NAPCO DUAL TECH GEMC-BSLC-DT-L User manual

1
ADVANCED ADAPTIVE PIR/MICROWAVE
TECHNOLOGY SENSORS
GEMC-BSLC-DT-L "DUAL TECH"
INSTALLATION INSTRUCTIONS
GENERAL DESCRIPTION
SPECIFICATIONS
General Coverage with standard wide-angle lens, meas-
ured indoors at 68°F (20°C), typical: 50 feet long x 40 feet
wide; plus "Look-down" zone.
Operating Temperature: 14° to 122°F (-10° to +49°C)
Mounting: Wall or corner, 6 - 9.8 feet (2 - 3m) maximum
Microwave Frequency: 10.525GHz ±25MHz
Dimensions (HxWxD): 4.6 x 2.5 x 2.5" (11.7 x 6.35 x
6.35cm)
Shipping Weight: .3lb (4.8oz, 136g)
Electrical Ratings
Input Power: 13.6-16.3VDC supplied by model GEMC-
BSLC, 4mA.
Maximum Wiring Length: 2000' (#16 AWG). Refer to
GEMC-BSLC documentation for complete wiring infor-
mation. Unit shall be connected to model GEMC-BSLC
which is employed in the GEMC C-Series control panel
which is provided with a minimum of 4 hours standby on
battery power.
FEATURES
 Microprocessor signal processing
 Utilizes analog to digital signal conversion
 System diagnostic electronics
 Watchdog microprocessor supervision
 Dual-element PIR sensor
 High-efficiency, dirt-resistant grooves-in lens
 "Look-down" zone
 Extensive RFI and EMI filtering ensure optimum immunity
to false alarms
 Large lens area assures high PIR sensitivity
 Selectable microwave/PIR LED indication visible from
virtually any angle, extinguishable after testing.
 Small size; modern, unobtrusive design
 Silent operation
 Bracket-free corner or wall mountable
 Universal Swivel Bracket Kit available (not evaluated by
UL)
ORDERING INFORMATION
SVLBKT Swivel Bracket Kit
BASIC OPERATION
This unit is a combination passive-infrared (PIR) sensor and
microwave sensor, both contained in a single package. The
unit will go into alarm when both sensors detect intrusion at
the same time. The PIR section operates by detecting a
rapid change in temperature when an intruder crosses a
protected area. When a beam experiences a change in
heat (projected back through the lens), a pulse is generated
by the sensor element. The microwave transmitter sends
out short bursts of RF energy, and the receiver detects
changes in the returned signal caused by motion within its
coverage area.
The microwave section is unaffected by visible light, air
drafts, or temperature changes (as from space heaters or air
conditioners, for example), but is sensitive to motion. Strong
vibrations can be troublesome. Microwave signals may
pass through non-metallic walls and windows. Infrared is
virtually unaffected by vibration, and will not penetrate walls
or windows.
Thus the two technologies complement each other, and it is
the combination of the two that provides an inherent immun-
ity to false alarms. Dual technology is ideal for use in hostile
environments. Since both must trip to cause an alarm, in-
stallation is easier and requires less discipline.
DETECTION PATTERNS
Figure 1 illustrates maximum PIR and microwave detection
patterns superimposed on each other.
Fig. 1. GEMC-BSLC-DT-Lwide-angle lens patterns showing maximum
recommended coverage:
(a) top view;
(b) side view for 6' mounting height.
50'
40'
85°
(a) PIR MW
6'
PIR MW
10' 20' 30' 40' 50
(b)
WI2071A\1 06/14
333 Bayview Avenue
Amityville, New York 11701
For Sales and Repairs, [phone]
For Technical Service, [phone] or visit us at
http://tech.napcosecurity.com/
(Note: Technical Service is for security professionals only)
Publicly traded on NASDAQ Symbol: NSSC
© NAPCO 2014

2
STANDARD LENS
The supplied lens will perform best in typical applications,
thus it is factory installed. Following are its specifications.
Number of Zones: 18 zones, 40 beams, plus "Look-
down".
Maximum Coverage: 50ft. long x 40ft. wide
Field of View: 80°
Note: (1) Should the lens become heavily soiled, it
may be cleaned using lukewarm water and a mild deter-
gent. To dry, use a soft lint-free cloth or allow to air dry.
(2) If the standard lens does not suit the application, select
another available lens. Note: Non-standard lenses have
not been evaluated by UL.
INSTALLATION
CHOOSING A SUITABLE LOCATION
The unit may be either wall mounted or corner mounted.
Corner mounting is generally recommended as greater
coverage may be obtained. Select a rigid surface that is
relatively free of vibration.
Position the sensor with respect to access doors or win-
dows so that an intruder will pass across its field of view,
not directly toward or away from it. Avoid areas containing
devices that may pose a chronic problem to either sensor.
For the dual-technology feature to be truly effective in ren-
dering the unit free from false alarms, neither sensor
should detect intrusion under normal conditions. Note:
The unit is shipped from the factory with jumper 4(A)
ALARM installed in Jumper Block J1 to allow the LED
to indicate simultaneous PIR and Microwave trips.
MOUNTING THE SENSOR
Open the case by inserting a small screwdriver in the slot
at the bottom and pushing up slightly. Remove the front
cover.
An array of "push-thru" holes is provided in the rear case
to simplify wall or corner mounting. A round push-thru
hole permits cable entry at the bottom. Cutaway notches
in the rear case will accommodate surface-mounted ca-
bles if the outer jacket is removed. After the proper knock-
outs have been removed, the rear case may be used as a
template to mark drill holes. Note: Any unused knockout
must be sealed with thecaulking material supplied to
eliminate drafts and prevent entry by insects. If mounting
higher than 3 meters, it may be necessary to tilt the unit
downward slightly for proper microwave coverage, and to
reset the Height Scale slightly for proper PIR coverage.
WIRING
Complete the terminal connections as follows:
Power (Terminals 1 [S] & 2 [S]): Connect to the [S] and
[S] terminals on the GEMC-BSLC.
SETTING THE HEIGHT SCALE
The Height Scale must be set to obtain the maximum rec-
ommended coverage. Remove the front cover. Note that
the Height Scale is printed along the edge of the circuit
board in the upper-left corner (see Fig. 3). The scale cali-
brations represent sensor mounting height (6 feet to 9.8
feet or 2-3 meters maximum) for the standard wide-angle
lens only. To set, loosen the Lock Screw shown in the
illustration to slide the board up or down, and align the
Pointer Mark groove in the rear case with the index Height
Scale on the PC board representing the mounting height
of the unit. Then tighten the Lock Screw (do not over-
tighten!).
LOOK DOWN ZONE
Coverage sensitivity is extended to the "Look-down" zone,
located directly below the unit. To remove the Look-down
zone, simply remove the lens from the Look-down holder.
You may wish to remove the Look-down lens if there are
large pets that may get below the unit.
JUMPER BLOCK
The Jumper Block "J1" (see Fig. 4) is used to select oper-
ating modes, numbered 1-5 from left to right, as follows:
Jumper 1(S) SENSITIVITY. Install this jumper for high
sensitivity or when using in narrow areas or corridors.
Jumper 2(D) LED DISABLE. Install this jumper if you
want to disable the LED.
After testing, be sure to either install jumper 4(A) ALARM
for normal LED operation where the LED lights upon an
alarm condition, or install jumper 2(D) LED DISABLE to
prevent the LED from lighting upon an alarm condition.
Note: Regardless of theposition of this 2(D) LED DIS-
ABLE jumper, troubles will always bedisplayed on the
keypad.
S S
12
Fig. 2. Power Terminals
1(S)
Fig. 4. Jumper Block "J1"
2(D) 3(P) 4(A) 5(M)
Jumper 1(S) SENSITIVITY
Jumper 2(D) LED DISABLE
Jumper 3(P) PIR
Jumper 4(A) ALARM
Jumper 5(M) MWAVE
Fig. 3. Circuit board layout
MICROWAVE RANGE ADJUST
(TURN CLOCKWISE TO INCREASE
RANGE)
POINTER MARK
PIR SENSOR
MICROWAVE
ANTENNA
JUMPER BLOCK J1
TAMPER
MICROSWITCH
LOCK SCREW
POWER TERMINALS
HEIGHT SCALE
LED

3
Jumper 3(P) PIR. Install this jumper for PIR Walk-Test
Mode; LED indicates PIR trips only. The PIR coverage is
adjusted by resetting the Height Scale (see SETTING THE
HEIGHT SCALE).
Jumper 4(A) ALARM. Install this jumper for LED to
indicate simultaneous PIR and Microwave trips (the LED
will indicate a condition that would cause an alarm if the
system were armed).
Jumper 5(M) MWAVE. Install this jumper to enable Mi-
crowave Walk-Test Mode; LED indicates microwave trips
only.
RANGE ADJUSTMENT
The Microwave Range Adjust control (see Fig. 3) should be
set at the minimum required to achieve the desired cover-
age. It is set so that the LED lights when motion is detect-
ed at the maximum desired range.
All tests MUST be made with the front cover in place.
1. Remove the front cover and install jumper 5(M)
MWAVE to enable Microwave Walk-Test Mode (LED
will indicate microwave trips only).
2. Set the Microwave Range Adjust control at mid-position.
Replace the front cover and walk test the unit (turn knob
clockwise to increase range).
3. If the desired range is insufficient, increase the Micro-
wave Range Adjust slightly and repeat the test as
necessary, increasing the control each time, until motion
is detected at the desired range. (If the desired range
was excessive, decrease the control slightly and repeat
this step). Turn knob counter-clockwise to decrease
range.
4. Re-install jumper 4(A) ALARM for the LED to indicate
simultaneous PIR and Microwave trips.
NOTE: The proper setting of the Microwave Range
Adjust control is when motion is detected at the
desired range. Because the range of the microwave
detector is not limited by the confines of walls, windows
or doors, further advancement of the control may result
in detection of motion beyond the desired coverage ar-
ea.
TESTING THE COVERAGE AREA
After the unit has been mounted and set up, its coverage
should be tested and, if necessary, altered to accommo-
date local environmental conditions (within the coverage
area). Satisfactory checks may be made using the LED on
the front of the unit. It is recommended that the coverage
area be tested at least once a year.
Testing the Unit
Complete connections to the terminal strip (see WIRING).
The unit will require a 1-minute "settling" time to adjust itself
to the surrounding temperature. After sufficient time has
been allowed, proceed as follows.
Test the range of the coverage
Install jumper 3(P) PIR to enable PIR Walk-Test Mode.
Replace the front cover. Walk out to the maximum deter-
mined coverage distance, then walk across the field of cov-
erage. The LED will remain lit as long as motion is detect-
ed.
Remove jumper 3(P) PIR and install jumper 5(M) MWAVE.
Replace the cover and repeat test.
Remove jumper 5(M) MWAVE, and install jumper 4(A)
ALARM. Replace the cover and repeat test. Confirm
that the LED lights at the maximum desired range.
Zone Masking
A problem zone may be deactivated in order to preserve
reliable system operation by zone masking the lens. Care-
fully apply a piece of zone masking foil (supplied) to the
inside grooved surface of the lens segment representing
the problem zone to block signal from the offending device
(refer to Fig. 5).
Fig. 5. Zone masking foil
(shaded area) applied to a
lens segment to deacti-
vate a problem zone.
COMPLETING THE INSTALLATION
When testing is finished, for proper operation, no jumpers
should be installed at 5(M) Microwave or 3(P) PIR Walk
Test positions.
 When jumper 4(A) ALARM is installed,theLED indi-
cates simultaneous PIR and Microwave trips (a condi-
tion that would cause an alarm if the system were
armed).
 When jumper 2(D) LED DISABLE is installed, the
LED is prevented from lighting upon simultaneous PIR
and Microwave trips (a condition that would cause an
alarm if the system were armed).
TROUBLESHOOTING
SYMPTOM PROBABLE
CAUSE REMEDY
Rapid LED flash, twice
a second. Microwave failure
Power down for 5 seconds.
Power up again and wait 1½
minutes. If symptom persists,
return unit for repair.
High speed LED wink-
ing flash. PIR Failure
Power down for 5 seconds.
Power up again and wait 1½
minutes. If symptom persists,
return unit for repair.
Unit holding loop in
alarm. Walk-Test Mode selected
Check to ensure jumper 4(A)
ALARM or jumper 2(D) LED DISA-
BLE is installed
Fig. 5. Zone Masking Foil

4
To terminate more than two conductors or
conductors of different wire sizes to a terminal,
use the "pigtail" type wiring method as shown at
right. Use insulated wire for the pigtail, and firmly
secure the conductors to the pigtail using an ap-
propriate wire nut or crimp connector for the num-
ber and gauge of conductors used.
IMPORTANT WIRING METHODS
Incorrect
Correct -- Use pigtail and wire nut / crimp connector
PIGTAIL
WIRE NUT OR
CRIMP
CONNECTOR
PIGTAIL
For single-conductor terminal
blocks (like the type shown at
left), to terminate more than one
conductor to a terminal, use the
wiring methods shown at right:
WIRE NUT OR
CRIMP
CONNECTOR
PIGTAIL
Correct -- Single incoming and/or pigtail with wire nut / crimp connectors
In
For "barrier" type terminal
blocks (like the type shown at
left), to terminate two conductors
to a terminal, use the wiring meth-
ods shown at right: Correct -- Separate incoming and outgoing conductors
In Out
Incorrect
Incorrect
In Out
NAPCO SECURITY SYSTEMS, INC. (NAPCO) warrants its products
to be free from manufacturing defects in materials and workmanship
for thirty-six months following the date of manufacture. NAPCO will,
within said period, at its option, repair or replace any product failing to
operate correctly without charge to the original purchaser or user.
This warranty shall not apply to any equipment, or any part thereof,
which has been repaired by others, improperly installed, improperly
used, abused, altered, damaged, subjected to acts of God, or on
which any serial numbers have been altered, defaced or removed.
Seller will not be responsible for any dismantling or reinstallation
charges.
THERE ARE NO WARRANTIES, EXPRESS OR IMPLIED, WHICH
EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF.
THERE IS NO EXPRESS OR IMPLIED WARRANTY OF
MERCHANTABILITY OR A WARRANTY OF FITNESS FOR A
PARTICULAR PURPOSE. ADDITIONALLY, THIS WARRANTY IS IN
LIEU OF ALL OTHER OBLIGATIONS OR LIABILITIES ON THE
PART OF NAPCO.
Any action for breach of warranty, including but not limited to any
implied warranty of merchantability, must be brought within the six
months following the end of the warranty period. IN NO CASE SHALL
NAPCO BE LIABLE TO ANYONE FOR ANY CONSEQUENTIAL OR
INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER
WARRANTY, EXPRESS OR IMPLIED, EVEN IF THE LOSS OR
DAMAGE IS CAUSED BY THE SELLER'S OWN NEGLIGENCE OR
FAULT.
In case of defect, contact the security professional who installed and
maintains your security system. In order to exercise the warranty, the
product must be returned by the security professional, shipping costs
prepaid and insured to NAPCO. After repair or replacement, NAPCO
assumes the cost of returning products under warranty. NAPCO shall
have no obligation under this warranty, or otherwise, if the product
has been repaired by others, improperly installed, improperly used,
abused, altered, damaged, subjected to accident, nuisance, flood, fire
or acts of God, or on which any serial numbers have been altered,
defaced or removed. NAPCO will not be responsible for any
dismantling, reassembly or reinstallation charges.
This warranty contains the entire warranty. It is the sole warranty and
any prior agreements or representations, whether oral or written, are
either merged herein or are expressly cancelled. NAPCO neither
assumes, nor authorizes any other person purporting to act on its
behalf to modify, to change, or to assume for it, any other warranty or
liability concerning its products.
In no event shall NAPCO be liable for an amount in excess of
NAPCO's original selling price of the product, for any loss or damage,
whether direct, indirect, incidental, consequential, or otherwise arising
out of any failure of the product. Seller's warranty, as hereinabove set
forth, shall not be enlarged, diminished or affected by and no
obligation or liability shall arise or grow out of Seller's rendering of
technical advice or service in connection with Buyer's order of the
goods furnished hereunder.
NAPCO RECOMMENDS THAT THE ENTIRE SYSTEM BE
COMPLETELY TESTED WEEKLY.
Warning: Despite frequent testing, and due to, but not limited to, any
or all of the following; criminal tampering, electrical or communications
disruption, it is possible for the system to fail to perform as expected.
NAPCO does not represent that the product/system may not be
compromised or circumvented; or that the product or system will
prevent any personal injury or property loss by burglary, robbery, fire
or otherwise; nor that the product or system will in all cases provide
adequate warning or protection. A properly installed and maintained
alarm may only reduce risk of burglary, robbery, fire or otherwise but it
is not insurance or a guarantee that these events will not occur.
CONSEQUENTLY, SELLER SHALL HAVE NO LIABILITY FOR ANY
PERSONAL INJURY, PROPERTY DAMAGE, OR OTHER LOSS
BASED ON A CLAIM THE PRODUCT FAILED TO GIVE WARNING.
Therefore, the installer should in turn advise the consumer to take any
and all precautions for his or her safety including, but not limited to,
fleeing the premises and calling police or fire department, in order to
mitigate the possibilities of harm and/or damage.
NAPCO is not an insurer of either the property or safety of the user's
family or employees, and limits its liability for any loss or damage
including incidental or consequential damages to NAPCO's original
selling price of the product regardless of the cause of such loss or
damage.
Some states do not allow limitations on how long an implied warranty
lasts or do not allow the exclusion or limitation of incidental or
consequential damages, or differentiate in their treatment of
limitations of liability for ordinary or gross negligence, so the above
limitations or exclusions may not apply to you. This Warranty gives
you specific legal rights and you may also have other rights which
vary from state to state.
NAPCO LIMITED WARRANTY
