Nakanishi NSK iProphy Air User manual

002
2019.XX.XX 001 N

English
11
Thank you for purchasing iProphy mobile.
This device is used for dental treatment. Please read this Operation Manual and carefully review the operating
instructions and care and maintenance guidelines to ensure proper operation and long life of the product. Keep
this Operation Manual available for future reference.
English
WARNING
User: Licensed Dental Professionals
Intended Use: The Nakanishi iProphy mobile is a cordless prophylaxis handpiece for use with disposable prophy
angles in hygiene operatory to perform cleaning and polishing procedures on teeth.
- Contents -
User and Intended Use .............................................................................................................................. 1
Cautions for handling and operation ....................................................................................................... 2
1. Package Contents ................................................................................................................................. 5
2. Component Names ................................................................................................................................ 6
3. Setup ................................................................................................................................................... 7
4. Preoperational checks ........................................................................................................................... 8
5. Operation ............................................................................................................................................. 8
6. Maintenance ....................................................................................................................................... 10
7. Rechargeable Battery .......................................................................................................................... 10
8. Mounting and Removing the AC Adaptor Plug Head ............................................................................... 11
9. Periodic Maintenance .......................................................................................................................... 11
10. Overload Protection ........................................................................................................................... 11
11. Troubleshooting ................................................................................................................................. 12
12. Specifications ................................................................................................................................... 13
13. Classification .................................................................................................................................... 13
14. Symbols ........................................................................................................................................... 14
15. Warranty ........................................................................................................................................... 14
16. Spare Parts ....................................................................................................................................... 14
17. Disposal ........................................................................................................................................... 15
18. Electromagnetic Compatibility Information ........................................................................................... 15
User and Intended Use
• Do not use this product in the vicinity of explosive substances and flammable materials.
Operation Principle:
A disposable handpiece connected to the motor handpiece rotates to clean the tooth surface.

2
Classification Degree of Risk
DANGER Hazard that could result in death or serious injury if the safety instructions are not
followed.
WARNING Hazard that could result in serious injury or damage to the device if the safety
instructions are not followed.
CAUTION Hazard that could result in moderate injury or damage to the device if the safety
instructions are not followed.
NOTICE General product specification information highlighted to avoid product malfunction and
reduction in performance.
Please read these instructions carefully and use only for intended purpose.
Safety instructions are intended to avoid potential hazards that could result in personal injury or damage to
the device.
Safety instructions are classified as follows in accordance with the degree of risk.
Cautions for handling and operation
DANGER
• Do not attempt to disassemble the product or tamper with the mechanism except as specified by NSK in
this Operation Manual. Unauthorized modification or repairs may cause injury, electric shock, or fire.
• Do not handle the AC adaptor with wet hands. Wet hands coming into contact with electricity may result in
electric shock.
• Do not wet the motor handpiece with a disinfectant solution or other fluids. The protective function of the
rechargeable battery may become damaged which may result in overheating, rupture, or explosion due to
the abnormal current or voltage to the battery.
• Should the rechargeable battery leak or the motor casing become deformed or discolored, immediately
stop use and contact your Authorized NSK Dealer for service. Using the handpiece under these abnormal
conditions may cause injury or damage to property.
• Should battery fluid leak and get into patient's or user's eyes, immediately flush eyes thoroughly with clean
water and seek medical attention. If left untreated this condition may result in blindness.
• Do not charge, use or store the product in direct sunlight, a vehicle, fire, stove, or other location where
temperatures may be outside the range shown in this manual. This may result in overheating, smoking,
reduction in performance or reduction in the life of the rechargeable battery.
• Never use an AC adaptor other than the one supplied by NSK for this product. This may cause the product
to fail.
• Do not heat the motor handpiece or dispose of in a fire. This may cause overheating, smoking, rupture,
or explosion due to melting of the insulator in the internal battery, damage to the gas relief valve or safety
mechanism, or ignition of the battery fluid.
• Do not pierce the motor handpiece, hit it with a hammer, or step on it. This may cause overheating,
smoking, rupture, or explosion due to an internal short-circuit as a result of rupture or deformation to the
internal battery.
• If the battery leaks or a strange smell comes from the handpiece, immediately discontinue use and keep
the handpiece away from fire and other combustible materials. This may cause smoking, rupture, or
explosion due to battery fluid catching fire.
WARNING
• The product may malfunction when used in the presence of electromagnetic interference. Do not use the
product in the vicinity of any device which emits electromagnetic waves. Turn off the Main Power Switch of
the product if an ultrasonic oscillation device or an electrode knife is being used nearby.

English
3
WARNING
• Using a motor handpiece, AC adaptor, or accessories other than those manufactured by NSK may reduce
the electromagnetic compatibility performance of this product (EMC) (An emission increase or immunity
decrease may occur).
• iProphy mobile should not be used adjacent to, or stacked with, other equipment. If adjacent or stacked use
is necessary, iProphy mobile should be observed to verify normal operation in the configuration in which it
will be used.
• Make sure to check the product before use by operating it outside the patient's mouth. If even a slight
abnormality is detected, immediately stop use and contact your Authorized NSK Dealer.
• If any abnormal vibrations, overheating, noise or power supply is perceived before or during use,
immediately stop using the product and contact your Authorized NSK Dealer.
• If the cause of the abnormality is a part that cannot be easily replaced or the cause of the abnormality is
unknown, contact your Authorized NSK Dealer.
• Keep away from explosive substances and flammable materials. Do not use the product on or near patients
being treated with a flammable anesthetic (nitrous oxide).
• If the battery fluid leaks and adheres to the skin or clothing, immediately wash it off with clean water. This
may cause skin irritation.
• This product cannot be sterilized. Do not attempt to sterilize this product.
CAUTION
• This product is intended for those who have received training and are licensed as a healthcare professional
such as dentists and dental hygienists. This product is designed for use in clinical settings such as dental
clinics, hospitals and for visiting dental professionals.
• Read this Operation Manual before use to fully understand the product functions.
• Always consider the safety of the patient when operating this product.
• Connect or disconnect the disposable handpiece only after rotation of the handpiece has completely
stopped. This may cause injury or cause damage to the connecting portion of the disposable handpiece.
• Do not drop or strike the product. This may cause electric shock or failure.
• Always install a handpiece sleeve before use to prevent contamination of the motor handpiece.
• Clean the motor handpiece immediately after use and before storage. Information on proper maintenance
of this handpiece is included in this manual.
• Do not lubricate the motor handpiece. This may cause overheating or a failure.
• Should an antiseptic solution, water, saline and other fluid come in contact with the motor handpiece or
stand, turn off the power immediately and thoroughly remove the fluid with an absorbent cloth.
• Do not clean the product with any solvent such as a paint thinner or benzene.
• Do not recharge or use near combustible materials. Heat generated during charging or use may cause
ignition of combustible items.
• Do not use the product in a place where static electricity may be generated. This may damage the
protection circuitry and cause the battery to leak.
• The rechargeable battery has a limited use. If you feel the operating time becomes shorter or the power
becomes weak the rechargeable battery should be replaced with a new one. Contact your Authorized NSK
Dealer.
• The maximum surface temperature of the handpiece might reach 45°C depending on use.
• Extended continuous use may cause overheating of the motor handpiece which may result in an accident.
Do not exceed 3 minutes of continual use and leave the handpiece off for at least 5 minutes before using
again.
• This product is rated Medical Electrical equipment. Electromagnetic compatibility (EMC) is described in the
enclosed documentation.
• Installation and use of this product requires special precautions regarding EMC. Refer to the enclosed EMC
information.

4
• Portable and mobile RF communications equipment can affect Medical Electrical equipment. Do not use RF
equipment near the product.
• During operation this product may interfere with computers, LAN cables in vicinity of use or could cause
noise in radio receivers nearby.
• U.S. Federal law restricts this device to sale by or on the order of a licensed physician.
NOTICE
• Turn off the switch after using the product. When the product is not used for a long period, disconnect the
AC adaptor from the outlet.
• The AC adaptor is a fast way to cut off the commercial power supply. Therefore, install the AC adaptor in
such a way that it can be quickly disconnected from the outlet in an emergency. Do not place any object
within 6 inches of the AC adaptor.
• When disconnecting the AC adaptor, be sure to hold the adaptor body. Disconnecting by pulling on the cord
may damage the cord.
• Refer to the disposable handpiece operation manual for information on the use and handling of the
disposable handpiece.
• Do not store the product in a place exposed to strong direct sunlight. This may cause discoloration of the
handpiece body.
• Users are responsible for the operational control, maintenance and continual inspection of this product.
• If the product is not used for a long period check for vibration, noise and overheating before using on a
patient.
• Repairs of this product are only to be performed by authorized service technicians according to NSK
requirements. Contact your Authorized NSK Dealer if repairs are necessary.
• No special training is required prior to using this device.
• The end user shall be responsible for any judgment on use of this product on a particular patient.
• The maximum rotation speed of the motor handpiece is 2,500rpm (in the full charge state).
• The speed of the motor handpiece may get slower than the preset speed when the battery capacity lowers
during use.
