N-Com B1 Instruction Manual

Firmware Version: 1.xx
EN
USER INSTRUCTIONS AND SAFETY

Congratulations on your purchase of an N-Com product.
N-Com B1 was made using the most advanced technologies and
the best materials. Long-running tests and thorough system
development have allowed the highest audio quality to be
achieved.
For additional information about B1, and to download high-
definition instructions as well as the latest Firmware version, visit
the website www.n-com.it
REFERENCE STANDARDS
The products of the N-Com line are in compliance with standards as per the table
below:
B1 The Bluetooth system complies with the main safety
requirements and other applicable provisions of Directive
99/5/CE, Directive 2002/95/CE, Directive 2002/96/CE
Battery
charger
Directive 2006/95, 2004/108, 2002/95/CE, 2002/96/CE,
2009/125/CE
Battery Directive 2006/66
The Declarations of Compliance can be downloaded from the website www.n-
com.it (Download section).
FccID: Y6MNCOM5 N21550
Bluetooth is a registered trademark property of Bluetooth SIG, Inc.

B1
3
Contents
1. WARNINGS AND SAFETY ...................................................... 4
1.1.Road safety.......................................................................... 4
1.2.Switching on the system in safe environments ........................... 4
1.3.Interferences ....................................................................... 4
1.4.Appropriate use .................................................................... 4
1.5.Qualified personnel ............................................................... 5
1.6.Accessories and batteries ....................................................... 5
1.7.Disposal .............................................................................. 6
2. CONTENT OF THE PACKAGING.............................................. 6
3. INSTALLATION .................................................................... 7
3.1.Installing the microphone ....................................................... 9
3.2.Connecting the battery .........................................................10
3.3.Installing the system on the helmet ........................................11
4. REMOVING THE SYSTEM..................................................... 14
5. SYSTEM CHARACTERISTICS ............................................... 14
5.1.Basic functions ....................................................................15
5.2.N-Com Wizard.....................................................................15
6. PAIRING UP BLUETOOTH DEVICES ..................................... 15
6.1.Affiliation reset function ........................................................16
7. MOBILE PHONE FUNCTIONS............................................... 16
8. GPS SATELLITE NAVIGATOR FUNCTIONS............................ 16
9. BLUETOOTH A2DP MUSIC PLAYER ...................................... 17
10. AUDIO DEVICES WITH CABLE CONNECTION ....................... 17
11. RIDER-PASSENGER INTERCOM MODE ................................. 18
11.1.Intercom affiliation .............................................................18
11.2.Intercom function...............................................................18
12. BATTERY ........................................................................... 19
12.1.Battery discharged signal.....................................................19
12.2.Recharging the system........................................................19
13. SUMMARY TABLE OF CONTROLS ......................................... 20
14. LIMITED WARRANTY.......................................................... 21
14.1.Warranty coverage .............................................................21
14.2.Exclusions and limitations of the coverage ..............................21
14.3.Validity of this limited warranty ............................................21
14.4.Procedure for the forwarding of claims...................................22
14.5.Product identification ..........................................................22
15. WARRANTY REGISTRATION FORM...................................... 23

B1
5
1. WARNINGS AND SAFETY
Read this User Manual carefully, as well as the User Manuals for other N-Com kits that you
will be using with the N-Com B1. Read the simple rules listed below. Failure to comply with
these rules may lead to dangerous situations.
Caution: The product cannot be used in official or non-official competitions, motordromes,
circuits, racing tracks and the like.
Caution: Installation of the N-Com B1 system results in a weight increase of
approximately 110g, which is added to the weight of the helmet and of the other
accessories.
Warning: The electronic components of the N-Com system mounted inside the helmet are
not waterproof. Consequently, make sure the inside of the helmet, including the
comfort padding, does not get wet in order to avoid damage to the system. If it does,
remove the N-Com system and the helmet comfort padding and let it air dry.
Disconnect the battery connector and let it dry as well.
1.1. Road safety
Always obey all Traffic Regulations in force. While riding the motorcycle, your hands should
always be engaged in actually riding the vehicle. Any operation to the N-Com system must
be carried out with the vehicle stopped. Specifically:
Set your cell phone on automatic answer (see the cell phone instructions to do this).
If your cell phone is not equipped with this function, first stop your vehicle in a safe
area, in compliance with Traffic Regulations and then answer the call.
Do not make any calls while riding. Stop your vehicle in a safe place in compliance
with Traffic Regulations, and then make the call.
Adjust the volume so that it does not cause a disturbance or distraction while riding
and at the same time allows you to distinctively hear background noises.
Do not operate your cell phone or other devices connected to N-Com while riding
your motorcycle.
In all cases, obey the Traffic Regulations and remember that riding the motorcycle
has absolute priority over any other maneuver.
1.2. Switching on the system in safe environments
When using the N-Com system, comply with all limitations and instructions related to
the use of cell phones.
Do not turn on your cell phone or the N-Com system whenever their use is forbidden
or when the devices can cause interference or dangerous situations.
Turn off while refueling. Do not use the N-Com system in filling stations. Do not use
the device near combustible materials or chemical products.
Turn off in proximity to explosive materials.
1.3. Interferences
All phones and devices with wireless signal transmission are subject to interferences that
may affect the performance of the device connected to them. These interferences are not
ascribable to a defect of the N-Com system.
1.4. Appropriate use
Use the device only in the normal position, as described in the product documentation. Do
not attempt to disassemble, tamper with or modify any part of the N-Com system.

B1
5
Caution: Adjust the volume of the N-Com system (where provided) and of the audio
sources connected to it before you use the system on the road.
Caution: Adjusting the volume to very high levels may cause damage to your hearing.
Caution: Adjust the volume of the N-Com system (where provided) and of the audio
sources connected to it so as to avoid audio reproduction at high volumes. Constant
exposure to high audio volumes may damage your hearing.
Caution: An incorrect installation of the system in the helmet may alter the aerodynamic
and safety characteristics of the helmet itself, thus creating dangerous conditions.
Install the N-Com system according to the instructions provided in the product
documentation. In case of doubt, please contact your local N-Com dealer.
Warning: Listening to other equipment should not interfere with driving the vehicle, which
must be the top priority at all times. Carry out all operations on the electronic
equipment and on the N-Com system with the vehicle stopped, in compliance with
Traffic Regulations.
1.5. Qualified personnel
Only qualified personnel can carry out technical assistance on this product. In case of
any malfunction, always turn to your local dealer.
The helmet is a safety device. Tampering with it and/or with the electronic system
inside the helmet, in addition to invalidating the product warranty, can also lead to
dangerous situations.
1.6. Accessories and batteries
Only use the type of batteries, battery chargers and accessories approved by Nolan
for the specific model.
The use of a battery type different from the recommended one may lead to
dangerous situations and invalidate the warranty.
Contact your local dealer to see about the availability of approved accessories.
When disconnecting the power supply cable of any accessory or of the battery
charger, always grab and pull the plug not the cable.
Do not use batteries for purposes other than the prescribed ones.
Never use batteries or battery chargers that turn out to be damaged.
Do not short-circuit the battery.
Keep the battery at a temperature between 0° / +45°C (charging); -20° / +60
°C (in use).
Danger of fire or explosion: do not throw the batteries into a fire nor expose them to
high temperatures!
Do not throw out batteries together with household refuse. The batteries should be
disposed of in compliance with local regulations
Do not wear the helmet while the battery is recharging.
The helmet should never be left within the reach of unsupervised children in order to
prevent damage to their health caused by access to the batteries.
Battery Lithium Ion593847 3,7V – 800mAh
AK00G-0500040VU 100/240v – 50/60 Hz 5V – 0,4 ABatterycharger
S-TR-038 100-240V - 60/50Hz 0.1A

6
1.7. Disposal
Refer to this user manual and to manuals related to other parts of the N-Com system in
order to disassemble the system from the helmet. Once the system has been
disassembled, dispose of it according to the following instructions:
The presence of a crossed-out wheelie bin indicates that in the European
Union the product is subject to separate collection at the end of its useful
life (European Directive 2002/96/EC).
Do not dispose of these products together with undifferentiated urban
waste.
The proper disposal of obsolete equipment contributes to preventing possible negative
consequences on people’s health and on the environment.
For more detailed information on the disposal of obsolete equipment, contact your
municipality, a waste disposal service or the store where the product was purchased.
2. CONTENT OF THE PACKAGING
The N-Com B1 package contains:
e-box B1 Electronic plate PC connection cable
Microphone Rechargeable battery Battery charger
Battery holder Key and screw
Clamp
Microphone-
Stop
Adhesive
Velcro pads

B1
7
3. INSTALLATION
Fig. 1
Fig. 2
Fig. 3
Remove the “N-Com” protection plate
located on the helm
et shell (Fig. 1)
and open the helmet chin guard (flip
up helmets).
Remove the right and left cheek pads
from the helmet (see specific
instructions provided in the user
manual of the helmet).
Remove the Noise Reducers from the
two cheek pads, and tear off the pre-
cut plastic (if equipped).
Fig. 4
Fig. 5
Fig. 6
Remove the back of the comfort
padding by pulling on the neck roll
until it separates from the shell (Fig.
4).
Temporarily put the padding on the
outside of the helmet (Fig. 5).
Remove the N-Com cover from the
helmet border gasket. Push from the
inside of the helmet to facilitate the
removal (Fig. 6).

8
Fig. 7
ONLY FOR FULL-FACE HELMETS
Remove the chin guard by pulling on
the special red tab.
Fig. 8
Remove the right and left polystyrene
cheek pads by gently pulling them out
of the helmet. The helmet shell can be
opened slightly to facilitate the
removal of the cheek pad .
Caution: In case the polystyrene cheek
pad is damaged during this operation,
turn to your local dealer for its
replacement.

B1
9
3.1. Installing the microphone
JET HELMETS OR FLIP-UP HELMETS
Fig. 9 Fig. 10
Fig. 11
Fig. 12
Prepare the microphone by inserting the
microphone clamp, being careful to position it
properly (Fig. 9)
Note: the flat part of the clamp must be facing
upward when the microphone is positioned as
shown in figure 11.
Position the microphone in its support as
shown in figure 10, being careful that the
fluorescent clamp is facing toward the inside of
the helmet.
Insert screw in the microphone clamp; use the
key to screw in the microphone securing screw
to the shell frame.
FULL-FACE HELMETS
Fig. 13
Fig. 14
Take the polystyrene cheek pad (left-hand side) and position the microphone in its
housing, as shown in fig. 13, making sure that the fluorescent band stays facing the
inside of the helmet. (Fig. 14)

10
3.2. Connecting the battery
Only for Jet helmets or flip-up helmets:
Fig. 15 Fig. 16
Hook up the battery cable (Red+Black) to the connector located on the wiring system
(Fig. 15).
Insert the battery in its holder, first positioning the side equipped with the cables
outlet, keeping the cables underneath the plastic tab (Fig. 16).
Fig. 17 Fig. 18
Insert the connectors set in the cable-stop guide located on the side of the battery-
holder (Fig. 17 and 18).
Only for full face helmets:
Fig. 19
Position the battery in the right
polystyrene cheek pad housing (Fig.
19).

B1
11
3.3. Installing the system on the helmet
Fig. 20
Position the system inside the helmet as shown in figure 20, next to the N-Com housing
in the shell.
Fig. 21
Looking at the helmet from the outside,
slide the rear positioning tab into
groove A as shown in the figure;
Press in the area marked PUSH from
inside the helmet until the fastening
clasp B clicks (Fig. 21).
Fig. 22

Pull out the connectors area from the
helmet gasket: the gasket will have to
be slightly deformed to facilitate the
insertion.

12
Fig. 23
Fig. 24
Insert the microphone connector in the micro USB electronic plate.
Before you place the speaker in its housing, apply the Velcro pad to the polystyrene
cheek pad (Fig. 24).
Fig. 25
Position the loudspeaker in the special
housing obtained in the polystyrene cheek
pad (Fig. 25).
Fig. 26
Replace the polystyrene cheek pad (left
s
ide), positioning the cable in the
groove that you see in the cheek pad
(Fig. 25).
Note: Make sure the cheek pad is properly
positioned in its housing, pushing in
the lined corner underneath the ribbing
on the shell (Fig. 26).

B1
13
Fig. 27
Only for Jet helmets or flip-up helmets
Secure the battery-holder support to
the right side of the helmet, lining up
the holes with the pins on the shell
(Fig. 27)
Before you place the speaker in its housing, apply the Velcro pad to the polystyrene
cheek pad (right side).
Position the loudspeaker in its housing obtained in the polystyrene cheek pad (right
side).
Replace the polystyrene cheek pad (right side), positioning the cable in the groove you
see in the cheek pad.
Fig. 28
Only for full-face helmets
Insert the chin guard (microphone side),
gently placing the microphone in its
housing. Then press down on the red tab
until the chin guard is locked in place on the
helmet. (Fig. 28)
Fig. 29
Fig. 30
Position the comfort padding in its housing (see specific instructions provided in the
helmet user manual), hooking the neck roll (Fig. 29).

14
Position both the comfort cheek pads in their housing (see specific instructions
provided in the helmet user manual) making sure that all the press-studs click.
Note: Carefully check the proper final positioning of the cheek pad, pulling the chinstrap
toward the inside of the helmet and testing the press-studs.
Caution: Make sure that there are no cables sticking out of the helmet and that the
loudspeakers are in their housing.
Caution: Always verify the proper length of the chinstrap and adjust it as necessary, once
again referring to the specific helmet instructions.
Position the e-box in the relevant housing. First insert the front part, then press down
on the e-box until both hooks fully click. To remove the e-box, press the two sliding
hooks at the same time until the e-box comes out.
Warning: Do not leave the helmet exposed to atmospheric agents without the e-box or
the protection plate provided with the helmet.
4. REMOVING THE SYSTEM
Fig. 31
To remove the system from the helmet,
remove the earphone and the comfort
cheek pads as shown in the assembly
operations. Then remove the polystyrene
cheek pads. Remove the protection plate,
then, looking at the helmet from the
outside, release the connector by acting on
the fastening clasp as illustrated in the
figure.
After releasing the connector from the shell, also remove the right part by releasing the
battery holder.
Now remove the entire system from the helmet.
5. SYSTEM CHARACTERISTICS
N-Com B1 allows wireless connection to a mobile phone, a satellite navigator, and an MP3
A2DP player using Bluetooth technology.
The system can also be used for wireless intercom communication between two helmets, if
both helmets are equipped with a N-Com Bluetooth system.
The system can be expanded by means of a USB Multimedia Wire accessory (sold
separately), which is used for cable connection to multimedia sources.
B1 can be managed, updated and customised using the “N-Com Wizard”
programme, which can be downloaded from the “Download” section of the
Internet site www.n-com.it

B1
15
5.1. Basic functions
All N-Com system functions are available through the operation of three pushbuttons: “”,
“on” and “”. Every time the system is given a command, a special acoustic signal can be
heard, which varies depending on the function being requested. This way, all the functions
can be used while wearing the helmet.
The type of command given to the system depends on how long the pushbutton is pressed.
System ON Press “on” and keep it pressed for about 2 seconds, until the
LEDs turn on and you hear a beep in the headset.
System OFF Press “on” and keep it pressed for about 4 seconds, until the
LEDs turn off and you hear a beep in the headset.
Increase Volume Briefly press “” to increase the volume. A double tone signals
the highest volume level.
Decrease Volume Briefly press “” to decrease the volume. A double tone signals
the lowest volume level.
5.2. N-Com Wizard
“N-Com Wizard” is the PC application that can be used to manage and
configure the B1 system.
The programme can be downloaded from the Internet site www.n-com.it, in the
“Download” section. In order to use it, a helmet equipped with B1 must be connected to
the PC, using the USB cable supplied with the system.
N-Com Wizard allows you to customize your B1, specifically:
Setting the system audio levels
Update the device firmware
The programme includes an on-line guide that explains how it works (after installing it on
your PC, press F1 to display this guide).
6. PAIRING UP BLUETOOTH DEVICES
In order for the B1 system to be connected to another Bluetooth device, the latter needs
to be first paired up with the N-Com system.
The pairing up procedure is the same for all Bluetooth devices: mobile phones, MP3
Bluetooth players, satellite navigators, etc.
1. Make sure the B1 is turned off;
2. Press “on” and keep it pressed (for more than 6 seconds), until the LEDs start to
flash quickly and you hear a sharp beep in the headset, indicating the “Pair-up
mode”;
3. On the Bluetooth device, turn on the search for Bluetooth devices (refer to the
instructions manual of your device for the proper pairing up procedure, as it
varies depending on the brand and model of the device);
4. After a few seconds, the device will display the name “N-Com B1 v.X.XX”,
followed by the manufacturer’s identification data;
5. Select the N-Com device. If a password is requested, enter 0000 (four zeros);
6. B1 will confirm the pairing up by means of a tone in the headset, and the LEDs
will stop flashing;
7. Turn off and on both the device and the B1 to store the pairing up data.
Note: The affiliation is stored in the helmet and in the cell phone and it is not lost when
the two devices are turned off. As a result it needs to be carried out only once.

16
Note: If a Bluetooth device (mobile phone or GPS) equipped with music player with
Bluetooth A2DP player has already been paired up, the pairing up DOES NOT have to
be repeated as the A2DP protocol has already been stored in the B1.
Once the Bluetooth device has been paired up, connection is automatic when the system is
turned on.
6.1. Affiliation reset function
You can remove all affiliated devices from the system memory. This operation is not
reversible; right after resetting, you will have to repeat the affiliation procedure for the cell
phone (or for other compatible Bluetooth devices).
To erase all devices previously affiliated, proceed as follows:
Press “on” and keep it pressed (for more than 4 seconds), until the LEDs start to flash
quickly and you hear a sharp beep in the headset, indicating the “Pair-up mode”;
Press “” and “” at the same time for 4 seconds, and release them when you hear a
beep. The N-Com will emit a special acoustic signal to confirm and will then turn itself
off.
This function can also be turned on through PC using the “N-Com Wizard”
programme.
7. MOBILE PHONE FUNCTIONS
Answering a phone
call Briefly press any key when you hear the incoming call signal
Hanging
up/rejecting a
phone call
Press “on” and keep it pressed for about 2 seconds (until you
hear the acoustic signal)
Voice call (if
equipped)
Press “on” and keep it pressed for about 2 seconds (until you
hear the acoustic signal)
Redial last number Briefly press “” and “” at the same time
Transferring a call
from helmet to
mobile phone
To transfer an ongoing call from the helmet to the mobile phone,
press both “” and “” at the same time and keep them
pressed for 4 seconds
Conference call function
B1 allows a conference call with Rider and Pillion Passenger.
When a call comes in on a mobile phone connected via Bluetooth to B1, the Rider-Pillion
Passenger intercom is temporarily turned off. However, if you wish to share the phone call
with the other helmet, simply turn on the intercom manually during the phone call (by
briefly pressing “on”).
Caution: this function is available only if the Pillion Passenger helmet is also equipped with
a N-Com system provided with the same function.
8. GPS SATELLITE NAVIGATOR FUNCTIONS
B1 is compatible with the most common satellite navigators for motorcycles.
By connecting the N-Com system to the GPS, all instructions will be transferred to the
helmet.
Every time the navigator communicates instructions, the intercom via Bluetooth with the
Pillion Passenger is cut off and automatically restored at the end of the communication.

B1
17
Note: If the navigator is pre-set for connection to a Bluetooth mobile phone, you will be
able to receive the phone call audio directly in the helmet through the GPS. In this
case, you can answer the call directly from the navigator.
GPS Conference Call Function
The Conference function allows you to keep the “Rider-Pillion Passenger” intercom open
even while the satellite navigator is giving instructions, thus preventing the intercom mode
to be turned off every time the navigator gives instructions. However, if you wish to
activate the Conference GPS function, simply turn on the intercom manually during the
GPS directions (by briefly pressing “on”).
Caution: this function is available only if the Pillion Passenger helmet is also equipped with
a N-Com system provided with the same function.
At the end of the GPS communication, the intercom with the second helmet stays open and
the "Conference" setting is stored for future GPS communications.
9. BLUETOOTH A2DP MUSIC PLAYER
You can listen to high quality music by connecting B1 to a device equipped with Bluetooth
A2DP (Advanced Audio Distribution Profile) protocol.
The B1 system is also equipped with Bluetooth AVRCP (Audio Video Remote Control
Profile) protocol, which allows you to stop and resume music reproduction directly from the
helmet (with devices equipped with AVRCP).
Connection to A2DP music
player
The connection is automatic when you turn on the
system. Wait a few seconds for the connection.
Play music (Play) Press the “” button and keep it pressed for 2 seconds.
Pause function (Pause) When the player is connected and playing music, press
“” for 2 seconds.
Next track (Skip) When the player is playing music, press “” for 4 about
seconds.
Stop playing music (Stop) Press “” for 2 seconds.
Note: The Bluetooth intercom does not work while listening to an A2DP audio source or an
un Mp3 player connected via cable.
10. AUDIO DEVICES WITH CABLE CONNECTION
N-Com B1 allows connection via cable (sold separately) to audio sources equipped with the
3.5mm output generally used by these devices for the headsets.
To listen to the audio source, connect the cable to the helmet using the micro-USB port,
then start playing the audio file on the device, then activate the audio peripheral device
using the specific key.
You can turn on or off listening in the helmet by pressing the “” key for 2 seconds.
N.B. : You cannot stay connected in intercom mode with the pillion passenger while using
the audio source via cable.

18
11. RIDER-PASSENGER INTERCOM MODE
In order to use B1 in wireless intercom mode, both helmets have to be equipped with a N-
Com Bluetooth system.
In order for two N-Com systems to communicate with one another, they have to be paired
up first.
11.1. Intercom affiliation
1. Make sure both N-Com Bluetooth systems are turned off;
2. Set both N-Com Bluetooth systems in Pairing up mode by pressing “on” (for more than
4 seconds), until the LEDS start to flash quickly;
3. On either one of the two helmets, press “on” briefly;
4. After a few seconds, the helmets “recognize” each another, a beep is emitted to signal
the pair up was successful and intercom communication is activated;
5. Turn off both N-Com Bluetooth systems and turn them back on to store the pair up
data.
11.2. Intercom function
To activate the intercom connection, turn on the two N-Com systems and briefly press
“on” on one of the helmets.
Intercom activation With B1 turned on, briefly press “on”.
Intercom deactivation With B1 turned on, briefly press “on”.

B1
19
12. BATTERY
Before using the N-Com device for the first time, recharge the battery completely for at
least 10 hours. To obtain best performances from the battery, it is recommended to
completely recharge the battery the first few times. Afterwards, you can recharge the
battery for shorter periods. Whenever possible, it is best to recharge the battery
completely.
12.1. Battery discharged signal
When turned on, the system signals when the battery is running down by switching to the
“Reserve” mode.
When the battery charging power falls below 1 hour of operation, the buttons “” and “”
start to flash in order to indicate that the system is in “Reserve” mode. Three consecutive
beeps also signal the reserve mode.
When the battery operates in “Reserve”, the system automatically turns itself off in case
no button is pressed for 30 minutes. The shutting off is signaled by a series of beeps in the
helmet. This function makes it possible to always have a small reserve of energy to use it
again in case you forget to turn off your helmet.
12.2. Recharging the system
To recharge the B1 system, connect the USB cable to a battery charger or to a powered
USB port. Charging occurs as follows:
B1 system turned off
When you connect the B1 system to the battery
charger, the blue LED begins to flash.
When the battery is fully charged, the blue LED stops
flashing and stays on.
B1 system turned on
When you connect the B1 system to the battery
charger, the red LED begins to flash.
When the battery is fully charged, the red LED turns off.
N.B.: If the device has not been charged for a long time (a few months), it may not be
possible to turn on the system during the first few minutes of the charging, as the
voltage may drop below the minimum limit.

20
13. SUMMARY TABLE OF CONTROLS
Button on on 




Pressure Brief Long Brief Long Brief Long Brief Long
Turning on X
(3s)
Turning off X
(4s)
Increase Volume X
Decrease Volume X
Activate / Deactivate
audio via cable X (2s)
Activate
intercom X
Basic Functions
Deactivate
intercom X
Answer phone call X X X
Voice call X
(2s)
Hang up/reject a
phone call X (2s)
Redial last number X
Mobile phone
connection X (2s)
Mobile phone
disconnection X (4s)
Call transfer X
(4s)
Bluetooth peripheral
Activate Conference
Mode X
Connect A2DP device X
(2s)
Disconnect A2PD
device X (2s)
Play music (Play) X
(2s)
Pause Function
(Pause) X (2s)
Mp3 player
Next track
(Forward) X (4s)
Pairing up mode -
system turned off X (4s)
Rider-Passenger
intercom pair up X
Setting
Erase pair ups** X
(4s)
*Briefly press at the same time.
**With N-Com system in Pairing up Mode.
