Namron PANELOVN ZIGBEE 400W User manual

400W/600W/800W/1000W
BRUKSANVISNING
INSTRUCTION MANUAL
PANELOVNZIGBEE

220-240V~ 50-60Hz IP24
Effekt:
Spenning:
Tetthetsgrad:
Frekvens:
Effektnivå:
Inkludert 1,6 m kabel og støpsel.
Effect:
Operating voltage:
IP Rating:
Frequency:
Powerlevel:
Included 1.6 m cable and plug.
400W/600W/800W/1000W
220-240V~50-60Hz
IP24
2405-2480MHz
0.87dBm
400W/600W/800W/1000W
220-240V~50-60Hz
IP24
2405-2480MHz
0,87dBm
Namron AS - Nedre Kalbakkvei 88B, N-1081 Oslo - NORWAY
PANELOVN ZIGBEE
400W/600W/800W/1000W
MÅ IKKE TILDEKKES/
DO NOT COVER
IP24
BRUK / USE STRØMBRYTER/
POWER SWITCH LED DISPLAY /
LED DISPLAY
ØKE/
INCREASE+
OK KNAPP /
OK BUTTON
SENKE-/
DECREASE-
USE WITHOUT PROGRAM
1.Insert the power plug and turn on the power switch. The display will
show the temperature.
2. Chose manual mode by pushing the “OK” button until the MA symbol
is shown in the display.
3.When the environment temperature is below set temperature, the
heater will start automatically. The heating icon will be shown in the
display.
4.Press “+” or “-”to set the desired temperature. The temperature can
be adjusted between 5-35C. Factory default setting is 19C . Press and
hold “+” or “-” to adjust the temperature in a faster speed.
BRUK UTEN PROGRAM
1.Sett i kontakten og skru på strømbryteren. Displayet vil nå vise
temperaturen.
2. Velge manuell modus ved å trykk på knappen «OK» slik at symbolet
MA vises i displayet.
3.Er omgivelsestemperaturen under innstilte temperatur, vil ovnen
automatisk starte å avgi varme. Varmeikonet vil vises i displayet.
4.Trykk “+” eller “-” for å stille inn ønsket temperatur. Temperaturen
kan stilles inn mellom 5C og 35C . Standardinnstilling er 19C . Trykk og
hold inne “+” eller “-” for å justere temperaturen i høyere hastighet.
USE WITH PROGRAM
1.Insert the power plug and turn on the power switch. The display will
show the temperature.
2. Chose auto mode by pushing the “OK” button until the AU symbol is
shown in the display.
3.Press and hold “OK” for 5 seconds, and the icon will flash. (Refer
to Zigbee IM of the panel heater for further instructions).
4.Proceed with program settings in your Zigbee Smart hub.
5.The heater could be turned off in the app. After heater is turned off
through the app and needs to be turned on from the product. Press the
power switch twice, press one time to return the switch to Off mode,
press it again to go to On mode, then the heater will be turned on.
BRUK MED PROGRAM
1.Sett i kontakten og skru på strømbryteren. Displayet vil nå vise
temperaturen.
2. Velge auto modus ved å trykk på knappen «OK» slik at symbolet AU
vises i displayet.
3.Trykk og hold inne knappen “OK” i fem sekunder, og ikonet vil
blinke (Se egen brukerveiledning for ZigBee innstillinger).
4.Programinnstillingene gjøres deretter i din Zigbee Smarthub.
5.Ovnen kan skrues av i appen. Etter at ovnen er skrudd av gjennom
appen og man ønsker å skru på ovnen fra produktet. Trykk to ganger på
strømbryteren, trykk én gang for å gå til Av-modus og trykk igjen for å gå
til På-modus.
Må ikke tildekkes, ovnens overflate kan bli
svært varm og må plasseres i trygg avstand fra
brennbart materiale. Koble fra strømmen ved
vedlikehold. Ved bruk av skjøteledning må den
være kortest mulig og rullet ut når ovnen er på.
Do not cover the heater surface, the heater can
become very hot and must be placed at a safe
distance from flammable material. Disconnect
power during maintenance. If using an exten-
sion cord it must be as short as possible and
be extended when the oven is on.
SIKKERHET/SAFETY

Namron AS - Nedre Kalbakkvei 88B, N-1081 Oslo - NORWAY
1) Bor hull i veggen. Avstand mellom hull: Se skjema (a).
2) Skru fast festet på veggen.
3) Press ovnen på festet og skru fast.
1) Drill holes in the wall. Distance between holes: See the form (a).
2) Attach the clips onto the wall.
3) Push the heater into the clips and use screws to thighten the
clips.
MONTERING AV OVNEN/ASSEMBLY OF THE HEATER
Watt A B
400W 150 465
(mm)
600W 210 525
800W 330 645
1000W 420 735
B
A130mm 81mm
185mm
Min.50
mm Min.50 mm
368mm
160mm
Min.50mm
Min.150mm
Trykk og hold inne “+“ og ”OK“ i fem sekunder for å gjøre innstillinger i Åpent-vindu-funksjonen. Åpent-vin-
du-ikonet vil da blinke. Trykk deretter på “+”/”-” for å velge «Av» eller «På». Trykk “OK” eller vent i fem
sekunder uten å trykke på noen knapper for å bekrefte innstillingen.
Standardinnstillingen for denne funksjonen er Av. Når funksjonen er aktivert vil Åpent-vindu-ikonet vises i
displayet. Detekterer ovnen et temperaturfall, vil den automatisk gå over i antifrost-modus og operere på 7C
mens Åpent-vindu-ikonet blinker. Om temperaturen stiger vil ovnen gå tilbake til forrige modus med
Åpent-vindu-funksjonen på. Du kan også gå tilbake til forrige modus ved å trykke på en vilkårlig knapp. Velg
«Av» for å deaktivere Åpent-vindu-funksjonen.
Press and hold “+“ and ”OK“ for five seconds to enter the open window detection settings. The open
window icon will be flashing. Then press “+”/”-”to choose «ON» or «OFF». Press “OK” or after five
seconds without operating the display, and the setting will be saved. The default factory setting for this
function is off.
If «ON» is selected, the window detection function is activated and the open window icon will be visible
in the display. When temperature drop is detected, the appliance will automatically enter anti-freeze mode
(heater works at 7C, with open window icon flashing). If temperature rises, the appliance will go back to
previous working mode. You can also press any button to go back to previous mode. Choose «OFF» to
deactivate the detection function.
Ovnen er utstyrt med minnefunksjon. Når strømmen returnerer vil ovnen gå tilbake til samme temperatur
som før strømbruddet.
The heater has a memory function and will automatically return to the desired temperature after a power cut.
Åpent-vindu-funksjon /
Open window detection
Minnefunksjon ved strømbrudd /
Memory function
Trykk og hold inne “+“ og ”–“ i fem sekunder til “CC” vises i displayet. Barnesikringen er da aktivert. Bruk
samme fremgangsmåte for å deaktivere funksjonen. Når ovnen er tilkoblet en smarthub, kan barnesikringen
aktiveres/deaktiveres derfra.
Press and hold “+“ and ”–“ for five seconds, until “CC” shows on the display. Child lock is now activated.
Repeat procedure to deactivate this function. Child lock can also be activated / deactivated in your smart hub.
Barnesikring / Child Lock
Trykk på “+“ ,”–“ og ”OK“ til “rE” vises i displayet. Ovnen går da tilbake til standardinnstillingen.
Press “+“ and ”–“ and ”OK“ key until display shows “rE”, heater will be set back to the factory default setting.
Tilbakestill til standardinnstilling /
Reset the thermostat to default
Trykk og hold inne ”–“ og ”OK“ i fem sekunder, og displayet vil blinke tre ganger. Etter 30 sekunder vil lyset i
displayet skrus av. Skru på lyset i displayet ved å trykke på en hvilken som helst knapp.
Press and hold “–“ and ”OK“ for five seconds and the display will flash three times. After 30 seconds
without being operated, the displays light will then turn off. Press any key to light it again.
Skru Av/På lyset i displayet /
Light on /off the display
Ovnen bør settes på maksimal temperatur i 30 minutter for å brenne elementet rent. Noe lukt kan oppstå når
dette gjøres.
The heater should be set to maximal temperature for 30 minutes to burn the element clean. Some smell may
occur.
Informasjon før førstegangs bruk /
Information before first time use

Namron AS - Nedre Kalbakkvei 88B, N-1081 Oslo - NORWAY
600W400W 800W 1000W
MÅL / MEASURES
368mm
465mm
368mm
525mm
368mm
645mm
368mm
735mm
1. 2. 3.
145mm Min.50mm
Min.175mm
270mm
160mm
A

Model identifier(s): 5401392/5401396
Item Symbol Value Unit Item Unit
Heat output Type of heat input, for electric storage local
space heaters only (select one)
Nominal heat output Pnom 0.4 kW manual heat charge control, with
integrated thermostat [no]
Minimum heat
output (indicative)
Pmin N/A kW manual heat charge control with room
and/or outdoor temperature feedback [no]
Maximum
continuous heat
output
Pmax,c 0.4 kW electronic heat charge control with room
and/or outdoor temperature feedback [no]
Auxiliary electricity
consumption
fan assisted heat output [no]
At nominal heat
output
elmax 0kW Type of heat output/room temperature control
(select one)
At minimum heat
output
elmin 0kW single stage heat output and no room
temperature control
[no]
In standby mode elSB 0.00088 kW Two or more manual stages, no room
temperature control
[no]
with mechanic thermostat room
temperature control
[no]
with electronic room temperature
control [no]
electronic room temperature control
plus day timer
[no]
electronic room temperature control
plus week timer
[yes]
Other control options (multiple selections
possible)
room temperature control, with
presence detection [no]
room temperature control, with open
window detection [yes]
with distance control option [yes]
with adaptive start control [no]
with working time limitation [no]
with black bulb sensor [no]
Contact details Namron AS - Nedre Kalbakkvei 88B, N-1081 Oslo - NORWAY

Model identifier(s): 5401393/5401397
Item Symbol Value Unit Item Unit
Heat output Type of heat input, for electric storage local
space heaters only (select one)
Nominal heat output Pnom 0.6 kW manual heat charge control, with
integrated thermostat [no]
Minimum heat
output (indicative)
Pmin N/A kW manual heat charge control with room
and/or outdoor temperature feedback [no]
Maximum
continuous heat
output
Pmax,c 0.6 kW electronic heat charge control with room
and/or outdoor temperature feedback [no]
Auxiliary electricity
consumption
fan assisted heat output [no]
At nominal heat
output
elmax 0kW Type of heat output/room temperature control
(select one)
At minimum heat
output
elmin 0kW single stage heat output and no room
temperature control
[no]
In standby mode elSB 0.00088 kW Two or more manual stages, no room
temperature control
[no]
with mechanic thermostat room
temperature control
[no]
with electronic room temperature
control [no]
electronic room temperature control
plus day timer
[no]
electronic room temperature control
plus week timer
[yes]
Other control options (multiple selections
possible)
room temperature control, with
presence detection [no]
room temperature control, with open
window detection [yes]
with distance control option [yes]
with adaptive start control [no]
with working time limitation [no]
with black bulb sensor [no]
Contact details Namron AS - Nedre Kalbakkvei 88B, N-1081 Oslo - NORWAY

Model identifier(s): 5401394/5401398
Item Symbol Value Unit Item Unit
Heat output Type of heat input, for electric storage local
space heaters only (select one)
Nominal heat output Pnom 0.8 kW manual heat charge control, with
integrated thermostat [no]
Minimum heat
output (indicative)
Pmin N/A kW manual heat charge control with room
and/or outdoor temperature feedback [no]
Maximum
continuous heat
output
Pmax,c 0.8 kW electronic heat charge control with room
and/or outdoor temperature feedback [no]
Auxiliary electricity
consumption
fan assisted heat output [no]
At nominal heat
output
elmax 0kW Type of heat output/room temperature control
(select one)
At minimum heat
output
elmin 0kW single stage heat output and no room
temperature control
[no]
In standby mode elSB 0.00088 kW Two or more manual stages, no room
temperature control
[no]
with mechanic thermostat room
temperature control
[no]
with electronic room temperature
control [no]
electronic room temperature control
plus day timer
[no]
electronic room temperature control
plus week timer
[yes]
Other control options (multiple selections
possible)
room temperature control, with
presence detection [no]
room temperature control, with open
window detection [yes]
with distance control option [yes]
with adaptive start control [no]
with working time limitation [no]
with black bulb sensor [no]
Contact details Namron AS - Nedre Kalbakkvei 88B, N-1081 Oslo - NORWAY

Model identifier(s): 5401395/5401399
Item Symbol Value Unit Item Unit
Heat output Type of heat input, for electric storage local
space heaters only (select one)
Nominal heat output Pnom 1kW manual heat charge control, with
integrated thermostat [no]
Minimum heat
output (indicative)
Pmin N/A kW manual heat charge control with room
and/or outdoor temperature feedback [no]
Maximum
continuous heat
output
Pmax,c 1kW electronic heat charge control with room
and/or outdoor temperature feedback [no]
Auxiliary electricity
consumption
fan assisted heat output [no]
At nominal heat
output
elmax 0kW Type of heat output/room temperature control
(select one)
At minimum heat
output
elmin 0kW single stage heat output and no room
temperature control
[no]
In standby mode elSB 0.00088 kW Two or more manual stages, no room
temperature control
[no]
with mechanic thermostat room
temperature control
[no]
with electronic room temperature
control [no]
electronic room temperature control
plus day timer
[no]
electronic room temperature control
plus week timer
[yes]
Other control options (multiple selections
possible)
room temperature control, with
presence detection [no]
room temperature control, with open
window detection [yes]
with distance control option [yes]
with adaptive start control [no]
with working time limitation [no]
with black bulb sensor [no]
Contact details Namron AS - Nedre Kalbakkvei 88B, N-1081 Oslo - NORWAY
