N Brown Group Corsica 4 Seater Dining Set User manual

No. People Assembly Time
Assembly Instructions - Please keep for future reference
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the JDW customer helpline: 0871 231 2000
Cat No. WT450
Corsica 4 Seater Dining Set
30 - 60
Minutes
GROUP
N
PLC
BROWN

Safety and Care Advice
Important - Please read these instructions fully before starting assembly
• Check you have all the
components and tools
listed on the next pages.
• Remove all ittings from the
plastic bags and seperate
them into their groups.
• Keep children and animals
away from the work area,
small parts could choke if
swallowed.
• Make sure you have
enough space to lay out
the parts before starting.
• Do not stand or put weight
on the product, this could
cause damage.
• Assemble the item as close
to its inal position (in the
same room) as possible.
• Assemble on a soft, level
surface to avoid damaging
the unit or your loor.
We do not recommend the
use of power
drills/drivers
for inserting
screws as this
could damage
the unit. Only use hand
screwdrivers.
Care and Maintenance
• Please clean using cloth
with glass cleaner, do not
use bleach or abrasive
cleaners.
• From time to time check
that there are no loose
screws on this unit.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal
centre.
If you need help or have damaged or missing parts, call the JDW
customer helpline: 0871 231 2000
If you are unhappy with the product and wish to return it,
please follow the retailer’s returns procedure.
Warning
Important - In order to help prevent overturning, this product must be used with the wall anti-tip
strap/device provided.
• To help prevent product toppling over please follow the below steps:
•Use the anti-tip strap/device provided.
• Do not allow children to climp or hang on the furniture.
• Do not place heavy items on top of the furniture, unless the furniture has been designated for
this purpose.
Please note that only the anti-tip strap/devices and screw are provided, you will need to provide
wall plugs and screws applicable for your wall type.

Exploded
View
B
C
D
E
B
AA

Components - Panels
Please check that you have all the components listed below before constructing your item.
Part No Description Qty
ATable’s leg
Side frame
Shelf
Table top frame
Glass table top
2
B 2
C 1
D
E
1
1
Components - Fixings
Please check that you have all the components listed below before constructing your item.
1 Screw M6x15 4
2 8
3
4 Allan Key
12
1
Tools Required
Ruler - Use this to measure your screws (mm)
Allan Key
0510 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 115 120 125 130 135 140 145 150 155 160 165 170
Washer
Screw M6x25

Assembly Instructions
Step 1
Step 2
A
4
1
3
A
C
D
4
1
3
• Attach leg frame A to
Top frame D, using
washer 3 and bolt 1,
tighten the bolt 70%.
• Attached shelf C to leg
frame A.
70%
C
70%
• Attach leg frame A to
shelf C and Top frame
D, using washer 3 and
bolt 1, tighten the bolt
70%.
D

Step 3
Step 4
B
4
2
3
B
4
32
70%
70%
• Attach side frame B to
leg frames A, using
washer 3 and bolt 2,
tighten the bolt 70%.
• Attached leg frame A to
Top frame D, using
washer 3 and bolt 1,
tighten the bolt 70%.

E
Step 5
Step 6
100%
• Re-tighten the all bolts
100%.
• Turn the table to
upright position.
• Place glass table top E
on the top frame.
D

Step 6
1. TO CLEAN,WITH DAMP CLOTH.DO NOT USE BLEACH,ACID SOLVENTS OR ABRASIVE CLEANERS
OR FRAME PARTS.
2. DURING VARYING WEATHER CONDITIONS AND WINTER PERIOD,WE STRONGLY RECOMMEND THAT
IT CAN BE.STORED IN A DRY AREA
WITH A SUITABLE COVER BEFORE STORAGE,PLS INSURE IT IS CLEAN AND DRY.
3. IN THE EVENT OF BARE METAL SHOWING DUE TO SCRATCH,IT IS PREFERRED TO TREAT WITH A
RUST REPELLING VARNISH OR SIMILAR.
4. PERIODICALLY CHECK AND ENSURE THAT ALL THE SCREWS ARE COMLETELY TIGHTEN.
5. A MATCHING FURNITURE COVER IS STRONGLY RECOMMENDED TO EXTEND TH USAGE LIFE-SPAN.
CARE AND CLEANING:
Finish

GROUP
N
PLC
BROWN
