GEM-EZM4/8 Wiring Diagram
GEM-EZM4/8
ZONE EXPANSION MODULE
for GEM-P816 & GEM-P1632
Control Panels
R
333 Bayview Avenue
Amityville, New York 11701
For Sales and Repairs, [phone]
For Technical Service, [phone]
© Napco 1999 WI898E 4/2000
DESCRIPTION
The capacity of the GEM-P816 and GEM-P1632 control panels may be expanded through the use of GEM-EZM4/8 zone expansion
module. Each GEM-EZM4/8 module provides up to 16 additional zones. It may be configured in a number of methods: 4 zones, 8 zones,
12 zones or 16 zones. Using any of these configurations, several GEM-EZM4/8 modules may be combined as necessary to supply the
required number of zones to the GEM-P816 and GEM-P1632 control panels. Refer to the GEM-P816 Installation Instructions (WI994)
and GEM-P1632 Installation Instructions (WI808) for wiring requirements for UL-listed applications. Note: The GEM-P816 is limited to
16 zones.
WIRING
Wire the expansion zones to the module and the module to the control panel in accordance with the wiring diagrams shown using
wire no thinner than #22AWG. Install end-of-line resistors on all zones even if one or more zones are not used.
NOTE: The addition of Zone Expansion Modules will reduce the amount of current available by 60mA at the control panel's Auxiliary
Power Output terminals.
Current
(Nominal
Voltage
12VDC)
60 mA
SPECIFICATIONS
MAXIMUM LOOP RESISTANCE
Standard Zone
Configuration
Primary Zones in
Zone Doubled
Configuration
Secondary Zones in
Zone Doubled
Configuration
300 Ohm 100 Ohm 100 Ohm
INSTALLATION INSTRUCTIONS
910 11 12

2
4-Wire Smoke Detector Wiring
CONFIGURATION (EZM GROUPS)
The EZM Group Configuration indicates how many zones the module will contain. Additional zones can be added in the following
configurations:
678910 11 12 13 14 15 16 17
Configuration 2 (8 Zones)
Configuration = 2 EZM
(Default Setting)
NOTE: If both zones in a zone-pair configuration (ex: zones 1 & 9 in the above diagrams) are to be used, then normally closed devices
must be wired to both zones. If Normally open zones for fire or panic devices are required, then the lower zone (2.2K EOL resistor)
must be used and the higher zone (3.9K EOL resistor) must not be programmed for any area. The 3.9K EOL resistor must be placed
across the terminals of the higher zone. For proper supervision, the 2.2K EOL resistor must be placed at the end of the loop.
EZM GROUP MODULE ASSIGNMENT
Regardless of how the modules are arranged, the expansion zones are
divided into consecutively-numbered groups of four. Each module may
comprise 1 group (4 zones), 2 groups (8 zones), 3 groups (12 zones) or 4
groups (16 zones). The EZM Group Assignment is done by configuring the
jumpers as shown in the above wiring diagrams. NOTE: The default setting
is 2 groups (8 zones).
BASE ADDRESS ASSIGNMENT
Every module must be assigned a unique “base address”. The Base
Address indicates which zones the module will contain. The base address
depends on the number of zones used by the previous module or by the
control panel. NOTES: (1) Groups must be numbered consecutively, that is,
missing numbers are not permitted. (2) No two modules may be numbered
alike.
Example. One GEM-EZM4/8 is used to provide 16 expansion zones to an
existing 8 zone installation, increasing the total to 24 zones. The next zone
available is zone 9, because the previous 8 zones are used by the control
panel. The GEM-EZM4/8 will provide zones 9-24 and its base address will
be "1" (see tables on next page).
GEM-EZM4/8
Groups 1, 2, 3 & 4,
Zones 9-24,
Base Address "1"
678910 11 12 13 14 15 16 17
Configuration 1 (4 Zones)
Configuration = 1 EZM
6 78 9 10 11 12 13 14 15 16 17
Configuration 3 (12 Zones using Zone Doubling)
Configuration = 3 EZM
6 78910 11 12 13 14 15 16 17
Configuration 4 (16 Zones using Zone Doubling)
Configuration = 4 EZM
NOTE: Normally open and normally closed devices may be
wired to any of the first four zones (1-4) in this configuration.
NOTE: Normally open and normally closed devices may be
wired to any of the eight zones (1-8) in this configuration.

3
The base address is assigned to the module by proper selection of Address Jumpers (to the right of the LED) in accordance with the
following tables. Also refer to the Zone Wiring Diagram. Note: The GEM-P816 is limited to 16 zones.
GEM-P1632 WITH ZONE DOUBLING DISABLED (Zones 1-8 on Control Panel)
Base Address Jumpers Config. 1 (1 EZM)
4 Zone
Config. 2 (2 EZM)
8 Zone (Default)
Config. 3 (3 EZM)
12 Zone
Config. 4 (3 EZM)
16 Zone
54321Base
Address
Zone
No.
Base
Address
Zone
No.
Base
Address
Zone
No.
Base
Address
Zone
No.
off off off off ON 1 9-12 1, 2 9-16 1, 2, 3 9-16 1, 2, 3, 4 9-24
off off off ON off 2 13-16 2, 3 13-20 2, 3, 4 13-20 2, 3, 4, 5 13-28
off off off ON ON 3 17-20 3, 4 17-24 3, 4, 5 17-24 3, 4, 5, 6 17-32
off off ON off off 4 21-24 4, 5 21-28 4, 5, 6 21-28
off off ON off ON 5 25-28 5, 6 25-32
GEM-P1632 WITH ZONE DOUBLING ENABLED (Zones 1-8 on Control Panel)
Base Address Jumpers Config. 1 (1 EZM)
4 Zone
Config. 2 (2 EZM)
8 Zone (Default)
Config. 3 (3 EZM)
12 Zone
Config. 4 (3 EZM)
16 Zone
54321Base
Address
Zone
No.
Base
Address
Zone
No.
Base
Address
Zone
No.
Base
Address
Zone
No.
off off off off ON 1 17-20 1, 2 17-24 1, 2, 3 17-28 1, 2, 3, 4 17-32
off off off ON off 2 21-24 2, 3 21-28 2, 3, 4 21-32
off off off ON ON 3 25-28 3, 4 25-32
PROGRAMMING
The control panel must be programmed with regard to the total number of zones required. When keypad programming the control
panel for the first time, the first programming option of the Easy Menu Driven Program Mode will be to enter the total number of zones
in the system, rounded up to the nearest four. You can then support this total by adding the appropriate number of GEM-EZM4/8
modules which can be configured as 4, 8, 12 or 16 zone modules. The number of modules required is a function of the number of
zones required as well as the configuration of the EZM's. If 24 additional zones are required and Config 2 (8 zones) is chosen, the
number of EZM's required will be 24/8 = 3 EZM's.
When downloading a control panel, the total number of zones is determined on the Zone Features screen by activating the required
number of EZM modules in the System Configuration screen.
For Fire Zones, if an EZM module is selected as Config 3 or Config 4, which are both zone doubled configurations, and one of
these doubled zones is programmed as a fire zone, the complimentary zone is lost. For example, if an EZM is configured as a 16 zone
module (Config 4), and zone 1 of the module is programmed as a Fire Zone, zone 9 of the module will lose the zone doubling profile
and cannot be used. It must be strapped out with a Z resistor (3.9K) across the zone. Zone 9 must be skipped in your control panel
programming, and the next available zone will be Zone 10.
TAMPER
If the cover is removed, the keypad sounder will pulse and the display will indicate a zone-module tamper condition along with the
module number. Press C to silence the sounder.
LOOP RESPONSE
Loop response times for Zones 1 through 8 are programmed in the control panel. Normal loop response for all expansion zones is
750mS. The module already comes without the jumper installed (defaulted to 750ms). To reduce the response time of zones 1 through
4 of the EZM Module to 50mS, add the Loop Response Jumper. To enable normal loop response (750 ms), remove the jumper. Refer
to the Wiring Diagram.
STATUS LED
The Status LED displays the condition of the zone module. The following is a list of conditions for the LED:
1. OFF = Control Panel has no power applied
2. ON Steady = Control Panel has power applied but the panel is not polling because:
a. the panel is in "CONFIG",
b. the panel is not programmed correctly to poll the address of the EZM,
c. the GRN wire is not connected correctly.

4
