Mylaps X2 RACELINK GPS User manual

MYLAPS.COM
QUICK START GUIDE
X2 RACELINK GPS
CHARGER CASE

WHAT’S IN THE BOX?
X2 RaceLink GPS
Charger Case
34x
X2 RaceLink GPS
Adapter and
Power Cable
50x
X2 RaceLink GPS
Holder
CHARGING
Place the X2 RaceLink GPS in one of the designated places in the charger case. Once
connected, the LED on the X2 RaceLink GPS will show the charge indication. The LED will
remain on as long as the X2 RaceLink GPS Charger Case is connected to power.
The X2 RaceLink GPS Charger Case charges up
to 34 X2 RaceLink GPS at the same time
The X2 RaceLink GPS will fully charge within 5
hours and then works for 16 hours
The X2 RaceLink GPS Charger Case is equipped
with sleep mode
When placed inside the Charger Case the X2
RaceLink GPS won’t emit any signals and the
battery won’t drain
SPECIFICATIONS CHARGER CASE
COMPATIBLE WITH X2 RaceLink GPS
NUMBER OF X2 RACELINKS 34
DIMENSIONS 48 x 25 x 12.5 cm / 18.9 x 9.8 x 4.9 inch
WEIGHT 3.7 kg / 8.1 lbs (empty case, excluding
adapter) 4.2 kg / 9.2 lbs (empty case,
including adapter) 10.1 kg / 22.3 lbs
(case filled with 34 X2 RaceLink GPS,
including adapter)
ENVIRONMENTAL PRO-
TECTION
IP 55 (lid closed) IP 20 (lid open)
COLOR Black
OPERATING TEMPERATURE 0 to +40 °C / 32 °F to 104 °F (do not
charge with closed lid)
DC VOLTAGE 12V DC
CONNECTIONS 4 pin LEMO DC connector
DIMENSIONS 14 x 6 x 3 cm / 5.5 x 2.4 x 1.2 inch
WEIGHT 0.5 kg / 1.1 lbs
HOUSING IP20
INPUT VOLTAGE 100…240 VAC 47/63 Hz
OUTPUT VOLTAGE 12VDC

LED INDICATION
First blink indicates GPS reception
Second blink indicates RF reception
If the LED goes solid RED there is less than 10% battery left
DUAL BLINK
1. GPS 2. LINK MEANING
RED RED NO GPS POSITION KNOWN, NO LINK TO THE SYSTEM
GREEN RED GPS POSITION KNOWN, NO LINK TO THE SYSTEM
RED GREEN NO GPS POSITION KNOWN, LINKED TO THE SYSTEM
GREEN GREEN GPS POSITION KNOWN, LINKED TO THE SYSTEM
LED INDICATION CHARGING STATE
RED CHARGING
GREEN FULL CHARGE
BLUE BLINKING BLUETOOTH LOW ENERGY MODE (4.5-6VDC FIRST 3 MINUTES)
BLUE SOLID BLUETOOTH CONNECTION ESTABLISHED
WHILE CHARGING
WHILE USED ON THE TRACK
BLINKS
2 TIMES

DASHBOARD INSTALLATION
SPECIFICATIONS X2 RACELINK GPS
Make sure the top sticker of the RaceLink GPS has a
clear view to the sky and around the vehicle.
Install both the GPS and RF antenna as high as
possible with a clear view to the sky.
Keep out of direct sunlight as much
as possible.
Do not place the RaceLink GPS next
to other RF antennas. Keep at least
1m distance.
<120 cm
<4 ft
BIKE & MX
CAR & KART
<60 cm
<2 ft <30 cm
<1 ft
DIMENSIONS 75 x 50 x 23 mm/2.95 x 1.97 x 0.9 in
WEIGHT 115 g / 0.25 lbs
(BACK UP)
BATTERY LIFETIME
Up to 16 hours
BATTERY
CHARGING
appr 1:4 ratio, 5 hours for full charge
OPERATING
TEMPERATURE
RANGE
0 to 60 °C / 32 to 140F
HUMIDITY RANGE 10% to 90% relative: IP65
POSITIONING 3 concurrent GNSS reception
SENSITIVITY -167 dBm, 72 channels
UPDATE RATE 5Hz
RF OUTPUT +20 dBm @ 2.4 GHz ISM
CHARGING 300 mA @ 5VDC Bluetooth mode
first 3 minutes
CHARGING
VOLTAGE RANGE
5 to 12VDC
CHARGING
TEMPERATURE
0 to 30 °C/ 32 to 86
