NanoCam Plus NCP-DVRWIFI User manual

USER MANUAL
FULL-HD 1080P
BARREL DASH CAM DVR
WITH WIFI CONNECTION
NCP-DVRWIFI

Caution ................................................................................................................................................................ 3
Battery Warning................................................................................................................................................................ 3
Notes on Installation ........................................................................................................................................................ 3
1. Introduction............................................................................................................................................................... 4
1.1 Features ................................................................................................................................................................ 4
1.2 Package Contents................................................................................................................................................. 4
1.3 Product Overview .................................................................................................................................................. 4
2. Getting Started ......................................................................................................................................................... 5
2.1 Inserting Memory Card ........................................................................................................................................ 5
2.2 Mounting you NCP-DVRWIFI ............................................................................................................................... 5
2.3 WiFi Connection .................................................................................................................................................. 6
2.4 Initial Settings ...................................................................................................................................................... 6
2.4.1 Formatting your Micro SD Card................................................................................................................ 6
2.4.2 Setting the Time & Date ........................................................................................................................... 7
2.5 App Operation ..................................................................................................................................................... 7
2.5.1 Camera Preview....................................................................................................................................... 7
2.5.2 Settings ................................................................................................................................................... 7
2.5.3 Mobile...................................................................................................................................................... 7
2.5.4 SD Card................................................................................................................................................... 7
2.5.5 FAQs........................................................................................................................................................ 7
2.5.6 Camera Preview....................................................................................................................................... 8
3. Settings ................................................................................................................................................................ 8
3.1 Park Mode........................................................................................................................................................... 8
3.2 Setting the Time & Date....................................................................................................................................... 8
3.3 Resolution ........................................................................................................................................................... 9
3.4 Movie Length....................................................................................................................................................... 9
3.5 G-Sensor........................................................................................................................................................... 10
3.6 Formatting Your Micro SD Card ......................................................................................................................... 10
3.7 Playback............................................................................................................................................................ 10
3.8 Deleting Videos.................................................................................................................................................. 11
Warranty Terms & Conditions................................................................................................................................ 11

3
Caution
•Ensure you are using your Car DVR within your countries’ road laws. Please make sure you are familiar with your local road legislation
before use.
• Avoid leaving your Car DVR in direct sunlight for extended periods of time in an unventilated space.
• Please set time and date before you use this device to record.
• The system is to be used only for non-commercial use, within the limits permitted by the relevant laws
• Avoid using the Car DVR in the vicinity of any devices that emit radio interference (eg. Microwave Ovens).
• It is considered normal operation for the Car DVR to get warm during use.
Battery Warning
•Always charge the Car DVR using the provided charger. Improper charging of the Car DVR may result in failure of the internal battery.
•Never dismantle the Car DVR or expose the internal battery.
•Do not dispose of the Car DVR in fire.
•Dispose of the Car DVR observing local regulations being mindful of the internal battery.
•Do not attempt to replace or expose the internal battery.
Notes on Installation
1. It is advised that the Car DVR is installed near the rear view mirror, at the top centre of the windshield for optimal operation.
2. Make sure that the lens is within the range of the windscreen wiper to ensure a clear view when it rains.
3. Do not touch the lens with your fingers. Finger prints left on the lens will result in unclear videos or photos. If photos or videos are blurred,
please clean the lens gently with a microfibre cloth.
4. Only use the included charging cable to power the Car DVR.

4
1. Introduction
Thank you for purchasing a NanoCam Plus Car DVR. We are certain that our product will give you troublefree operation while providing
you with a safety feature that enhances your driving experience. Our products, like most after-market safety enhanced devices, are
designed to assist and aid the driver, not to replace the manual function of the person operating the vehicle. Please read through these
instructions before attempting to install this product.
For the latest manual and product updates, please visit our website at www.nanocamplus.com.au or www.nanocamplus.co.nz
1.1 Features
• Recording 1080P footage at 30 frames per second.
• WiFi Smartphone connectivity and app.
• 140° Field of view
• Park mode
1.2 Package Contents
Dash Cam USB DC Power Adapter Mini USB Power Cable
1.3 Product Overview
1. Lens 5. Power Input
2. Speaker 6. Power Button
3. Mount Unlock Button 7. Reset Button
4. SD Card Slot 8. Mount
1 2
7
8
6
3
4
5

5
2. Getting Started
2.1 Inserting Memory Card
Please note that the Micro SD card can only go into your device one way.
Attempting to install the card other than how it's described below will cause damage to either your card, device, or both.
Do not force your card into the slot. If force is required, it is likely that your card is in the wrong way. A correctly inserted card will
require you to use your finger nail to push the card into the slot until a click sound is heard/felt.
Instructions
Ensure that your NCP-DVRWIFI is not connected to any power. Position the Micro SD card with the text facing the front of the
camera. The gold contact ends of your memory card should always go into the slot first. Use your fingernail to press the card into
the slot until a click is heard.
Note:
1. Do not insert or remove a Micro SD card while your NCP-DVRWIFI is powered up or recording. This may damage your Micro SD
card.
2. Please use Class 10 rated Micro SD cards up to 32GB.
3. Please format the Micro SD card before initial use (in FAT 32 format if you are using a computer to format your Micro SD card). The
card can also be formatted using the App.
4. To quickly delete all items on your Micro SD card you can format the card in the settings menu of the App.
To remove the memory card
Ensure that your NCP-DVRWIFI is powered off. Using your fingernail press the SD card until a click is heard and release. The card
should eject from the slot. Please ensure you always handle your Micro SD Card with care.
2.2 Mounting you NCP-DVRWIFI
Please read through all mounting instructions for all components before you
attempt to mount your NCP-DVRWIFI.
It is recommended that you install the NCP-DVRWIFI in a position behind your
rear-view mirror, ensuring that your front driving view is not obstructed. Once you
have mounted your camera using your preferred method it is recommended that
you run the power cable around your windscreen under your vehicles interior trim
in the driver's side direction

6
2.3 WiFi Connection
All settings on the NCP-DVRWIFI are edited through the NCP-DVRWIFI App. The system requirements for your smart phone are
noted below.
iPhone: iPhone 5 or later using iOS 8.0 and above.
Samsung Galaxy: S3 and later using Android 4.2.2 and above.
For you to correctly connect your smart device to your NCP-DVRWIFI you will need to have the NCP-DVRWIFI App from the App
store. You will also need to connect your smart phone to the NCP-DVRWIFI's WiFi signal using your smartphones WiFi settings.
For a step by step guide on connecting to your Dash Cam please follow the steps below.
1. Using your Android or iOS smartphone, download the NCP-DVRWIFI app from the app store or Google Play store.
2. Make sure that the NCP-DVRWIFI is correctly installed and powered up.
3. On your smart device go to the WiFi settings menu located in the settings section.
4. Connect to the NCP-DVRWIFIs WiFi connection.
5. When prompted enter the password 12345.
6. When the WiFi connection is established open the NCP-DVRWIFI app on your smartphone.
2.4 Initial Settings
Before using the NCP-DVRWIFI we recommend formatting the inserted Micro SD Card and Setting the correct time and date.
2.4.1 Formatting your Micro SD Card
Formatting your Micro SD Card deletes all data on the Micro SD Card and prepares it for use with the NCP-DVRWIFI.
It is recommended that you format your Micro SD Card before you use the NCP-DVRWIFI. It is also advised that the Micro
SD Card is formatted once a month.
To Format the inserted Micro SD Card, please follow the instructions below.
1. Connect your smart device to the NCP-DVRWIFI using the instructions laid out in the WiFI Connection section of this
manual.
2. In the home page of the app press the Settings button.
3. In the settings menu scroll down to and tap the Format SD Card setting.
4. When prompted press OK to continue the formatting process.
Note:
1. Once the Micro SD Card is formatted, any data that was previously on the card will be unrecoverable.
2. It is recommended that you format your Micro SD Card once a month.

7
2.4.2 Setting the Time & Date
The NCP-DVRWIFI will sync the time and date with your smartphone when connected via WiFi.
It is advised that you sync the time and date manually before you begin recording to ensure any footage you record is
stamped with the correct time and date.
To manually sync the time and date, please follow the instructions below.
1. Connect your smart device to the NCP-DVRWIFI using the instructions laid out in the WiFI Connection section of this
manual.
2. In the home page of the app press the Settings button.
3. In the settings menu scroll down to and tap the Sync Time setting.
4. Tap Ok to complete the Time Sync
Note:
1. It is important that you sync the time and date to ensure that the date stamp on the footage matches the time the
footage was recorded.
2. Any footage that is not correctly time stamped may not be accepted by your insurance company
2.5 App Operation
To use the NCP-DVRWIFI App your smart device will need to be connected to the Dash Cams wireless connection. For
instructions on wirelessly connecting your smart device to your NCP-DVRWIFI please see the section of this manual named WiFi
Connection.
2.5.1 Camera Preview
View the live video preview from the NCP-DVRWIFI.
2.5.2 Settings
Is used to configure the required settings of your Dash Camera.
2.5.3 Mobile
Access video files saved to your Smartphone.
2.5.4 SD Card
Access video files saved to the Micro SD Card inserted in the NCP-DVRWIFI.
2.5.5 FAQs
Frequently asked questions about the NCP-DVRWIFI.

8
2.5.6 Camera Preview
1. Library Button
2. Record Button
3. Photo Button
The Camera Preview screen displays the cameras live view.
To manually start or stop recording tap the Record Button to
toggle recording start and stop.
To take a snapshot tap the Photo Button to take a photo.
3. Settings
The Sound Record Setting mutes the on board microphone.
To mute the microphone while recording please follow the directions below.
1. Connect your smart device to the NCP-DVRWIFI using the instructions
laid out in the WiFI Connection section of this manual.
2. In the home page of the app press the Settings button.
3. In the settings menu switch the Sound Record setting on or off as required.
Note:
1. Settings can only be changed via the App while your smartphone is connected to the NCP-DVRWIFI.
2. Audio on videos recorded while the microphone is muted cannot be recovered.
3.1 Park Mode
Park Mode monitors your vehicle while it is parked using the built in G sensor. If an impact to your vehicle is detected the camera
will turn on and record 60 seconds of footage.
To activate Park Mode please follow the directions below.
1. Connect your smart device to the NCP-DVRWIFI using the instructions laid out in the WiFI Connection section of this manual.
2. In the home page of the app press the Settings button.
3. In the settings menu switch the Parking Mode setting on or off as required.
Note:
1. Settings can only be changed via the App while your smartphone is connected to the NCP-DVRWIFI.
3.2 Setting the Time & Date
The NCP-DVRWIFI will sync the time and date with your smartphone when connected via WiFi.
It is advised that you sync the time and date manually before you begin recording to ensure any footage you record is stamped
with the correct time and date.
To manually sync the time and date, please follow the instructions below.
1. Connect your smart device to the NCP-DVRWIFI using the instructions laid out in the WiFI Connection section of this manual.
2. In the home page of the app press the Settings button.

9
3. In the settings menu scroll down to and tap the Sync Time setting.
4. Tap Ok to complete the Time Sync.
Note:
1. It is important that you sync the time and date to ensure that the date stamp on the footage matches the time the footage was
recorded.
2. Any footage that is not correctly time stamped may not be accepted by your insurance company.
3.3 Resolution
The Movie Quality setting allows you to set the recording resolution of the NCP-DVRWIFI.
• 1080P recordings will provide a higher quality video, but will yield bigger file sizes.
• 720P will record high definition recordings and will yield smaller file sizes.
To set your required resolution please follow the directions below.
1. Connect your smart device to the NCP-DVRWIFI using the instructions laid out in the WiFI Connection section of this manual.
2. In the home page of the app press the Settings button.
3. In the settings menu scroll down to and tap the Movie Quality setting.
4. Select your required resolution.
Note:
1. Settings can only be changed via the App while your smartphone is connected to the NCP-DVRWIFI.
3.4 Movie Length
The Movie Length setting allows you to set the amount of time that the NCP-DVRWIFI will record before starting a new
recording.
These are called recording loops.
To set your required recording time please use follow the directions below.
1. Connect your smart device to the NCP-DVRWIFI using the instructions laid out in the WiFI Connection section of this manual.
2. In the home page of the app press the Settings button.
3. In the settings menu scroll down to and tap the Movie Length setting.
4. Select your required recording length.
Note:
1. Settings can only be changed via the App while your smartphone is connected to the NCP-DVRWIFI.
2. It is advised that you set the recording time to 1 minute, this will mean that any false G Sensor triggers will only save a 1 minute of
footage.

10
3.5 G-Sensor
The G Sensor monitors for impacts to your vehicle while driving. If an impact is detected the camera saves the recording
away from the standard loop recording files to ensure it is not recorded over.
To set the sensitivity of the G Sensor please follow the instructions below.
1. Connect your smart device to the NCP-DVRWIFI using the instructions laid out in the WiFI Connection section of this
manual.
2. In the home page of the app press the Settings button.
3. In the settings menu scroll down to and tap the G-Sensor setting.
4. Select your required G Sensor sensitivity.
Note:
1. Settings can only be changed via the App while your smartphone is connected to the NCP-DVRWIFI.
2. If your Micro SD Card is filling up quickly, try setting the G Sensor to the lowest setting.
3.6 Formatting Your Micro SD Card
Formatting your Micro SD Card deletes all data on the Micro SD Card and prepares it for use with the NCP-DVRWIFI.
It is recommended that you format your Micro SD Card before you use the NCP-DVRWIFI. It is also advised that the Micro
SD Card is formatted once a month.
To Format the inserted Micro SD Card, please follow the instructions below.
1. Connect your smart device to the NCP-DVRWIFI using the instructions laid out in the WiFI Connection section of this
manual.
2. In the home page of the app press the Settings button.
3. In the settings menu scroll down to and tap the Format SD Card setting.
4. When prompted press OK to continue the formatting process.
Note:
1. Once the Micro SD Card is formatted, any data that was previously on the card will be unrecoverable.
2. It is recommended that you format your Micro SD Card once a month.
3.7 Playback
To playback videos from the inserted Micro SD Card, please follow the steps below.
Please note, video playback may take a few seconds to buffer.
1. Connect your smart device to the NCP-DVRWIFI using the instructions laid out in the WiFi Connection section of this
manual.
2. In the opening page of the App press the (SD Card Files) button.
3. Select the video you want to play.
4. Press the Open button to begin playback.
