Nanocable 10.35.0010 User manual

10.35.0010
DOUBLE USB WALL PLUG MANUAL

Please read and follow these instructions to avoid damaging the item. We
do not cover damage that may result from improper use of the article or
non-compliance with the safety instructions.
Important safety advice:
• Read instructions before use.
• To protect against electric shock or personal injury, do not handle the
electrical outlet or cables near any liquid.
• Do not expose the plug to extreme temperatures. Must be used in
moderate environments.
• Do not handle the product in any way other than as instructed in this
manual.
• Do not attempt to repair, any repair or service should be performed only
by qualied personnel.
• The product may not be opened or its components modied. The
manufacturer is not responsible for any radio or television interference
caused by unauthorized modications.
• The device is not a toy. Do not allow children to play with it, or allow
children to introduce foreign objects.
• Never clean the surface of the device with solvents, paint thinners,
cleaners or other products.
• Save these instructions.
2

Use:
This product is used as a power outlet and has 2 additional USB ports for
charging electronic devices with a voltage of 5V DC/2.4A.
It may only be used and installed in the manner described in this manual.
This product is not intended for use by children or people without experien-
ce or knowledge of its use, unless instructed and supervised by a person
responsible for its safety.
Composition:
• 1 x Power socket schuko
• 1 x Fixing plate
• 1 x Embellisher
• 2 x Screws
Technical details:
Power socket schuko: connection by means of a 3 wire electric cable
(15A, 250V AC): phase conductor (L), neutral conductor (N) and ground
point ( ).
USB outputs: DC 5V and 2.4A maximum, either one alone or between
the two.
3

Dimensions:
4

Installation:
In case of any doubts, the installation should be carried out by qualied
personnel.
1. Use a voltage tester to verify the voltage given on the phase conductor (L),
usually black, brown or gray, before installing the product.
2. Switch off the power supply before installing the product. Start the ins-
tallation of the socket only after making sure that there is no voltage in the
cables.
5

3. Install the double USB plug on the wall:
– Place the xing plate (1) on the wall with the ↑UP in the upper part and
screw it with the two screws included in the product.
– Connect the three cables to the schuko socket (2) and secure with the
corresponding screw:
-L: brown, black or grey cable.
-N: blue cable.
- : green or yellow cable.
* The colors of the specified cables are the most common.
– Embed the schuko socket with the cables connected to the wall
mounting plate (1).
– Place on both (1) and (2) the embellisher (3) leaving the ↑UP of the
back side in the top.
6

Environmental awareness:
Product certications:
In accordance with European waste regulations 2002/96/EG,
this symbol on the product or its packaging indicates that
this product may not be treated as household waste. It must
be ensured that this product is disposed of correctly; it will
avoid possible negative consequences for the environment
and human health, which could otherwise be caused by
improper handling of the waste from this product.
7
