.
- Ensure that all other passengers, luggage and loose objects are properly secured.
- Do not lubricate any of the moving parts.
- It is recommended that the car seat should not be used more than 5 years from the date of production
the product may deteriorate due to, for example, ageing of the plastic.
- Never use the child seat without the covers. Only covers approved by the manufacturer may be used.
- The child seat must be secured with the car seat belt when not in use.
- Ensure that the seat is not damaged by heavy objects or being caught in the car door.
- Never make unauthorised alterations to the product.
- Child seat parts may become hot in direct sunlight. Cover with sheet to prevent this.
- Most accidents occur on short trips, so do not be tempted to avoid using the seat simply because you
are not travelling very far.
- Do not leave the child in the seat for long periods of time. Take regular breaks on long journeys.
- Set a good example by always wearing a seatbelt yourself.
- Make sure that your child never plays with the buckle.
Warning: failure to follow each of the following instructions can result in your child striking the vehicle’s
interior during a sudden stop or crash.
Warning: take care that the straps holding the restraint to the vehicle, are as tight as possible. Make sure
that the straps restraining the child are adjusted to the child’s body and the straps are not twisted.
Warning: it is important that the lap part of the harness belt system is worn low down, so that the pelvis
is firmly engaged.
Warning: the child restraint system MUST BE CHANGED after it has suffered from a violent impact in an
accident.
Car seat belt
The product must only be used with a 3-point car seat belt that has been approved to ECE R16 or
equivalent. NEVER use a 2-point seatbelt.Your child seat can be fitted in most cars. However, some cars
are designed so that proper installation is not possible. In this case, try another seat.
Notice
1. The child car seat must only be used in vehicles which are fitted with a three point seat belt system
that has been approved by regulation ECE-16 or similar.
2. A correct fit is likely if the vehicle manufacturer has declared in the vehicle handbook that the vehicle
is capable of accepting a‘Universal’ child restraint for this group.
3. The child carseat is a ‘Universal’ child restraint; it conforms to regulation ECE R44/04 for general use
in vehicles. It will fit most, but not all vehicle seats.
4. This child seat has been declared ‘Universal’ under more stringent conditions than those applied to
earlier designs, which do not carry the ‘Universal’ mark.
5. Child car seats canmark vehicle seat upholstery. The manufacturer cannot be held responsible for
damage or marking to vehicle seats.
6. Never use rearward facing child seat on a passenger seat with an active airbag.
7. If in doubt, consult manufacturer or the retailer.

9
Car seat travelling advice
In order to maximise the protection that the seat can give your child, please adjust the harness so that
it fits snugly and make sure that the seat is fitted correctly. Research shows that correct installation is
the most important factor in car seat safety. Please take the time to read the instruction manual care -
fully. Our product offers maximum protection when it is used in accordance with the instructions.If you
have any questions concerning the use of the product please do not hesitate to contact us.
- This child seat is designed for use for children whose weight is 13kg or less and whose heights are
66cm (26 inches) or less.
- This child seat must only be used rear facing position, and must NEVER be used forward facing. For
maximum protection, the centre rear seat position is recommended as the safest position in most
vehicles for installing a child restraint. (Only if the vehicle seat is fitted with a 3-point adult belt).
- Your child seat should not be purchased or sold as a second hand item.
- Remove child out of the car as first priority in an accident.
- While travelling it is recommended that any luggage or other objects liable to cause injuries in the
event of a collision shall be properly secured.
- Do not use your child seat on a vehicle seat with lap belts only.
- Your child seat should be securely belted to the vehicle, even when unoccupied because in a crash an
unsecured child seat may injure other passengers.
- Please take a rest every two hours if you are travelling with a baby in the car seat.
- Please check the car seat condition if you are going to travel a long distance with a child.
- Please put all excess luggage into the boot of your car if you are going to travel with a baby, because
loose items may hurt a baby when travelling on unstable roads or because they move suddenly when
braking.
- Please always check the car seat before you place a baby into it.
- Please get in touch with the dealer if anything breaks on the car seat. Only the manufacturer or an
authorised agent may do repairs. DON’T try and fix the car seat by yourself. It might be damaged or
cause more damage.
- Always check the buckle hole before you buckle up as it may contain crumbs or obstructions that
prevent a secure lock.
- Keep your car seat out of reach of children when not in use.
- Please keep the PE bag out of the reach of children when unpacking the car seat.
- NEVER place the car seat on a seat where an air bag is active.
- Do not modify the car seat.
Airbag warning
Cleaning instructions
- For quick cleanups, simply blot the desired area with a mild soap solution using a damp sponge and
cool water. Clean your car seat base with a mild soap solution and cool water. Never use household
detergents they can weaken plastic components.
- Harness straps are only surface washable with a damp cloth and a mild soap solution.
DO NOT! machine wash or use hot water to wash.
! Extreme Danger !
Do not use a rear facing car seat on a front passenger seat where a passenger side
air bag is fitted. The air bag inflates rapidly and can throw a rear-facing child seat
into the back of a passenger seat with great force, which can injure a child.

10
Parts
Handle adjustment
A.1
Face the seat: push the red button each side of the handle, rotate and release the red button to desired
position until you hear a click. There are three positions available. See the picture.
A.1. carrying/fitting position, make sure handle is locked.
A.2. Rocker - keep away from the edge of surfaces e.g. tables.
A.3. Feeding position.
NEVER place the car seat on a soft surface e.g. cushion, mattress, pillow etc, due to risk of suffocation if
car seat tips over. Never leave a child unattended.
A
B
C
D
E
F
A.2 A.3A.1
Shoulder strap
Harness adjuster
Belt hook
Handle adjustment
Carry handle
Shoulder pads
Crotch pad
Insert cushion
Head hugger
A.
B.
C.
D.
E.
F.
G.
H.
I.
G
H
I
B.1.To remove the headhugger, undo the harness and remove the chest pads by sliding them down the
harness.Thread the harness straps through the button holes at the base of the head hugger from front to
back and remove. Replace chest pads if required and fasten harness.To fit the head hugger, undo the harness
and remove the chest pads, thread the harness straps through the head hugger button holes from the back
to the front, replace chest pads and fasten harness.
B.2.The insert cushion is designed to give newborn and smaller babies extra support.To remove the cushion,
undo the harness and take the cushion out.To fit the cushion, undo the harness and place the cushion in the
car seat so that the curved cut-out area sits just behind the crotch pad.
B.1
Removing the head hugger and insert cushion

Harness adjustment
(Approx weights)
Newborn - 10kg
10kg - 13kg
C.1. This car seat has 2 sets of slots. Select the most suitable slots according to the child’s weight.
The shoulder harness straps should emerge from the backrest level with (or slightly above) the child’s
shoulders.
C.2. To change the harness strap position, undo the harness straps and remove chest pad by sliding it
down the shoulder strap. Pull through the belt slots in the back of the car seat and re-thread them through
the desired slots.
NOTE: Make sure the harness straps are set at equal heights before using the car seat.
C.1 C.2
Positioning the car seat
WARNING: Do NOT fit the car seat were an active air bag is fitted.
NOTE: Only fit the car seat using a 3 point seat belt.
11

Installing the car seat
NOTE: If the vehicle seat belt buckle is above the top edge of the child seat then this car seat is not suitable
for the vehicle (this is called ‘buckle crunch’ and can cause the vehicle seat belt to come undone in an
accident).
DEF
D. Choose a seat suitable for fitting the car seat to. See section above.
E. Pull the seat belt straps so there is a lot of slack allowing you to wrap it around the car seat. This will make
it easier to thread through the correct mounting points
F. Fit the lap belt across the car seat first by sliding the belt under the two side mouldings
H
GG.1 G.2
G. Once the lap belt is secure wrap the shoulder belt around the back of the car seat and attach it into the
clip (see G.1) Make sure all the slack is out of the shoulder belt (see G.2)
H. Once the seat belts are in their correct mounting points make sure the seat belt buckle is secure and
there are no twists in the belt.
NOTE: Pull front to back and left to right to check for secure installation.
NOTE: Vehicle MUST be on level ground and child seated when levelling.
I.1 I.2
12

7
Fitting the harness
Removing the car seat
1. Press the red release button on buckle, unfasten the buckle connector A&B.
2. Lift up the harness straps and lay them flat on the back of child seat.
3. Take your child out of the child seat.
4. Unbuckle the vehicle seat belt.
5. Pull out the vehicle seat belt through the seat belt hooks in the child seat.
6. Remove the child seat from the vehicle.
A
B
J1
J2
J3
J4
J6
J7
J1 - Press the belt adjuster
button and pull on the
shoulder harness straps to
create slack. DO NOT pull
on the shoulder pads as
these are fixed.
J3 - Place the child in
the seat and ensure
there are no spaces
under the child.
J4 - Place the
shoulder harness
over the shoul-
ders.
J6 - Pull the harness
adjuster strap to
secure the harness
around the child.
J7 - The harness should allow 2
finger-widths of space. This is
the ideal tightness.
J8 - To release harness: Press the red
button on the buckle and pull out the
shoulder harness.
J5 - Buckle up the
harness. Ensure
harness buckle is
firmly clicked into
place.
J2 - Unbuckle the
harness and move
the shoulder straps
apart.
J5
J8
START HERE
Note: do not
place your child
in a sleeping
bag, blanket or
other bulky
wrapping before
putting the child
in the restraint.
The shoulder
straps will not fit
snugly and the
child will not be
safe.
Note: a new
born baby will
need extra
support around
the head and
body. Please
don't remove
the cushion if
you are going to
use it for your
newborn baby
or baby less than
7 months old.
Note: check that the buckle is
secured by attempting to pull
the above and below part to
remove the connectors.

[e-mail]
Imported by MyChild. M34 3QA
www.mychildonline.co.uk
