MyKronoz ZeFit2 Pulse User manual

ENGLISH
CHARGING
PAIRING
WEARING
DISPLAY
ACTIVITY
HEART-RATE
TIMER
SLEEP
GOALS
REMINDERS
NOTIFICATIONS
SMS
MISSED CALLS
TECH SPECS
05
06
08
09
10
11
11
12
13
13
14
15
15
16
Pulse

4
CHARGING
TERMINALS
TOUCH
SCREEN
OVERVIEW
i
To interact with ZeFit2Pulse touchscreen, double tap on the touch-sensitive area to wake the
device. ZeFit2Pulse touchscreen only respond to tap gestures in this specific touch-sensitive
area. ZeFit2Pulse screen turns off when not in use. To ensure ZeFit2Pulse is responding
accurately to your taps, we recommend using your fingertip and not your nail. To move
between screens, swipe left or right.

5
1. CHARGING
Charge ZeFit
2
Pulse for two hours before your
first use.
1. Put ZeFit
2
Pulse on the magnetic charging
dock
2. Make sure the pin on the charging dock fit
correctly onto the charging terminals on the
back of ZeFit
2
Pulse
3. Plug the small end of the USB cable
provided into the charging’s dock USB port
4. Plug the big end of the USB cable into a
power source
5. A battery indicator will fill to indicate
charging is in progress. Once ZeFit
2
Pulse is
charged, the battery indicator will be full
i
A full charge takes 1:30 hour. When the
battery level gets low, a battery indicator
will appear.

6
2. PAIRING
GET ZeFit2Pulse APP
The first time you use ZeFit2Pulse, a SET UP message will prompt you to set
up your ZeFit2Pulse using a mobile device or a computer.
To set up your ZeFit2Pulse using your mobile device, you first need to get
ZeFit2App. Search for ZeFit2App in the App store, Google Play or Win-
dows Phone store, download and install the App on your mobile device.
iOS Android Windows Phone
System Requirements
Visit www.mykronoz.com to get the latest compatibility list
iOS 7+ devices with Bluetooth 4.0 BLE
iPhone 4s, 5, 5c, 5s, 6, 6 Plus, iPad (3rd, 4th
and 5thgen) iPad Mini, iPod touch (5thgen)
Select Android 4.3 +
devices that support
Bluetooth 4.0 BLE
Select Windows
Phone 8.1 that support
Bluetooth 4.0 BLE
i

7
I You can also set up your ZeFit
2
Pulse using our Mac or PC software available on
MyKronoz website: http://www.mykronoz.com/support/
I System requirements: Windows 7,8, XP,10 - Mac OS X 10.8 and above
1. Enable Bluetooth on your mobile device
2. Open ZeFit
2
App on your mobile device. Sign up if you are a new member or Log in
with your existing account. After entering your personal information, tap Set up
3. Make sure ZeFit
2
Pulse is nearby and select ZeFit
2
Pulse in the list of devices
4. You will receive a pairing request on your mobile device.
Press Pair to accept it
5. Then, a pairing request will appear on your ZeFit
2
Pulse
display. Tap on your ZeFit
2
Pulse to accept the pairing
6. When ZeFit
2
Pulse is successfully paired, you will be
notified on ZeFit
2
Pulse and on your mobile device’s screen
i
If pairing fails, repeat the same steps. Pairing is a one-time process. If you want to
pair ZeFit2Pulse with another account, you first need to unpair it from the current
one. Open ZeFit2App, go to Settings > Connect ZeFit2Pulse > Unpair ZeFit2Pulse.
Tap Connect ZeFit2Pulse to pair a new device

8
3. WEARING
ZeFit
2
Pulse has a removable wristband and is
adjustable to fit different wrist sizes.
1. Pop ZeFit
2
Pulse tracker unit into the wristband
2. Place ZeFit
2
Pulse around your wrist and put the
clasp pin inside the hole
3. Press a few times to ensure the pin is fully
inserted and that ZeFit
2
Pulse is securely fastened
i
To get the most accurate data, we recommend wearing ZeFit2Pulse on your
non-dominant hand and not too loose.

9
i
ZeFit
2
Pulse will automatically sync the time and date of your paired mobile device. You can set
your preferred time and date format manually in the Settings tab of ZeFit
2
App. Make sure you
keep the device charged to avoid the time being reset
4. DISPLAYS
Homepage 24h
Incoming call Pairing request Upgrading
Homepage 12h Syncing
Full memory Low power Successful pairing
Sleep modeActivity mode Anti-lost alert

10
i
ZeFit2Pulse shows daily data. The activity tracker resets at midnight. To upload your
latest activity data, do not forget to tap the sync icon in the upper right hand corner
of ZeFit2App
5. ACTIVITY
ZeFit2Pulse tracks the number of steps taken, distance travelled, calories
burned and heart rate level throughout the day. You can view your daily
activity in real-time on ZeFit2Pulse display by swiping left or right on the
touchscreen.
STEPS DISTANCE CALORIES

11
7. TIMER
On the timer interface, press and hold the display for 3 seconds to launch
the timer. Repeat the same steps to turn it off.
6. HEART-RATE
On the heart-rate interface, press and hold the display for 3 seconds to
launch heart rate monitor. You can define your tracking frequency and heart
rate zones in ZeFit2app and set up an alert if you reach a low heart rate or
high heart rate level.

12
ZeFit2Pulse tracks the hours slept and the quality of your sleep
(light sleep, deep sleep, awake times)
I START / EXIT SLEEP MODE
To start sleep mode, open ZeFit2App, tap on the bottom purple sleep bar,
click on Add sleep log > Start Sleep now
To end sleep mode, open ZeFit2App, tap on the bottom purple sleep bar,
click on Add sleep log > Awake
I PRESET SLEEP
Open ZeFit2App > Go to Settings > Advanced Settings > Click on Preset
sleep to enter your desired bed and wake up times. By default, ZeFit2Pulse
will track your sleep from 11pm until 7am.
i
To upload your latest sleep data, do not forget to tap the sync icon in the upper right hand
corner of ZeFit2App.If you forgot to activate sleep mode, you can manually add sleep
logs in ZeFit2App. Open ZeFit2App, click on Add sleep log > Add sleep
8. SLEEP

13
9. GOALS
10. REMINDERS
Tap the Goals tab of ZeFit2App to set daily goals for steps taken, distance travel-
led, calories burned and hours slept. Click on the sync button in the upper right
corner to save your goals. On the Steps screen of your ZeFit2Pulse, a progress bar
will show how close you are to your daily goal.
Tap the Reminders tab of ZeFit2App to add daily life reminders. You can set up
to 6 daily reminders, and choose the type of reminder and preferred time and
day. ZeFit2Pulse will gently vibrate and display the corresponding reminder icon
to alert you. A single tap on your ZeFit2Pulse can dismiss the reminder. If not
dismissed, the same alert will repeat after two minutes.
Once you hit one of your daily goal, ZeFit2Pulse will
gently vibrate and display a Goal achieved icon

14
11. NOTIFICATIONS
ZeFit2Pulse shows notifications of incoming and missed calls, SMS, email, social
media activity, calendar events and anti-lost alert*. Open ZeFit2App, tap Settings >
Notifications to select the notifications you want to receive onto your ZeFit2Pulse.
If you wish to disable certain notifications, swipe the selection button to the left.
A single tap on your ZeFit2Pulse can dismiss the notification. If not dismissed, the
notification will reappear next time you wake up the screen.
Setting up notifications for iOS users:
I Go to “Settings” of your iOS device
I Tap “Notification Center”
I Select which type of notifications you wish to receive on ZeFit2Pulse
I Enable ”Show in Notification Center” to receive the notification on ZeFit2Pulse
i
Caller ID supports latin character only. For more languages support, please contact
[email protected]. *Windows Phones may not support those features, please contact
[email protected] more information.

15
12. SMS
13. MISSED CALLS
When receiving a SMS notification, press and hold ZeFit2Pulse display to read the
SMS content and see the identity of the sender. You can scroll down to read the full
text message.
Press and hold to skip to another SMS.
When receiving a Missed Call notification, press and hold ZeFit2Pulse to see the
identity of the missed call. You can scroll down to check the missed call history.
Press and hold to skip to another notification.
i
You can read the latest 3 SMS received. You can view the latest 5 Missed Calls.

16
14. TECH SPECS
Size & Circumference 50 x 22. 5 x 11.7 mm
Min:154 mm
Max: 210 mm
Weight 25 gr
Bluetooth 4.0 BLE
Battery type Li-iOn 200 mAh
Battery life Up to 10 days
Charging time 2 hours
Memory 14 days of activity
Display TFT Color touchscreen (0.9” / 160*80 pixels)
Sensor 3-axis accelerometer
Operating temperature -20°C to +40°C
Water resistance IP67
International warranty 1 year

17
06
07
11
13
14
14
15
16
17
18
19
20
20
21
FRANÇAIS
Pulse
CHARGE
APPAIRAGE
COMMENT LA PORTER
AFFICHAGES
ACTIVITÉ
FRÉQUENCE CARDIAQUE
CHRONOMÈTRE
SOMMEIL
OBJECTIFS
RAPPELS
NOTIFICATIONS
SMS
APPELS MANQUÉS
SPECS TECH
19
20
22
23
24
25
25
26
27
27
28
29
29
30

18
PRÉSENTATION
i
Pour interagir avec l’écran tactile de ZeFit
2
Pulse appuyez deux fois sur la zone tactile. L’écran tactile de ZeFit
2
Pulse répond uniquement aux touchés dans cette zone spécifique. L’écran de ZeFit
2
Pulse s’éteint lorsque vous
ne l’utilisez pas. Appuyez deux fois sur la zone tactile pour rallumer l’écran de l’appareil. Pour s’assurer que ZeFit
2
Pulse réponde précisément aux pressions, nous recommandons d’utiliser votre doigt et non votre ongle. Pour
naviguer d’un écran à un autre, faites glisser votre doigt sur l’écran vers la gauche ou la droite
CONTACTS
DE CHARGE
ÉCRAN
TACTILE

19
1. CHARGE
Chargez ZeFit
2
Pulse pendant deux heures
avant sa première utilisation.
1. Disposez ZeFit
2
Pulse sur son socle de
charge magnétique
2. Assurez-vous que les bornes du socle soient
bien alignées avec les contacts de charge
situés à l’arrière de ZeFit
2
Pulse
3. Branchez la petite extrémité du câble USB
fourni dans le port USB de la station de charge
4. Branchez la grande extrémité du câble USB
à une source d’alimentation
5. Un indicateur de la batterie confirme que la
recharge est en cours. Une fois ZeFit
2
Pulse est
chargée, l’indicateur de la batterie sera plein
i
Une charge complète prend 1h30.
Lorsque le niveau de la batterie est faible,
un indicateur de batterie s’affiche

20
2. APPAIRAGE
Téléchargez l’application ZeFit2
Lors de la première utilisation de ZeFi
t2
Pulse, le message SET UP à l’écran vous
indiquera de la configurer à l’aide de votre appareil mobile ou de votre ordinateur.
Pour configurer votre ZeFit
2
Pulse à l’aide de votre appareil mobile, vous devez
préalablement télécharger l’application ZeFit
2
. Recherchez l’application ZeFit
2
sur l’App
store, Google Play ou Windows Phone store, téléchargez-la et installez-la sur votre
appareil mobile.
iOS Android Windows Phone
Configurations requises
Consultez la liste des appareils compatibles sur www.mykronoz.com
Les appareils iOS 7+ équipés de Bluetooth
4.0 BLE - iPhone 4s, 5, 5c, 5s, 6, 6 Plus - iPad
(3ème , 4ème and 5ème gen.) iPad Mini - iPodtouch
(5èmegen.)
Certains appareils
Android 4.3 + équipés de
Bluetooth 4.0 BLE
Certains appareils
Windows Phone 8.1
équipés de Bluetooth
i
