Napoleon BGNV40-N User manual

1
W415-0320/D/01.06.07
W415-0320/D/01.16.07

2
W415-0320/D/01.06.07
WHAT TO DO IF YOU SMELL GAS
WARNINGS & SAFETY PRECAUTIONS

3
W415-0320/D/01.06.07
Pg 2-6 INTRODUCTION
Warnings and Safety Precautions
Warranty
General Instructions
General Information
Care of Glass & Plated Parts
Dimensions
7 VENTING
Vent Safety Switch
High Limit Switch
Venting Action
8-9 PENINSULAINSTALLATIONPROCEDURE
Framing
Bar / Countertop Installation
Brick Panel Installation
Facing
10 OPENENDINSTALLATIONPROCEDURE
Framing
Brick Panel Installation
Facing
11 SEE-THRU INSTALLATION PROCEDURE
Framing
Brick Panel Installation
Facing
12 ISLAND INSTALLATION PROCEDURE
Framing
Brick Panel Installation
Facing
13 GAS SUPPLY CONNECTION
14-17 FINISHING
Mantle Height Locations
Heat shield stand-off removal
Log Placement/Charcoal Embers
Logo Placement
Door Opening and Closing
Upper Louvre Bracket and Hood
Lower Louvre Bracket and Hinge Screen
Louvre Installation
End Door Installation
18 OPTIONAL BLOWER INSTALLATION
19 OPERATION / MAINTENANCE
Operating Instructions
Maintenance
20 ADJUSTMENTS
Pilot Burner Adjustment
Venturi Adjustments
21-22 REPLACEMENTS
Ordering Replacement Parts
Replacement Parts
23 ACCESSORIES
24-25 TROUBLE SHOOTING GUIDE
26 SERVICE HISTORY
WARNING
• Do not burn wood or other materials in this fireplace.
• Adults and especially children should be alerted to the hazards of high surface temperatures and should stay
away to avoid burns or clothing ignition. Supervise young children when they are in the same room as the
fireplace.
• Due to high temperatures, the fireplace should be located out of traffic and away from furniture and draperies.
• Clothing or other flammable material should not be placed on or near the fireplace.
• Any safety screen or guard removed for servicing must be replaced prior to operating the fireplace.
• It is imperative that the control compartments, burners and circulating blower and its passageway in the fireplace
and venting system are kept clean. The fireplace and its venting system should be inspected before use and at
least annually by a qualified service person. More frequent cleaning may be required due to excessive lint from
carpeting, bedding material, etc. The fireplace area must be kept clear and free from combustible materials,
gasoline and other flammable vapours and liquids.
• Under no circumstances should this fireplace be modified.
• This fireplace must not be connected to a chimney flue pipe serving a separate solid fuel burning appliance.
• Do not use this fireplace if any part has been under water. Immediately call a qualified service technician to inspect
the fireplace and to replace any part of the control system and any gas control which has been under water.
• Do not operate the fireplace with the glass door removed, cracked or broken. Replacement of the glass should be
done by a licensed or qualified service person.
• Do not strike or slam shut the fireplace glass door.
•This fireplace uses and requires a fast acting thermocouple. Replace only with a fast acting thermocouple sup-
plied by Wolf Steel Ltd.
TABLE of CONTENTS
NOTE: changes, other than editorial, are denoted by a vertical line in the margin.
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE

4
W415-0320/D/01.06.07
NAPOLEON gas fireplaces are manufactured under the strict Standard of the world recognized
ISO 9001 : 2000 Quality Assurance Certificate.
NAPOLEON products are designed with superior components and materials, assembled by trained craftsmen
who take great pride in their work. The burner and valve assembly are leak and test-fired at a quality test
station. The complete fireplace is thoroughly inspected by a qualified technician before packaging to ensure that
you, the customer, receives the quality product that you expect from NAPOLEON.
NAPOLEON GAS FIREPLACE PRESIDENT'S LIFETIME LIMITED WARRANTY
The following materials and workmanship in your newThe following materials and workmanship in your new
The following materials and workmanship in your newThe following materials and workmanship in your new
The following materials and workmanship in your new NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON gas fireplace are war-gas fireplace are war-
gas fireplace are war-gas fireplace are war-
gas fireplace are war-
ranted against defects for as long as you own the fireplace. This covers: combustion chamber,ranted against defects for as long as you own the fireplace. This covers: combustion chamber,
ranted against defects for as long as you own the fireplace. This covers: combustion chamber,ranted against defects for as long as you own the fireplace. This covers: combustion chamber,
ranted against defects for as long as you own the fireplace. This covers: combustion chamber,
heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass (thermal breakageheat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass (thermal breakage
heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass (thermal breakageheat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass (thermal breakage
heat exchanger, stainless steel burner, phazer™ logs and embers, ceramic glass (thermal breakage
only), gold plated parts against tarnishing, porcelainized enamelled components and aluminumonly), gold plated parts against tarnishing, porcelainized enamelled components and aluminum
only), gold plated parts against tarnishing, porcelainized enamelled components and aluminumonly), gold plated parts against tarnishing, porcelainized enamelled components and aluminum
only), gold plated parts against tarnishing, porcelainized enamelled components and aluminum
extrusion trims.extrusion trims.
extrusion trims.extrusion trims.
extrusion trims.
Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,
Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,
Electrical (110V and millivolt) components and wearable parts such as blowers, gas valves,
thermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly arethermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are
thermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly arethermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are
thermal switch, switches, wiring, remote controls, ignitor, gasketing, and pilot assembly are
covered andcovered and
covered andcovered and
covered and NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON will provide replacement parts free of charge during the first year ofwill provide replacement parts free of charge during the first year of
will provide replacement parts free of charge during the first year ofwill provide replacement parts free of charge during the first year of
will provide replacement parts free of charge during the first year of
the limited warranty.the limited warranty.
the limited warranty.the limited warranty.
the limited warranty.
Labour related to warranty repair is covered free of charge during the first year. Repair work,Labour related to warranty repair is covered free of charge during the first year. Repair work,
Labour related to warranty repair is covered free of charge during the first year. Repair work,Labour related to warranty repair is covered free of charge during the first year. Repair work,
Labour related to warranty repair is covered free of charge during the first year. Repair work,
however, requires the prior approval of an authorized company official. Labour costs to thehowever, requires the prior approval of an authorized company official. Labour costs to the
however, requires the prior approval of an authorized company official. Labour costs to thehowever, requires the prior approval of an authorized company official. Labour costs to the
however, requires the prior approval of an authorized company official. Labour costs to the
account ofaccount of
account ofaccount of
account of NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON are based on a predetermined rate schedule and any repair work mustare based on a predetermined rate schedule and any repair work must
are based on a predetermined rate schedule and any repair work mustare based on a predetermined rate schedule and any repair work must
are based on a predetermined rate schedule and any repair work must
be done through an authorizedbe done through an authorized
be done through an authorizedbe done through an authorized
be done through an authorized NAPOLEONNAPOLEON
NAPOLEONNAPOLEON
NAPOLEON dealer.dealer.
dealer.dealer.
dealer.
CONDITIONS AND LIMITATIONS
NAPOLEONwarrants itsproducts againstmanufacturing defectsto theoriginal purchaseronly --i.e., theindividual orlegal entity(registered customer)whose nameappears onthe
warrantyregistrationcard filed withNAPOLEON -- providedthatthe purchase wasmadethrough an authorizedNAPOLEONdealerand is subjecttothe following conditionsandlimitations:
Thisfactory warrantyis nontransferableand may not be extended whatsoever byany ofour representatives.
Thegas fireplace mustbe installedby a licenced,authorized servicetechnician or contractor.Installation must bedone inaccordance with theinstallation instructions included with the
productand alllocal and national building andfire codes.
This limited warranty does notcover damages causedby misuse, lack ofmaintenance, accident, alterations,abuse or neglect and partsinstalled from othermanufacturers will nullify
this warranty.
Thislimited warranty furtherdoes not coveranyscratches, dents,corrosionor discolouring causedby excessive heat,abrasive and chemicalcleaners nor chippingon porcelain enamel
parts,mechanical breakageof PHAZER™logs and embers, nor any venting components used inthe installationof thefireplace.
NAPOLEONwarrants its stainlesssteel burners againstdefectsin workmanship andmaterial for life,subjectto the followingconditions: During thefirst10 years NAPOLEONwill replace
or repair the defective parts at our option free of charge. From 10 years to life, NAPOLEON will provide replacement burners at 50% of the current retail price.
Inthe firstyear only,thiswarranty extendsto the repairor replacement of warranted partswhichare defective inmaterial orworkmanship providedthat theproduct has been operated
inaccordance withthe operation instructions and under normal conditions.
After the first year, with respect to this President's Limited Lifetime Warranty, NAPOLEON may, at its discretion, fully dischargeall obligationswith respect to this warrantyby refunding
tothe originalwarranted purchaserthe wholesaleprice ofany warrantedbut defectivepart(s).
Afterthe first year, NAPOLEON will not beresponsible for installation,labour orany other costsor expensesrelated to thereinstallation of a warranted part,and such expensesare not
coveredby thiswarranty.
Notwithstandinganyprovisions containedin this President'sLimited LifetimeWarranty, NAPOLEON’S responsibilityunder this warrantyis defined asabove and itshall not inany event
extendto any incidental,consequential orindirect damages.
Thiswarranty defines theobligationsand liability ofNAPOLEON withrespect to theNAPOLEONgas fireplace andany other warrantiesexpressed or impliedwithrespect to thisproduct,
itscomponents oraccessories areexcluded.
NAPOLEONneither assumes, nor authorizes any third party to assume, on its behalf, anyother liabilitieswith respectto thesale of this product. NAPOLEON will not be responsible
for: over-firing, downdrafts, spillage caused by environmental conditions such as rooftops, buildings, nearby trees, hills, mountains, inadequate vents or ventilation, excessive venting
configurations,insufficient makeup air, or negative air pressures which mayor maynot becaused by mechanical systems such as exhaust fans, furnaces, clothes dryers,etc.
Any damages to fireplace, combustion chamber,heat exchanger, brass trimor other component due to water, weather damage, long periodsof dampness, condensation, damaging
chemicals or cleaners will not be the responsibility of NAPOLEON.
Thebill of saleor copywill be requiredtogether with aserial number anda modelnumber when makingany warranty claimsfrom yourauthorized dealer. Thewarranty registration card
mustbe returnedwithin fourteendays to register the warranty.
NAPOLEONreserves theright tohave its representative inspect any product or part thereof prior to honouring any warranty claim.
ALL SPECIFICATIONS AND DESIGNSARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE DUE TO ON-GOING PRODUCT IMPROVEMENTS. NAPOLEON® ISAREGISTERED
TRADEMARKOFWOLFSTEELLTD. PATENTS U.S. 5.303.693.801-CAN.2.073.411, 2.082.915.©WOLFSTEELLTD.

5
W415-0320/D/01.06.07
THIS GAS FIREPLACE SHOULD BE INSTALLED AND
SERVICED BYA QUALIFIED INSTALLER to conform with
local codes. Installation practices vary from region to re-
gion and it is important to know the specifics that apply to
your area,
for example: in Massachusetts State:
•The fireplace damper must be removed or welded in the open
position prior to installation of a fireplace insert or gas log.
•The appliance off valve must be a “T” handle gas cock.
•The flexible connector must not be longer than 36 inches.
•The appliance is not approved for installation in a bedroom or
bathroom unless the unit is a direct vent sealed combustion
product.
• WARNING: This product must be installed by a licensed plumber
or gas fitter when installed within the commonwealth of
Massachusetts.
In absence of local codes, install to the current CAN/CGA -
B149 Installation Code in Canada or to the National Fuel
Gas Code,ANSI Z223.1, and NFPA54 in the United States.
Mobile home installation must conform with local codes.
In the absence of local codes, install to the current stand-
ard for gas equipped mobile housing CAN/CSA Z240 MH
Series in Canada or the manufactured home construction
and safety standard, Title 24 CFR, part 3280, or the Fire
Safety Criteria for manufactured home installations, Sites
and Community Standard ANSI/NFPA 5OIA in the United
States.
Purge all gas lines with the glass door of the fireplace
open. Assure that a continuous gas flow is at the burner
before closing the door.
Under extreme vent configurations, allow several min-
utes (5-15) for the flame to stabilize after ignition.
The fireplace and its individual shutoff valve must be dis-
connected from the gas supply piping system during any
pressure testing of that system at test pressures in ex-
cess of 1/2 psig (3.5 kPa). The fireplace must be isolated
from the gas supply piping system by closing its individual
manual shutoff valve during any pressure testing of the
gas supply piping system at test pressures equal to or
less than 1/2 psig (3.5 kPa).
When the fireplace is installed directly on carpeting, vinyl
tile or other combustible material other than wood flooring,
the fireplace shall be installed on a metal or wood panel
extending the full width and depth.
If the optional heat circulating blower is installed, the blower
must be electrically connected and grounded in accord-
ance with local codes. In the absence of local codes, use
the current CSA C22.1 CANADIAN ELECTRICAL CODE in
Canada or the ANSI/NFPA 70 NATIONAL ELECTRICAL
CODE in the United States.
Minimum clearance to combustible construction
from the fireplace:
sides, back, bottom, and top 0 inches
recessed depth (corner installation) 2525
2525
25 inches
Objects placed in front of the fireplace must be kept
a minimum of 48" away from the glass front faces of
the unit.
FOR YOUR SATISFACTION, ALL BURNER ASSEMBLIES
HAVE BEEN TEST-FIRED TO ASSURE THEIR OPERA-
TIONS AND QUALITY! Maximum input is 30,000 BTU/h
for natural gas and propane. When the fireplace is installed
at elevations above 4,500ft, and in the absence of specific
recommendations from the local authority having jurisdic-
tion, the certified high altitude input rating shall be reduced
at the rate of 4% for each additional 1,000ft. Maximum out-
put for natural gas is 20,400 BTU/hr at an efficiency of 68%
with the fan on.
Minimum inlet gas supply pressure is 4.5 inches water
column for natural gas and 11 inches water column for
propane. Maximum inlet gas pressure is 7 inches water
column for natural gas and 13 inches water column for
propane. Manifold pressure under flow conditions is 3.5
inches water column for natural gas and 10 inches water
column for propane.
This fireplace is approved for bedroom and bed-sitting room
installations and is suitable for mobile home installation.
NOEXTERNALELECTRICITY(110 VOLTSOR24VOLTS) IS
REQUIRED FOR THE GAS SYSTEM OPERATION. Expan-
sion / contraction noises during heating up and cooling
down cycles are normal and are to be expected.
If utilizing one of Wolf Steel's trim or surround kits, follow
the framing instructions on page 14 and the finishing in-
structions on page 23, for removal of the top extension.
Do not use abrasive cleaners to clean these parts. Buff
lightly with a clean dry cloth. The glass is 3/16" tempered
glass available from your Napoleon / Wolf Steel Ltd. dealer.
Do not substitute materials.
If the door glass should crack or break, do not operate the
fireplace. Replace only with a door assembly certified with
the fireplace. See DOOR, LOUVREAND TRIM INSTALLA-
TION for removal and replacement details. Clean the glass
after the first 10 hours of operation with a recommended
gas fireplace glass cleaner. Thereafter clean as required.
Do not clean glass when hot!
If the glass is not kept clean permanent discolouration
and / or blemishes may result.
Provide adequate ventilation air. Provide adequate ac-
cessibility clearance for servicing and operating the fire-
place. Never obstruct the front opening of the fireplace.
For safe and proper operation of the fireplace follow the
venting instruction exactly.
Provide a means for visually checking the vent connec-
tion to the fireplace after the fireplace is installed.
In order to avoid the possibility of exposed insulation
or vapour barrier coming in contact with the fireplace
body, it is recommended that the walls of the fireplace
enclosure be “finished” (ie: drywall/sheetrock), as you
would finish any other outside wall of a home. This will
ensure that clearance to combustibles is maintained
within the cavity.
GENERAL INSTRUCTIONS GENERAL INFORMATION
INTRODUCTION
CARE OF GLASS, AND PLATED PARTS

6
W415-0320/D/01.06.07
DIMENSIONS
OPEN-END
SEE-THRU
PENINSULA
ISLAND
FIGURES1a-d

7
W415-0320/D/01.06.07
This is a vented appliance and must be connected to a
chimney in accordance with the current installation codes.
In absence of local codes, install to the current National
FuelGas Code,ANSIZ223.1, orthe currentCAN/CGAB149,
Installation Codes. This model can be common-vented.
Aminimum five inch diameter (5"ø) B-vent or classAvent is
required. A minimum 5' vent height is required. Secure the
B-vent to the exhaust collar on the stove top with 3 screws.
In cold climates, the use of a B-vent and an insulated chase
is recommended.
This thermally activated switch, located in front of the draft
hood, senses an increase in temperature and acts as a
safety shut-off (See 'A' below). It shuts down the gas to the
main burner in the event of a severe downdraft of air or a
blocked or disconnected chimney flue. If the flue is blocked
or has no "draw", the safety switch will automatically shut
off the supply of gas to the main burner within 10 minutes.
This switch must be manually reset by depressing
the plunger. Refer to Figure 2.
Tampering with the safety switch can result in car-
bon monoxide poisoning and possible death.
The one wire running from the vent safety switch is attached
to terminal 1 of the valve (See 'B' below). The other wire
(laying loose in the valve control area) may be attached to a
wall switch or thermostat.
This thermally activated switch, located in front of the draft
hood, senses an increase in temperature and acts as a
safety shut-off (See 'A' below). It shuts down the gas to the
main burner in the unlikely event of the unit overheating.
The HI Limit switch will automatically reset after the unit
has cooled down, resuming gas flow to the main burner.
A test for correct venting action must be made before
the installed unit can be left with the customer.
Follow the procedure below:
1. Close all doors and windows in the room / start ex-
haust fans in the home / turn the fireplace blower off (if so
equipped).
2. Set controls to "high" and light the unit.
3. Wait 5 minutes. Light a match and hold to the front of
the draft hood. FIGURES 4 & 5.
FIGURE4
FIGURE3
Venting action is satisfactory, if smoke and flames are
drawn into the draft hood.
Venting action is unsatisfactory, if the smoke spills back, and
the flame splays outward. If venting action is unsatisfactory,
turn off the unit, wait 10 minutes and try again. If the smoke is
still not drawn into the draft hood, turn the unit off and check for
vent blockage or restriction. If necessary, consult with a quali-
fied inspector.
The Vent Safety or Hi Limit switches must not be
adjusted or disabled.
In the event that either switch or any associated
parts are exchanged, only original manufacturer's
parts may be used.
FIGURE2
VALVE
THERMOSTATOR
WALL SWITCH
VENTSAFETY
SWITCH
HIGHLIMIT
SWITCH
FIGURE5
PLUNGER A
HILIMIT
SWITCH
B
VENTING
VENTING SAFETY SWITCH
HIGH LIMIT SWITCH
VENTING ACTION CHECK

8
W415-0320/D/01.06.07
When finishing the fireplace, combustible material may
rest directly on of the top extension.
Note: Maximum weight tolerance is 400 lbs, provided
that it is evenly distributed across the top extensions of
the fireplace.
In order to achieve a countertop or bar type appearance
with the minimum height allowed, framing must be non-
combustible and may be done with metal studding attached
to the top extension sides or the upper frame of the fire-
place.FIGURE 9.
Refer to page 7.
Note: In order to avoid the possibility of exposed
insulation or vapour barrier coming in contact with the
fireplace body, it is recommended that the walls of the
fireplace enclosure be “finished” (ie: drywall/sheetrock),
as you would finish any other outside wall of a home. This
will ensure that clearance to combustibles is maintained
within the cavity.
It is best to frame your fireplace after it is positioned and
the vent system is installed. Use 2x4's and frame to local
building codes. FIGURE 6.
To install the fireplace face flush with the finished wall,
position the framework to accommodate the thickness
of the finished wall.
FIGURE6
FIGURE9
FIGURE7
A= 22 "minusfinishingmaterialthicknesseachside.
FIGURE8
* The top extension may be removed if non-combustible
framing is faced with a non-combustible material placed
flush with the front face of the unit and extending from the
top of the unit. (Example: cement board) (not supplied).
Combustible counter / bar tops must maintain a minimum
of 38½ inches from the base of the fireplace to the underside
of the top. Figure 7.
NOTE: Wolf Steel trim and/or surround kits will not to-
tally cover the top extension of the fireplace. In order to
obtain a smooth transition from the trim / surround to the
wall, it is recommended that the top extension be re-
moved and the unit be installed following the above pro-
cedure.
TOP EXTENTION
TOP OF THE UNIT
PENINSULA INSTALLATION PROCEDURE
VENTING
FRAMING
COUNTERTOP / BAR INSTALLATION

9
W415-0320/D/01.06.07
FIGURE11
DRYWALL
4"MIN
DRYWALL
Combustible materials may be installed flush with the front
of the fireplace but must not cover any of the black face-
areas of the fireplace. Non-combustible material (brick,
stone or ceramic tile) may protrude in these areas.
It is not necessary to install a hearth extension with this
fireplace system.
When roughing in the fireplace, raise the fireplace to ac-
commodate for the thickness of the finished floor materi-
als, i.e. tile, carpeting, hard wood, which if not planned for
will interfere with the opening of the lower access door and
the installation of many decorative flashing accessories.
Objects placed in front of the fireplace should be
kept a minimum of 48" away from the glass front
faces.
Refer to pages 14-17 for complete instructions regarding
mantle requirements and installations, log placement,
glass door and upper and lower louvre attachments.
Install the base panels as illustrated in steps 1-4 . The
side panel sits under the bracket tab.Holding the side
panel in position, bend down the tab to secure. DETAIL 5.
FIGURES10a-e
RETAINER
DETAIL5
STEP3
STEP2
STEP1
STEP4
STEP5
BRICK PANEL INSTALLATION FACING
FINISHING

10
W415-0320/D/01.06.07
Refer to page 7.
Note: In order to avoid the possibility of exposed insula-
tion or vapour barrier coming in contact with the
fireplace body, it is recommended that the walls of the
fireplace enclosure be “finished” (ie: drywall/sheetrock),
as you would finish any other outside wall of a home. This
will ensure that clearance to combustibles is maintained
within the cavity.
It is best to frame your fireplace after it is positioned and
the vent system is installed. Use 2x4's and frame to local
building codes. FIGURE 12.
NOTE:LEFTCORNERUNITILLUSTRATED
To install the fireplace face flush with the finished wall,
position the framework to accommodate the thickness
of the finished wall.
Combustible materials may be installed flush with the front
of the fireplace but must not cover any of the black face-
areas of the fireplace. Non-combustible material (brick,
stone or ceramic tile) may protrude in these areas.
It is not necessary to install a hearth extension with this
fireplace system.
When roughing in the fireplace, raise the fireplace to ac-
commodate for the thickness of the finished floor materi-
als, i.e. tile, carpeting, hard wood, which if not planned for
will interfere with the opening of the lower access door and
the installation of many decorative flashing accessories.
Objects placed in front of the fireplace should be
kept a minimum of 48" away from the glass front
faces.
Refer to pages 14-17 for complete instructions regarding
mantle requirements and installations, log placement,
glass door and upper and lower louvre attachments.
Install the base panels as illustrated in steps 1-4 on page
9. The side panel sits under the bracket tab.Holding the
side panel in position, bend down the tab to secure. DE-
TAIL 6.
A = 251/4" minus finishing material thickness each side.
FIGURES13a-c
FIGURE12
STEP6
RETAINER
DETAIL6
STEP5
DRYWALL
4"MIN
DRYWALL
FIGURE14
OPEN-END INSTALLATION PROCEDURE
BRICK PANEL INSTALLATION
VENTING
FRAMING
FACING
FINISHING

11
W415-0320/D/01.06.07
DRYWALL
DRYWALL
4"MIN
FIGURE17
Refer to page 7.
Note: In order to avoid the possibility of exposed insula-
tion or vapour barrier coming in contact with the
fireplace body, it is recommended that the walls of the
fireplace enclosure be “finished” (ie: drywall/sheetrock),
as you would finish any other outside wall of a home.
This will ensure that clearance to combustibles is
maintained within the cavity.
It is best to frame your fireplace after it is positioned and
the vent system is installed. Use 2x4's and frame to local
building codes. FIGURE 15.
See PAGE 7 for bar type / countertop installation.
A = 221/8" minus finishing material thickness, each side.
FIGURE15
FIGURES16a-c
Install the base panels as illustrated in steps 1-4 on page
9. Both side panels sit under the bracket tab.Holding the
side panel in position, bend down the tab to secure. DE-
TAIL 6.
RETAINER
RETAINER
STEP5
STEP6
DETAIL5& 6
Combustible materials may be installed flush with the front
of the fireplace but must not cover any of the black face-
areas of the fireplace. Non-combustible material (brick,
stone or ceramic tile) may protrude in these areas.
It is not necessary to install a hearth extension with this
fireplace system.
When roughing in the fireplace, raise the fireplace to ac-
commodate for the thickness of the finished floor materi-
als, i.e. tile, carpeting, hard wood, which if not planned for
will interfere with the opening of the lower access door
and the installation of many decorative flashing accesso-
ries.
Objects placed in front of the fireplace should be
kept a minimum of 48" away from the glass front
faces.
Refer to pages 14-17 for complete instructions regarding
mantle requirements and installations, log placement,
glass door and upper and lower louvre attachments.
SEE-THROUGH INSTALLATION PROCEDURE
FACING
FINISHING
VENTING
FRAMING
BRICK PANEL INSTALLATION

12
W415-0320/D/01.06.07
FIGURE20
DRYWALL DRYWALL
Combustible materials may be installed flush with the front
of the fireplace but must not cover any of the black face-
areas of the fireplace. Non-combustible material (brick,
stone or ceramic tile) may protrude in these areas.
It is not necessary to install a hearth extension with this
fireplace system.
When roughing in the fireplace, raise the fireplace to ac-
commodate for the thickness of the finished floor materi-
als, i.e. tile, carpeting, hard wood, which if not planned for
will interfere with the opening of the lower access door and
the installation of many decorative flashing accessories.
Objects placed in front of the fireplace should be
kept a minimum of 48" away from the glass front
faces.
Refer to pages 14-17 for complete instructions regarding
mantle requirements and installations, log placement,
glass door and upper and lower louvre attachments.
It is best to frame your fireplace after it is positioned. Use
2x4's and frame to local building codes. FIGURE 18.
To install the fireplace face flush with the finished wall,
position the framework to accommodate the thickness
of the finished wall.
FIGURE18
A = 221/8" minus finishing material thickness each side.
B= 36 " minus finishing material thickness each end.
Install the base panels as illustrated in steps 1-4 on page
9.
FIGURE19
ISLAND INSTALLATION PROCEDURE
BRICK PANEL INSTALLATIONFRAMING
FACING
FINISHING

13
W415-0320/D/01.06.07
Proceed once the vent installation is complete.
1. Move the fireplace into position and secure using the
nailing tabs and/or secure to the floor through the 1/4"ø
holes located at either end of the base.
2. Route a 3/8" N.P.T. black iron gas line, 1/2" type-L cop-
per tubing or equivalent to the fireplace.
3. For ease of accessibility, an optional remote wall switch
or millivolt thermostat may be installed in a convenient lo-
cation. Route 2-strand (solid core) millivolt wire through
the electrical hole located at the bottom left side of the unit.
The recommended maximum lead length depends on wire
size: WIRESIZE MAX.LENGTH
14gauge 100 feet
16gauge 60 feet
18gauge 40 feet
Attach the one lead to terminal 3 (located on the gas valve)
and the other lead to the vent safety switch wire ( located
loose in the valve compartment). See FIGURE 3.
Do not connect either the wall switch, thermostat
or gas valve to electricity (110 volts).
4. Install rigid black pipe, 1/2" type-L copper tubing or, if
local codes permit, a 3/8" flex connector and shutoff valve
to the gas line and the fireplace gas valve. Seal and tighten
securely. An adapter fitting is required between the gas
valve and thecopper tubing or flex connector. DO NOT KINK
FLEXIBLECONNECTOR.FIGURE6.
5. Check for gas leaks by brushing on a soap and water
solution.
Do not use open flame.
6. Mark the appropriate boxes on the rating plate label to
indicate the model type.
Purge all gas lines with the glass door of the fire-
place open. Assure that a continuous gas flow is
at the burner before closing the door.
FIGURE22
P
I
P
I
L
O T
3
12
N
O
L
O
T
H
I
L
O
F
F
O
FIGURE21
FIGURE23
GAS INSTALLATION

14
W415-0320/D/01.06.07
Combustible mantle clearance can vary according to the
mantle depth. Use the graph to help evaluate the clearance
needed. The three-sided top extension piece may be re-
moved if non-combustible framing is faced with a non-com-
bustible material.
FIGURE24
Dashed lines are suitable mantle sizes and clearances
when a non-combustible facing is used.
*SEEFIGURE9.
FINISHING
MANTLE INSTALLATION
When using a non-combustible finishing material, the stand-
offsmay be removed,by removingthe set screwin the centre
and sliding the stand-offs out of the mounting clips.
HEAT SHIELD STAND-OFF
REMOVAL
HEAT SHIELD
STAND-OFFS
END HEAT SHIELD SHOWN
FIGURE25
FIGURE26

15
W415-0320/D/01.06.07
PHAZERTM logs, glowing and charcoal embers, exclusive
to Napoleon fireplaces, provide a unique and realistic glow-
ing effect that is different in every installation. Take the time
to carefully position the embers for a maximum glowing
effect.Figures 27 A - H.
1. Looking at the unit from the valve side, place log #1
diagonally across the textured burner cover onto the pins.
The texture is designed to cradle the underside of the log.
2. Depending on the type of installation, the view of the log
positioning will reverse. Here the lower end of log #2 rests
near the back left corner of the firebox on the locating pin.
The upper end sits on top of log #1, inside the groove on
log #2.
3. Log # 3 is made up of
two pieces, a and b. Piece
#3a is the base of log #3.
The base sits diagonally in
the designated area lo-
cated between logs #1 and
fits tight up against #2.
4. The slot in the under-
side of piece #3b fits over
#3a. Place the end of
piece #3b onto the pin.
5. When pieces #3a and #3b are attached to create log
#3, the upper end of log #3 should rest in the groove, on
top of log # 2.
6.As with log # 1, log #4 is also cradled by the texture of the
burner cover and the pin in the base. Position log #4 so that
the lower end fits onto the pin. The upper end rests against
the moulded locater on the top of log # 1.
7. Like log #3, log #5
also comes in two
pieces. The base
(#5a) slopes out-
wards between logs
#2 and #4.
As with pieces #3a &
b, piece #5b fits over
piece #5a. Place the
end of piece #5b onto
the pin.
8. The upper end of log #5 rests in the groove, on top of
log #4 and creates the final appearance of log set.
#2
B
C#3a
a
Db#3
LOCATING PINS
ALOCATING PINS #1
PILOT
#3
E
#2
#3 #4
#5
H
#1
F
#4
#5
a
b
G
LOG PLACEMENT

16
W415-0320/D/01.06.07
SLOT
TAB
B
L36 LOUVRE INSTALLATION
FIGURE36a-c
HOOD
Attach the hood by pressing the
top flange into the clips along
the top of the louvre opening.
Secure using a screw through
the centre slot.
LOWERLOUVRES
Insert the hinge clips into the
slots located at the bottom left
and right corners of the unit.
To remove the louvres, pull the
back tabs of the clips forward,
while pushing the louvre assem-
bly back. Lift the clip.
UPPERLOUVRES
Insert the louvre tabs into the
slots located at the top left and
right corners of the unit.
ACLIPS
CENTRE
SLOT
FLANGE
CHINGE
CLIP SLOT
A
B
C
For proper ignition, it is very important to that glowingFor proper ignition, it is very important to that glowing
For proper ignition, it is very important to that glowingFor proper ignition, it is very important to that glowing
For proper ignition, it is very important to that glowing
emberember
emberember
embers ars ar
s ars ar
s are in placee in place
e in placee in place
e in place..
..
.
Tear the embers into small pieces
and place on the ported area of the burner. Care should be
taken to shred the embers into thin, small irregular pieces
as only the exposed edges of the fibre hairs will glow. The
ember material will only glow when exposed to direct flame;
however, care should be taken to not block the burner
ports. Blocked burner ports can cause an incorrect flame
pattern, carbon deposits and delayed ignition. PHAZERTM
logs glow when exposed to direct flame.
Randomly place the embers around the bottom brick pan-
els in a realistic manner but not in contact with the flames.
Keep ember dust away from burner ports to avoid plugging
them.
Finedustfound in bottomofbagnot to be used. PHAZERTM
logs, and embers glow when exposed to direct flame. Use
only certified PHAZERTM logs, glowing embers and char-
coal embers available from your Napoleon / Wolf Steel Ltd.
dealer.
GLOWING EMBERS
FIGURE28
Remove the
backing of the
logo supplied and
place on the glass
viewing door, as
indicated.
LOGO PLACEMENT
GLOWING EMBERS
CHARCOAL EMBERS
LOGO
½"
½"
FIGURE30
Ensure that glowing embers sufficiently cover the carry over
ports, highlighted below, to achieve maximum glow.
CARRY OVER PORTS
FIGURE29

17
W415-0320/D/01.06.07
Ensure that the
door is properly
clipped onto the
steel lip to pre-
vent overheat-
ing, glass break-
age and / or dis-
colouration of
the upper trim.
To install the door(s),
hook it over the steel lip
located above the door
opening.
Secure with screws
along the bottom of the
door. Tighten screws
snugly. Do not over-
tighten.
DOOR
STEEL LIP
FIGURE37
FIGURE38
END DOOR INSTALLATION
FIGURE39

18
W415-0320/D/01.06.07
Remove the thermodisc bracket from the top of the firebox.
Remove the thermodisc from the bracket supplied in the
blower kit and install the thermodisc into the fireplace
bracket. Then replace the bracket in the location it was
removed.
Connectthe two ends of theunattached wires by the bracket
to the thermodisc.
Connect the opposite ends of the wires to the red and
black leads of the blower harness.
The wire harness provided in this kit is a universal har-
ness. When installed, ensure that any excess wire is
contained,preventing it from makingcontact with mov-
ing or hot objects.
Drywall dust will penetrate into the blower bearings,
causing irreparable damage. Care must be taken to
prevent drywall dust from coming into contact with the
bloweror its compartment. Any damage resulting from
this condition is not covered by the warranty policy.
Becausethebloweristhermallyactivated,whenturned
on, it will automatically start approximately 10 minutes
afterlightingthefireplace and will run for approximately
30 - 45 minutes after the fireplace has been turned off.
Use of the fan increases the output of heat.
in accordance with local codes. In the absence of local
codes, use the current CSA C22.1 CANADIAN ELECTRICAL CODE
in Canada orthe ANSI/NFPA 70 NATIONAL ELECTRICAL CODE inthe
United States.
Remove the
blower from its
mounting bracket
and attach to the
bracket supplied
with the fireplace.
This bracket is
found secured on
the mounting stud
located at the bot-
tom of the vent
side wall.
Position the vibration reducing pad, centred, onto the
threaded stud, piercing a hole into the pad. The blower
must be able to be positioned entirely onto the pad.
Tilt the blower onto its side and slide it past the controls.
Position the blower under the clip and onto the stud. Se-
cure with a wing nut.
FIGURE43
FIGURE40
FIGURE42
FIGURE44
FIGURE41
The blower bracket contains two holes that allow the blower
to be positioned away from the intended gas supply hole.
THIS BLOWER IS NOT SUITABLE FOR THE 4 SIDED ISLAND INSTALLATION.
THERMODISCBRACKET
THERMODISCWIRESTOBLOWER
OPTIONAL BLOWER INSTALLATION

19
W415-0320/D/01.06.07
not use any phone in your building.
• Immediately call your gas supplier from
a neighbour's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call
the fire department.
WARNING: The gas valve has an interlock
device which will not allow the pilot burner to be lit until the
thermocouple has cooled.Allow approximately 60 seconds
for the thermocouple to cool.
When lighting and re-lighting, the gas knob cannot be
turned from pilot to off unless the knob is depressed
slightly.
LIGHTING INSTRUCTIONS
Purge the gas line with a glass door open. Assure that
a continuous gas flow is at the burner before re-install-
ing the door.
A. This fireplace is equipped with a pilot which must be lit by
hand while following these instructions exactly.
B. Before operating smell all around the fireplace area for
gas and next to the floor because some gas is heavier
than air and will settle on the floor.
C. Use only your hand to turn the gas control knob. Never use
tools. If the knob will not turn by hand, do not try to repair it.
Call a qualified service technician. Force or attempted re-
pair may result in a fire or explosion.
D. Do not use this fireplace if any part has been under water.
Immediately call a qualified service technician to inspect
the fireplace and replace any part of the control system and
any gas control which has been under water.
• Turn off all gas to the fireplace.
• Open windows.
• Do not try to light any appliance.
• Do not touch any electric switch; do
1. Stop! Read the above safety information on this label.
2. Turn off all electric power to the fireplace.
3. Turn the gas knob clockwise to off.
4. Wait five (5) minutes to clear out any gas. If you smell
gas including near the floor. Stop! Follow "B" in the above
safety information on this label. If you don't smell gas go
the next step.
5. Turn gas knob counter-clockwise to pilot.
6. Depress slightly and hold gas knob while lighting the
pilot with the push button ignitor. Keep knob depressed
for one minute, then release. If pilot does not continue to
burn, repeat steps 3through 5.
7. With pilot lit, depress and turn gas knob counter-clock-
wise to on.
8. If equipped with remote on-off switch/thermostat, main
burner may not come on when you turn valve to on.
Remote switch must be in the on position to ignite
burner.
9. Turn on all electric power to the fireplace.
1. Turn off all electric power to the fireplace if service is to be
performed.
2. For a complete shut-down procedure: push in gas control
knob slightly and turn clockwise to off. Do not force.
3. For a temporary shut-down procedure: set thermostat to
lowest setting or remote switch to off. Press and turn the
gas knob clockwise to pilot.
Turn off the gas and electrical power before servicing the
fireplace.
CAUTION: Label all wires prior to disconnection when servic-
ing controls. Wiring errors can cause improper and danger-
ous operation. Verify proper operation after servicing. This fire-
place and its venting system should be inspected before use
and at least annually by a qualified service person. The fire-
place area must be kept clear and free of combustible materi-
als, gasoline or other flammable vapours and liquids. The flow
of combustion and ventilation air must not be obstructed.
1. In order to properly clean the burner and pilot assembly,
remove the logs to expose both assemblies.
2. Keepthecontrolcompartment,logs,burner,airshutteropen-
ing and the area surrounding the logs clean by vacuuming or
brushing, at least once a year.
3. Checkto see that all burner ports are burning. Clean out any
of the ports which may not be burning or are not burning prop-
erly.
4. Check to see that the pilot flame is large enough to engulf
the thermocouple and thermopile and reaches toward the
burner with the third jet.
5. Replace the cleaned logs.
6. Check to see that the main and runner burners ignite com-
pletely on all openings when the gas knob for the burners is
turned on.A5 to 10 second total light-up period is satisfactory. If
ignition takes longer, consult your Napoleon dealer / distributor.
7. Check that the gasketing on the sides, top and bottom
of the door is not broken or missing. Replace if necessary.
OPERATION / MAINTENANCE
FOR YOUR SAFETY READ BEFORE LIGHTING: WHAT TO DO IF YOU SMELL GAS:
TO TURN OFF GAS
MAINTENANCE
GAS KNOB

20
W415-0320/D/01.06.07
Adjust the pilot screw to provide properly sized flame. Turn
in a clockwise direction to reduce the gas flow.
Closing the air shutter will cause a more yellow flame, but
can lead to carboning. Opening the air shutter will cause a
more blue flame, but can cause flame lifting from the burner
ports. The flame may not appear yellow immediately; al-
low 15 to 30 minutes for the final flame colour to be estab-
lished.
AIRSHUTTERADJUSTMENTMUST ONLYBE DONEBYA
QUALIFIEDGASINSTALLER!
FIGURE45
FIGURE46
FIGURE47
MODELBGNV40
NG 1/4"
LP 7/16"
FIGURE48
VENTURI
ADJUSTMENTS
PILOT BURNER ADJUSTMENT
VENTURI ADJUSTMENT
