Mysphera IOTPS10101 User manual

MYSPHERA • Ronda Auguste y Louis Lumiere 23, Nave 13 • 4 980 Parque
Tecnológico de Valencia • Paterna, Valencia • Spain
Telf.: [phone] • [e-mail] • www.mysphera.com
Pág. 1
User Manual
IOTPS10101
PRESENCE SENSOR
Mysphera S.L.
Parque Tecnológico de Valencia
Ronda Auguste y Louis Lumiere, 23 – ave 13,
46980 Paterna (Valencia)
[email protected]
www.mysphera.com
Telf.: [phone] / Ext. 112
Fax [phone]

MYSPHERA • Ronda Auguste y Louis Lumiere 23, Nave 13 • 4 980 Parque
Tecnológico de Valencia • Paterna, Valencia • Spain
Telf.: [phone] • [e-mail] • www.mysphera.com
Pág. 2
Modified December 2019
© 2019 Mysphera S.L. ("MYSPHERA") all rights reserved.
Any type of exploitation and, in particular, the reproduction, distribution, public
communication and / or transformation, in whole or in part, by any means, of this document
without the prior express written consent of MYSPHERA is prohibited.
The warranty and repair services linked to the product will not apply if the product has
been repaired, modified or altered, except that such repair, modification or alteration
has been authorized in writing by MYSPHERA; or it is not possible to determine the
product serial number.
MYSPHERA PROVIDES THIS "AS IS" MA UAL, WITHOUT WARRA TIES OF A Y
KI D, OR EXPRESS OR IMPLIED, I CLUDED, BETWEE OTHER, THE IMPLIED
WARRA TIES OR CO DITIO S OF MERCHA TABILITY OR FITI G A PARTICULAR
PURPOSE.
EITHER MYSPHERA, OR ITS PERSO EL OR AGE TS, WILL BE LIABLE FOR
A Y I DIRECT, SPECIAL, ACCIDE TAL OR CO SEQUE TIAL DAMAGES
(I CLUDI G THOSE DERIVED FROM LOSS OF BE EFITS, LOSS OF COMMERCIAL
OPPORTU ITIES, IMPOSSIBILITY OF USI G THE COMMITTEE OF THE
COMMITTEE, THE BUSI ESS U IT A D OTHER DAMAGES OF A SIMILAR ATURE),
EVE WHE MYSPHERA HAS BEE I FORMED OF THE POSSIBILITY THAT SUCH
DAMAGES HAVE TO PLACE AS A RESULT OF A Y DEFECTS OR ERRORS I THIS
MA UAL OR I THE PRODUCT.
THE SPECIFICATIO S A D I FORMATIO RELATI G TO THE PRODUCTS
CO TAI ED I THIS MA UAL ARE MADE AVAILABLE TO THE OW ER FOR
EXCLUSIVELY I FORMATIO AL PURPOSES; BOTH ARE SUBJECT TO CHA GE AT
A Y TIME WITHOUT PRIOR OTICE A D A COMMITME T U DERTAKE BY
MYSPHERA SHOULD OT BE CO SIDERED.
MYSPHERA DOES OT ASSUME A Y RESPO SIBILITY OR OBLIGATIO I
RELATIO TO THOSE ERRORS OR IMPRECISIO S THAT THIS MA UAL MAY
CO TAI , I CLUDI G THE PRODUCTS A D THE SOFTWARE THAT ARE
DESCRIBED I IT.
Trademarks and permits:
The names of products and companies that appear in this manual may or may not be
registered trademarks or be linked to copyright held by their respective owners; its use
is carried out exclusively for identification and explanation purposes and for the benefit
of the product owner, without any intention of infringing the indicated rights.
Changes History
Product name Presence Sensor
Product ID IOTPS10101 Date version December 2019
Nº Total of pages 10
Version Changes Date of change
0.1 Initial versión 07 09 2018
1.0 1st version 09 05 2019
1.1 English version 09 12 2019

MYSPHERA • Ronda Auguste y Louis Lumiere 23, Nave 13 • 4 980 Parque
Tecnológico de Valencia • Paterna, Valencia • Spain
Telf.: [phone] • [e-mail] • www.mysphera.com
Pág. 3
Used simbols in this guide:
Simbol Description
USB.
Electric risk.
Warnings:
• The product label is located on the bottom of the product.
• To reduce the risk of fire or electric shock, do not expose the product to rain or
moisture.
• Do not place open flame sources, such as burning candles on the product, or in
its vicinity.
• Do not expose this product to dripping or splashing.
• This product must be used indoors. It is not designed or tested for outdoor use.
• Operating temperature range:-5ºC to 45ºC
Precautions:
• Do not make unauthorized alterations to this product; doing so may compromise
security, compliance with standards, system performance and may void the
warranty.
Important Instructions:
• Read these instructions.
• Keep these instructions.
• Observe the warnings.
• Follow all instructions.
• Do not use this appliance near water.
• Perform the installation according to the manufacturer's instructions.
• Do not place it near any heat source, such as radiators, heating grilles, stoves or
other appliances (including amplifiers) that produce heat.
• Use only accessories specified by the manufacturer.

MYSPHERA • Ronda Auguste y Louis Lumiere 23, Nave 13 • 4 980 Parque
Tecnológico de Valencia • Paterna, Valencia • Spain
Telf.: [phone] • [e-mail] • www.mysphera.com
Pág. 4
Table of Co te ts
Table of Contents ............................................................................................................. 4
1. Introduction ............................................................................................................ 5
1.1. Package contents ............................................................................................... 5
2. Product description ................................................................................................ 5
2.1. Version ............................................................................................................... 5
2.2. Identification ....................................................................................................... 5
3. Instalation ............................................................................................................... 6
4. Intended Use .......................................................................................................... 6
5. Maintenance and cleaning...................................................................................... 7
6. Storage and devices removal ................................................................................. 7
6.1. Storage ............................................................................................................... 7
6.2. 6.2. Wireless Gateway removal .......................................................................... 7
7. Incidents solution ................................................................................................... 8
7.1. Usual incidents ................................................................................................... 8
8. Safety information .................................................................................................. 8
8.1. Electric safety ..................................................................................................... 8
8.2. Other safety considerations ................................................................................ 8
8.3. Information about radiofrecuency ........................................................................ 9
8.3.1. Radiolectric devices manufacturing ............................................................. 9
8.3.2. Radio Frecuency exposure (RF) .................................................................. 9
9. Declaration of conformity ........................................................................................ 9
9.1. CE Mark ............................................................................................................. 9
9.2. FCC Mark ........................................................................................................... 9
9.3. Updating device .................................................................................................10
10. Recycling ..............................................................................................................10
11. Authorized distributors ...........................................................................................10

MYSPHERA • Ronda Auguste y Louis Lumiere 23, Nave 13 • 4 980 Parque
Tecnológico de Valencia • Paterna, Valencia • Spain
Telf.: [phone] • [e-mail] • www.mysphera.com
Pág. 5
1. I troductio
1.1. Package contents
The package is an installation kit consisting of:
• • 4 x Presence sensor
• • Door opening detection sensor
• • Magnet to match with door sensor
2. Product descriptio
The LOCS kit is a support product for the elderly living alone.
The system provides peace of mind to family members closest to the elderly through useful
and reliable information about the activity detected at home.
This information is collected at the home of the elderly through discrete 100% wireless
sensors of great autonomy, whose presence poses inadvertent since they emit neither light
nor sound.
2.1. Version
Product: IOTPS10101
Case: 1.0.0 Cover, base with battery holder and battery cover
Hardware: 1.0.0 MSIoTS10-P. Based on chip CC2541, with sensors PIR y Tª/Hª.
Firmware: 1.0.0 Firmware for presence detection operation.
2.2. Identification
Label rear of the device.
Ilustratio 1 – Prese ce Se sor ide tificatio

MYSPHERA • Ronda Auguste y Louis Lumiere 23, Nave 13 • 4 980 Parque
Tecnológico de Valencia • Paterna, Valencia • Spain
Telf.: [phone] • [e-mail] • www.mysphera.com
Pág. 6
- Product identifier code:
o Start with 3 letters indicating type / family of the product.
o Followed by 2 letters indicating the type of interface and / or communication
of the product.
o Followed by 1 digit indicating version of the enclosures / enclosures /
mechanical encapsulation.
o Followed by 2 digits indicating the hardware version.
o Finishing with 2 digits that indicate the firmware version.
- IEEE adress: 12-digit alphanumeric MAC identification, unique for each device /
product manufactured.
- S / : Serial number of the hardware used in that product.
o Internal product accounting code.
o Hardware manufacturing number.
- Electrical characteristics of use.
- Certification and marking symbols: CE and FCC
- Place and year of manufacture.
3. I stalatio
Each of the presence sensors will be placed on the wall or supported by a piece of furniture
at an approximate height of 1.5 m from the ground level, in their respective areas (Bathroom,
Kitchen, Bedroom and Living Room). It will be verified that the sensors are on, for this it is
necessary to press the button on the front of the device, if pressing it turns on a blue light
means that the sensor is on and that you have just sent a test frame that It will last a few
seconds and the LED will turn off again returning to normal mode. If the light does not turn
on, it will be necessary to press the button for 2-3 seconds until the blue light comes on.
This is how we can see that the sensor is working. The door sensor will be placed in the
frame of the door that leads to the exit of the house, also the magnet that is responsible for
exciting the sensor will be placed every time the door is opened or closed. We must also
confirm that the door sensor is on for this we will follow the same procedure as with the
presence sensor, we will press the button for 2-3 seconds until the orange LED that
indicates that the sensor is on is lit. The user or family that owns the set must have a
multimedia device with Bluetooth technology capable of receiving Bluetooth frames sent by
the devices that make up the installed set.
4. I te ded Use
Once all the sensors are placed in place and in operation, we will access the application
installed on the mobile device to verify that all the sensors, in addition to being well
configured, receive presence, if so, the installation will be in operation and we can check
Instantly the movements of the person in the "Gateway" application whenever we want.

MYSPHERA • Ronda Auguste y Louis Lumiere 23, Nave 13 • 4 980 Parque
Tecnológico de Valencia • Paterna, Valencia • Spain
Telf.: [phone] • [e-mail] • www.mysphera.com
Pág. 7
5. Mai te a ce a d clea i g
o special cleaning products are needed for cleaning this device. Dampen a cloth with
water and run it across the surface.
Do not clean the equipment when it is turned on.
Do not use solvents.
This device does not require special maintenance.
Once the AA batteries are exhausted, the 3 batteries must be replaced. To do this, open
the battery cover with a screwdriver and replace the 3 AA batteries. Then close the battery
cover and turn on the device by pressing and holding the button for 2-3 seconds.
6. Storage a d devices removal
6.1. Storage
• When the wireless gateway is not used, it should be stored in a clean and dry area.
Otherwise it can become a source of pollution.
• Store the wireless gateway under the following conditions:
• • Temperature: -10 ° C to 50C ° (14 ° F to 122 ° F)
• • Relative humidity: 20% to 80% (no condensation)
6.2. 6.2. Wireless Gateway removal
DO OT OPE A Y GATEWAY WIRELESS
In case of failure or at the end of the use of the wireless gateway, it must be returned to the
manufacturer for replacement and / or repair or removal from the market.
Contact MYSPHERA before disposing of the wireless gateway. This product should not be
treated as household waste.
By ensuring that this product is disposed of correctly, it will help avoid possible negative
consequences for the environment and human health, which could otherwise be caused by
improper handling of the waste from this product.

MYSPHERA • Ronda Auguste y Louis Lumiere 23, Nave 13 • 4 980 Parque
Tecnológico de Valencia • Paterna, Valencia • Spain
Telf.: [phone] • [e-mail] • www.mysphera.com
Pág. 8
7. I cide ts solutio
7.1. Usual incidents
INCIDENT
The device does ot tur o .
SOLUTIO
It may be a problem of lack of charge, this will have to open the back cover of the sensor and
replace the batteries. If it still does not work, you will have to change the device and take the
damaged one to MYSPHERA.
INCIDENT
Whe you ope the applicatio , o e of the se sors does ot appear.
SOLUTIO
Contact the installation company to verify if the sensor has been configured correctly.
INCIDENT
O e of the prese ce se sors does ’t detect.
SOLUTIO
Possible fault of the presence sensor, it will be necessary to change the device and send the fault
to MYSPHERA.
INCIDENT
Do ot ope the applicatio .
SOLUTIO
When this error occurs, it must be verified that the multimedia device has a 3G connection. If not,
you will have to find a site with good coverage or change the SIM available to the multimedia
device.
8. Safety i formatio
8.1. Electric safety
Product protected against short circuits.
It does not emit electric shocks.
8.2. Other safety considerations
Product not designed or intended for uses other than its installation in stable places and
with the ability to detect movement.
It does not carry an implicit risk for people, animals or objects.

MYSPHERA • Ronda Auguste y Louis Lumiere 23, Nave 13 • 4 980 Parque
Tecnológico de Valencia • Paterna, Valencia • Spain
Telf.: [phone] • [e-mail] • www.mysphera.com
Pág. 9
The company is not responsible for improper use of it and the possible consequences that
the product itself or the parts that form it may have.
8.3. Information about radiofrecuency
8.3.1. Radiolectric devices manufacturing
Cuadro acional Atribución Frecuencias (Spain, Orden ETU/416/2018, 26th April, 2018)
https://www.boe.es/diario_boe/txt.php?id=BOE-A-2018-5704
European Frequency Information System ( 2402 MHz - 2480 MHz )
https://www.efis.dk/views2/search-general.jsp
MYSPHERA declares that the radio equipment is manufactured so that it can operate in at
least one Member State without violating the requirements applicable to the use of the radio
spectrum in accordance with Article 10.2 of Directive 2014/53 / EU.
This device can be put into service and used without restrictions in several European Union
countries (BE / DE / ES / FR / GR / IT / L / O / UK)
8.3.2. Radio Frecuency exposure (RF)
The product works at a very low frequency and the exposure of people to it is not harmful.
This device has been designed and meets the safety requirements for RF exposure of
portable devices (< 5 mm) in accordance with FCC rule part §2.1093 and KDB 447498 D01.
9. Declaratio of co formity
http://www.mysphera.com/declaration-of-conformity
9.1. CE Mark
MySPHERA declares that this device complies with the requirements and
specifications set out in Directive 2014/53 / EU (RED).
9.2. FCC Mark
This device complies with the Part 15 C specification of the FCC Rules.
Your operation is subject to the following two conditions:
(1) This device must not cause harmful interference, and
(2) This device must accept any interference received, including interference from
improper use.
Changes or modifications not expressly approved by the party responsible for
compliance may void the user's authorization to operate the device.

MYSPHERA • Ronda Auguste y Louis Lumiere 23, Nave 13 • 4 980 Parque
Tecnológico de Valencia • Paterna, Valencia • Spain
Telf.: [phone] • [e-mail] • www.mysphera.com
Pág. 10
9.3. Updating device
The programming and functionality of the hardware and firmware are carried out at the
factory complying with the essential requirements of the product.
The end user cannot make any modification of the FW / SW or functionality or have any
button, connector or element that allows changing any parameter that affects the correct
functioning of the product or the fulfillment of its essential requirements.
If any update, change or special modification of FW is required, the product must return to
Mysphera. You cannot vary operating parameters automatically or remotely.
10. Recycli g
The product must not be disposed of as waste and must be delivered to MYSPHERA for
proper recycling. Proper disposal and recycling help protect natural resources, people's
health and the environment. For more information on the disposal and recycling of this
product, contact your municipality, the waste management service or the store where you
purchased this product.
11. Authorized distributors
MYSPHERA S.L.
Parque Tecnológico de Valencia
Ronda Auguste y Louis Lumiere, 23 – ave 13,
E-46980 Paterna (Valencia)
[email protected]m
https://www.mysphera.com
Telf.: [phone]
Fax [phone]
