NanoCam Plus NCP-DVR1080 User manual

USER MANUAL
FULL HD DASH CAM DVR
WITH 2.4" SCREEN
NCP-DVR1080

3
Caution....................................................................................................................................................................... 5
Battery warning .......................................................................................................................................................... 5
Notes on Installation ................................................................................................................................................... 5
1 Introduction .............................................................................................................................................................. 6
1.1 Features ............................................................................................................................................................. 6
1.2 Package Contents .............................................................................................................................................. 6
1.3 Product Overview ............................................................................................................................................... 6
2 Getting Started ......................................................................................................................................................... 7
2.1 Inserting the Memory Card.................................................................................................................................. 7
2.2 Installing Car DVR............................................................................................................................................... 7
2.2.1 Adjust the device position ....................................................................................................................... 7
2.2.2 Connect to Power................................................................................................................................... 7
2.3 Powering the Car DVR On / Off........................................................................................................................... 8
2.3.1 Auto Power On / Off................................................................................................................................ 8
2.3.2 Manual Power On / Off and Reset........................................................................................................... 8
2.3.2.1 Manual Power On ................................................................................................................................... 8
2.3.2.2 Power Off................................................................................................................................................ 8
2.3.2.3 Reset the device ..................................................................................................................................... 8
2.4 Playing back Video on PC................................................................................................................................... 8
2.5 Initial Settings ..................................................................................................................................................... 8
2.5.1 Formatting Inserted Micro SD Card ......................................................................................................... 8
2.5.2 Set the Date / Time ................................................................................................................................. 9
2.6 Using the DVR .................................................................................................................................................... 9
2.6.1 Recording Video ..................................................................................................................................... 9
2.6.2 Locked Recording................................................................................................................................... 9
2.6.3 Recording Screen ................................................................................................................................. 10
2.6.4 Video Mode .......................................................................................................................................... 11
2.7 Video Menu ...................................................................................................................................................... 11
2.7.1 Resolution............................................................................................................................................. 11
2.7.2 Loop Recording .................................................................................................................................... 11
2.7.3 Exposure............................................................................................................................................... 12
2.7.4 WDR..................................................................................................................................................... 12
2.7.5 Motion Detection................................................................................................................................... 12
2.7.6 Recording Audio ................................................................................................................................... 13

4
2.7.7 Date Stamp........................................................................................................................................... 14
2.7.8 G Sensor .............................................................................................................................................. 14
2.7.9 Shrink Video Files.................................................................................................................................. 14
2.8.0 Park Mode ............................................................................................................................................ 14
2.8.1 Number Plate........................................................................................................................................ 14
3 Photo Mode ............................................................................................................................................................ 15
3.1 Photo Menu...................................................................................................................................................... 15
3.1.1 Capture Mode....................................................................................................................................... 15
3.1.2 Resolution............................................................................................................................................. 15
3.1.3 Sequence ............................................................................................................................................. 16
3.1.4 Quality................................................................................................................................................... 16
3.1.5 Sharpness............................................................................................................................................. 16
3.1.6 White Balance....................................................................................................................................... 17
3.1.7 Colour................................................................................................................................................... 17
3.1.8 ISO ....................................................................................................................................................... 17
3.1.9 Exposure............................................................................................................................................... 18
3.1.2.0 Quick review ......................................................................................................................................... 18
3.1.2.1 Date Stamp........................................................................................................................................... 18
3.2 Setting Menu .................................................................................................................................................... 19
3.2.1 Date / Time ........................................................................................................................................... 19
3.2.2 Key Beeps ............................................................................................................................................ 19
3.2.3 Language.............................................................................................................................................. 20
3.2.4 Frequency............................................................................................................................................. 20
3.2.5 Screen Saver ........................................................................................................................................ 20
3.2.7 Format .................................................................................................................................................. 21
3.2.8 Default Settings..................................................................................................................................... 21
3.3 Playback Screen............................................................................................................................................... 22
3.4 Playback Menu................................................................................................................................................. 22
3.4.1 Deleting Photos & Videos...................................................................................................................... 22
3.4.2 Locking and Unlocking Photos and Videos ........................................................................................... 22
3.4.3 Slide Show............................................................................................................................................ 23
4 Menu Tables....................................................................................................................................................... 24-25
Warranty................................................................................................................................................................... 27

5
Caution
•Ensure you are using your Car DVR within your countries’ road laws. Please make sure you are familiar with your local road legislation
before use.
•Avoid leaving your Car DVR in direct sunlight for extended periods of time in an unventilated space.
•Please set time and date before you use this device to record.
•The notifications given by the Car DVR are suggestions only, please drive to the actual conditions.
•The system is to be used only for non-commercial use, within the limits permitted by the relevant laws
•Avoid using the Car DVR in the vicinity of any devices that emit radio interference (eg. Microwave Ovens).
•It is considered normal operation for the Car DVR to get warm during use.
Battery Warning
•Always charge the Car DVR using the provided charger. Improper charging of the Car DVR may result in failure of the internal battery.
•Never dismantle the Car DVR or expose the internal battery.
•Do not dispose of the Car DVR in fire.
•Dispose of the Car DVR observing local regulations being mindful of the internal battery.
•Do not attempt to replace or expose the internal battery.
Notes on Installation
1. It is advised that the Car DVR is installed near the rear view mirror, at the top centre of the windshield for optimal operation.
2. Make sure that the lens is within the range of the windscreen wiper to ensure a clear view when it rains.
3. Do not touch the lens with your fingers. Finger prints left on the lens will result in unclear videos or photos. If photos or videos are blurred,
please clean the lens gently with a microfibre cloth.
4. Only use the included charging cable to power the Car DVR.

1. Introduction
Thank you for purchasing a NanoCam Plus Car DVR. We are certain that our product will give you troublefree operation while providing
you with a safety feature that enhances your driving experience. Our products, like most after-market safety enhanced devices, are
designed to assist and aid the driver, not to replace the manual function of the person operating the vehicle. Please read through these
instructions before attempting to install this product.
For the latest manual and product updates, please visit our website at www.nanocamplus.com.au or www.nanocamplus.co.nz
1.1 Features
•Recording full high definition 1080P footage at 30 frames per second.
•2.4” colour screen
•120° wide angle lens
•Emergency recording saves your footage when an impact is detected
•Supports Micro SD cards, class 6 and above up to 32GB
1.2 Package Contents
Car DVR Windscreen Mount Micro USB Cable 12v Adapter
1.3 Product Overview
1. Mounting socket
2. Micro USB Port
3. Reset Button
4. Micro SD Slot
5. Microphone
6. Status light
7. Power Light
8. (On/Off) Button
9. (Mode) Button
10. (Menu) Button
11. 2.4” LCD Screen
12. (Down) Button
13. (Rec/OK) Button
14. (Up) Button
15. Camera Lens
6

7
2. Getting Started
2.1 Inserting Memory Card
With the Car DVR turned off and the screen facing towards you insert the memory card into the slot on the underside of the camera with
the text on the Micro SD card facing away from you. Push the memory card in until a click is heard.
Note:
1. Do not remove or insert the memory card while the Car DVR is turned on as this may damage
the memory card or corrupt the memory cards stored data.
2. Please use a Class 6 or higher rated micro SD card with a maximum capacity of 32GB.
3. Please format the Micro SD card before the initial use.
4. When removing the memory card, be careful as the card may eject quickly.
To remove the memory card
Ensure that the Car DVR is powered off, then push the memory card until a click is heard and then release the card to eject.
2.2 Installing the Car DVR
1. Remove the protective stickers from the Car DVR and the Suction Mount.
2. Slot the mount bracket into the socket on the top of the Car DVR and with the screen facing you, slide the bracket from left to
right until the bracket locks in place.
3. Press the mount base firmly against the windscreen.
2.2.1 Adjust the device position
1. Loosen the knob on the right hand side of the mounting bracket, and adjust the vertical and horizontal angle of the camera.
2. Tighten the knob to lock the position of the camera.
2.2.2 Connecting to Power
Only use the included charger to power and charge the Car DVR.
1. Once the Car DVR is securely installed on your vehicle's windscreen, plug the 12v charger into your vehicle's cigarette
lighter.
2. Run the cable along your vehicle's console and windscreen and plug the USB Micro plug into the Car DVR.
Note:
1. It is recommended that the Car DVR is installed behind your vehicle's rear view
mirror.
2. Make sure that the camera view is not obstructed by any window tint or any other
objects.
3. When removing the suction mount be sure to release the suction mount by
switching the suction latch to the down position.

8
2.3 Powering the Car DVR On / Off
2.3.1 Auto Power On/Off
When the Car DVR is correctly installed and connected to your vehicle's 12v power supply, the Car DVR will automatically
power up and start recording when the vehicle accessories are activated.
2.3.2 Manual Power On/Off and Reset
2.3.2.1 Manual Power On
Hold the Power button on the top of the camera until the NanoCam Plus start up screen appears.
2.3.2.2 Power Off
Make sure that recording has been stopped and then press the Power button on the top of the car DVR. After
powering down the device please wait for 10 seconds before turning the Car DVR back on.
2.3.2.3 Reset the Device
If the Car DVR does not function normally, try restarting the car DVR. To restart the car DVR, with a flattened paper
clip press the small button in the middle of the underside of the Car DVR.
2.4 Playing back video on a PC
To playback video files on your PC it is recommended to connect the Micro SD card (not included) directly to your PC using either
a USB Micro SD card reader (not included) or if your PC has a SD card slot, a Micro SD/SD Card converter (not included). Once
the Micro SD card is connected it should appear as a removable storage device. It is recommended that you transfer video files
that you want to playback to a file on your computer before attempting to playback. This will reduce any delay in playback.
2.5 Initial Settings
Before using the Car DVR we recommend Formatting the Inserted Micro SD Card and setting the correct Time and Date.
2.5.1 Formatting the Inserted Micro SD Card
Formatting the Micro SD card will delete all information on the inserted Micro SD Card and prepare the card for use with
the Car DVR.
1. Press the (Rec/Ok) Button to stop the Car DVR from recording.
2. Press the (Menu) Button to enter the Video Menu.
3. Press the (Menu) Button again to enter the Settings Menu.
4. Use the and Buttons to navigate the Settings Menu and highlight the Format setting and press (Rec/Ok) to select.
5. Select OK to confirm and press the (Rec/Ok) Button.
Note:
1. Menus cannot be accessed while the camera is recording. Please stop the recording before attempting to access the menu.
2. Formatting your Micro SD Card will delete all files from the card. Once these files have been deleted you will not be able to recover
them.

9
2.5.2 Set Date / Time
Setting the Time and Date allows you to stamp your footage with the time as a reference.
1. Press the (Rec/Ok) Button to stop the Car DVR from recording.
2. Press the (Menu) Button to enter the Video Menu.
3. Press the (Menu) Button again to enter the Settings Menu.
4. Use the and Buttons to navigate the Settings Menu and highlight the Date/Time setting and press (Rec/Ok) to
select.
5. Use the and buttons to edit the selected digit and the (Rec/Ok) button to confirm and progress to the next digit.
The final field sets the format that the date will be presented in.
6. To save and exit the time and date, press the (Menu) button.
Note:
1. Menus cannot be accessed while the camera is recording. Please stop the recording before attempting to access the menu.
2. Once the time and date is set it can be stamped onto your footage using the Date Stamp setting. Please see section Date Stamp
for more details.
2.6 Using the Car DVR
2.6.1 Recording Video
When the Car DVR is connected to your vehicle's 12v power supply, the Car DVR will automatically power up and begin
recording when you start your vehicle. During the start up the buttons will be unresponsive and the camera will take a
moment to begin recording. The Car DVR will automatically stop recording and shutdown when your vehicle is powered off.
Note:
1. Because of how some vehicles are wired, the recording may continue when the engine is switched off. If this happens, please
manually turn off the Car DVR or remove the car adapter from the cigarette lighter when not in use.
2. The recording loop length can be configured to save a video file for every 3 or 5 minutes of recording. For information on how to
adjust this setting please refer to the Loop Recording section of this manual.
3. The device saves the recorded footage and photos on to the inserted Micro SD Card. If the memory card capacity is full, the oldest
file in the memory card will be overwritten.
2.6.2 Locked Recording
Locked Recording saves the current video file and protects it from being overwritten. To manually start a Locked
Recording follow the instructions below.
1. During recording push the (Mode) button.
2. To unlock the footage, press the (Rec/Ok) button again.
Note:
1. If the G Sensor (Gravity Sensing) function is enabled and a collision is detected, the device will automatically trigger the
emergency recording and protect the current video file. Please refer to the section titled G Sensor (Gravity Sensing).
2. The emergency recording file is created as a new file, which will be protected to avoid being overwritten by normal loop
recording. If the inserted Micro SD Card fills up with Emergency Recording files the message “SD Card Full” will appear on the
screen, the oldest emergency file will be automatically deleted when a new emergency recording file is created.

10
2.6.3 Recording Screen
Number Icon Item Description
1 Recording Indicator The Record Indicator will flash when the Car DVR is Recording
2 Mode Mode shows whether you are in Video mode or Photo mode
3 Loop Shows the duration of the loop clips
4 Motion Detection The Motion Detection Icon will appear when Motion detection is activated
5 Exposure Shows the current exposure setting
6 Microphone Shows if the microphone is muted or recording
7 Wide Dynamic Range The WDR icon will appear when the Wide Dynamic Range setting is active
8 Day/Night Mode Will show a sun or moon icon indicating if the LCD light is activated or not
9 Gravity Sensing Icon shows the current Gravity Sensitivity
10 Recording duration Shows the current recording duration
11 Resolution Shows the current set resolution
12 Memory card The Memory Card icon shows when a Micro SD Card is installed
13 Date Shows the current date
14 Time Shows the current time
15 Battery Shows the battery level
16 Emergency Recording Shows when the Gravity Sensing function has been triggered

11
2.6.4 Video Mode
When the Car DVR is powered up the video screen will start by default. In this screen recording will automatically start and
can be stopped by pressing the (Rec/Ok) Button. To access the Video Menu, ensure that the Car DVR is not recording
then press the (Menu) button.
2.7 Video Menu
2.7.1 Resolution
Resolution sets the video quality. Higher resolution video will capture more detail and will also produce larger files. To
change the recording resolution, please follow the instructions below.
1. Press the (Rec/Ok) Button to stop the Car DVR from recording.
2. Press the (Menu) Button to enter the Video Menu.
3. Use the and Buttons to navigate the Settings Menu and highlight the Resolution setting and press (Rec/Ok) to
select.
4. Use the and Buttons to highlight your required resolution, then press the (Rec/Ok) button to confirm your selection.
Note:
1. Menus cannot be accessed while the camera is recording. Please stop the recording before attempting to access the menu.
2. Higher resolution clips will create larger files which will fill the Micro SD Card faster.
2.7.2 Loop Recording
Loop recording allows you to set the duration that the camera will record before creating a new clip. To set the clip length
please follow the instructions below.
1. Press the (Rec/Ok) Button to stop the Car DVR from recording.
2. Press the (Menu) Button to enter the Video Menu.
3. Use the and Buttons to navigate the Settings Menu and highlight the Loop Recording setting and press (Rec/Ok)
to select.
4. Use the and Buttons to highlight your required Clip Length, then press the (Rec/Ok) button to confirm your
selection.
Note:
1. Menus cannot be accessed while the camera is recording. Please stop the recording before attempting to access the menu.
2. Selecting the OFF option will create the longest possible clip, in most cases depending on the set resolution and other factors this
will be limited to 10MB.
3. To avoid filling the card quickly it is advised to use the 2 or 3 minute options.

2.7.3 Exposure
Exposure is used to manually control the light sensitivity settings. To change the Exposure setting follow the instructions
below.
1. Press the (Rec/Ok) Button to stop the Car DVR from recording.
2. Press the (Menu) Button to enter the Video Menu.
3. Use the and Buttons to navigate the Settings Menu and highlight the Exposure setting and press OK to select.
4. Use the and Buttons to highlight your required Exposure setting, then press the (Rec/Ok) button to confirm your
selection.
Note:
1. Menus cannot be accessed while the camera is recording. Please stop the recording before attempting to access the menu.
2.7.4 WDR
The WDR setting increases the dynamic range of the camera. To turn this setting on or off, please follow the instructions
below.
1. Press the (Rec/Ok) Button to stop the Car DVR from recording.
2. Press the (Menu) Button to enter the Video Menu.
3. Use the and Buttons to navigate the Settings Menu and highlight the WDR setting and press (Rec/Ok) to select.
4. Use the and Buttons to highlight either OFF or ON, then press the (Rec/Ok) button to confirm your selection.
Note:
1. Menus cannot be accessed while the camera is recording. Please stop the recording before attempting to access the menu.
2.7.5 Motion Detection
Motion Detection is used to pause recording when no motion is detected in front of the camera, and to start recording
when motion is detected again. To activate the Motion Detection setting follow the instructions below.
1. Press the (Rec/Ok) Button to stop the Car DVR from recording.
2. Press the (Menu) Button to enter the Video Menu.
3. Use the and Buttons to navigate the Settings Menu and highlight the Motion Detection setting and press (Rec/
Ok) to select.
4. Use the and Buttons to highlight either OFF or ON, then press the (Rec/Ok) button to confirm your selection.
Note:
1. Menus cannot be accessed while the camera is recording. Please stop the recording before attempting to access the menu.
12

2.7.6 Recording Audio
The Recording Audio setting allows you to mute the microphone during recording, or set it to record. To set your recording
preferences, please follow the instructions below.
1. Press the (Rec/Ok) Button to stop the Car DVR from recording.
2. Press the (Menu) Button to enter the Video Menu.
3. Use the and Buttons to navigate the Settings Menu and highlight the Recording Audio setting and press (Rec/
Ok) to select.
4. Use the and Buttons to highlight either OFF or ON, then press the (Rec/Ok) button to confirm your selection.
Note:
1. Menus cannot be accessed while the camera is recording. Please stop the recording before attempting to access the menu.
2.7.7 Date Stamp
Date stamp will stamp the current date onto the footage for future reference. To set the date stamp please follow the
instructions below.
1. Press the (Rec/Ok) Button to stop the Car DVR from recording.
2. Press the (Menu) Button to enter the Video Menu.
3. Use the and Buttons to navigate the Settings Menu and highlight the Date Stamp setting and press (Rec/Ok) to
select.
4. Use the and Buttons to highlight either OFF or ON, then press the (Rec/Ok) button to confirm your selection.
Note:
1. Menus cannot be accessed while the camera is recording. Please stop the recording before attempting to access the menu.
2. For date stamp to be correct the time and date must be set first. To set the time and date please see section Date/Time (3.2.1).
2.7.8 G Sensor (Gravity Sensing)
The G Sensor defines the required force needed to trigger emergency recording. Once Emergency recording is triggered
the current recording will be saved and protected from being saved over by the normal loop recording. To set the required
sensitivity please follow the instructions below.
1. Press the (Rec/Ok) Button to stop the Car DVR from recording.
2. Press the (Menu) Button to enter the Video Menu.
3. Use the and Buttons to navigate the Settings Menu and highlight the Gravity Sensing setting and press (Rec/
Ok) to select.
4. Use the and Buttons to highlight either OFF or ON, then press the (Rec/Ok) button to confirm your selection.
Note:
1. Menus cannot be accessed while the camera is recording. Please stop the recording before attempting to access the menu.
2. If your memory card is filling up quickly you may need to lower the sensitivity of the G Sensor (Gravity Sensor) to decrease
the number of triggers caused by normal driving.
13

14
2.7.9 Shrink Video Files
The Shrink Video Files setting allows you to shrink the output size of the video files. To set your recording preferences,
please follow the instructions below.
1. Press the (Rec/Ok) Button to stop the Car DVR from recording.
2. Press the (Menu) Button to enter the Video Menu.
3. Use the and Buttons to navigate the Settings Menu and highlight the Shrink Video Files setting and press (Rec/
Ok) to select.
4. Use the and Buttons to select requred shrink size, then press the (Rec/Ok) button to confirm your selection.
Note:
1. Menus cannot be accessed while the camera is recording. Please stop the recording before attempting to access the menu.
2. Shrinking the video files does impact the video quality.
2.8.0 Park Mode
When activated, Park Mode will monitor the DVR's G Sensor after you have turned off your vehicle. If an impact is detected
the DVR will power up and record a 60 second clip. To set Park Mode, follow the instructions below.
1. Ensure that the Car DVR is not recording.
2. Press the (Menu) Button to enter the Video Menu.
3. Use the and Buttons to navigate the Settings Menu and highlight the Parking Mode setting and press (Rec/Ok)
to select.
4. Use the and Buttons to highlight either OFF or ON, then press the (Rec/Ok) button to confirm your selection.
Note:
1. Menus cannot be accessed while the camera is recording. Please stop the recording before attempting to access the menu.
2. Park mode requires the DVR's internal battery to be fully charged.
3. Park Mode is activated when an impact is detected and will record from that point onward.
2.8.1 Number Plate
Number Plate will stamp your vehicles number plate onto the footage for reference. To set the Number Plate setting
please follow the instructions below.
1. Press the (Rec/Ok) Button to stop the Car DVR from recording.
2. Press the (Menu) Button to enter the Video Menu.
3. Use the and Buttons to navigate the Settings Menu and highlight the Number Plate setting and press (Rec/Ok) to
select.
4. Select ON and then press the (Rec/Ok) Button.
5. Use the and Buttons to select cycle through numbers and letters. The (Menu) button is used to confirm and
proceed to the next character.
6. When you have finished inputting your vehicles number plate, use the (Rec/Ok) button to save and exit.
Note:
1. Menus cannot be accessed while the camera is recording. Please stop the recording before attempting to access the menu.
2. For date stamp to be correct the time and date must be set first. To set the time and date please see section Date/Time (3.2.1).

15
3. Photo Mode
This screen is used to capture still images using your Car DVR. To access the Photo screen ensure that the camera is not recording
and press the (Mode) button. Photo mode also has a menu which is used to edit the photo settings. This menu can be accessed by
pressing the (Menu) in the Photo Screen.
3.1 Photo Menu
3.1.1 Capture Mode
Capture mode is used to set a delayed timer. To set a timer delay follow the instructions below.
1. Enter the Photo screen.
2. Press the (Menu) Button to enter the Photo Menu.
3. Use the and Buttons to navigate the Photo Menu and highlight Timer setting and press (Rec/Ok) to select.
4. Use the and Buttons to highlight your required timer delay, then press the (Rec/Ok) button to confirm your
selection.
Note:
1. Menus cannot be accessed while the camera is recording. Please stop the recording before attempting to access the menu.
2. This setting can only be accessed through the Photo Menu, please make sure that you are in the Photo screen when you access
the menu.
3.1.2 Resolution
Resolution sets the still image quality. Higher resolution images will capture more detail and will also produce larger files. To
change the photo resolution, please follow the instructions below.
1. Enter the Photo screen.
2. Press the (Menu) Button to enter the Photo Menu.
3. Use the and Buttons to navigate the Photo Menu and highlight Resolution setting and press (Rec/Ok) to select.
4. Use the and Buttons to highlight your required resolution, then press the (Rec/Ok) button to confirm your selection.
Note:
1. Menus cannot be accessed while the camera is recording. Please stop the recording before attempting to access the menu.
2. This setting can only be accessed through the Photo Menu, please make sure that you are in the Photo screen when you access
the menu.

16
3.1.3 Sequence
When Sequence is activated, when a photo is triggered a sequence of 3 photos is taken. To activate or deactivate
Sequence mode, follow the instructions below
1. Enter the Photo screen.
2. Press the (Menu) Button to enter the Photo Menu.
3. Use the and Buttons to navigate the Photo Menu and highlight Sequence setting and press (Rec/Ok) to select.
4. Use the and Buttons to highlight OFF or ON, then press the (Rec/Ok) button to confirm your selection.
Note:
1. Menus cannot be accessed while the camera is recording. Please stop the recording before attempting to access the menu.
2. This setting can only be accessed through the Photo Menu, please make sure that you are in the Photo screen when you access
the menu.
3.1.4 Quality
Quality sets the image detail. Higher quality images will capture more detail and will also produce larger files. To change the
recording resolution, please follow the instructions below.
1. Enter the Photo screen.
2. Press the (Menu) Button to enter the Photo Menu.
3. Use the and Buttons to navigate the Photo Menu and highlight the Quality setting and press (Rec/Ok) to select.
4. Use the and Buttons to highlight your required quality, then press the (Rec/Ok) button to confirm your selection.
Note:
1. Menus cannot be accessed while the camera is recording. Please stop the recording before attempting to access the menu.
2. This setting can only be accessed through the Photo Menu, please make sure that you are in the Photo screen when you access
the menu.
3.1.5 Sharpness
Sharpness sets the boldness of the image. Images with a stronger sharpness will create bolder images with stronger
outlines. To change the photo Sharpness, please follow the instructions below.
1. Enter the Photo screen.
2. Press the (Menu) Button to enter the Photo Menu.
3. Use the and Buttons to navigate the Photo Menu and highlight the Sharpness setting and press (Rec/Ok) to
select.
4. Use the and Buttons to highlight your required sharpness, then press the (Rec/Ok) button to confirm your
selection.
Note:
1. Menus cannot be accessed while the camera is recording. Please stop the recording before attempting to access the menu.
2. This setting can only be accessed through the Photo Menu, please make sure that you are in the Photo screen when you access
the menu.

17
3.1.6 White Balance
The White Balance setting is used to manually adjust the settings used to counteract different light conditions. This setting
is set to Auto by default. To change the White Balance setting follow the instructions below.
1. Enter the Photo screen.
2. Press the (Menu) Button to enter the Photo Menu.
3. Use the and Buttons to navigate the Photo Menu and highlight the White Balance setting and press (Rec/Ok) to
select.
4. Use the and Buttons to highlight your required setting, then press the (Rec/Ok) button to confirm your selection.
Note:
1. Menus cannot be accessed while the camera is recording. Please stop the recording before attempting to access the menu.
2. This setting can only be accessed through the Photo Menu, please make sure that you are in the Photo screen when you access
the menu.
3.1.7 Colour
The Colour setting is used to set the colour palette. To change the Colour setting follow the instructions below.
1. Enter the Photo screen.
2. Press the (Menu) Button to enter the Photo Menu.
3. Use the and Buttons to navigate the Photo Menu and highlight the Colour setting and press (Rec/Ok) to select.
4. Use the and Buttons to highlight your required colour setting, then press the (Rec/Ok) button to confirm your
selection.
Note:
1. Menus cannot be accessed while the camera is recording. Please stop the recording before attempting to access the menu.
2. This setting can only be accessed through the Photo Menu, please make sure that you are in the Photo screen when you access
the menu.
3.1.8 ISO
ISO is used to manage how much light is let into the image sensor. Setting a higher ISO will let in more light and blurred
movement and lower ISO will capture less movement and less light. To change the ISO setting follow the instructions below.
1. Enter the Photo screen.
2. Press the (Menu) Button to enter the Photo Menu.
3. Use the and Buttons to navigate the Photo Menu and highlight the ISO setting and press (Rec/Ok) to select.
4. Use the and Buttons to highlight your required ISO setting, then press the (Rec/Ok) button to confirm your
selection.
Note:
1. Menus cannot be accessed while the camera is recording. Please stop the recording before attempting to access the menu.
2. This setting can only be accessed through the Photo Menu, please make sure that you are in the Photo screen when you
access the menu.

18
3.1.9 Exposure
Exposure is used to manually control the light settings. To change the Exposure setting follow the instructions below
1. Enter the Photo screen.
2. Press the (Menu) Button to enter the Photo Menu.
3. Use the and Buttons to navigate the Photo Menu and highlight the Exposure setting and press (Rec/Ok) to select.
4. Use the and Buttons to highlight your required Exposure setting, then press the (Rec/Ok) button to confirm your
selection.
Note:
1. Menus cannot be accessed while the camera is recording. Please stop the recording before attempting to access the menu.
2. This setting can only be accessed through the Photo Menu, please make sure that you are in the Photo screen when you access
the menu.
3.1.2.0 Quick Review
Quick review displays the photo on screen for the set amount of time after the photo has been taken. To change the Quick
Review setting follow the instructions below.
1. Enter the Photo screen.
2. Press the (Menu) Button to enter the Photo Menu.
3. Use the and Buttons to navigate the Photo Menu and highlight the Quick Review setting and press (Rec/Ok) to
select.
4. Use the and Buttons to highlight your required image diplay time setting, then press the (Rec/Ok) button to confirm
your selection.
Note:
1. Menus cannot be accessed while the camera is recording. Please stop the recording before attempting to access the menu.
2. This setting can only be accessed through the Photo Menu, please make sure that you are in the Photo screen when you access
the menu.
3.1.2.1 Date Stamp
Date stamp is used to stamp your photos with the time and date that they are taken. To select your preferred time and date
format follow the instructions below.
1. Enter the Photo screen.
2. Press the (Menu) Button to enter the Photo Menu.
3. Use the and Buttons to navigate the Photo Menu and highlight the Date Stamp setting and press (Rec/Ok) to
select.
4. Use the and Buttons to highlight either Date, Date/Time or ON, then press the (Rec/Ok) button to confirm your
selection.

19
Note:
1. Menus cannot be accessed while the camera is recording. Please stop the recording before attempting to access the menu.
2. This setting can only be accessed through the Photo Menu, please make sure that you are in the Photo screen when you access
the menu.
3. The Date Stamp setting is not used to set the cameras internal clock. To set the time follow the instructions Date/Time (3.2.1) in
the settings section.
3.2 Setting Menu
This menu is used to edit the cameras operational settings. This menu can be accessed through either the Video or Photo menu
by pressing the (Menu) button whilst in either of these menus. While in this menu the and buttons are used to navigate and
the (Rec/Ok) button to select the highlighted setting.
3.2.1 Date/Time
The Date/Time setting is used to set the cameras internal clock. To set the internal clock follow the instructions below.
1. Press the (Rec/Ok) Button to stop the Car DVR from recording.
2. Press the (Menu) Button to enter the Video Menu.
3. Press the (Menu) Button again to enter the Settings Menu.
4. Use the and Buttons to navigate the Settings Menu and highlight the Date/Time setting and press (Rec/Ok) to
select.
5. Use the and buttons to edit the selected digit and the (Rec/Ok) button to confirm and progress to the next digit.
The final field sets the format that the date will be presented in.
6. To save and exit the time and date, press the (Menu) button.
Note:
1. Menus cannot be accessed while the camera is recording. Please stop the recording before attempting to access the menu.
2. Once the time and date is set it can be stamped onto your footage using the Date Stamp setting. Please see section Date Stamp
(3.1.2.1) for more details.
3.2.2 Key Beeps
The Key beeps setting is used to turn Off or On the beep that indicates a key press. To adjust the key beep settings, follow
the instructions below.
1. Ensure that the DVR is not recording.
2. Press the (Menu) Button to enter the Video Menu.
3. Press the (Menu) Button again to enter the Settings Menu.
4. Use the and Buttons to navigate the Settings Menu and highlight the Key beeps setting and press (Rec/Ok) to
select.
5. Use the and buttons to highlight ON or OFF, then press the (Rec/Ok) button to confirm your selection.
Note:
1. Menus cannot be accessed while the camera is recording. Please stop the recording before attempting to access the menu.
2. This setting can only be accessed through the Settings Menu which can be accessed via the Video and Photo Menus.

20
3.2.3 Language
The Language setting is used to select your preferred Language in the menus. To set the systems language follow the
instructions below.
1. Ensure that the DVR is not recording.
2. Press the (Menu) Button to enter the Video Menu.
3. Press the (Menu) Button again to enter the Settings Menu.
4. Use the and Buttons to navigate the Settings Menu and highlight the Language setting and press (Rec/Ok) to
select.
5. Use the and Buttons to highlight your preferred Language, then press the (Rec/Ok) button to confirm your
selection.
Note:
1. Menus cannot be accessed while the camera is recording. Please stop the recording before attempting to access the menu.
2. This setting can only be accessed through the Settings Menu which can be accessed via the Video and Photo Menus.
3.2.4 Frequency
The Frequency setting is used to set the cameras frequency. To adjust the frequency, follow the instructions below.
1. Ensure that the DVR is not recording.
2. Press the (Menu) Button to enter the Video Menu.
3. Press the (Menu) Button again to enter the Settings Menu.
4. Use the and Buttons to navigate the Settings Menu and highlight the Frequency setting and press (Rec/Ok) to
select.
5. Use the and Buttons to highlight your preferred Frequency, then press the (Rec/Ok) button to confirm your
selection.
Note:
1. Menus cannot be accessed while the camera is recording. Please stop the recording before attempting to access the menu.
2. This setting can only be accessed through the Settings Menu which can be accessed via the Video and Photo Menus.
3.2.5 Screen Saver
The Screen Saver setting is used to set the duration of inactivity of the camera before the screen goes into sleep mode. To
set the screen saver follow the instructions below.
1. Ensure that the DVR is not recording.
2. Press the (Menu) Button to enter the Video Menu.
3. Press the (Menu) Button again to enter the Settings Menu.
4. Use the and Buttons to navigate the Settings Menu and highlight the Screen Saver setting and press (Rec/Ok)
to select.
5. Use the and buttons to highlight your preferred duration of inactivity, then press the (Rec/Ok) button to confirm
your selection.
