Napoleon GD33NR User manual

1
W415-0341/K/10.05.07
$10.00

2
W415-0341/K/10.05.07
PG 3-5 INTRODUCTION
Warranty
General Instructions
General Information
Care of Glass & Plated Parts
Dimensions
5-14 VENTING
Venting Lengths
Air Terminal Locations
Venting Application Flow Chart
Venting Specifications
15-24 INSTALLATION
Wall & Ceiling Protection
Using Flexible Vent Components
Using Rigid Vent Components
Restricting Vertical Vents
Mobile Home Installation
Gas Installation
Framing
Nailing Tab Installation
Mantle Clearances & Enclosures
25-27 FINISHING
Log Placement
Door Removal & Installation
Logo Placement
Louvre Removal & Installation
28 OPTIONAL BLOWER
29-30 OPERATION / MAINTENANCE
Operating Instructions
Maintenance
30 ADJUSTMENTS
Pilot Burner Adjustment
Venturi Adjustment
31-33 REPLACEMENTS
Ordering Replacement Parts
Replacement Parts
Accessories
Vent Kits
Terminal Kits
34-35 TROUBLE SHOOTING GUIDE
36 NOTES
NOTE: Changes, other than editorial, are denoted by a vertical line in the margin.
WARNING
• Do not burn wood or other materials in this fireplace.
• Adults and especially children should be alerted to the hazards of high surface temperatures and should stay awa
y
to avoid burns or clothing ignition. Supervise young children when they are in the same room as the fireplace.
• Clothing or other flammable material should not be placed on or near the fireplace.
• Due to high temperatures, the fireplace should be located out of traffic and away from furniture and draperies.
• Ensure you have incorporated adequate safety measure to protect infants/toddlers from touching hot surfaces.
• Even after the fireplace is out, the glass and/or screen will remain hot for an extended period of time.
• Check with your local hearth specialty dealer for safety screens and hearth guards to protect children from ho
t
surfaces. These screens and guards must be fastened to the floor.
• Any safety screen or guard removed for servicing must be replaced prior to operating the fireplace.
• It is imperative that the control compartments, burners and circulating blower and its passageway in the fireplac
e
and venting system are kept clean. The fireplace and its venting system should be inspected before use and at leas
t
annually by a qualified service person. More frequent cleaning may be required due to excessive lint from carpeting
,
bedding material, etc. The fireplace area must be kept clear and free from combustible materials, gasoline an
d
other flammable vapours and liquids.
• Under no circumstances should this fireplace be modified.
• This fireplace must not be connected to a chimney flue pipe serving a separate solid fuel burning appliance.
• Do not use this fireplace if any part has been under water. Immediately call a qualified service technician to inspec
t
the fireplace and to replace any part of the control system and any gas control which has been under water.
• Do not operate the fireplace with the glass door removed, cracked or broken. Replacement of the glass should b
e
done by a licensed or qualified service person.
• Do not strike or slam shut the fireplace glass door.
• This fireplace uses and requires a fast acting thermocouple. Replace only with a fast acting thermocouple supplie
d
by Wolf Steel Ltd.
• Pressure relief doors must be kept closed while the fireplace is operating to prevent exhaust fumes containin
g
carbon monoxide, from entering into the home. Temperatures of the exhaust escaping through these openings ca
n
also cause the surrounding combustible materials to overheat and catch fire.
• Only doors / optional fronts certified with the unit are to be installed on the appliance.
TABLE of CONTENTS
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE

3
W415-0341/K/10.05.07
®
®
®
®
®
®
®
®
®
®
®®
®
®
®
®®
®®
®
®

4
W415-0341/K/10.05.07
Models GD33 and BGD33 have been certified by Intertek
Testing Services under the Warnock Hersey Logo.
Models GD34 and BGD34 have been certified by Under-
writers' Laboratorities of Canada under the UL Logo.
FORYOURSATISFACTION, THIS FIREPLACE HAS BEEN
TEST-FIRED TO ASSURE ITS OPERATION AND QUAL-
ITY!
MODELRATESAND EFFICIENCIES
*For elevations between 2,000 and 4,500 ft. above sea
level, this fire place must be de-rated by 10% using the
certified High Altitude Kit.
This fireplace is approved for bathroom, bedroom and
bed-sitting room installations and is suitable for mobile
home installation.
No external electricity (110 volts or 24 volts) is required
for the gas system operation.
Expansion / contraction noises during heating up and
cooling down cycles are normal and are to be expected.
Provide adequate circulation air. Provide adequate ac-
cessibility clearance for servicing and operating the fire-
place. Never obstruct the front opening of the fireplace.
Purge all gas lines with the glass door of the fireplace
removed. Assure that a continuous gas flow is at the
burner before installing the door.
Under extreme vent configurations, allow several
minutes (5-15) for the flame to stablize after ignition.
Six inches is the minimum bend radius allowed for the 7"
diameter flexible liner.
Objects placed in front of the fireplace must be kept at a
minimum of 48" from the front face of the unit.
Use only accessories designed for and listed with the
model.
Do not use abrasive cleaners to clean plated parts. Buff
lightly with a clean dry cloth. BGD33 / BGD34: The glass is
3/16" tempered glass available from your Napoleon® / Wolf
Steel Ltd. dealer. GD33 / GD34: The glass is 3/16" ceramic
glassavailablefrom your Napoleon® / WolfSteelLtd.dealer.
DO NOT SUBSTITUTE MATERIALS. Clean the glass after
the first 10 hours of operation with a recommended gas
fireplace glass cleaner. Thereafter clean as required. DO
NOT CLEAN GLASS WHEN HOT! If the glass is not kept
clean permanent discolouration and / or blemishes may
result.
THIS GAS FIREPLACE SHOULD BE INSTALLED AND
SERVICED BYA QUALIFIED INSTALLER to conform with
local codes. Installation practices vary from region to re-
gion and it is important to know the specifics that apply to
your area,
for example: in Massachusetts State:
• The fireplace damper must be removed or welded in the open
position prior to installation of a fireplace insert or gas log.
• A carbon monoxide detector is required in all rooms containing
gas fired appliances.
• The appliance off valve must be a “T” handle gas cock.
• The flexible connector must not be longer than 36 inches.
• The appliance is not approved for installation in a bedroom or
bathroom unless the unit is a direct vent sealed combustion
product.
• WARNING: This product must be installed by a licensed plumber
or gas fitter when installed within the commonwealth of
Massachusetts.
In absence of local codes, install to the current National
FuelGas Code, ANSI Z223.1, or thecurrentCAN/CGA B149,
Installation Codes. Mobile home installation must conform
with local codes or in the absence of local codes, install to
the current standard for gas equipped mobile housing CAN/
CSA ZA240 MH Series in Canada or the Manufactured
Home Construction and Safety Standard, Title 24 CFR, Part
3280, or the Fire Safety Criteria for Manufactured Home
Installations, Sites, and Communities StandardANSI/NFPA
501A in the United States.
The fireplace and its individual shutoff valve must be dis-
connected from the gas supply piping system during any
pressure testing of that system at test pressures in excess
of 1/2 psig (3.5 kPa). The fireplace must be isolated from
the gas supply piping system by closing its individual
manual shutoff valve during any pressure testing of the
gas supply piping system at test pressures equal to or
less than 1/2 psig (3.5 kPa).
When the fireplace is installed directly on carpeting, vinyl
tile or other combustible material other than wood flooring,
the fireplace shall be installed on a metal or wood panel
extending the full width and depth.
If the optional blower is installed, the receptacle / junction
box must be electrically connected and grounded in ac-
cordance with local codes. In the absence of local codes,
usethe current CSA C22.1 CANADIAN ELECTRICAL CODE
in Canada or the ANSI/NFPA 70 NATIONAL ELECTRICAL
CODE in the United States.
GENERAL INSTRUCTIONS GENERAL INFORMATION
MODEL *GD33 BGD33 GD34 BGD34
ALTITUDE 0-2000 2000-4500 0-4500 0-4500 0-4500
FT
MAX. INPUT 22,000 20,000 16,400 24,500 19,000
BTU/HR
MAX.OUTPUT 17,380 15,800 11,644 20,090 14,820
BTU/HR
EFFICIENCY 79% 79% 71% 82% 78%
W/ THE FAN ON
TABLE1
CARE OF GLASS, AND PLATED PARTS

5
W415-0341/K/10.05.07
33
1
/ 8 "
29
5
/ 8 "
6
3
/ 4 "
17"
34
1
/ 4 "
17
1
/ 8 "
13"
4" DIA.
7" DIA.
15"
11"
33
17"
13 1/2"
34 1/4"
8 1/2"
4" DIA.
7" DIA.
11"
2 5/8"
5 3/4"GAS
INLET
ELECTRICAL INLET
LEFT SIDE
13"
35"
29 5/8"
20 1/4"
6” STAND OFF
Use only Wolf Steel, Simpson Dura-Vent, Selkirk Direct
Temp or American Metal Amerivent venting components.
Minimum and maximum vent lengths, for both horizontal
and vertical installations, and air terminal locations for
either system are set out in this manual and must be
adhered to. For Simpson Dura-Vent, Selkirk Direct Temp
and American Metal Amerivent, follow the installation
procedure provided with the venting components.
All outer pipe joints of these venting systems must be
sealed using Red RTV High Temperature Sealant.
A starter adaptor must be used with the following vent
systems and may be purchased from the corresponding
supplier:
PART 4"/7" SUPPLIER
Duravent W175-0053 Wolf Steel
Amerivent 4DSC-N2 American Metal
DirectTemp 4DT-AAN Selkirk
For vent systems that provide seals on the inner exhaust
flue, only the outer air intake joints must be sealed using
a red high temperature silicone (RTV). This same
sealant may be used on both the inner exhaust and the
outer intake vent pipe joints of all other approved vent
systems except for the exhaust vent pipe connection to
the fireplace flue collar which must be sealed using the
black high temperature sealant Mill Pac.
VENTING LENGTHS AND AIR TERMINAL LOCATIONS
The maximum allowable vertical vent length is 40 feet.
For optimum flame appearance and fireplace performance,
keep the vent length and number of elbows to a minimum.
The air terminal must remain unobstructed at all times.
Examine the air terminal at least once a year to verify that it
is unobstructed and undamaged.
Horizontal runs may have a 0 inch rise per foot in all
cases using Wolf Steel, Simpson Dura-Vent, Selkirk
Direct Temp, or American Metal Amerivent rigid vent
components and Wolf Steel flexible vent components.
For optimum performance, it is recommended that
horizontal runs have a minimum 1/4 inch rise per foot
when using Simpson Dura-Vent, Selkirk Direct Temp,
American Metal Amerivent or Wolf Steel rigid vent
components and a minimum 1 inch rise per foot when
using Wolf Steel flexible vent comonents. For safe and
proper operation of the fireplace,
follow the venting instructions exactly.
BGD33NR
B/GD34NT
FIGURE1a
FIGURE1b
FIGURE1c
When using Wolf Steel venting components, use only
approved Wolf Steel rigid / flexible components with the
following termination kits:Wall Terminal Kit GD222, or 1/12
to 7/12 Pitch Roof Terminal Kit GD110, 8/12 to 12/12 Roof
Terminal Kit GD111, Flat Roof Terminal Kit GD112 or
Periscope Kit GD201 (for wall penetration below grade).
With flexible venting, in conjunction with the various
terminations, use either the 5 foot Vent Kit GD220 or the 10
foot Vent Kit GD330.
2
5
/ 8 "
5
3
/ 4 "GAS
INLET
ELECTRICAL INLET
LEFT SIDE
VENTING
GD33NR

6
W415-0341/K/10.05.07
VENT INSTALLATIONS
*A clearance to combustibles of 2" at the vent pipe top
must be maintained. The firestop spacer W010-1777sup-
plied with the unit must be used to maintain this clear-
ance.
** The first 5 1/8" of finishing material above the GD34
must be non-combustible. The header must be steel.
For safe and proper operation of the fireplace follow the
venting instruction exactly.
Deviation from the minimum or the maximum vertical
vent length can create difficulty in burner start-up and/
or carboning.
A terminal shall not terminate directly above a sidewalk
or paved driveway which is located betweeen two sin-
gle family dwellings and serves both dwellings. Local
codes or regulations may require different clearances.
In order to avoid the possibility of exposed insulation or
vapour barrier coming in contact with the fireplace
body, it is recommended that the walls of the fireplace
enclosure be “finished” (ie: drywall/sheetrock), as you
would finish any other outside wall of a home. This will
ensure that clearance to combustibles is maintained
within the cavity.
Wolf Steel, Simpson Dura-Vent, Selkirk Direct Temp and
American Metal Amerivent venting systems must not be
combined.
Purge all gas lines with the glass door of the fireplace
open. Assure that a continuous gas flow is at the burner
before closing the door.
Under extreme vent configurations, allow several minutes
(5-15) for the flame to stabilize after ignition.
Six (6") inches is the minimum bend radius allowed for
the 7" diameter flexible liner.
FORSPECIFIC VENTING PARAMETERS,REFERTO
PAGES 9-14.
Minimum clearance to combustible construction
from fireplace and vent surfaces:
BGD33 GD33 BGD34 GD34
SIDE OF THE UNIT 0" 0" 0" 0"
BACK OF THE UNIT 0" 0" 0" 0"
BOTTOM OF THE UNIT 0" 0" 0" 0"
TOP OF THE UNIT 0" 0" 0" 51/8"**
TOP OF THE VENT PIPE 2"* 2"* 2" 2"
SIDES OF THE VENT PIPE 1" 1" 1" 1"
BOTTOM OF THE VENT PIPE 1" 1" 1" 1"
RECESSED DEPTH 13" 13" 13" 13"
TABLE2
ALL MODELS: Vent lengths that pass through unheated
spaces (attics, garages, crawl spaces) should be insu-
lated with the insulation wrapped in a protective sleeve
to minimize condensation.
Provide a means for visually checking the vent connec-
tion to the fireplace after the fireplace is installed.
Do not allow the inside liner to bunch up on horizontal or
vertical runs and elbows. Keep it pulled tight. A 1¼" air
gap between the inner and outer liner all around is re-
quired for safe operation.
Use a firestop, vent pipe shield or attic insulation shield
when penetrating interior walls, floor or ceiling.
TYPICAL VENT INSTALLATIONS
16”
MINIMUM
40 FT MAXIMUM
3 FT MINIMUM
FI G U RE 4a - b
FIGURE3a-b
FIGURES2a- d
24"MAXIMUM
8" MINIMUM (BGD33)
12" MINIMUM (GD33)
201/4"
1" RISE / FT *
* REFER TO "VENTING SECTION"
10” MINIMUM
(BGD34)
24” MINIMUM
(GD34)
53 5/8”
24” MAX
11” MIN
1” RISE/FT*
* REFER TO “VENTING SECTION”
BGD33 and GD33: When
venting straight out the
back, only the rigid vent
can be used. Do not use
flexible vent. For all other
venting configurations, flexible vent is acceptable. When
venting either a GD33 or a BGD33, the horizontal run
must be kept to a maximum of 24 inches. A GD33 must
be kept to a minimum of 12 inches and a BGD33 must be
kept to a minimum of 8 inches. When terminating verti-
cally, the vertical rise is a minimum 36 inches to a maxi-
mum 40 feet from the centre of the fireplace flue outlet.

7
W415-0341/K/10.05.07
MINIMUM AIR TERMINAL LOCATION CLEARANCES
FIGURE5

8
W415-0341/K/10.05.07
Horizontal
run +
vertical
rise to
maximum
of 40 feet
FirFir FirFir
Firee
ee
eplaceplace
placeplace
place VV
VV
Vent Exitent Exit
ent Exitent Exit
ent Exit
BGD33 & GD33BGD33 & GD33 BGD33 & GD33BGD33 & GD33
BGD33 & GD33 BGD34 & GD34BGD34 & GD34
BGD34 & GD34BGD34 & GD34
BGD34 & GD34
HorizontalHorizontal HorizontalHorizontal
Horizontal
TT TT
Terer
erer
erminamina
minamina
minationtion
tiontion
tion VV
VV
Verer
erer
erticaltical
ticaltical
tical TT
TT
Terer
erer
erminamina
minamina
minationtion
tiontion
tion VV
VV
Verer
erer
erticaltical
ticaltical
tical TT
TT
Terer
erer
erminamina
minamina
minationtion
tiontion
tion
Vertical rise
is equal to
or greater
than the
horizontal
run
Vertical
riseis less
than
horizontal
run
Horizontal
run +
vertical
rise to
maximum
of 40 feet
Horizontal
run +
vertical rise
to maxi-
mum of
24.75 feet
3.5 times
the vertica
l
rise equal
to or
greater
than the
horizontal
run
HorizontalHorizontal HorizontalHorizontal
Horizontal
TT TT
Terer
erer
erminamina
minamina
minationtion
tiontion
tion
Vertical rise
is equal to
or greater
than the
horizontal
run
Horizontal
run +
vertical
rise to
maximum
of 40 feet
Vertical rise
is equal to
or greater
than the
horizontal
run
Horizontal
run +
vertical
rise to
maximum
of 40 feet
Vertical rise
is equal to
or greater
than the
horizontal
run
Horizontal
run +
vertical
rise to
maximum
of 40 feet
Vertical
riseis less
than
horizontal
run
3 times the
vertical rise
equal to or
greater
than the
horizontal
run
Vertical rise
is less than
horizontal
run
Horizontal
run +
vertical rise
to maxi-
mum of
24.75 feet
4.2 times
the vertica
l
rise equal
to or
greater
than the
horizontal
run
Vertical
riseis less
than
horizontal
run
Horizontal
run +
vertical
rise to
maximum
of 40 feet
3 times the
vertical rise
equal to or
greater
than the
horizontal
run
VENTING APPLICATION FLOW CHART

9
W415-0341/K/10.05.07
when (H(H
(H(H
(HTT
TT
T))
))
) <<
<<
<(V(V
(V(V
(VTT
TT
T))
))
)
Simple venting configuration (only two 90° elbows)
for the following symbols used in the venting calcula-
tions and examples are:
>- greater than
>- equal to or greater than
<- less than
<- equal to or less than
HT- total of both horizontal vent lengths (HR) and offsets
(HO) in feet
HR- combined horizontal vent lengths in feet
HO- offset factor: .03(total degrees of offset - 90°**
**
*) in
feet
VT- combined vertical vent lengths in feet
feet inches
1° 0.03 0.5
15° 0.45 6.0
30° 0.9 11.0
45° 1.35 16.0
90°**
**
*2.7 32.0
**
**
* the first 90° offset has a zero value and is shown in
the formula as -90°
DEFINITIONS ELBOW VENT LENGTH VALUES
Example 1:Example 1:
Example 1:Example 1:
Example 1:
See graph to determine the required vertical rise VTfor the
required horizontal run HT
For vent configurations requiring more than two 90° el-
bows the following formulas apply:
Formula 1: H
T
< V
T
Formula 2: H
T
+ V
T
< 40 feet
REQUIRED
VERTICAL
RISE IN
FEET
VT
HORIZONTAL VENT RUN PLUS OFFSETS IN FEET HH
HH
HTT
TT
T
V
1
=9ft
V
2
=6ft
VT= V
1
+ V
2
= 9 + 6 = 15 ft
H
1
=3ft
H
2
=2ft
H
3
=1.5ft
HR=H1+H2 +H3= 3 + 2 + 1.5 = 6.5 ft
HO=.03(four 90° elbows - 90°)
=.03(90 + 90 + 90 + 90 - 90) = 8.1 ft
H
T
=H
R
+ H
O
=6.5 +8.1 =14.6 ft
H
T
+ V
T
=14.6+15=29.6ft
Formula1: H
T
< V
T
14.6 < 15
Formula2: H
T
+ V
T
< 40 feet
29.6 < 40
Sincebothformulas aremet, thisvent configurationis ac-
ceptable.
FIGURE7
FIGURE6 H1
H2
V1
V2
H3
90°
90°
90°
90°
The shaded area within the lines represents acceptable
values for HTand VT .
BGD33 & GD33 HORIZONTAL TERMINATION

10
W415-0341/K/10.05.07
when (H(H
(H(H
(HTT
TT
T) > (V) > (V
) > (V) > (V
) > (VTT
TT
T))
))
)
Simple venting configuration (only two 90° elbows)
Example 2:Example 2:
Example 2:Example 2:
Example 2:
V
1
=4ft
V
2
=1.5ft
VT= V
1
+ V
2
= 4 + 1.5 = 5.5 ft
H
1
=2ft
H
2
=1ft
H
3
=1ft
H
4
=1.5ft
HR=H1+ H2 + H3+ H4 = 2 + 1 + 1 + 1.5 = 5.5 ft
HO=.03(four 90° elbows + one 45° elbow - 90°)
=.03(90 + 90 + 90 + 90 + 45 - 90) = 9.45 ft
H
T
=H
R
+ H
O
=5.5 + 9.45 = 14.95 ft
H
T
+ V
T
=14.95+5.5=20.45ft
Formula1: H
T
< 3.5V
T
3.5VT= 3.5x 5.5 = 19.25 ft
14.95<19.25
Formula2: H
T
+ V
T
< 24.75 feet
20.45<24.75
Sincebothformulas aremet, thisventconfiguration isac-
ceptable.
FIGURE9
For vent configurations requiring more than two 90° elbows
the following formulas apply:
Formula 1: H
T
< 3.5V
T
Formula 2: H
T
+ V
T
< 24.75 feet
REQUIRED
VERTICAL
RISE IN
INCHES
HORIZONTAL VENT RUN PLUS OFFSETS IN FEET
HH
HH
H
TT
TT
T
See graph to determine the required vertical rise VTfor the
required horizontal run HT
FIGURE8
H1
H2
H3
H4
V1
V2
90°
90°
45°
90°
90°
V
T
The shaded area within the lines represents acceptable
values for HTand VT .
BGD33 & GD33 HORIZONTAL TERMINATION

11
W415-0341/K/10.05.07
when (HT) < (VT)
Simple venting configuration (only one 90° elbow)
VERTICAL
RISE IN
FEET
V
T
FIGURE10
See graph to determine the required vertical rise VTfor the
required horizontal run HT.
For vent configurations requiring more than one 90° el-
bow, the following formulas apply:
Formula 1: H
T
< V
T
Formula 2: H
T
+ V
T
< 40 feet
90°
90°
Example 3:
V
1
=3ft
V
2
=8ft
VT= V
1
+ V
2
= 3 + 8 = 11 ft
H
1
= 2.5ft
H
2
=2ft
H
R
=H
1
+H
2
=2.5+2=4.5ft
H
O
=. 03(three 90° elbows - 90°) = .03(270° - 90°) = 5.4 ft
H
T
=H
R
+H
O
=4.5+5.4=9.9ft
H
T
+ V
T
= 9.9+ 11=20.9 ft
Formula1: H
T
< V
T
9.9<11
Formula2: H
T
+ V
T
< 40 feet
20.9<40
Sincebothformulas aremet, thisvent configurationis ac-
ceptable.
FIGURE11
90°
H1
V2
H2
V1
HORIZONTAL VENT RUN PLUS OFFSET IN FEET HH
HH
HTT
TT
T
The shaded area within the lines represents acceptable
values for HTand VT .
BGD34 & GD34 HORIZONTAL TERMINATION

12
W415-0341/K/10.05.07
For vent configurations requiring more than one 90° elbow
the following formulas apply:
Formula 1: HT< 4.2 VT
Formula 2: HT+ VT< 24.75 feet
Example 4:
V1=VT= 6 ft
H1=3ft
H2=5ft
HR=H1+ H2 = 3 + 5 = 8 ft
HO= .03(two 90° elbows - 90°) = .03(180° - 90°) = 2.7 ft
HT=HR+ HO = 8 + 2.7 = 10.7 ft
H
T
+ V
T
= 10.7 + 6 =16.7
Formula1: HT < 4.2 VT
4.2 VT = 4.2 x 6 = 25.2 ft
10.7 < 25.2
Formula2: HT + VT< 24.75 feet
16.7< 24.75
Since both formulas are met, this vent configuration is ac-
ceptable.
when (HT)> (VT)
Simple venting configura-
tion
(only one 90° elbow)
See graph to determine the re-
quired vertical rise VTfor the re-
quired horizontal run HT.
Example 5:
V
1
=4ft
V
2
= 1.5ft
VT=V1 + V2 = 4 + 1.5 = 5.5 ft
H
1
=2ft
H
2
=1ft
H
3
=1ft
H
4
= 1.5ft
HR=H1+ H2 + H3+ H4 = 2 + 1 + 1 + 1. 5 = 5.5 ft
HO= .03(four 90° elbows - 90°) = .03(360° - 90°) = 8.1 ft
H
T
=H
R
+ H
O
=5.5 +8.1 =13.6ft
H
T
+ V
T
=13.6+5.5= 19.1ft
Formula 1:H
T
< 4.2 V
T
4.2 VT = 4.2 x 5.5 = 23.1 ft
13.6<23.1
Formula 2:H
T
+ V
T
< 24.75 feet
19.1<24.75
Sincebothformulas aremet, thisventconfiguration isac-
ceptable.
FIGURE12
REQUIRED
VERTICAL
RISE IN
INCHES
VT
HORIZONTAL VENT RUN PLUS OFFSET IN FEET HH
HH
HTT
TT
T
The shaded area within the lines represents acceptable
values for HTand VT .
BGD34 & GD34 HORIZONTAL TERMINATION
FIGURE14
H2
H4
V2
90°
H3
H1
V1
90°
H
2
H1
V190°
FIGURE13

13
W415-0341/K/10.05.07
REQUIRED
VERTICAL RISE
IN FEET
V
T
HORIZONTAL VENT RUN PLUS OFFSET IN FEET
HH
HH
H
TT
TT
T
The shaded area within the lines represents acceptable
values for HTand VT .
Example 6:
when (HT) < (VT)
Simple venting configurations
V
1
=5ft
V
2
=10ft
VT= V
1
+ V
2
= 5 + 10 = 15 ft
H
1
=3ft
H
2
=2.5ft
HR=H1+ H2= 3 + 2.5 = 5.5 ft
HO=.03(three 90° elbows - 90°)
=.03(90 + 90 + 90 - 90) = 5.4 ft
H
T
=H
R
+ H
O
=5.5 +5.4 =10.9ft
H
T
+ V
T
=10.9+15 =25.9ft
Formula1: H
T
< V
T
10.9<15
Formula2: H
T
+ V
T
< 40 feet
25.9<40
Sincebothformulas aremet, thisvent configurationis ac-
ceptable.
FIGURE15
FIGURE16
For vent configurations requiring more than zero 90° elbow
(top exit) or one 90° elbow (rear exit), the following formu-
las apply:
Formula 1: H
T
< V
T
Formula 2: H
T
+ V
T
< 40 feet
See graph to determine the required vertical rise VTfor the
required horizontal run HT.
90°
90°
90°
H1
H2
V1
V2
VERTICAL TERMINATION
BGD34 / GD34 BGD33 / GD33

14
W415-0341/K/10.05.07
MAXIMUM
VERTICAL
RISE IN
FEET
V
T
HORIZONTAL VENT RUN PLUS OFFSET IN FEET
HH
HH
H
TT
TT
T
The shaded area within the lines represents acceptable
values for HTand VT .
For vent configurations requiring more than two 90° elbow
(top exit) or one 90° elbow (rear exit), the following formu-
las apply:
Formula 1: H
T
< 3V
T
Formula 2: H
T
+ V
T
< 40 feet
Example 7:
See graph to determine the required vertical rise VTfor the
required horizontal run HT.
V
1
=2ft
V
2
=1ft
V
3
=1.5ft
VT= V
1
+ V
2
+ V
3
= 2 + 1 + 1.5 = 4.5 ft
H
1
=6ft
H
2
=2ft
HR=H1+ H2= 6 + 2 = 8 ft
HO=.03(four 90° elbows - 90°)
=.03(90 + 90 + 90 + 90 - 90) = 8.1 ft
H
T
=H
R
+ H
O
=8 +8.1= 16.1ft
H
T
+ V
T
= 16.1 + 4.5 =20.6ft
Formula1: H
T
< 3V
T
3VT= 3 x 4.5 = 13.5 ft
16.1>13.5
Sincethisformulaisnotmet,thisventconfigurationisunac-
ceptable.
Formula2: H
T
+ V
T
< 40 feet
20.6<40
Sinceonlyformula2ismet,thisventconfigurationisunac-
ceptableandanewfireplace locationorventconfiguration
willneed tobe establishedto satisfyboth formulas.
Example 8:
V
1
=1.5ft
V
2
=5ft
VT= V
1
+ V
2
= 1.5 + 5 = 6.5 ft
H
1
=1ft
H
2
=1ft
H
3
=10.75ft
HR=H1+ H2+ H3= 1 + 1 + 10.75 = 12.75 ft
HO=.03(three 90° elbows + one 45° elbow - 90°)
=.03(90 + 90 + 90 + 45 - 90) = 6.75 ft
H
T
=H
R
+H
O
=12.75 +6.75 =19.5 ft
H
T
+ V
T
=19.5+6.5 =26ft
Formula1: H
T
< 3V
T
3VT = 3x 6.5 = 19.5 ft
19.5=19.5
Formula2: H
T
+ V
T
< 40 feet
26<40
Sincebothformulas aremet, thisvent configurationis ac-
ceptable.
when (HT) > (VT)
FIGURE17
Simple venting configurations
VERTICAL TERMINATION
FIGURE18
H1
H2
V3
V1
90° 90°
90°
V2
90°
FIGURE19
H2
H3
V1
V2
90°
45°
90°
H1
90°
BGD34 / GD34
BGD33 / GD33

15
W415-0341/K/10.05.07
For optimum performance, it is recommende
d
that horizontal runs have a minimum ¼ inch rise
p
er foot when using Simpson DurSimpson Dur
Simpson DurSimpson Dur
Simpson Dura-Va-V
a-Va-V
a-Vent,ent,
ent,ent,
ent,
SelkirSelkir
SelkirSelkir
Selkirk Dirk Dir
k Dirk Dir
k Directect
ectect
ect TT
TT
Tempemp
empemp
emp,,
,,
, American Meta
l
American Meta
l
American Meta
l
American Meta
l
American Meta
l
Amerivent, or
A
merivent, or
Amerivent, or
A
merivent, or
A
merivent, or Wolf Steel rigid vent components
and a minimum 1 inch rise per foot when usin
g
Wolf Steel flexible vent components
For safe and proper operation of the fireplace,
follow the venting instructions exactly.
N
OTE:
H
ORIZONTAL TERMINATION - A clearance
to
c
ombustibles of 1" at the bottom and sides of the ve
nt
a
nd 2" at the top must be maintained when penetratin
g
c
ombustible walls. The firestop spacer supplied wi
th
t
he unit must be used to maintain the clearance.
V
ERTICAL TERMINATION - Only a clearance
to
c
ombustibles of 1" all around the vent pipe is require
d.
WALL AND CEILING PROTECTION
INSTALLATION
This application occurs when venting through an exterior
w
all. Having determined the air terminal location, cut
a
nd frame a hole in the exterior wall 9 7/8 inches wide b
y
1
1 3/8 inches high to accommodate the firestop sleeve
a
ssembly.
N
OTE: THE FIRESTOP SLEEVE ASSEMBLY MUST BE
I
NSTALLED WITH THE 2" CLEARANCE TO THE TOP.
1
. Insert the firestop sleeve assembly into the wall, mar
k
t
he wall depth and trim the vent sleeve to suit. The
s
crews that secure the vent sleeve may need to be
r
epositioned to ensure a rigid assembly is maintained.
2
.Apply a bead of caulking (not supplied) to the insid
e
s
urface of the firestop flange and secure the assembly
to
t
he wall. (Ensure that the rectangular shaped assembly
is
i
nstalled to maintain 2" from the top of the vent).
3
. Once the vent pipe liner is installed in it's final positio
n,
a
pply high temperature sealant (not supplied) betwee
n
t
he pipe/liner, and the firestop.
N
OTE: DO NOT FILL THE CAVITY BETWEEN THE PIP
E/
L
INER AND THE VENT SLEEVE WITH ANY TYPE O
F
M
ATERIAL.
FIGURE21
GD33/BGD33 HORIZONTAL INSTALLATION
If flexible venting is to be used remove the rigid firestop
spacer. The remaining hole is sized for flexible venting.
FIRESTOP SLEEVE ASSEMBLY
1. Assemble the two halves of the vent sleeve by aligning
t
he holes that come together to make a rectangular shap
e
(
lip to the outside). Secure using 6 of the screws supplie
d
i
n the manual baggie.
N
OTE: SCREWS NOT REQUIRED IN TWO BLIND HOLE
S.
S
ee Figure 20a.
2
. Fit the firestop
s
pacer into one end
o
f the vent sleeve
a
nd secure through
t
he aligned holes
o
n the top, bottom,
a
nd sides with the
r
emaining 5 screws
s
upplied. See
F
igure 20b.FIGURE20a
FIGURE20b

16
W415-0341/K/10.05.07
This application occurs
when venting through a
roof. Installation kits for
various roof pitches are
available from your
Napoleon dealer. See
Accessories to order
the specific kit required.
1. Determine the air terminal location, cut and frame 9½
inch openings in the ceiling and the roof to provide the
minimum clearance between the fireplace pipe / liner and
any combustible material. Try to center the exhaust pipe
location midway between two joists to prevent having to
cut them. Use a plumb bob to line up the center of the
openings.
Do not fill this space with any type of material.
A vent pipe shield will
prevent any materials
such as insulation,
from filling up the 1" air
space around the pipe.
Nail headers between
the joist for extra sup-
port.
2. Apply a bead of
caulking (not supplied)
to the framework or to the Wolf Steel vent pipe shield plate
or equivalent (in the case of a finished ceiling), and secure
over the opening in the ceiling. A firestop must be placed
on the bottom of each framed opening in a roof or ceiling
that the venting system passes through. Apply a bead of
caulking all around and place a firestop spacer over the
vent shield to restrict cold air from being drawn into the
room or around the fireplace. Ensure that both spacer and
shield maintain the required clearance to combustibles.
Once the vent pipe / liner is installed in its final position,
apply sealant between the pipe / liner and the firestop
spacer.
3. In the attic, after the pipe / liner has been installed,
slide the vent pipe collar down to cover up the open end of
the shield and tighten. This will prevent any materials, such
as insulation, from filling up the 1" air space around the
pipe.
FIGURE25
VERTICAL INSTALLATION
FIGURE23
FIGURE24
GD34/BGD34 HORIZONTAL INSTALLATION
This application occurs when venting through an exterior
wall.Having determined the correct height for the air terminal
location,cut and frame a hole in the exteriorwall 9 7/8 inches
wide by 11 3/8 inches high to accomodate the firestop
assembly. Dry fit the firestop assembly before proceeding
to ensure the brackets on the rear surface fit to the inside
surface of the horizontal framing.
As an alternative to framing, the vent pipe/liner can be
enclosed in the wall using Napoleon® vent sleeve VS47KT.
NOTE: THE FIRESTOPASSEMBLY MUST BE INSTALLED
WITH THE VENT SHIELD TO THE TOP.
1. Apply a bead of caulking (not supplied) around the corner
edge of the inside surface of the firestop assembly, fit the
firestop assembly to the hole and secure using the 4 screws
(W415-0026) supplied in your manual baggie.
2. Once the vent pipe / liner is installed in its final position,
apply high temperature sealant (not supplied) between the
pipe/liner and the firestop.
NOTE: DO NOT FILL THE CAVITY BETWEEN THE PIPE/
LINER AND THE FRAMING WITH ANY TYPE OF
MATERIAL.
11
3/8
”
9
7/8
”
DETERMINE
THE
CORRECT
HEIGHT
A
ULKING
FIRESTOP
A
SSEMBLY
VENT
SHIELD
FINISHING
MATERIAL
FIGURE22

17
W415-0341/K/10.05.07
FIGURE28
FIGURE26
1. Cut or frame a hole in an exterior wall with a minimum
round or square opening listed in TABLE 2 on page 6.
Secure the firestop spacer over the opening to the interior
wall.
2. Stretch the 4" diameter aluminum flexible liner to the
required length taking into account the additional length
needed for the finished wall surface. Slip the liner a mini-
mum of 2" over the inner sleeve of the air terminal and
secure with 3 #8 screws. Apply a heavy bead of the high
temperature sealant.
3. Using the 7" diameter flexible aluminum liner, slide
over the outer combustion air sleeve of the air terminal and
secure with 3 #8 screws. Seal as before.
The air terminal mounting plate may be recessed into
the exterior wall or siding by 1½", the depth of the return
flange.
4. Insert the liners through the firestop maintaining the
required clearance to combustibles. Holding the air termi-
nal (lettering in an upright, readable position), secure to
the exterior wall and make weather tight by sealing with
caulking (not supplied).
5. Apply a heavy bead of the high temperature sealant,
supplied with the unit, to the inside of the 4" liner approxi-
mately 1" from the end. Slip the liner a minimum of 2" over
the fireplace vent collar and secure with 3 #8 screws.
6. Using the 7" diameter flexible aluminium liner, apply
sealant, slide a minimum of 2" over the fireplace combus-
tion air collar and secure with 3 #8 screws.
FIGURE27
USING FLEXIBLE VENT COMPONENTS
HORIZONTAL AIR TERMINAL INSTALLATION
VERTICAL AIR TERMINAL INSTALLATION
GD33 and BGD33: When venting straight out the back, only
the rigid vent can be used. Do not use flexible vent. For all
other venting configurations, flexible vent is acceptable.
For optimum performance, it is recommended that
horizontal runs have a minimum ¼ inch rise per foot
when using Simpson Dura-Vent, Selkirk Direct Temp,
American Metal Amerivent, or Wolf Steel rigid vent com-
ponents and a minimum 1 inch rise per foot when using
Wolf Steel flexible vent components.
For safe and proper operation of the fireplace, follow the
venting instructions exactly.
1. Fasten the roof
support to the roof
using the screws
provided. The roof
support is
optional. In this
case the venting
is to be
adequately
supported using
either an alternate
method suitable
to the authority
having jurisdiction or the optional roof support. (Fig. 28)
2. Stretch the inner aluminum
flexliner tothe required length.
Slip the liner a minimum of
2” over the inner sleeve of the
air terminal connector and
secure with 3 #8 screws.
Seal using a heavy bead of
the high temperature
sealant. (Fig. 29)
3. Repeat using the outer
aluminum flex liner. (Fig. 29)
4. Thread the air terminal
connector / liner assembly
downthroughtheroof. The air
terminal must be located
vertically and plumb. Attach
the air terminal connector to the roof support, ensuring that
the top of the air terminal is 16” above the highest point that
it penetrates the roof. (Fig. 30)
AIR
TERMINAL
CONNECTOR
INNER FLEX
LINER
OUTER FLEX
LINER
INNER
SLEEVE
HIGH
TEMPERATURE
SEALANT
FIGURE29
Use only approved aluminum flexible liner kits marked:
"Wolf Steel Approved Venting" as
identified by the stamp only on the 7”
outer liner.
For safe and proper operation of the fireplace, follow
theventinginstructionsexactly.

18
W415-0341/K/10.05.07
1. Install the 4 inch diameter aluminium flexible liner to
the fireplace. Secure with 3 screws and flat washers. Seal
the joint and screw holes using the high temperature seal-
ant provided.
2. Install the 7 inch diameter aluminium flexible liner to
the fireplace. Attach and seal the joints.
FIREPLACE VENT CONNECTION
5. Remove nails from the shingles, above and to the sides
of the chimney. Place the flashing over the air terminal
connector leaving a min. 3/4” of the air terminal connector
showing above the top of the flashing. Slide the flashing
underneath the sides and upper edge of the shingles.
Ensure that the air terminal connector is properly centred
within the flashing, giving a 3/4” margin all around. Fasten
to the roof. Do not nail through the lower portion of the
flashing. Make weather-tight by sealing with caulking.
Where possible, cover the sides and top edges of the
flashingwith roofing material. (Fig. 30)
6. Aligning the seams of the terminal and air terminal
connector, place the terminal over the air terminal
connector making sure the liner goes into the hole in
the terminal. Secure with the three screws provided.
(Fig.30)
7.Applyaheavybead of weatherproofcaulking 2inches
abovetheflashing. Note: Maintainaminimum 2”space
between the air inlet base and the storm collar. Install
thestorm collar aroundthe air terminaland slide down
to the caulking. Tighten to ensure that a weather-tight
sealbetweenthe airterminaland thecollar is achieved.
(Fig.30)
Spacers are attached to the inner flex liner at
predetermined intervals to maintain a 1-1/4” air gap to
the outer flex liner. These spacers must not be removed.
STORM COLLAR
FLASHING
CAULKING
WEATHER
SEALANT
2”
AIR INLET
BASE
FIGURE30
USING RIGID VENT
COMPONENTS
For optimum performance, it is recommended that
horizontal runs have a minimum ¼ inch rise per foot
when using Simpson Dura-Vent, Selkirk Direct Temp,
American Metal Amerivent, or Wolf Steel rigid vent
components.
For safe and proper operation of the fireplace, follow
the venting instructions exactly.
The vent system must be supported approximately every 3
feet for both vertical and horizontal runs. Use Wolf Steel
vent spacers W615-0033 every 3 feet on either side of
each elbow to maintain the minimum 1¼" clearance
between the outer and inner vent pipes. Use Napoleon®
support ring assembly W010-0370 or equivalent
noncombustible strapping to maintain the minimum
clearance to combustibles for both vertical and horizontal
runs.
HORIZONTAL AIR TERMINAL INSTALLATION
FIGURE31
1. Movethe fireplace into position. Measure the vent length
required between terminal and fireplace taking into account
the additional length needed for the finished wall surface
and any 1¼" overlaps between venting components.
2. Apply high temperature sealant to the outer edge of the
4" inner collar of the fireplace. Attach the first vent compo-
nent and secure using 3 self tapping screws. Repeat using
7" piping.
3. Holding the air terminal (lettering in an upright, read-
able position), insert into both vent pipes with a twisting
motion to ensure that both the terminal sleeves engage
into the vent pipes and the sealant. Secure the terminal to
the exterior wall and make weather tight by sealing with
caulking (not supplied).
The air terminal mounting plate may be recessed into the
exterior wall or siding by 1½", the depth of the return
flange.

19
W415-0341/K/10.05.07
Vertical installations may dis-
playa very active flame. If this
appearance is not desirable,
remove the baffle plate from
therear wall of the firebox, ex-
posing the flue gas outlet
opening. Reverse the
restrictor plate, superimpos-
ing the flue outlet hole with
the smaller restrictor plate
opening. Replace the baffle
plate. This reduces the veloc-
ityof the exhaust gases, slow-
ing down the flame pattern
and creating a more tradi-
tional flame appearance.
FIGURES34a-b
RESTRICTING VERTICAL VENTS (GD33 ONLY)
Vertical terminations running longer than 15 feet may dis-
play a very active flame. If this appearance is not desirable,
the vent exit must be restricted using the restrictor plate.
This reduces the velocity of the exhaust gases, slowing
down the flame pattern and creating a more traditional
appearance.
RESTRICTING VERTICAL VENTS (BGD34 & GD34)
Note: Some vent configurations may cause excessive air
flow around the pilot flame and contribute to pilot outage.
In this case the restrictor plate can be installed over the
flue opening to stabilize the pilot flame.
If the attic space is tight, we recommend threading
the Wolf Steel vent pipe collar or equivalent loosely onto
the air terminal assembly as it is passed through the
attic. The air terminal must be located vertically and plumb.
7.Remove nails from the shingles, above and to the
sides of the chimney. Place the flashing over the air termi-
nal and slide it underneath the sides and upper edge of
the shingles. Ensure that the air terminal is properly
centered within the flashing, giving a 3/4" margin all around.
Fasten to the roof. Do NOT nail through the lower portion of
the flashing. Make weather-tight by sealing with caulking.
Where possible, cover the sides and top edges of the flash-
ing with roofing material.
8. Apply a heavy bead of waterproof caulking 2 inches
above the flashing. Slide the storm collar around the air
terminal and down to the caulking. Tighten to ensure that a
weather-tight seal between the air terminal and the collar
is achieved.Attach the other storm collar centered between
the air intake and air exhaust slots onto the air terminal.
Tighten securely. Attach the rain cap.
9. Continue adding rigid venting sections, sealing and
securing as above. Attach a 4" collapsed telescopic pipe to
the last section of rigid piping. Secure with screws and
seal. Repeat using a 7" telescopic pipe.
10. Run a bead of high temperature sealant around the
outside of the 4" elbow. Pull the adjustable pipe a mini-
mum 2" onto the elbow. Secure with 3 screws. Repeat with
the 7" telescopic pipe.
11. In the attic, slide the vent pipe collar down to cover up
the open end of the shield and tighten. This will prevent
any materials, such as insulation, from filling up the 1" air
space around the pipe.
1. Follow the instructions for "Horizontal Air Terminal In-
stallations".
2. Continue adding components alternating inner and
outer venting. Ensure that all 4" venting and elbows have
sufficient vent spacers attached and each component is
sealed and securely fastened to the one prior.Attach the 4"
telescopic sleeve to the vent run. Repeat using a 7" tel-
escopic sleeve. Seal and secure as before. To facilitate
completion, attach 4" and 7" couplers to the air terminal.
3.Install the air terminal. See item 3 , Horizontal Air Ter-
minal Installation. Extend the 4" telescopic sleeve; apply
sealant and connect to the air terminal assembly. Fasten
with self tapping screws. Repeat using the 7" telescopic
sleeve.
1. Attach 4" and 7" elbows to the fireplace. Apply high
temperature sealant and secure the joints with 3 screws.
2. Move the fireplace
into position.
3. Fasten the roof
support to the roof using
the screws provided.The
roof support is optional.
The venting is to be ad-
equately supported
using either an alternate
method suitable to the
authority having jurisdic-
tion or the optional roof
support.
4. Apply high
temperature sealant to
the outer edge of the
inner sleeve of the air ter-
minal. Slip a 4" diameter
coupler a minimum of 2"
over the sleeve and
secure using 3 screws.
5.Apply high temperature sealant to the outer edge of the
of the outside sleeve of the air terminal. Slip a 7" diameter
coupler over the sleeve and secure as before. Trim the 7"
coupler even with the 4" coupler end.
6.Thread the air terminal pipe assembly down through
the roof support and attach, ensuring that a minimum 16"
of air terminal will penetrate the roof when fastened.
VERTICAL VENTING INSTALLATION
A 45° corner installation
can have 0 inch rise
between the fireplace
combustion air collar
and the air terminal. In
this case, vent lengths
must be kept to a maxi-
mum of 24". For longer
vent lengths, a minimum
vertical rise of 24" is
required.
EXTENDED HORIZONTAL AND CORNER
AIR TERMINAL INSTALLATION
FIGURE32
FIGURE33

20
W415-0341/K/10.05.07
GAS INSTALLATION
MOBILE HOME INSTALLATION
FIGURES35a-b
RESTRICTING VERTICAL VENTS (BGD33 ONLY)
Warning:
This restrictor (located
in the lower valve
compartment) must not
be installed on any vent
configuration that has a
horizontal termination
or vertical vent with
vertical termination less than 10'.
Vertical installations over 10' may display a very active
flame. If this appearance is not desirable, install the
restrictor plate. This reduces the velocity of the exhaust
gases, slowing down the flame pattern and creating a
more traditional flame appearance.
This appliance may be installed as an OEM (Original
Equipment Manufacturer) installation in a manufactured
home or mobile home and must be installed in accordance
with the manufacturer’s instructions and the Manufactured
Home Construction and Safety Standard, Title 24 CFR,
Part3280, in the United Statesor the Mobile Home Standard,
CAN/CSA Z240 MH Series, in Canada.
This Mobile/Manufactured Home Listed appliance comes
factory equipped with a means to secure the unit.
The fireplace is equipped with two 1/4” diameter holes
located in the front left and right corners of the base. For
mobile home installations, the fireplace must be fastened
in place. Use #10 hex head screws, inserted through the
holes in the base to secure.
Remove the screws securing the restrictor plate and ro-
tate the plate 180°. Secure using the same two screws
through the existing holes.
Proceed once the vent installation is complete.
1. Route a 3/8" N.P.T. black iron gas line, ½" type-L cop-
per tubing or equivalent to the fireplace.
2. For ease of accessibility, an optional remote wall
switch or millivolt thermostat may be installed in a
convenient location. Route 2-strand (solid core) millivolt
wire through the electrical hole located at the bottom left
side of the unit. The recommended maximum lead length
depends on wire size:
Attach the two leads to terminals 1 and 3 located on the
gas valve.
Do not connect either the wall switch, thermostat or
gas valve to electricity (110 volts).
3. Install rigid black pipe, ½" type-L copper tubing or, if
local codes permit, a 3/8" flex connector and shutoff valve
tothegasline andthefireplacegasvalve.Sealandtighten
securely. An adapter fitting is required between the gas
valve and the copper tubing or flex connector.
DONOTKINK FLEXIBLE CONNECTOR.
4. Check for gas leaks by brushing on a soap and water
solution.
WIRESIZE MAX.LENGTH
14 gauge 100 feet
16 gauge 60 feet
18 gauge 40 feet
TABLE3
FIGURE37
FIGURE38
Do not use open flame.
Purge all gas lines with the glass door of the fireplace
removed. Assure that a continuous gas flow is at the
burner before re-installing the door.
Always turn off the pilot and the fuel supply at the source,
prior to moving the mobile home.
After moving the mobile home and prior to lighting the
fireplace, ensure that the logs are positioned correctly.
This appliance may be installed in an aftermarket
permanently located, manufactured (mobile) home, where
not prohibited by local codes.
This appliance is only to be used with the type of gas
indicated on the rating plate. This appliance is not
convertible for use with other gases, unless a certified kit
is used.
Conversion Kits
The mobile home appliance is field convertible between
Natural Gas (NG) and Propane (LP). To convert from one
gas to another consult your Napoleon®dealer/distributor.
FIGURE36
