MyKronoz ZeRound 2 User manual

Round
ENGLISH
2
CHARGING...............
SET UP.......................
CALLS.......................
CALL HISTORY/SMS..
NOTIFICATIONS........
VOICE CONTROL......
ACTIVITY....................
SLEEP TRACKING..............
FIND MY PHONE..............
CAMERA REMOTE............
APPS...................................
MUSIC................................
SETTINGS...........................
TECH SPECS.......................
06
07
09
11
12
13
14
14
15
15
15
16
16
17

4
TOUCHSCREEN
SPEAKER BUTTON
TOUCH-SENSITIVE
AREA
MICROPHONE
OVERVIEW
i
BUTTON
I Power ON / OFF:
long press for 3 seconds.
I Press to go to the clock face.
TOUCH-SENSITIVE AREA
I Tap on the touch-sensitive area
to go back to previous menu.
I RESET long press for 8 seconds.

5
i
If you want to change your ZeRound
2
watch face, press firmly on the current watch
face, swipe left or right to go through the different watch faces available and tap on
the one you want to select and use.
NAVIGATE THE TOUCHSCREEN
I Tap with one finger
to open or select a
menu item.
I Slide to the right
for activity menu.
I Slide to the left for
main menu.
I Slide up for notifications.
I Slide down for shortcuts.

6
i
2.
3.
1.
1. CHARGING
Charge ZeRound
2
for two hours before your
first use.
1. Put the charging cradle beneath the watch.
2. Make sure the pins fit correctly onto the
charging terminals on the back of ZeRound
2
.
3. Connect the charging cradle with the USB
cable.
4. Plug the big end of the USB cable to a
power source.
5. A battery indicator will fill to indicate charging
is in progress. Once ZeRound
2
is charged, the
battery indicator will be full.
i
A full charge takes 2 hours. Unplug the
cable after ZeRound2is fully charged.
When the battery level gets low, a low
battery indicator will appear.

7
2. SET UP
I Make sure the Bluetooth is enabled on your mobile device.
I Download ZeRound2application from the App store or the Google Play Store.
I Open ZeRound2application on your smartphone and follow the on-screen
instructions.
I If the automatic pairing process is not starting, go to the settings menu and
click on “Connect ZeRound2”.
I To connect the first Bluetooth antenna, follow the application’s instructions.
I To connect the second Bluetooth antenna, open the Bluetooth settings of your
phone and select ZeRound2.
If your Android phone is NFC compatible, you can enable the pairing operation
by simply approaching ZeRound2to your Smartphone.
i
You only need to pair your device once. After the initial pairing, ZeRound2will
automatically connect to your phone as long as it is turned on and within range.
To pair ZeRound2with another smartphone, we recommend you to first unpair it
from your original device and then repeat the pairing procedure described above.

8
ZeRound2will sync the notifications of SMS, emails, social media, calendar events, and personal
life reminders once ZeRound2App has been successfully installed on your smartphone. Please
note some features will not work unless ZeRound2App has been installed on your smartphone.
Visit www.mykronoz.com to get the latest compatibility list.
System Requirements
iOS 8+
iPhone 4s, 5, 5c, 5s, 6, 6s, 6s plus, 7,
7 plus, iPad (3rd , 4th and 5th generation)
iPad Mini, iPod touch (5th generation)
SELECT ANDROID 5.0 +
ZeRound2app is available for select
Android 5.0 + devices that support
Bluetooth 4.0
i

9
3. CALLS
ZeRound2allows you to make and receive calls.
MAKING A CALL
FROM THE PHONE MENU
MAKING A CALL
FROM THE PHONEBOOK
Go to the Phone menu, enter a
number with the dialer
pad and tap on
Go the Phonebook panel,
select a contact and
tap on

10
1. ANSWER
2. REJECT
3. MUTE
1. TURN OFF THE MICROPHONE
2. END CURRENT CALL
INCOMING
CALL OPTIONS
IN-CALL
OPTIONS
12 12
3

11
5. SMS
After a successful Bluetooth connection and installation of ZeRound2App,
you can read SMS messages on your ZeRound2.
QUICK REPLY
You can reply using the SMS template (Android only).
4. CALL HISTORY
From the Call history menu, see the list of recent incoming and outgoing
calls. Tap on the call to view the contact’s name, phone number and make a
call directly or send a SMS (Android only).

12
6. NOTIFICATIONS
After successful Bluetooth connection and installation of ZeRound2App on
your smartphone, ZeRound2will show notifications of SMS, emails, social
media, calendar events and personal life reminders.
SETTING UP NOTIFICATIONS FOR IOS USERS
Go to the Settings of your iOS device:
I Tap on Notifications.
I Select which type of notifications you wish to receive on ZeRound2.
I Enable Show in Notifications to receive the notification on ZeRound2.
i
You can also set up daily life reminders: open ZeRound
2
mobile application, click
on the reminders tab, set up your preferred reminder type and time. ZeRound
2
will
gently vibrate and display the corresponding icon to alert you.

13
7. VOICE CONTROL
Use the Voice Control feature to voice command your mobile device remotely or
search information from the Internet.
To start using the feature, tap on the Voice Control icon to open the respective page
on ZeRound2.
Then tap on the Voice Control again to turn the function on or off.
Examples of what you can ask or do:
I Call (name of your contact).
I Send a SMS to (name of your contact).
I What’s the weather like?
I Set an alarm for tomorrow 5 am.
This feature is available with iOS 8+ devices that support Siri and Select Android 5.0 +
devices that support Google Now. To use voice control, your smartphone must have
access to the Internet using either 3/4G or Wifi.
i

14
8. ACTIVITY
Tap on the Activity icon to open the Activity menu.
I Swipe left or right to see your results of steps, distance, calories and active minutes.
Activity Goals:
I Press on the Goals icon in the settings menu of your ZeRound2or from the
mobile application to change your daily goals.
9. SLEEP
ZeRound2 tracks the hours slept and the quality of your sleep (light sleep & deep sleep).
Start/Exit sleep mode:
I Press on the sleep icon on ZeRound2.
I Long press on Start to start monitoring your sleep.
I Long press on End to stop monitoring your sleep.
Sleep goals:
I Press on the sleep icon on ZeRound2.
I Slide to the right to set up your daily sleep goals.
I Sleep Goal is 8 hours by default.
i
To upload your latest data on your application, go to the Activity menu and slide
your finger down the screen.

15
10. FIND MY PHONE
To enjoy this feature, make sure ZeRound2is connected to your smartphone
via Bluetooth and mobile app. Enabling Find my phone function will make
your phone ring and help you find it.
ZeRound2 tracks the hours slept and the quality of your sleep (light sleep & deep sleep).
Start/Exit sleep mode:
I Press on the sleep icon on ZeRound2.
I Long press on Start to start monitoring your sleep.
I Long press on End to stop monitoring your sleep.
Sleep goals:
I Press on the sleep icon on ZeRound2.
I Slide to the right to set up your daily sleep goals.
I Sleep Goal is 8 hours by default.
11. CAMERA REMOTE
To enjoy this feature, make sure the camera of your smartphone is on. Enabling
Camera Remote function will let you take pictures remotely from your ZeRound2.
12. APPS
Several applications* can be found in this menu:
I Calendar I Alarm I Calculator
I Anti-Lost Alert I Stopwatch I Sound recorder
*Non-exhaustive list

16
13. MUSIC
You can control your smartphone music player using the music app on your
ZeRound2. You first need to start the player from your phone, then you can
use the basic control like skip track, play/pause and volume level adjustment
straight from your wrist.
14. SETTINGS
Use the Settings panel to configure the settings* of your ZeRound2:
I Bluetooth
I Clock
I Wake screen on wrist flick
I Reset
I Sound
I Display
I Watch info
I Language
I Power display
*Non-exhaustive list

17
15. TECH SPECS
Dimensions 45*12 mm
Weight 57 gr
Connectivity Bluetooth 3.0 + 4.0
Battery type Lithium-ion 260mAh
Talk time 2.5 hours
Standby time 3 days
Charging time 2 hours
Display TFT 1.22 inches / 240*204 pixels
Sensor 3-axis accelerometer
Operating temperature -10°C to + 60°C
Water resistance IP67
International warranty 1 year
*Non-exhaustive list

Round
FRANÇAIS
2
CHARGE...................................
CONFIGURATION...................
APPELS....................................
HISTORIQUE D’APPELS / SMS
NOTIFICATIONS......................
COMMANDE VOCALE............
ACTIVITÉ..................................
SOMMEIL..........................................
TROUVER MON TÉLÉPHONE..........
DÉCLENCHEUR PHOTO...................
APPLICATIONS...................................
MUSIQUE...........................................
PARAMÈTRES....................................
CARACTÉRISTIQUES TECHNIQUES..
22
23
25
27
28
29
30
30
31
31
31
32
32
33

20
PRÉSENTATION
ÉCRAN TACTILE
HAUT-PARLEUR BOUTON
ZONE TACTILE
MICROPHONE
BOUTON
I ALLUMER / ÉTEINDRE
Maintenez appuyé le bouton 3 secondes.
I Appuyez sur le bouton pour accéder
au cadran de l’heure.
ZONE TACTILE
I Appuyer sur la zone tactile pour revenir
au menu précédent.
I RÉINITIALISER Maintenez appuyé le
bouton pendant 8 secondes pour réinitialiser.
ii
