Napoleon NZ6000-1 User manual

EN
W415-1501 / 05.15.15
FR
PG
53
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
NEVER LEAVE CHILDREN OR OTHER AT RISK INDIVIDUALS ALONE WITH THE APPLIANCE.
INSTALLATION AND
OPERATING INSTRUCTIONS
1.26C
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada /
103 Miller Drive, Crittenden, Kentucky, USA, 41030
Phone [phone] • Fax [phone] • www.napoleonfireplaces.com • [email protected]
SAFETY INFORMATION
If the information in these instructions are not followed
exactly, a fire or explosion may result causing property
damage, personal injury or death.
Please read entire manual before you install and use your
heater.
This heater has not been tested with an unvented gas log set.
To reduce risk of fire or injury, do not install an unvented gas
log set into the heater.
- This heater can be very hot when burning.
- Combustible materials such as firewood, wet clothing, etc.
placed too close can catch fire.
- Children and pets must be kept from touching the heater when
it is hot.
- The chimney must be sound and free of cracks. Before
installing this unit, contact the local building or fire authority
and follow their guidelines.
- Operate only with the doors tightly closed.
- Burn wood behind the log retainer directly on the firebricks.
- Do not use an elevated grate or otherwise raise the fire.
- This heater is designed to burn natural wood only. Higher
efficiencies and lower emissions generally result when burning
air dried seasoned hardwoods, as compared to softwoods or to
green or freshly cut hardwoods.
- Do not start a fire with chemicals or fluids such as gasoline,
engine oil, etc.
- Do not burn treated wood, coal, charcoal, coloured paper,
cardboard, solvents or garbage.
- Do not let the heater become hot enough for any part to glow
red.
$10.00
!WARNING
HOT GLASS WILL CAUSE
BURNS.
DO NOT TOUCH GLASS UNTIL
COOLED.
NEVER ALLOW CHILDREN TO
TOUCH GLASS.
!
WARNING
NZ6000-1
SOLID FUEL BURNING
ZERO CLEARANCE
APPLIANCE
THIS APPLIANCE HAS BEEN TESTEDAND LISTED BY INTERTEK TESTING SERVICES LTD. AS PER THE STANDARDS: ULC S610, UL 127 FOR FACTORY BUILT
FIREPLACES.

W415-1501 / 05.15.15
2
EN
TABLE OF CONTENTS
NOTE: Changes, other than editorial, are denoted by a vertical line in the margin.
1.0 INSTALLATION OVERVIEW 3
2.0 INTRODUCTION 4
2.1 DIMENSIONS 5
2.2 GENERAL INSTRUCTIONS 5
2.3 GENERAL INFORMATION 7
2.3.1 FEATURES 7
2.3.2 HEATING SPECIFICATIONS 7
2.3.3 ELECTRICAL SPECIFICATIONS 7
2.3.4 PACKING LIST 7
2.3.5 EPA COMPLIANCE 7
2.4 RATING PLATE INFORMATION 8
2.5 HI-EFFICIENCY HEATING 9
3.0 INSTALLATION PLANNING 9
3.1 LOCATION AND CLEARANCES 10
3.1.1 VENTILATION OPENINGS 10
3.2 OUTSIDE COMBUSTION AIR 11
3.3 FLOOR PROTECTION 12
3.3.1 EMBER STRIPAND HEARTH EXTENSIONS 12
3.3.2 HEARTH EXTENSION 13
3.3.3 HEARTH EXAMPLES 14
4.0 INSTALLATION 15
4.1 CHIMNEY 15
4.2 TYPICAL CHIMNEY INSTALLATION 16
4.3 ADDING CHIMNEY SECTIONS 17
4.4 OFFSETCHIMNEYINSTALLATION 18
4.5 INSTALLING FLASHINGAND STORM COLLAR 19
4.6 CONNECTION TO A MASONRY CHIMNEY 19
4.7 AIR COOLED CHIMNEY INSTALLATION 20
5.0 FRAMING 21
5.1 WHEN USING A SOLID PACK CHIMNEY 22
5.2 WHEN USING AN AIR COOLED CHIMNEY 22
5.3 MINIMUM CLEARANCE TO COMBUSTIBLES 23
5.4 MINIMUM ENCLOSURE CLEARANCES 23
5.5 MINIMUM MANTEL CLEARANCES 24
6.0 FINISHING 25
6.1 FACEPLATE 25
6.2 UPPER GRILL INSTALLATION 25
6.3 KEYSTONE INSTALLATION 26
6.4 DOOR HANDLE INSTALLATION 26
6.5 DOOR INSTALLATION 27
6.6 DOOR HANDLE INSTALLATION 27
6.7 SECONDARYAIR TUBE REMOVAL / INSTALLATION 28
6.8 FIREBRICK AND BAFFLE INSTALLATION 29
6.10 OPTIONAL NZ64 BLOWER INSTALLATION 30
6.11 NZ150-KT KIT 32
6.12 NSK6 OPTIONAL SCREEN KIT 32
6.13 SMOKE SHELF 33
7.0 SELECTING WOOD 34
8.0 OPERATION 35
8.1 OPERATING SOUNDS AND SMELLS 35
8.2 DRAFT CONTROL 36
8.3 FIRE EXTINGUISHERS AND SMOKE DETECTORS 37
8.4 FUEL LOADINGAND BURN CYCLE 37
8.5 STARTING THE FIRE 38
8.6 FLASH FIRES 40
8.7 SMOKING 40
8.9 OVERNIGHT BURN 40
8.8 RELOADING THE APPLIANCE 40
9.0 MAINTENANCE 41
9.1 ASH REMOVAL PROCEDURES 41
9.2 CREOSOTE FORMATION AND REMOVAL 41
9.3 RUN-AWAY OR CHIMNEY FIRE 42
9.4 CHIMNEY CLEANING 42
9.5 GLASS AND GASKET REPLACEMENT 43
9.6 CARE OF GLASS 43
9.7 NZ64 BLOWER REPLACEMENT 44
10.0 REPLACEMENTS 45
11.0 TROUBLE SHOOTING GUIDE 47
12.0 WARRANTY 48
13.0 SERVICE HISTORY 49
14.0 NOTES 50

W415-1501 / 05.15.15
3
EN
1.0 INSTALLATION OVERVIEW
THIS APPLIANCE AND ITS COMPONENTS ARE DESIGNED TO BE INSTALLED AND OPERATED
AS A SYSTEM. ANY ALTERATION TO OR SUBSTITUTION FOR ITEMS IN THIS SYSTEM, UNLESS
ALLOWED BY THESE INSTALLATION INSTRUCTIONS, WILL VOID THE ETL LISTING AND MAY VOID
THE PRODUCT WARRANTY. IT MAY ALSO CREATE A HAZARDOUS INSTALLATION. READ THROUGH
THESE INSTRUCTIONS THOROUGHLY BEFORE STARTING YOUR INSTALLATION AND FOLLOW
THEM CAREFULLY THROUGHOUT YOUR PROJECT.
SEE
CHIMNEY
INSTALLATION
SEE
MINIMUM
MANTEL
CLEARANCES
SEE
FIREBRICK
INSTALLATION
SEE
GLASS AND
GASKET
REPLACEMENT
&
CARE OF GLASS
SEE
HEARTH
EXTENSION
SEE OPTIONAL
NZ64
BLOWER
INSTALLATION
SEE
HIGH
EFFICIENCY
HEATING
SEE
DOOR HANDLE
INSTALLATION
SEE
CONNECTION
TO A MASONRY
CHIMNEY
SEE
OUTSIDE
COMBUSTION
AIR
SEE
OUTSIDE
COMBUSTION
AIR
SEE
FRAMING
SEE
RATING PLATE
INFORMTATION
SEE
VENTILATION
OPENINGS

W415-1501 / 05.15.15
4
EN
3.17E
!
WARNING
• THIS APPLIANCE IS HOT WHEN OPERATED AND CAN CAUSE SEVERE BURNS IF CONTACTED.
• ANY CHANGES OR ALTERATIONS TO THIS APPLIANCE OR ITS CONTROLS CAN BE DANGEROUS AND
IS PROHIBITED.
• Do not operate appliance before reading and understanding operating instructions. Failure to operate appliance
according to operating instructions could cause fire or injury.
• Before installing this appliance, contact the local building or fire authority and follow their guidelines.
• This appliance must be installed by a qualified installer.
• Risk of burns. The appliance should be turned off and cooled before servicing.
• Do not operate without fully assembling all components.
• Do not let the appliance become hot enough for any part to glow red.
• Do not install damaged, incomplete or substitute components.
• Risk of cuts and abrasions. Wear protective gloves and safety glasses during installation. Sheet metal edges
may be sharp.
• Children and adults should be alerted to the hazards of high surface temperature and should stay away to avoid
burns or clothing ignition.
• Young children should be carefully supervised when they are in the same room as the appliance. Toddlers,
young children and others may be susceptible to accidental contact burns. A physical barrier is recommended if
there are at risk individuals in the house. To restrict access to an appliance or stove, install an adjustable safety
gate to keep toddlers, young children and other at risk individuals out of the room and away from hot surfaces.
• Clothing or other flammable material should not be placed on or near the appliance. Objects placed in front of
the appliance must be kept a minimum of 48” (1219.2mm) away from the front face of the appliance.
• Due to high temperatures, the appliance should be located out of traffic and away from furniture and draperies.
• Ensure you have incorporated adequate safety measures to protect infants/toddlers from touching hot surfaces.
• Even after the appliance is out, the glass and/or screen will remain hot for an extended period of time.
• Check with your local hearth specialty dealer for safety screens and hearth guards to protect children from hot
surfaces. These screens and guards must be fastened to the floor.
• Any safety screen or guard removed for servicing must be replaced prior to operating the appliance.
• Under no circumstances should this appliance be modified.
• This appliance must not be connected to a chimney flue pipe servicing a separate solid fuel burning appliance.
• Do not operate the appliance with the glass door removed, cracked or broken. Replacement of the glass should
be done by a licensed or qualified service person.
• Do not strike or slam shut the appliance glass door.
• Only doors / optional fronts certified with the unit are to be installed on the appliance.
• Keep the packaging material out of reach of children and dispose of the material in a safe manner. As with all
plastic bags, these are not toys and should be kept away from children and infants.
• If the appliance is not properly installed, a house fire may result. Do not expose the appliance to the elements
(ex. rain, etc.) and keep the appliance dry at all times. Wet insulation will produce an odour when the appliance
is used.
• The chimney must be sound and free of cracks. Clean your chimney a minimum of twice a year and as required.
• Do not start a fire with chemicals or fluids such as gasoline, engine oil, etc.
• Your appliance requires periodic maintenance and cleaning. Failure to maintain your appliance may lead to
smoke spillage in your home.
• Lower emissions generally result when burning air dried seasoned hardwoods, as compared to softwoods or too
green or freshly cut hardwoods. Burning wet unseasoned wood can cause excessive creosote accumulation.
When this is ignited it can cause a chimney fire that may result in a serious house fire.
• This appliance is designed to burn natural wood only. Do not burn trash or garbage, lawn clippings / waste,
rubber, waste petroleum products, paints or paint thinners / solvents, plastic, materials containing asbestos,
construction debris, railroad ties or treated wood, manure or animal remains, salt water driftwood or salted
materials, unseasoned wood, coal, charcoal, coloured paper, cardboard, plywood or particleboard. Burning
these materials may result in release of toxic fumes or render the appliance ineffective and cause smoke.
• Burn wood directly on the firebricks. Do not elevate grate or otherwise raise the fire.
• Do not store wood within appliance installation clearances or within the space required for re-fueling and ash
removal.
• Ashes must be disposed in a metal container with a tight lid and placed on a non-combustible surface well away
from the home or structure until completely cool.
• Ensure clearances to combustibles are maintained when building a mantel or shelves above the appliance.
Elevated temperatures on the wall or in the air above the appliance can cause melting, discolouration or
damage to decorations, a T.V. or other electronic components.
2.0 INTRODUCTION

W415-1501 / 05.15.15
5
EN
2.1 DIMENSIONS
2.2 GENERAL INSTRUCTIONS
BEFORE INSTALLING THIS APPLIANCE, CONTACT THE LOCAL BUILDING OR FIRE AUTHORITY AND
FOLLOW THEIR GUIDELINES.
THIS APPLIANCE MUST BE INSTALLED BY A QUALIFIED INSTALLER. FOLLOW THE INSTALLATION
DIRECTIONS. DO NOT OPERATE WITHOUT FULLY ASSEMBLING ALL COMPONENTS.
IF THIS APPLIANCE IS NOT PROPERLY INSTALLED, A HOUSE FIRE MAY RESULT.
DO NOT EXPOSE THE APPLIANCE TO THE ELEMENTS (EX. RAIN, ETC.) AND KEEP THE APPLIANCE
DRY AT ALL TIMES. WET INSULATION WILL PRODUCE AN ODOUR WHEN THE APPLIANCE IS USED.
THIS APPLIANCE IS HOT WHEN OPERATED AND CAN CAUSE SEVERE BURNS IF CONTACTED.
CHILDREN AND PETS MUST BE KEPT FROM TOUCHING THE APPLIANCE WHEN IT IS HOT. CON-
TACT YOUR LOCAL AUTHORIZED DEALER / DISTRIBUTOR FOR SAFETY SCREENS THAT MAY BE
AVAILABLE FOR THIS PRODUCT.
COMBUSTIBLE MATERIAL SUCH AS FIREWOOD, WET CLOTHING, ETC. PLACED TOO CLOSE CAN
CATCH FIRE. OBJECTS PLACED IN FRONT OF THE APPLIANCE MUST BE KEPT A MINIMUM OF 48"
(1219.2MM) FROM THE FRONT OF THE APPLIANCE.
ALL WIRING SHOULD BE DONE BY A QUALIFIED ELECTRICIAN AND SHALL BE IN COMPLIANCE
WITH LOCAL CODES AND WITH THE NATIONAL ELECTRIC CODE ANSI/NF NO. 70-CURRENT (IN THE
UNITED STATES), OR WITH THE CURRENT CSA C22.1 CANADIAN ELECTRIC CODE (IN CANADA).
44 15/16" 1141mm
49 1/16" 1246mm
50 1/8"
1273mm
24 3/16"
614mm
8 7/16"
214mm
4 1/4"
108mm
27 3/16" 690mm
25 1/8" 638mm
1 3/8"
36mm
49 1/16" 1246mm
14 7/8"
378mm
24 1/2" 623mm

W415-1501 / 05.15.15
6
EN
1
2
3
4
4
5
5
5
1. Combustion and dilution air is brought into the appliance through the fresh air intake collars located on
the bottom front sides of the appliance.
2. The combustion air is brought into the firebox through many small holes in the airwash located at the
top and sides of the opening.
3. The dilution air is introduced high in the firebox above the baffle to cool the chimney.
4. Inside the firebox combustion takes place and exhausts out the chimney.
5. The optional blower can be installed to draw fresh outside air into the home (not recommended in
colder climates), then either the NZ150-KT kit or the NZ64 blower can be installed inside and will circu-
late the air into your home.

W415-1501 / 05.15.15
7
EN
2.3 GENERAL INFORMATION
2.3.1 FEATURES
Shipped with appliance: Shipped with faceplate:
Installation manual Faceplate
Baffle 12 faceplate screws
Ember Strip
Log Retainer Shipped with the door(s):
Flex duct w/ start collar 10' (3m) length, 6" (152mm) Installation instructions and hardware
diameter (1 for NZ150-KT or blower kit and 2 for
outside combustion air supplies).
Approximate Heating Capacity up to 3,000 square feet (279 square meters) (Will vary with the home's floor
plan, insulation and outside temperature).
Maximum burning time up to 14 hours.
BTU Output per hour 10,000 to 80,000 (cord wood method).
The blower on "HIGH" draws 2.2 amps on 120 voltsA.C. (Approximately 250 watts).
CALIFORNIA PROP 65 WARNING:
Use of this product may produce smoke which contains
chemicals known to the State of California to cause can-
cer, birth defects, or other reproductive harm.
Do not use makeshift compromises during installation.
Do not block or restrict air, grille or louvre openings! Do
not add a hood.
Burning your appliance with the door open or ajar creates a fire hazard that may result in a house and/or
chimney fire.
All venting connections must be in compliance with the chimney manufacturers installation instructions.
Clearances referred to throughout this manual are the minimum requirements.
Your appliance must be installed in accordance with all national and local building code standards and
the standard of Chimney and Appliances, Vents and Solid Fuel Burning Appliances NFPA #211. Consult
the authority having jurisdiction (such as municipal building department, fire department, fire prevention
bureau, etc.) to determine the need to obtain a permit. If you are in doubt about the proper installation for
your situation, contact your dealer or local building or fire official. The manufacturer does not guarantee
that this appliance and its options will completely heat your entire home.
Expansion / contraction noises during heating up and cooling down cycles are normal and to be expected.
It is recommended that in all cases, the appliance be secured to the floor. Use the pallet packing brackets
to accomplish this.
This appliance has been certified EPA exempt.
• Maximum log length of 32" (813mm)
• Long burn time - up to 14 hours
• Optional 320 CFM blower for convection heat
• Thermostat for automatic control of the blower
• Large firebox capacity - 4.8 cu. ft. (0.1 cu. m.)
• Large glass doors for maximum visibility
• Firebrick lining for firebox protection
• Outside air for combustion
DO NOT LET THE APPLIANCE BECOME HOT ENOUGH FOR ANY PART TO GLOW RED.
2.3.2 HEATING SPECIFICATIONS
2.3.3 ELECTRICAL SPECIFICATIONS
2.3.4 PACKING LIST
2.3.5 EPA COMPLIANCE

W415-1501 / 05.15.15
8
EN
*POUR PLUS D'INFORMATIONS, CONSULTEZ LE MANUEL
D'INSTRUCTIONS DU FABRICANT.
*FOR FURTHER INFORMATION SEE THE MANUFACTURER'S
INSTALLATION AND OPERATING MANUAL.
BACK
0"(0 mm) TO STAND-OFFS
HEADER
96"(2.44 m) FROM BASE OF UNIT
CHIMNEY 2"(51 mm) REFER TO MANUFACTURER'S
INSTALLATION INSTRUCTIONS.
MANTEL
12"(305 mm) TO TOPEDGE OF FACEPLATE
TOP FACING
96"(2.44 m) FROM BASE OF UNIT
SIDE FACING
6"(153 mm) FROM SIDE OF UNIT
ADJACENT SIDEWALL
21"(534 mm) TO EDGE OF FACEPLATE
HEARTH PROTECTION
21"(534 mm) FROM FRONT OF UNIT
HEARTH PROTECTION
8"(203 mm) FROM SIDES OF UNIT
*TOP OF UNIT
(ENCLOSURE CEILING)
120"(3.05 m) FROM BASE OF UNIT
ARRIÈRE 0"(0 mm) AUX ESPACEURS
LINTEAU 96"(2.44 m) DE LA BASE DE L'APPAREIL
CHEMINÉE 2"(51 mm) RÉFÉREZ-VOUS AU MANUEL
D'INSTRUCTIONS DU FABRICANT.
TABLETTE 12"(305 mm) DU HAUT DE LA FAÇADE
DESSUS 96"(2.44 m) DE LA BASE DE L'APPAREIL
CÔTÉ 6"(153 mm) DU CÔTÉ DE L'APPAREIL
MUR LATÉRALADJACENT 21"(534 mm) DU BORD DE LA FAÇADE
PROTECTION DE PLANCHER 21"(534 mm) DU DEVANT DU FOYER
PROTECTION DE PLANCHER 8"(203 mm) DES CÔTÉS DU FOYER
*HAUT DE L'APPAREIL 120"(3.05 m) DE LA BASE DE L'APPAREIL
(PLAFOND DE L'ENCLAVE)
INSULATED CHIMNEY MINIMUM CLEARANCES TO
COMBUSTIBLES:
DÉGAGEMENTS MINIMAUX DE LA CHEMINÉE PRÉFABRIQUÉE
STANDARD AUX MATÉRIAUX COMBUSTIBLES
DÉGAGEMENTS MINIMAUX DE LA CHEMINÉE REFROIDIE À L'AIRAUX MATÉRIAUX COMBUSTIBLES
Face must have a
minimum 8' height
Cement board and steel studs
on enclosure ceiling
not required above 10'
Cement board from
the side of the unit
framing may start
Cement board Metal Studs
AIR COOLED CHIMNEY MINIMUM CLEARANCES TO COMBUSTIBLES:
Face metal studs,
clad with cement board
Face must have a
minimum 7' height
of cement board
Minimum
enclosure ceiling
height 7'
6"
Cement board from
the side of the unit
to combustibles
combustible
facing and wood
framing may start
at 84" above the
base of the unit
Cement board Metal Studs
*POUR PLUS D'INFORMATIONS, CONSULTEZ LE
MANUEL D'INSTRUCTIONS DU FABRICANT.
STARTER COLLAR NZAC-KT MUST BE USED IN CONJUNCTION WITH
FMI 8DM AIR COOLED CHIMNEY
CHIMNEY REQUIREMENTS
*FOR FURTHER INFORMATION SEE THE MANUFACTURER'S
INSTALLATION AND OPERATING MANUAL.
BACK
0"(0 mm) TO STAND-OFFS
HEADER
72"(2.83 m) FROM BASE OF UNIT
CHIMNEY
2"(51 mm) REFER TO MANUFACTURER'S
INSTALLATION INSTRUCTIONS.
MANTEL
12"(305 mm) TO TOPEDGE OF FACEPLATE
TOP FACING
84"(3.31 m) FROM BASE OF UNIT
SIDE FACING
6"(153 mm) FROM SIDE OF UNIT
ADJACENT SIDEWALL
21"(534 mm) TO EDGE OF FACEPLATE
HEARTH PROTECTION
21"(534 mm) FROM FRONT OF UNIT
HEARTH PROTECTION
8"(203 mm) FROM SIDES OF UNIT
*TOP OF UNIT
(ENCLOSURE CEILING)
84"(3.31 m) FROM BASE OF UNIT
ARRIÈRE 0"(0 mm) AUX ESPACEURS
LINTEAU 72"(2.83 m) DE LA BASE DE L'APPAREIL
CHEMINÉE 2"(51 mm) RÉFÉREZ-VOUS AU MANUEL
D'INSTRUCTIONS DU FABRICANT.
TABLETTE 12"(305 mm) DU HAUT DE LA FAÇADE
DESSUS 84"(3.31 m) DE LA BASE DE L'APPAREIL
CÔTÉ 6"(153 mm) DU CÔTÉ DE L'APPAREIL
MUR LATÉRALADJACENT 21"(534 mm) DU BORD DE LA FAÇADE
PROTECTION DE PLANCHER 21"(534 mm) DU DEVANT DU FOYER
PROTECTION DE PLANCHER 8"(203 mm) DES CÔTÉS DU FOYER
*HAUT DE L'APPAREIL 84"(3.31 m) DE LA BASE DE L'APPAREIL
(PLAFOND DE L'ENCLAVE)
LE COLLET DE DÉPART NZAC-KT DOIT ÊTRE UTILISÉ
CONJOINTEMENTAVEC LACHEMINÉE REFROIDIE À L'AIR FMI 8DM
SPÉCIFICATIONS POUR LA CHEMINÉE
Montants d'acier de façade
recouverts de panneaux de ciment
La façade doit posséder
un panneau de ciment
d'une hauteur
minimale de 7'
Hauteur minimale
du plafond de
l'enclave de 7'
6"
Panneau de ciment
sur le côté de
l'appareil aux matériaux
combustibles
La façade combustible
et la charpente de bois
peuvent débuter à 84"
au-dessus de la base
de l'appareil
Panneau de ciment Montants d'acier
Montants d'acier de façade
et de plafond de l'enclave
recouverts de panneaux de ciment
La façade doit posséder un
panneau de ciment d'une
hauteur minimale de 8'
Panneau de ciment et montants
d'acier sur le plafond de l'enclave
non requis à plus de 10'
Hauteur minimale
du plafond de
l'enclave de 7' à 10'
6"
Panneau de ciment
sur le côté de
l'appareil aux matériaux
combustibles
La façade combustible et la
charpente de bois peuvent
débuter à 96" au-dessus
de la base de l'appareil
Panneaux de ciment Montants d'acier
U.S. Environmental Protection Agency: This Heater has been
certified EPA exempt: 40 CFR Part 60, Subpart AAA DO NOT REMOVE THIS LABEL U.S.Environmental Protection Agency: Cet appareil de chauffage
est testé EPA et exempt: CFR 40 Part 60, Subpart AAA
NE RETIREZ PAS CETTE PLAQUE
2.4 RATING PLATE INFORMATION
Rating plate is located behind the appliance faceplate.
This illustration is for reference only. Refer to the rating plate on
the appliance for accurate information.
RATING
PLATE
LOCATION
FACEPLATE
MODEL NO. NZ6000-1
LISTED FACTORY BUILT FIREPLACE
SERIAL
NO.
NZ6000
POUR INSTALLATION ET UTILISATION CONFORMÉMENT AUX MANUELD'INSTRUCTIONS DU FABRICANT.
RENSEIGNEZ-VOUS AUPRÈS DESAUTORITÉS LOCALES DU BÂTIMENT OU DU SERVICE DES INCENDIES AU
SUJET DES RESTRICTIONS ET DES INSPECTIONS D'INSTALLATION DANS VOTRE RÉGION. NE PAS
RACCORDER À LA CHEMINÉE D'UNAUTRE APPAREIL.
CERTIFIED TO / CERTIFIÉ SELON: ULC S610, UL-127
N° DE MODÈLE NZ6000-1
FOYER PRÉFABRIQUÉ HOMOLOGUÉ
COMPOSANTS REQUIS POUR L'INSTALLATION:
EXIGENCES POUR LA CHEMINÉE (voir le manuel d'instructions)
La cheminée doit être certifiée selon l'une des normes suivantes : ULC S610 ou ULC S629
pour le Canada ou selon les normes UL 103HT ou UL-127 pour les États-Unis
Installation dans une cheminée en maçonnerie : La gaine en acier inoxydable doit être
certifiée selon les normes ULC S640 M92 ou ULC 639 pour le Canada ou selon la norme
UL 1777 pour les États-Unis
Cheminée refroidie à l'air : Utilisez seulement FMI 8DM
COMPONENTS REQUIRED FOR INSTALLATION:
CHIMNEY REQUIREMENTS (see installation manual):
SHIPPED WITH THE FIREPLACE:
INSTALLATION MANUAL
BAFFLE
EMBER STRIP
LOG RETAINER
FLEX DUCT W/ START COLLAR 10' LENGTH,
6" DIA (FOR BLOWERAND OUTSIDEAIR
SUPPLY).
SHIPPED WITH FACEPLATE:
FACEPLATE
12 FACEPLATE SCREWS
SHIPPED WITH THE DOOR(S):
INSTALLATION INSTUCTIONS AND
HARDWARE
Chimney must be certified to one of the following standards ULC S604, ULC S610
or ULC S629 for Canada or UL 103HT or UL-127 for the United States
Masonry chimney installation: Stainless steel liner must be certified to ULC S640
M92 or ULC 639 for Canada or UL 1777 for the United States
Air cooled chimney: Use only FMI 8DM
AVERTISSEMENT :
• Tenir les portes fermées
lorsque le foyer fonctionne.
N'ouvrez que pour ravitailler le feu.
• Transporter les cendres dans un
contenant incombustible possédant un
couvercle étanche.
• Pour emploi avec du bois de corde
seulement.
• Ne peut être installé dans une maison
mobile.
LIVRÉ AVEC LE FOYER
MANUEL D'INSTRUCTIONS
DÉFLECTEUR
PARE-BRAISES
PARE-BÛCHES
GAINE FLEXIBLE AVEC COLLET DE RACCORD
DE PRISE D'AIR DE 10', 6" DE DIAMÈTRE
(POUR LA SOUFFLERIE ET
L'APPROVISIONNEMENT EN AIR EXTÉRIEUR)
LIVRÉ AVEC LA FAÇADE :
FAÇADE
12 VIS POUR LA FAÇADE
LIVRÉ AVEC LA/LES PORTE(S) :
INSTRUCTIONS D'INSTALLATION
ET QUINCAILLERIE
W385-2065
PREVENT CREOSOTE FIRE: INSPECT
CHIMNEY AND CHIMNEYCONNECTOR, IF
APPLICABLE, TWICE MONTHLY AND CLEAN
IF NECESSARY.
DO NOT OVERFIRE: IF EXTERIOR OF UNIT
GLOWS RED, YOU ARE OVERFIRING.
KEEP FURNISHINGS AND OTHER
COMBUSTIBLE MATERIALS A
CONSIDERABLE DISTANCEAWAY FROM
APPLIANCE.
TYPE OF FUEL: WOOD ONLY.
PREVENIR LES FEUX DE CREOSOTE:
INSPECTEZ LA CHEMINEE OU LE RACCORD
DE CHEMINEE, SI APPLICABLE, DEUX FOIS
PAR MOIS ETNETTOYEZ SI NECESSAIRE.
NE SURCHAUFFEZ PAS: SI L'EXTERIEUR DE
L'UNITE DEVIENT ROUGE, VOUS
SURCHAUFFEZ.
GARDEZ LES MEUBLES ET AUTRES
MATERIELS COMUSTIBLESAUNE
DISTANCE CONSIDERABLE DE L'APPAREIL
DE CHAUFFAGE.
TYPE DE COMBUSTIBLE: BOIS SEULEMENT.
IMPORTANT
BEFORE COMMENCING INSTALLATION
REFER TO THE LABELLOCATED BEHIND
THE FACEPLATE AND TO THE
MANUFACTURER'S INSTALLATION
INSTRUCTIONS PACKAGEDTOGETHER
WITH THIS UNIT.
THE INSTALLATION MUST BE APPROVED
BY THE AUTHORITY HAVING
JURISDICTION.
AVANT DE COMMENCER L'INSTALLATION,
REFEREZ-VOUS À L'ÉTIQUETTE QUI SE
TROUVE DERRIÈRE LA FAÇADE AINSI
QU'AUX INSTRUCTIONS D'INSTALLATION
DU MANUFACTURIER FOURNIESAVEC
L'UNITÉ.
L'INSTALLATION DOIT ÊTRE APPROUVÉE
PAR L'AUTORITÉ COMPÉTENTE.
24 NAPOLEON ROAD. BARRIE, ONTRAIO L4M 0G8 CANADA
INSTALL AND USE ONLY IN ACCORDANCE WITH THE MANUFACTURER'S INSTALLATION AND OWNER'S
MANUAL. CONTACT LOCAL BUILDING OR FIRE OFFICIALSABOUT RESTRICTIONS AND INSTALLATION
INSPECTION IN YOUR AREA. DO NOT CONNECT THIS UNIT TOA CHIMNEY SERVINGANOTHER APPLIANCE.
WARNING:
• Operate with feed doors
closed. Open to feed fire only.
• Transport ashes in an air-tight
non-combustible container.
• For use with cord wood only.
• Not for use in a Mobile Home.
MINIMUM CHIMNEY HEIGHT 15 ft (4.57 m) MAXIMUM NUMBER OF ELBOWS 4
MAXIMUM CHIMNEY HEIGHT 34 ft (10.36 m) FLUE COLLAR 8"ø
MAXIMUM OFFSET ANGLE 30º US - 45º CANADA
HAUTEUR MINIMALE DE LA CHEMINÉE 15 pi (4.57 m) NOMBRE MAXIMAL DE COUDES 4
HAUTEUR MAXIMALE DE LA CHEMINÉE 34 pi (10.36 m) BUSE D'ÉVACUATION 8"ø
ANGLE DE DÉVIATION MAXIMAL 30º US - 45º CANADA
9700539 (WSL)
4001657 (NGZ)
4001658 (NAC)
4001659 (WUSA)
REFERENCE
#15528
MANUFACTURE DATE:
YEAR: 2015 2016 2017 2018
MONTH: 2019 2020
243658710912111
OPTIONAL COMPONENTS / PIECES OPTIONNELS
BLOWER KIT / SOUFFLERIE : NZ64
HOT AIR GRAVITY VENTS / VENTILATION PAR GRAVITE: NZ221 ACCESSORIES PROVIDED BY MANUFACTURER ARE TO BE UTILIZED ONLY/
SEULS LES ACCESSOIRES FOURNIS PAR LE FABRICANT PEUVENT ÊTRE UTILISÉS.
SAMP
M
M
E MANUFACTURER'SURER'S
TING MANUAL.
ATE
TE
NITNIT
UNIT
T
OF UNIT
SA
MP
M
M
AM
AM
AM
M
AM
AM
AM
AM
AM
M
M
M
M
F
ace
m
us
t h
a
v
e
amust have a
minimum 8' hei
g
h
tm 8' height
and steel studsnd steel studs
nclosure ceilingosure ceiling
required above 10'quired above 10'
M
M
M
M
M
C
ement board
f
rom
Cement board from
th
e
s
i
de
of
th
e
u
ni
tthe side of the unit
f
ramin
g
ma
y
star
t
Cement boardCement board
M
M
Metal StudsMetal Stud
M
AM
AM
AM
AM
CHIMNEY MINIMUM CLEARANCES TO COMBUSTIBCLEARANCES TO COMBUST
A
A
A
A
Face must have aFace
minimum 7' heigminimu
of cement boof ceme
A
comco
facf
Cement board
A
A
SAMP
D IN CONJUNC
CONJU
MNEY
S
QUIREMENTSUIREMENTS
S
S
S
S
S
S
S
S
S
ATION SEE THE MANUFACTUREE THE MANUFACTUR
D OPERATING MANUAL.PERATING MANUAL.
TO STAND-OFFSTO STAND-OF
83 m)83 m)
FROM BASE OF UNITFROM BASE O
51 mm)51 mm)
REFER TO MANUFACTURER'SREFER TO M
INSTALLATION INSTRUCTIONS.INSTALLA
12"(305 mm)12"(305 mm)
TO TOPEDGE OF FACEPLATE
OPEDGE OF FACEPLATE
84"(3.31 m)84"(3.31 m
FROM BASE OF UNIT
OM BASE OF UNIT
6"(153 mm)6"(153 mm)
FROM SIDE OF UNITFROM SIDE OF UNIT
DEWALL
LL
21"(534 mm)21"(534 mm)
TO EDGE OF FACEPLATETO EDGE OF FACEPLATE
ECTION
ON
21"(534 mm)21"(534 mm)
FROM FRONT OF UNITFROM FRONT OF UNIT
TION
N
8"(203 mm)8"(203 mm)
FROM SIDES OF UNITFROM SIDES OF UNIT
84"(3.31 m)
"(3.31 m)
FROM BASE OF UNITFROM BASE OF UNIT
M
M
La façade doit posséderLa façade doit posséde
panneau de ciment dpanneau de ciment
hauteur minimalehau
P
a
nn
eau
de
c
im
e
nt
e
t m
o
nt
a
nt
sPanneau de cime
d'acier sur le plafond de l'enclaved'acier sur le plafond
n
on requis à plus de 10'
non requis à plus de
M
M
M
M
M
La façadeLa façad
charpecharp
débd
Panneaux dePanneaux d
M
M
REMOVE THIS LABELEMOVE THIS LABEL
NE RETIREZ PAS CETNE RETIREZ PAS CE
MPLE
M
M
MP
MP
MP
MP
MP
ANTS REQUIS POUR L'INSTALLATION:TS REQUIS POUR L'INSTALLATION:
EXIGENCES POUR LA CHEMINÉE (voir le manEXIGENCES POUR LA CHEMINÉE (voir le ma
La cheminée doit être certifiée selon l'une des normes suivantesLa cheminée doit être certifiée selon l'une des normes suivantes
pour le Canada ou selon les normes UL 103HT ou UL-1pour le Canada ou selon les normes UL 103HT ou UL-
Installation dans une cheminée en maçonnerie : La gaineInstallation dans une chem
certifiée selon les normes ULC S640 M92 ou ULC 639certifiée selon les normes
UL 1777 pour les États
Cheminée refroidie à l'air : UtiliseCh
e installation manual):stallation manual):
EPLATE:PLATE:
SCREWSCREWS
D WITH THE DOOR(S):WITH THE DOOR(
LLATION INSTUCTIONS ANDLATION INSTUCTIONS AND
RDWAREDWARE
ollowing standards ULC S604, ULC S610ndards ULC S604, ULC S610
03HT or UL-127 for the United Statesfor the United States
ess steel liner must be certified to ULC S640e certified to ULC S640
nada or UL 1777 for the United Statesnited States
chimney: Use only FMI 8DM
C LE FOYERR
D'INSTRUCTIONSS
CTEUR
E-BRAISESBRAISES
ARE-BÛCHESRE-BÛCHES
GAINE FLEXIBLE AVEC COLLET DE RACCORDGAINE FLEXIBLE AVEC COLLET DE RACCORD
DE PRISE D'AIR DE 10', 6" DE DIAMÈTRE
DE PRISE D'AIR DE 10', 6" DE DIAMÈTRE
(
P
O
UR LA
SO
UFFLERIE ET
(POUR LA SOUFFLERIE ET
L'APPROVISIONNEMENT EN AIR EXTÉRIEUR
)L'APPROVISIONNEMENT EN AIR EXTÉRIEUR)
LIVRÉ AVEC LA FAÇADE
:FAÇADE :
FA
Ç
AD
E
12 VIS P
O
UR LA FAÇAD
E12 VIS POUR LA FAÇADE
LIVRÉ AVEC LA/LES PORTLIVRÉ AVEC LA/LES POR
INSTRUCTIONS D'INSTAINSTRUCTIONS D'INST
ET QUINCAILLERIEET QUINCAILLERIE
MP
LE
P
E
AP
IF NE
DO NOTDO
GLOWS REGLOWS
KEEP FURNISKEEP FUR
COMBUSTIBLE MCOMBUS
CONSIDERABLE DCONS
A
PPLIAN
C
E.
APP
TYPE OF FUEL: WOOD OTYPE OF FUEL: WOOD O
PREVENIR LES FEUX DE CR
R LES FEUX DE CR
INSPECTEZ LA CHEMINEE O
CTEZ LA CHEMINEE
DE CHEMINEE, SI APPLICCHEMINEE, SI APPL
PAR MOIS ETNETTOYAR MOIS ET NETTO
NE SURCHAUFFEZNE SURCHAUFFEZ
L'UNITE DEVIENTL'UNITE DEVIEN
SURCHAUFFESURCHAUFF
GARDEZ LEGARDEZ L
MATERIEMATERI
DISTADISTA
DEDE
T
MP
TRAIO L4M 0G8 CANADARAIO L4M 0G8 CANAD
15 ft (4.57 m) MAXIMUM NUMBER OF ELBOWS 4ELBOWS 4
HT 34 ft (10.36 m) FLUE COLLART
8
"
ø8"ø
LE 30º US - 45º CANADAE 30
HAUTEUR MINIMALE DE LA CHEMINÉE 15 piHAUTEUR MINIMALE D
HAUTEUR MAXIMALE DE LA CHEMINÉE 34HAUTEUR MAXIMALE DE
ANGLE DE DÉVIATION MAXIMALANGLE DE DÉVIATION MAX
NLY/LY/
E UTILISÉS.UTILISÉS.
NOTE: The rating plate must remain with the appliance at all times. It must not be removed.

W415-1501 / 05.15.15
9
EN
A HOTAIR GRAVITY VENT SYSTEM (NZ221) may be
used to distribute heat to an adjoining room (located either
above, or beside the room containing the appliance) by way
of vents. Air flow through this vent must be experimented
with and the dampers of the grill adjusted manually to suit
your requirements. This may take a few attempts; thereafter
adjustments should no longer be required as is normally
experienced with your central heating system registers.
The hot air vent must be installed in an upward direction!
NEVER install in a downward direction. The hot air gravity
vent system is not to be connected to a central heating
system.
No more than two hot air gravity vents may be connected to the
appliance. Individual vent runs are not to exceed 10 feet (3m).
All hot air gravity vents must be insulated.
2.5 HI-EFFICIENCY HEATING
GRAVITY VENT OPTION
- 2 DUCTS
GRAVITY VENT OPTION
- 1 DUCT
NO DUCTING
VENTING KIT INSTALLATION
AVERTISSEMENT:
AIRCOMBURANT
SEULEMENT
WARNING:
COMBUSTIONAIR
ONLY
WARNING:
BLOWER
CONNECTIONONLY
AVERTISSEMENT:
CONNEXIONDE LA
SOUFFLERIE
SEULEMENT
3.0 INSTALLATION PLANNING
68.3A
!
WARNING
WEAR GLOVES AND SAFETY GLASSES FOR PROTECTION.
CAREFULLY FOLLOW THE INSTRUCTIONS FOR ASSEMBLY OF THE PIPE AND OTHER PARTS NEEDED TO INSTALL THE
APPLIANCE. FAILURE TO DO SO MAY RESULT IN A FIRE, ESPECIALLY IF COMBUSTIBLES ARE TOO CLOSE TO THE
APPLIANCE OR CHIMNEY AND AIR SPACES ARE BLOCKED, PREVENTING THE FREE MOVEMENT OF COOLING AIR.
DO NOT DRAW OUTSIDE AIR FROM GARAGE SPACES. EXHAUST PRODUCTS OF GASOLINE ENGINES ARE HAZARDOUS.
DO NOT INSTALL OUTSIDE AIR DUCTS SUCH THAT THE AIR MAY BE DRAWN FROM ATTIC SPACES, BASEMENTS OR
ABOVE THE ROOFING WHERE OTHER HEATING APPLIANCES OR FANS AND CHIMNEYS EXHAUST OR UTILIZE AIR.
THESE PRECAUTIONS WILL REDUCE THE POSSIBILITY OF APPLIANCE SMOKING OR AIR FLOW REVERSAL. THE
OUTSIDE AIR INLET MUST REMAIN CLEAR OF LEAVES, DEBRIS ICE AND/OR SNOW. IT MUST BE UNRESTRICTED WHILE
APPLIANCE IS IN USE TO PREVENT ROOM AIR STARVATION WHICH CAN CAUSE SMOKE SPILLAGE AND AN INABILITY
TO MAINTAIN A FIRE. SMOKE SPILLAGE CAN ALSO SET OFF SMOKE ALARMS.
NEGATIVE PRESSURE WITHIN YOUR HOME MAY INADVERTENTLY AFFECT YOUR APPLIANCE.
TO PREVENT CONTACT WITH SAGGING OR LOOSE INSULATION, THE APPLIANCE MUST NOT BE INSTALLED
AGAINST VAPOUR BARRIERS OR EXPOSED INSULATION. LOCALIZED OVERHEATING COULD OCCUR AND A FIRE
COULD RESULT.
DO NOT USE MAKESHIFT COMPROMISES DURING INSTALLATION. DO NOT BLOCK OR RESTRICT AIR, GRILLE OR
LOUVRE OPENINGS. DO NOT ADD A HOOD.
KEEP HAND TOOLS IN GOOD CONDITION, SHARPEN CUTTING EDGES AND MAKE SURE TOOL HANDLES ARE
SECURE.
ALWAYS MAINTAIN THE MINIMUM AIR SPACE REQUIRED TO THE ENCLOSURE TO PREVENT FIRES.

W415-1501 / 05.15.15
10
EN
3.1 LOCATION AND CLEARANCES
The appliance is shipped with a set-up face that is 1/8" (38m) larger
on the top, bottom and each side than the faceplate. Leave the set-up
face in place to act as a template when installing the finishing face.
IMPORTANT
This appliance, fully dressed, weighs 850 lbs (386kg). Ensure there is
adequate floor support for the appliance, chimney and facing material.
Some material could weigh thousands of pounds.
DO NOT INSTALL INTO ANY AREA HAVING A HEIGHT LESS THAN 7 FEET (2.1M) (CEILING OF
ENCLOSURE TO APPLIANCE BOTTOM, EXCLUDING HEARTH HEIGHT).
We recommend that the appliance be secured to the floor in
all cases.
Using the door opening as a datum, level the appliance by
shimming underneath the appliance. Remove and discard the
lifting handles. Bend the tabs down and secure the appliance to
the floor.
3.1.1 VENTILATION OPENINGS
The appliance enclosure must be provided with sufficient air circulation to avoid a fire hazard. Install ventilation
grilles (minimum openings of 40 sq. inches (0.03 sq. meters)) at both floor and ceiling levels of the enclosure.
These grilles must not restrict the flow of heat by more than 25%. Do not install into any area having a
height less than 7 ft (2m) (ceiling of enclosure to appliance bottom, excluding hearth height). The location
of windows, doors and the traffic flow in the room where the stove is to be located should be considered. If
possible, you should choose a location where the chimney will pass through the house without cutting a floor
or roof joist.

W415-1501 / 05.15.15
11
EN
10' (3m) MIN. TO
CHIMNEY CAP.
NOTE: Incorporate a vertical loop or trap into air
liners to reduce air flow when appliance is not in
use.
Insulating the intake liners is recommended in colder
climates to prevent condensation from occurring.
The Napoleon Model NZ6000-1 takes outside air
directly into the appliance through the openings in the
left and right hand sides.
Decide on the most convenient location for the fresh
air inlet ducts and hoods which may be installed
above or below floor level.
The fresh air inlet ducts and hoods must be installed.
Secure and seal the intake liners to the collars using
3 sheet metal screws, and high temperature sealant.
3.2 OUTSIDE COMBUSTION AIR
0
2 (4)
4 (8)
6 (12)
8 (16)
10 (20)
5
(10) 10 (20) 15 (30) 20 (40) 25 (50)
AIR INTAKE LINERS
HORIZONTAL RUN
VERTICAL RISE
Included with the appliance are:
- Two 10' (3m) lengths of vent. Use a connector and seal if adding
more length.
- Two of intake hoods.
The vertical height of the air intake liner must not be greater than 2/3
the height of the chimney. If additional liner length is required, it may be
doubled by increasing the size from 6" (152mm) diameter to 8" (203mm)
diameter. Use a 6" (152mm) to 8" (203mm) increaser at the hood and
a decreaser at the appliance. Values in brackets represent 8" (203mm)
diameter intake liners.
The duct terminations must be located so they can not be blocked (i.e. snowdrifts). 4' (1.2m) above grade is
recommended. Make a 6 ½" (165mm) inch hole to suit in an outside wall of the house. From outside, place the
fresh air hood into the hole, open side down. Seal with caulking and secure.
Horizontal run may be:
5' (1.5m)
15' (4.6m)
20' (6.1m)
25' (7.6m)
Vertical rise is between:
6' (1.8m) & 10' (3m) max
3' (0.9m) & 6' (1.8m)
1' (0.3m) & 3' (0.9m)
0' (0m) & 1' (0.3m)

W415-1501 / 05.15.15
12
EN
An acceptable 61½" (1562mm) x 20" (508mm) non-combustible
(ie: brick, stone or ceramic tile) hearth extension must be installed.
Hearth must extend 20" (508mm) in front of the faceplate when it is not
elevated (see local building codes). Hearth must extend a minimum of 6"
(152mm) to both sides of the appliance [61 ½" (1562mm)].
The hearth must extend a minimum 20" (508mm) in front of the appliance
although if raised a minimum of 6 1/2" (165mm) the 20" (508mm) may be
reduced to a minimum of 18" (0.45m).
The hearth must extend a minimum of 6" (152mm) to both sides of the
appliance [61 ½" (1562mm)]
The hearth must be a minimum of 1" (25mm) thick cement board (or
equivalent) plus ¼" (6.4mm) ceramic tile.
Ensure that the gap between the appliance and a non-combustible
hearth extension is sealed with sand/cement grout or covered with
an ember strip (or both) to prevent sparks and embers from falling
into this area.
Raised hearths must be constructed of non-combustible materials such as cement blocks or bricks.
While the appliance can be installed directly on the floor, a non-combustible hearth extension is required in
front of the appliance, that must not be built higher than the bottom of the appliance faceplate. It may therefore
be advisable to build the appliance on a raised platform.
A raised hearth together with the appliance built on a raised platform is recommended for easier wood loading and
fire viewing.
EMBER STRIP
(See “HEARTH
EXAMPLES” Section)
HEARTH EXTENSIONS ARE TO BE INSTALLED ONLY AS DESCRIBED TO PREVENT HIGH
TEMPERATURES FROM OCCURRING ON CONCEALED COMBUSTIBLE MATERIALS. HEARTH
EMBER STRIPS PREVENT BURNING OR HOT PARTICLES FROM INADVERTENTLY FALLING
DIRECTLY ON COMBUSTIBLE SURFACES IN THE EVENT THE BUILDING SHOULD SETTLE AND
DISTURB THE ORIGINAL CONSTRUCTION.
3.3 FLOOR PROTECTION
3.3.1 EMBER STRIP AND HEARTH EXTENSIONS

W415-1501 / 05.15.15
13
EN
3.3.2 HEARTH EXTENSION
18" (457mm)
6 1/2"
(165mm)
61 1/2"
(1562mm)
61 1/2" (1562mm)
20" (508mm)
6"
(152mm) 6"
(152mm)
An acceptable 61½" (1562mm) x 20" (508mm) non-combustible (ie: brick,
stone or ceramic tile) hearth extension must be installed. Hearth must
extend 20" (508mm) in front of the faceplate when it is not elevated (see
local building codes). Hearth must extend a minimum of 6" (152mm) to
both sides of the appliance [61½" (1562mm)].
Hearth must be a minimum of 1" (25mm) thick cement board (or
equivalent) plus ¼" (6.4mm) ceramic tile.
Ensure that the gap between the appliance and a combustible hearth
extension is sealed with sand/cement grout or covered with a metal strip
(or both) to prevent sparks and embers from falling into this area.
HEARTH EXTENSION
Elevated hearths must be constructed of noncombustible materials such
as cement blocks or bricks.
While the appliance can be installed directly on the floor, a non-
combustible hearth extension is required in front of the appliance, that
must not be built higher than the bottom of the appliance faceplate. It may
therefore be advisable to build the appliance on a raised platform.
Hearths raised minimum 6 ½" (165mm) must extend a minimum of 18" (457mm).
EMBER STRIP
SEE
HEARTH
EXAMPLES

W415-1501 / 05.15.15
14
EN
NON-COMBUSTIBLE MATERIALS
SUCH AS CEMENT
BLOCKS OR BRICKS
COMBUSTIBLE FRAMING
PLYWOOD INCREASE
HEADER HEIGHT
THIS DIMENSION
See “Framing” section
RAISED
APPLIANCE
COMBUSTIBLE FRAMING
NON-COMBUSTIBLE
MATERIALS SUCH
AS CEMENT BLOCKS
OR BRICKS
PLYWOOD INCREASE
HEADER HEIGHT
THIS DIMENSION
See “Framing” section
RAISED
HEARTH
RAISED
APPLIANCE
COMBUSTIBLE FLOOR
EMBER STRIP
EMBER STRIP
EMBER STRIP
EMBER STRIP
COMBUSTIBLE FLOOR
MIN. 1/4” (6.4mm)
TILE OR MARBLE 20” MIN.
(508mm)
MIN. 1” (25mm) CEMENT BOARD
6
1/2
”
(165mm)
18” MIN.
(457mm)
MIN. 1/4” (6.4mm)
TILE OR MARBLE
MIN. 1” (25mm)
CEMENT BOARD
MIN. 1/4” (6.4mm)
MARBLE OR STONE
18” MIN.
(457mm)
18” MIN.
(457mm)
3.3.3 HEARTH EXAMPLES
FLUSH HEARTH
RAISED HEARTH
RAISED APPLIANCE
RAISED HEARTH AND APPLIANCE

W415-1501 / 05.15.15
15
EN
4.0 INSTALLATION
NOTE: All venting connections must be in compliance with the chimney manufacturers installation
instructions.
This appliance was tested to CAN/ULC S610 and UL 127 Factory Built Fireplace Standards. This appliance
has met the test criteria for Zero Clearance Installation to Combustible Surfaces and Certified to burn firewood
only.
A
ny 8” (203.2mm) diameter chimney listed to these standards may be installed. In accordance with these
standards, the appliance may also be connected to any chimney listed to CAN/ULC-S604 and CAN/ULC-S629
for Canada or UL-103HT for the United states.
Installation of all types of factory-built chimney systems is to
be in accordance with the chimney manufacturers installation
instructions. An appropriate chimney manufacturers anchor base
plate and anchor base plate gasket is required in order to initiate
their system. Use the high temperature gasket, supplied, to
seal between the anchor plate and the appliance top. Air cooled
chimney systems are not recommended in colder climates.
Complete installation instructions for Selkirk Ultra Temp Chimney
for Canada and Ultra Temp Platinum Chimney for USA, refer to:
www.selkirkinc.com/products/chimney.aspx
A
chimney venting the appliance shall not vent any other
appliance. The minimum overall chimney height from the top of the
appliance is 15ft (4.6m). The maximum overall chimney height from the top of the appliance is 34ft (10.4m).
Factory-built chimney systems for use in dwellings constructed for three or more families must be enclosed
above the room in which the appliance is located. This enclosure must have a fire resistance rating equal to or
greater than that of the floor or roof assembly through which they pass.
The chimney should not be built with an offset angle in excess of 45° in Canada and 30° in USA.
Ensure that minimum clearances are maintained.
Portions of the chimney that extend through accessible spaces must always be encased to avoid personal
contact with the chimney and thereby avoid damage to the chimney.
The chimney must be supported at a maximum of 20ft (6.1m) intervals [approx. 200 lbs/20 FT (90.7kg/6.1m)].
63.2A
ANCHOR PLATE
ANCHOR PLATE GASKET
APPLIANCE TOP
ANCHOR PLATE FOR A FACTORY
BUILT CHIMNEY
NEVER INSTALL A SINGLE WALL SLIP SECTION OR SMOKE PIPE IN A CHASE STRUCTURE.
THE HIGHER TEMPERATURE OF THIS SINGLE WALL PIPE MAY RADIATE SUFFICIENT HEAT TO
COMBUSTIBLE CHASE MATERIALS TO CAUSE A FIRE.
TO AVOID DANGER OF FIRE, ALL INSTRUCTIONS MUST BE STRICTLY FOLLOWED, INCLUDING
THE PROVISION OF AIR SPACE CLEARANCE BETWEEN CHIMNEY SYSTEM AND ENCLOSURE. TO
PROTECT AGAINST THE EFFECTS OF CORROSION ON THOSE PARTS EXPOSED TO THE WEATHER,
WE RECOMMEND THAT THE CHASE TOP BE PAINTED WITH A RUST-RESISTANT PAINT.
MAINTAIN A MINIMUM 2" (51mm) AIR CLEARANCE TO ALL PARTS OF THE CHIMNEY SYSTEM AT ALL
TIMES. FAILURE TO MAINTAIN THIS 2" (50.8mm) AIR CLEARANCE WILL CAUSE A STRUCTURE FIRE.
DETAILED INSTRUCTIONS FOR INSTALLATION OF THE CHASE TOP, STORM COLLAR AND
TERMINATION CAP ARE PACKAGED WITH THESE PARTS.
FIRESTOP SPACERS MUST BE USED WHENEVER THE CHIMNEY PENETRATES A CEILING/FLOOR
AREA.
THE CHIMNEY MUST BE SOUNDAND FREE OF CRACKS. CLEAN YOUR CHIMNEYAMINIMUM OF TWICE A
YEAR AND AS REQUIRED.
A raised hearth together with the appliance built on a raised platform is recommended for easier wood loading
and fire viewing.
4.1 CHIMNEY

W415-1501 / 05.15.15
16
EN
* The first flue offset closest to the top of the appliance must be a minimum distance of 12” (304.8mm)
from the top of the appliance.
1. Move the appliance into position. Try to center the exhaust flue of the appliance,
midpoint between two joists to prevent having to cut them. Use a plumb bob to
line up the centre.
2. Cut and frame an opening in the ceiling to provide a
minimum clearance of 2” (50.8mm) between the
outside of the chimney and any combustible material.
DO NOT FILL THIS SPACE WITH ANY TYPE OF
MATERIAL! Nail headers between the joists for extra
support. Firestop spacers must be placed on each
framed opening in any floor or ceiling that the chim-
ney passes through.
3. Hold a plumb bob from the underside of the roof
to determine where the opening in the roof should
be. Cut and frame the roof opening maintaining
proper 2” (50.8mm) clearances.
NOTE: 30° or 45° offsets may be installed back to
back.
63.5A
15 FT
(4.6m)
MINIMUM
34 FT
(10.4m)
MAXIMUM
RAIN CAP RAIN CAP
RAIN CAP
STORM COLLAR
ROOF FLASHING STORM COLLAR
ROOF FLASHING
STORM COLLAR
ROOF FLASHING
ATTIC INSULATION
SHIELD
ATTIC INSULATION
SHIELD ATTIC INSULATION
SHIELD
CEILING RADIATION
SHIELD
OFFSET
SUPPORT
OFFSET
SUPPORT
FIRESTOP FIRESTOP
12” (304.8mm)
MIN*
15 FT
(4.6m)
MINIMUM
34 FT
(10.4m)
MAXIMUM
12” (304.8mm)
MIN*
15 FT
(4.6m)
MINIMUM
34 FT
(10.4m)
MAXIMUM
2"
(50.8mm)
Min.
TypicalRoofJoist FramingTypical Joist Framing
2"
(50.8mm)
Min.
2" (50.8mm)
Min.
2"
(50.8mm)
Min.
STRAIGHT CHIMNEY SINGLE OFFSET
CHIMNEY DOUBLE OFFSET CHIMNEY
HEADERS
FIRESTOP SPACER -
UNDERSIDE OF JOIST
4.2 TYPICAL CHIMNEY INSTALLATION

W415-1501 / 05.15.15
17
EN
4.3 ADDING CHIMNEY SECTIONS
A
dd chimney sections, securely, to the required height.
If the chimney system is enclosed within the attic area, a rafter
radiation shield is required.
The chimney must extend at least 3ft (0.9m) above its point of
contact with the roof and at least 2ft (0.6m) higher than any wall,
roof or building within 10ft (3.1m).
If the chimney extends more than 5ft (1.5m) above the roof,
it must be secured using a roof brace or guide wires.
A
raincap must be installed to avoid internal damage and
corrosion.
Floor, Ceiling
Joist
LIVINGSPACE
Framed
Enclosure
2” (50.8mm)
clearance from
chimney to
combustible wall
Chimney Lengths
CeilingJoist
Chimney must be
totally enclosed
when passing
through living space
with a minimum 2”
(50.8mm) clearance
to combustibles.
3 ft.
(0.9m)
MIN.
2ft.
(0.6m)
59.2A
3 ft. (0.9m)
MIN. 2ft.
(0.6m)
10ft.
(3.1m)

W415-1501 / 05.15.15
18
EN
The first flue offset closest to the top of the unit must
be a minimum distance of 12" (304.8mm) from the top
of the appliance.
Attach an elbow to the chimney section, angled toward
the offset. Secure with 3 sheet metal screws.
To achieve the minimum offset, attach and secure a
second elbow. To achieve longer offsets, you may
install any available length of chimney pipe between
the elbows. Supports must be used on the first vertical
chimney section after a return elbow.
!
WARNING
CHIMNEY SECTIONS INSTALLED BETWEEN AN OFFSET AND RETURN REQUIRE STRUCTURAL
SUPPORT TO REDUCE OFF-CENTER LOADING AND TO PREVENT CHIMNEY SECTIONS FROM
SEPARATING AT THE CHIMNEY JOISTS.
THE CHIMNEY SHOULD NOT BE BUILT WITH AN OFFSET ANGLE IN EXCESS OF 45° IN CANADA AND
30° IN USA. DO NOT COMBINE OFFSET CHIMNEY COMPONENTS TO EXCEED THESE ANGLES.
Attic Insulation
Shield
StormCollar
Elbow
Elbow Support
Straps
Elbow
Roof
Flashing
Rain Cap
Elbow Support
Band
Roof Joist
Chimney Section
Floor , Ceiling Joist
If the offset length is
more than 36”
(914.4mm), an
intermediate support
must be employed.
To achieve longer
offsets, you may
install any available
length of chimney
pipe between the
elbows.The
intermediate support
must be used in
conjunction with an
offset support.
Firestop
63.6A
4.4 OFFSET CHIMNEY INSTALLATION

W415-1501 / 05.15.15
19
EN
The appliance may be connected
to either a lined or unlined masonry
chimney.
IF THE CHIMNEY IS LINED:
The flues must be made of vitrified
clay and be in sizes of 8”
(203.2mm) square or 8” (203.2mm)
round (inside diameters) or 8”x12”
[(203.2mm x 304.8mm)] with a
minimum height of 15 feet (4.6m)
above the appliance.
8” (203.2mm) round flues are
recommended.
Installation must conform to
both national and local code
requirements.
IF THE CHIMNEY IS UNLINED:
A
stainless steel liner listed to
either Standard ULC-S640M in Canada or UL-1777 in the USA,
must be used: Liners for New Masonry Chimneys, may be
used to connect the appliance to the chimney. The liner must
be continuous from the appliance to the chimney cap and be
installed only per manufacturers instructions.
In both cases, the chimney structure must be supported by angle
iron anchored into the masonry walls. The allowable masonry
used in chimney construction is 3 1/2” (88.9mm) brick, solidly
mortared and must fully encase the flue. Ensure there are no
leaks.
In no case is the masonry enclosure to be supported by the
appliance. Allow a 1” (25.4mm) air cavity for expansion. Use the flue tile support accessory, see your local
authorized dealer / distributor.
NOTE: The flue tile support is to be suspended on appropriate lintels. 62.4C
ANGLE IRON RESTS
ON BRICK SIDE-WALLS,
FREE OF UNIT.
FLUE TILE
HI-TEMP GASKET
ANGLE IRON
TO SUPPORT
CHIMNEY
WEIGHT
FLUE TILE
SUPPORT
APPLIANCE TOP
UNLINED CHIMNEY INSTALL
USE AN 7” (177.8mm)
OR 8" (203.2mm) LINER
WITH A DRIPLESS TYPE
A CONNECTOR
(IF USING 7”
(177.8mm) AN
INCREASER
MUST ALSO
BE USED).
LINER
SUPPORT
LINED CHIMNEY INSTALL
HI-TEMP GASKET
FIREPLACE TOP
FOR A MASONRY FIREPLACE USE A
FLUE TILE SUPPORT. FOR A
PRE-FABRICATED CHIMNEY USE AN
ANCHOR PLATE.
4.5 INSTALLING FLASHING AND STORM COLLAR
88.1A
Remove the nails from the shingles above and to the sides of
the chimney. Place the flashing over the chimney pipe and slide
underneath the sides and upper edge of the shingles. Ensure that
the chimney pipe is properly centered within the flashing, giving
a 3/4” (19.1mm) margin all around. Fasten to the roof on the top
and sides. DO NOT NAIL through the lower portion of the flashing.
Make weather-tight by sealing with caulking. Where possible, cover
the sides and top edges of the flashing with roofing material. Apply
waterproof caulking, provided with the flashing, around the chimney,
1” (25.4mm) above the top of the flashing and push the storm collar
down into the caulking. Insert a rain cap onto the top of the last
chimney section.
RAIN CAP
CAULKING
STORM COLLAR
WEATHER
SEALANT
FLASHING
4.6 CONNECTION TO A MASONRY CHIMNEY

W415-1501 / 05.15.15
20
EN
4.7 AIR COOLED CHIMNEY INSTALLATION
A. Remove the knock out.
B. Cut away the insulation to gain access to the ring.
C. Remove the ring secured by four screws.
D. Slide the starter collar through the insulation wrap and
affix using the four screws removed in step 3.
E. Secure the inner liner of the chimney to the appliance
8" (203mm) collar using 3 screws supplied with the
starter collar (W170-0098).
F. Follow the chimney manufacturer's instructions for
installing the chimney.
KNOCK-OUT
1
INSULATION
2
STARTER COLLAR
4
RING
3
Use only the following brand and type of chimney.
CHIMNEY COMPONENTS FMI 8DM
12" (304.8mm) Chimney Section 12-8DM
18" (457.2mm) Chimney Section 18-8DM
24" (609.6mm) Chimney Section 24-8DM
36" (914.4mm) Chimney Section 36-8DM
48" (1219.2mm) Chimney Section 48-8DM
Offsets 30E-8DM
Flashing 6F8 or 12F8
Chimney Cap RTL-8HT
Roof Support 38 RS
Firestop FS-8DM
CHIMNEY COMPONENTS WOLF STEEL
Starter Collar NZAC-KT
