Napoleon Ascent X Series User manual

FRENCH PG. 25
W415-1853 / A / 08.17.18
Ascent X™ Series
(GX42 illustrated)
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbour’s phone. Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency, or the supplier.
WARNING
!
ENGLISH
For indoor use only
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
OWNER’S MANUAL
SAFETY INFORMATION
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada / 103 Miller Drive, Crittenden, Kentucky, USA, 41030
Phone [phone] • www.napoleonappliances.com • [email protected]
GX42 Only GX36-1 & GX70-1

W415-1853 / A / 08.17.18
EN
2
safety information
• This appliance is hot when operated and can cause
severe burns if contacted.
• Any changes to this appliance or its control can be
dangerous and are prohibited.
• Do not operate appliance before reading and
understanding operating instructions. Failure
to operate appliance according to operating
instructions could cause fire or injury.
• Risk of fire or asphyxiation do not operate appliance
with fixed glass removed.
• Do not connect 110 volts to the control valve.
• Risk of burns. The appliance should be turned off
and cooled before servicing.
• Do not install damaged, incomplete or substitute
components.
• Risk of cuts and abrasions. Wear protective gloves
and safety glasses during installation. Sheet metal
edges may be sharp.
• Children and adults should be alerted to the
hazards of high surface temperature and should
stay away to avoid burns or clothing ignition.
• Young children should be carefully supervised
when they are in the same room as the appliance.
Toddlers, young children, and others may be
susceptible to accidental contact burns. A
physical barrier is recommended if there are at
risk individuals in the house. To restrict access to
an appliance or stove, install an adjustable safety
gate to keep toddlers, young children and other at
risk individuals out of the room and away from hot
surfaces.
• Clothing or other flammable material should not be
placed on or near the appliance.
• Due to high temperatures, the appliance should be
located out of traffic and away from furniture and
draperies.
• Ensure you have incorporated adequate safety
measure to protect infants/toddlers from touching
hot surfaces.
• Even after the appliance is out, the glass and/or
screen will remain hot for an extended period of
time.
• Check with your local hearth specialty dealer
for safety screens and hearth guards to protect
children from hot surfaces. These screens and
guards must be fastened to the floor.
• Any safety screen, guard or barrier removed for
servicing the appliance, must be replaced prior to
operating the appliance.
• The appliance is a vented gas-fired appliance. Do
not burn wood or other materials in the appliance.
• The appliance area must be kept clear and free
from combustible materials, gasoline and other
flammable vapors and liquids.
3.1
!
WARNING
• Under no circumstances should this appliance be
modified.
• This appliance must not be connected to a chimney
flue pipe serving a separate solid fuel burning
appliance.
• Do not use this appliance if any part has been
under water. Immediately call a qualified service
technician to inspect the appliance and to replace
any part of the control system and any gas control
which has been under water.
• Do not operate the appliance with the glass door
removed, cracked or broken. Replacement of the
glass should be done by a licensed or qualified
service person.
• Do not strike or slam shut the appliance glass door.
• When equipped with pressure relief doors, they
must be kept closed while the appliance is
operating to prevent exhaust fumes containing
carbon monoxide, from entering into the home.
Temperatures of the exhaust escaping through
these openings can also cause the surrounding
combustible materials to overheat and catch fire.
• Only doors / optional fronts certified with the unit
are to be installed on the appliance.
• Keep the packaging material out of reach of
children and dispose of the material in a safe
manner. As with all plastic bags, these are not toys
and should be kept away from children and infants.
• As with any combustion appliance, we recommend
having your appliance regularly inspected and
serviced as well as having a carbon monoxide
detector installed in the same area to defend you
and your family against carbon monoxide.
• Ensure clearances to combustibles are maintained
when building a mantel or shelves above the
appliance. Elevated temperatures on the wall or
in the air above the appliance can cause melting,
discolouration or damage to decorations, a T.V. or
other electronic components.
• A barrier designed to reduce the risk of burns from
the hot viewing glass is provided with this appliance
and shall be installed.
• If the barrier becomes damaged, the barrier shall
be replaced with the manufacturer’s barrier for this
appliance.
• Installation and repair should be done by a qualified
service person. The appliance should be inspected
before use and at least annually by a professional
service person. More frequent cleaning may be
required due to excessive lint from carpeting,
bedding material, etc. It is imperative that control
compartments, burners and circulating air
passageways of the appliance be kept clean.

EN
W415-1853 / A / 08.17.18 3
table of contents
1.0 getting to know your appliance 5
1.1 control access 6
1.2 rating plate information 6
2.0 operating your appliance 7
2.1 using your appliance 7
2.2 on/off components 7
2.2.1 changing the batteries in the battery holder 8
2.2.2 turndown (GX36-1 & GX42 only) 9
3.0 clearances around appliance 10
4.0 maintenance 12
4.1 care of glass 13
4.2 care of plated parts 13
4.3 safety barrier removal 14
4.4 firebox glass door removal 14
5.0 replacement parts 15
6.0 GX36-1 accessories 16
7.0 GX42 accessories 18
8.0 GX70-1 accessories 19
9.0 troubleshooting 20
10.0 warranty 21
11.0 service history 22
Changes, other than editorial, are denoted by a vertical line in the margin.
This owner’s manual is written for a complete series of appliances that have a variety of different features and
specifications. Before reading this manual, be sure you know which model of appliance that you have. This infor-
mation will have been filled out by the installer on the following page and on the rating plate that is permanently
attached to the appliance (see “rating plate information” section).
This manual is for the:
• Ascent X Series (GX36-1, GX42 and GX70-1 models)
If required, more detailed technical information is included in the appliance installation manual.
The information throughout this manual is believed to be correct at the time of printing. Wolf Steel Ltd. reserves
the right to change or modify any information within this manual at any time without notice.
Visit the Napoleon website for the most current version of your appliance’s manual.
!
WARNING:
Electric
This product can expose you to chemicals including lead and lead compounds,
Gas, Wood
Mantels (including Firebox)
Accessories / Metal
Accessories / Brick
Accessories / Powder Coat
Fibre
which are known to the State of California to cause cancer, and chemicals including BBP and
DEHP, which are known to the State of California to cause birth defects or other reproductive
harm. For more information, go to www.P65Warnings.ca.gov.
!
AVERTISSEMENT:
Ce produit peut vous exposer à des substances chimiques incluant le
plomb et les composés de plomb qui, selon l’État de Californie, causeraient le cancer, et des
substances chimiques incluant le BBP et DEHP qui, selon d’État de Californie, causeraient des
malformations congénitales ou autres dangers pour la reproduction.
Pour de plus amples renseignements, visitez le www.P65Warnings.ca.gov.
!
WARNING:
This product can expose you to chemicals including lead and lead compounds,
which are known to the State of California to cause cancer, and chemicals including carbon
monoxide, which are known to the State of California to cause birth defects or other reproduc-
tive harm. For more information, go to www.P65Warnings.ca.gov.
!
AVERTISSEMENT:
Ce produit peut vous exposer à des substances chimiques incluant le
plomb et les composés de plomb qui, selon l’État de Californie, causeraient le cancer, et des
substances chimiques incluant le monoxyde de carbone qui, selon d’État de Californie, cause-
raient des malformations congénitales ou autres dangers pour la reproduction.
Pour de plus amples renseignements, visitez le www.P65Warnings.ca.gov.
!
WARNING:
This product can expose you to chemicals including wood dust, which are
known to the State of California to cause cancer, and chemicals including BBP and DEHP,
which are known to the State of California to cause birth defects or other reproductive harm.
For more information, go to www.P65Warnings.ca.gov.
!
AVERTISSEMENT:
Ce produit peut vous exposer à des substances chimiques incluant le
poussière de bois qui, selon l’État de Californie, causeraient le cancer, et des substances
chimiques incluant le BBP et DEHP qui, selon d’État de Californie, causeraient des malforma-
tions congénitales ou autres dangers pour la reproduction.
Pour de plus amples renseignements, visitez le www.P65Warnings.ca.gov.
!
WARNING:
This product can expose you to chemicals including chromium, which are
known to the State of California to cause cancer, and chemicals including toluene, which are
known to the State of California to cause birth defects or other reproductive harm.
For more information, go to www.P65Warnings.ca.gov.
!
AVERTISSEMENT:
Ce produit peut vous exposer à des substances chimiques incluant le
chrome qui, selon l’État de Californie, causeraient le cancer, et des substances chimiques
incluant le toluène qui, selon d’État de Californie, causeraient des malformations congénitales
ou autres dangers pour la reproduction.
Pour de plus amples renseignements, visitez le www.P65Warnings.ca.gov.
!
WARNING:
This product can expose you to chemicals including silica, which are
known to the State of California to cause cancer.
For more information, go to www.P65Warnings.ca.gov.
!
AVERTISSEMENT:
Ce produit peut vous exposer à des substances chimiques incluant le
silice qui, selon l’État de Californie, causeraient le cancer.
Pour de plus amples renseignements, visitez le www.P65Warnings.ca.gov.
!
WARNING:
This product can expose you to chemicals including titanium dioxide, which
are known to the State of California to cause cancer, and chemicals including toluene, which
are known to the State of California to cause birth defects or other reproductive harm.
For more information, go to www.P65Warnings.ca.gov.
!
AVERTISSEMENT:
Ce produit peut vous exposer à des substances chimiques incluant le
dioxyde de titane qui, selon l’État de Californie, causeraient le cancer, et des substances
chimiques incluant le toluène qui, selon d’État de Californie, causeraient des malformations
congénitales ou autres dangers pour la reproduction.
Pour de plus amples renseignements, visitez le www.P65Warnings.ca.gov.
!
WARNING:
This product can expose you to chemicals including silica, which are known to
the State of California to cause cancer, and chemicals including toluene, which are known to
the State of California to cause birth defects or other reproductive harm.
For more information, go to www.P65Warnings.ca.gov.
!
AVERTISSEMENT:
silice qui, selon l’État de Californie, causeraient le cancer, et des substances chimiques
incluant le toluène qui, selon d’État de Californie, causeraient des malformations congénitales
ou autres dangers pour la reproduction.
Pour de plus amples renseignements, visitez le www.P65Warnings.ca.gov.
Ce produit peut vous exposer à des substances chimiques incluant le
!
ADVERTENICA:
Este producto puede exponerlo a productos químicos, entre ellos, plomo
y compuestos con plomo, que el Estado de California reconoce como causantes de cáncer, y
productos químicos, entre ellos, bencilbutilftalato (BBP, por sus siglas en inglés) y di(2-etilhex-
il) ftalato (DEHP, por sus siglas en inglés), que el Estado de California reconoce como caus-
antes de malformaciones congénitas u otros daños para la reproducción. Para obtener más
información, visite www.P65Warnings.ca.gov.

W415-1853 / A / 08.17.18
EN
4
welcome
Dealer Information
Name of Dealer:
Dealer Location:
Dealer Phone:
Dealer E-mail:
Customer:
Customer Address:
Date of Installation:
Location of the appliance:
Installer:
Napoleon is proudly committed to your total home comfort. We are proud to say that our products continunously
surpass industry standards and our inspiration is you! More than anything, we want you to feel confident in
choosing Napoleon for your home. Our products are designed to provide that confidence and ensure that every
Napoleon product is beyond compare.
Napoleon products are designed with superior components and materials assembled by trained craftsmen who
take great pride in their work.
A barrier designed to reduce the risk of burns from the hot viewing glass is provided with the appliance for your
safety. This barrier must be installed.
Your Napoleon appliance has been thoroughly inspected by a qualified technician before packaging to ensure that
you, the customer, receives the quality product that you expect from Napoloen.
Dealer : Fill in your dealer information (or business card) and the appliance installation information
below.
congratulations!
Model:
Serial Number:
Dealer: Business card location
Natural Gas: GX36NTR-1
GX36NTRE-1
GX42NTRE
GX70NTE-1
Propane: GX36PTR-1
GX36PTRE-1
GX42PTRE
GX70PTE-1

EN
W415-1853 / A / 08.17.18 5
getting to know your appliance
1.0 getting to know your appliance
Burner
Pilot
Safety barrier Glass door
Door trim Valve / rating
plate / lighting
instructions /
battery back up /
anticondensation
Some features and locations may vary depending on the model.
note:
LA VITRE CHAUDE CAUSERA DES
BRÛLURES.
NE PAS TOUCHER LA VITRE
AVANT QU’ELLE AIT REFROIDI.
NE JAMAIS LAISSER LES ENFANTS
TOUCHER LA VITRE.
HOT GLASS WILL CAUSE BURNS.
DO NOT TOUCH GLASS UNTIL
COOLED.
NEVER ALLOW CHILDREN TO
TOUCH GLASS.
!
DANGER
!
AVERTISSEMENT
A barrier designed to reduce the risk of burns from
the hot viewing glass is provided with this appliance
and shall be installed for the protection of children
and other at-risk individuals.
Une barriére conçu à réduire le risque de brûlures
causées par le verre chaud est fourni avec l’appareil
et sera installé pour la protection des enfants et
d’autres personnes à risque.
LA VITRE CHAUDE CAUSERA
DES BRÛLURES.
NE PAS TOUCHER LA VITRE
AVANT QU’ELLE AIT REFROIDI.
NE JAMAIS LAISSER LES
ENFANTS TOUCHER LA VITRE.
HOT GLASS WILL CAUSE
BURNS.
DO NOT TOUCH GLASS UNTIL
COOLED.
NEVER ALLOW CHILDREN TO
TOUCH GLASS.
!
WARNING
!
AVERTISSEMENT
The area above the appliance opening including the safety barrier, barrier frame and
the surface of the wall can get very hot during operation and should never be touched
until the appliance is off and completely cooled.

W415-1853 / A / 08.17.18
EN
6
getting to know your appliance
Access to the control can be done by removing the safety barrier, glass door, door trim and control cover (see
“maintenance” section for instructions on how to remove these components).
1.1 control access
FLAME ADJUSTMENT
KNOB
This illustration is for reference only. Refer to the rating plate on the appliance for accurate information.
1.2 rating plate information
The rating plate must remain with the appliance at all times. It must not be removed.
note:
MAX SIZE: 8.5" X 4.75"
HOLE TO BE 0.250"Ø / 0.312“ FROM EDGES
MATERIAL: CLASS III A-2, PERMANENT LABEL, WATERPROOF, 0.010 IN. VELVET MATTE LEXAN AND/OR 0.050 IN. HI-TEMP POLYESTER, CAPABLE OF WITHSTANDING A MAXIMUM
TEMPERATURE OF 175°F (79°C).
MIN. LETTERING FOR "NOT FOR USE WITH SOLID FUEL. ", "NE CONVIENT PAS AUX COMBUSTIBLES SOLIDES. " TO BE 10 POINT VOGUE, BOLD FACE, UPPER CASE AND 2
POINT LEADING SPACING OR EQUIVALENT.
BLACK LETTERING ON WHITE BACKGROUND.
SERIAL NUMBERS TO BE ASCENDING FROM GX42 023218
Certified to Canadian and American National Standards: CSA 2.22-2016 / ANSI Z21.50-2016 for Vented Decorative Gas Appliances
Certifié selon les normes Nationales Canadiennes et Américaines: CSA 2.22-2016 / ANSI Z21.50-2016 pour les Appareils à gaz décoratif à évacuation
Direct vent, vented gas fireplaces. Approved for bedroom, bathroom and bed-sitting room installation. Suitable for mobile home installation, if installed in accordance with the current
standard CAN / CSA Z240MH Series gas equipped mobile homes in Canada, or, in the United States, the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part
3280. When this US Standard is not applicable, use the Standard for Fire Safety Criteria for Manufactured Home Installations, Sites and Communities, ANSI / NFPA 501A. This appliance
must be installed in accordance with local codes, if any; if none, follow the current ANSI Z223.1 or CSA B149. For use with barrier W565-0307. Follow installation instructions.
Foyer à gaz ventilé. Homologué pour installation dans une chambre à coucher, une salle de bain et un studio. Approprié pour installation dans une maison mobile si son installation
conforme aux exigences de la norme CAN / CSA Z240MH Séries de maisons mobile équipées au gaz en vigueur au Canada, ou, aux États-Unis selon la norme 24 CFR, Part 3280,
Manufactured Home Construction and Safety Standard. Dans le cas ou cette norme d’États-Unis n’est pas pertinentes, utiliser la norme NFPA 501A, Fire Safety Criteria for Manufactured
Home Installations, Sites and Communities. Installer l’appareil selon les codes ou règlements locaux ou, en l’absence de tels règlements, selon les codes d’installation ANSI Z223.1 ou
CSA B149 en vigueur. Utiliser uniquement avec l’écran W565-0307. Suivre les instructions d’installation.
9700539 (WSL) 4001658 (NAC) 4001657 (NGZ) 4001659 (WUSA)
WOLF STEEL LTD. 24 Napoleon Road, Barrie, ON, L4M 0G8 Canada
GX42NTRE CX42NTRE CX42PTRE GX42PTRE
MODEL / MODÈLE
Altitude
Input
Reduced Input
P4
Élévation
Alimentation
Alimentation Réduite
P4
Manifold Pressure: 3.5” w.c. (NG)
Minimum Supply Pressure: 4.5” w.c. (NG)
Maximum Supply Pressure: 7”* w.c. (NG)
Pression au Collecteur: 3,5” d’une colonne d’eau (GN)
Pression d’Alimentation Min.: 4,5” d’une colonne d’eau (GN)
Pression d’Alimentation Max.: 7” ** d’une colonne d’eau (GN)
** Maximum inlet pressure not to exceed 13”.
Manifold Pressure: 10” w.c. (P)
Minimum Supply Pressure: 11” w.c. (P)
Maximum Supply Pressure: 13”* w.c. (P)
Pression au Collecteur: 10” d’une colonne d’eau (P)
Pression d’Alimentation Min.: 11” d’une colonne d’eau (P)
Pression d’Alimentation Max.: 13” * d’une colonne d’eau (P)
** Pression d’alimentation maximale ne devait pas dépasser 13”.
0-4500ft (0-1370m)
Minimum clearance to combustible materials:
Top, sides & back: per standoff spacers for framing and finishing
materials. For non-combustible framing and finishing materials,
see installation manual.
Top 0”
Floor 0”
Sides 0”
Back 0”
Vent top 3”
Vent sides & bottom 1”
Recessed depth 18 9/16”
*** Mantel 8” from appliance opening
Dégagements minimaux des matériaux combustibles:
Dessus, côtés et arrière: selon les espaceurs de dégagements
pour les matériaux d’ossature selon le manuel du propriétaire
pour les matériaux de finition.
Dessus 0”
Plancher 0”
Côtés 0”
Arrière 0”
Dessus du conduit d’évent 3”
Côtés et dessous du conduit d’évent 1”
Profondeur d’encastré une face 18 9/16”
*** Tablette 8” de l’ouverture de l’appareil
WARNING: Do not add any material to the appliance which will come in contact with the
flames, other than that supplied by the manufacturer with the appliance.
AVERTISSEMENT: N’ajoutez pas à cet appareil aucun matériau devant entretien
contact avec les flammes autre que celui qui est fourni avec cet appareil par le fabricant.
*** Maximum horizontal extension: 2”. See installation manual
for greater extensions, minimum vent lengths and maximum
vent lengths.
*** L’extension horizontale maximale: 2”. Référez au manuel d’installation
pour des extensions plus grandes, les longueurs d’évacuation minimaux et
maximum.
The appliance must be vented using the appropriate Napoleon vent kits. See installation
manual for venting specifications. Proper reinstallation and resealing is necessary after servicing
the vent-air intake system.
L’appareil doit être ventilé à l’aide de l’ensemble d’évacuation propre à Napoleon. Référez au
manuel d’installation pour les spécifications d’évacuation. Il est nécessaire de bien réinstaller et
resceller l’évacuation après avoir executer l’entretien du système de prise d’air.
Optional fan kit: AUB / GZ600KT
Ensemble de ventilateur facultatif: AUB / GZ600KT
Serial Number / N° de Série:
W385-2246 / C
TITLE: LABEL, RATING PLATE (C)GX42(N)TRE / (C)GX42(P)TRE
REVISION: C: Updated recessed depth || 08.08.18_JFK
DWG#: W385-2246
DATE: 06.25.18_JDP
WOLF STEEL LTD.
REFERENCE# 161746
GX42
51.27%
22,000
30,000
Electrical rating: 115V, 60HZ. Less than 12 amperes.
Spécifications électriques: 115V, 60HZ. Moins de 12 ampère.
VENTED DECORATIVE GAS APPLIANCE: NOT A SOURCE OF
HEAT, NOT INTENDED FOR USE AS A HEATING APPLIANCE,
NOT FOR USE WITH SOLID FUEL.
APPAREIL À GAZ DÉCORATIF À ÉVACUATION: N’EST PAS
UNE SOURCE DE CHALEUR; N’EST PAS DESTINÉ À ÈTRE
UTILISÉ COMME UN APPAREIL DE CHAUFFAGE; NE
CONVIENT PAS AUX COMBUSTIBLES SOLIDES.
FOR USE WITH GLASS DOORS CERTIFIED WITH THIS APPLIANCE ONLY.
POUR UTILISATION UNIQUEMENT AVEC LES PORTES EN VERRE
CERTIFIÉES AVEC L’APPAREIL.
24,000
C
PAGE 1 OF 2
CERTIFIEDUNDER / HOMOLOGUE SELON LES NORMES: CSA 2.33b - 2008, ANSI Z21.88b- 2008 VENTED GAS FIREPLACE HEATER / APPAREILDE CHAUFFAGE ALIMENTÉ
AUGAZ ET VENTILÉ
VENTEDGAS FIREPLACE HEATER.APPROVED FOR BEDROOM, BATHROOMAND BED-SITTING ROOM INSTALLATION.SUITABLE FOR MOBILE HOME INSTALLATIONIF INSTALLED INACCORDANCE WITH THE
CURRENTSTANDARDCAN/CSA Z240MH SERIES GAS EQUIPPED MOBILE HOMES, IN CANADAOR IN THE UNITED STATES THE MANUFACTUREDHOME CONSTRUCTION AND SAFETY STANDARD,TITLE 24 CFR,
PART3280. WHEN THISUS STANDARD IS NOT APPLICABLE USE THE STANDARDFOR FIRE SAFETY CRITERIA FOR MANUFACTUREDHOME INSTALLATIONS,SITES AND COMMUNITIES, ANSI / NFPA501A.
FOYERDE CHAUFFAGEAU GAZ AVEC ÉVACUATION.HOMOLOGUÉ POUR INSTALLATIONDANS UNE CHAMBRE À COUCHER, UNE SALLE DE BAIN ET UN STUDIO.APPROPRIÉ POUR INSTALLATIONDANS UNE
MAISONMOBILE SI SON INSTALLATIONCONFORME AUX EXIGENCES DE LANORME CAN/CSA Z240MH SÉRIE DE MAISONS MOBILES ÉQUIPÉESAU GAZ, EN VIGUEUR AU CANADA OU AUX ÉTATS-UNISDE LA
NORMEDE SECURITÉ ET DE CONSTRUCTION DE MAISONSMANUFACTURÉES, TITRE 24 CFR, SECTION 3280. DANS LE CAS OU CETTENORME D'ÉTATS-UNIS NE PEUT ÊTREAPPLIQUÉE, SE RÉFÉRER A LA NORME
RELATIVEAUCRITÈRE DE MESURES DE SÉCURITÉ CONTRE L'INCENDIE POUR LES INSTALLATIONSDANS LES MAISONS MANUFACTURÉS,LES SITES ET LES COMMUNAUTÉS, ANSI/NFPA501A.
NOTFOR USE WITH
SOLIDFUEL. FOR USE
WITHGLASS DOORS
CERTIFIEDWITH THIS
UNITONLY.
WARNING
:
DONOT ADD ANY MATERIAL
TOTHE APPLIANCE, WHICH WILL COME
INCONTACT WITH THE FLAMES, OTHER
THANTHAT SUPPLIED BY THE
MANUFACTURERWITH THE APPLIANCE.
MINIMUMCLEARANCE TO
COMBUSTIBLEMATERIALS:
TOP 0”
FLOOR 0”
RECESSEDDEPTH ONE SIDED 23"
RECESSEDDEPTH SEE THRU 13.5”
FRAMING (NOT INCLUDING
FACE MATERIAL)
SIDES 0”
VENT 2"
BACK 0”
MANTLE 15"*
TOP,SIDES& BACK: PER STAND OFF SPACERS FOR FRAMING MATERIALS. FOR FINISHING MATERIALS
SEEOWNERS MANUAL
UNCOMBUSTIBLE SOLIDE NE
DOITPAS ÊTRÉ UTILISÉ AVEC
CETAPPAREIL. UTILISER AVEC
LESPORTES VITRÉES
HOMOLOGUÉESSEULEMENT
AVECCETTE UNITÉ.
AVERTISSEMENT:
N'AJOUTEZPAS A
CETAPPAREILAUCUN MATÉRIAU DEVANT
ENTREREN CONTACT AVECLES FLAMMES
AUTREQUE CELUI QUI EST FOURNI AVEC
CETAPPAREIL PARLE FABRICANT.
DÉGAGEMENTSMINIMAUX DES
MATÉRIAUXCOMBUSTIBLES:
DESSUS 0”
PROFONDEURD'ENCASTRÉ 25"
PLANCHER 0”
ÉVENT 2"
CÔTES 0”
MANTEAU 15" *
ARRIÉRE 0”
MADEIN CANADA / FABRIQUÉAU CANADA
WOLFSTEEL LTD.BARRIE, ONTARIO, CANADA
ALTITUDE/ÉLÉVATION
INPUT/ALIMENTATION
REDUCEDINPUT/ALIMENTATIONRÉDUITE
ORIFICE/INJECTEUR
MANIFOLDPRESSURE/
PRESSIONAUCOLLECTEUR
MINIMUMSUPPLYPRESSURE/
PRESSIOND'ALIMENTATIONMINIMALE
MAXIMUMSUPPLYPRESSURE/
PRESSIOND'ALIMENTATIONMAXIMALE
0-4500FT(0-1370M)
30,000BTU/H
23,000BTU/H
#38
3.5"WATERCOLUMN/D'UNECOLONNED'EAU
4.5"WATERCOLUMN/D'UNECOLONNED'EAU
7.0"WATERCOLUMN/D'UNECOLONNED'EAU
0-4500FT(0-1370M)
30,000BTU/H
23,000BTU/H
#53
10"WATERCOLUMN/D'UNECOLONNED'EAU
11"WATERCOLUMN/D'UNECOLONNED'EAU
13"WATERCOLUMN/D'UNECOLONNE D'EAU
THEAPPLIANCE MUST BE VENTED USING THE APPROPRIATE
NAPOLEONVENT KITS. SEE OWNERS INSTALLATION MANUAL
FORVENTING SPECIFICS. PROPER REINSTALLATIONAND
RESEALINGIS NECESSARY AFTER SERVICING THE VENT-AIR
INTAKESYSTEM.
L'APPAREILDOIT ÉVACUERSES GAZ EN UTILISANT L'ENSEMBLE
D'ÉVACUATIONPROPREA NAPOLEON. RÉFÉRER AU MANUEL
D'INSTALLATIONDEPROPRIÉTAIRE POUR L'ÉVACUATION
PRÉCISE.IL EST IMPORTANT DE BIEN RÉINSTALLERET
RESCELLERL'ÉVENT APRÈS AVOIRASSURÉ LE MAINTIEN DU
SYSTÉMEDE PRISE D'AIR.
CLASSIFICATION:115V 0.82AMP,60HZ
W385-2007
MODEL NATURALGAS /
GAZ NATURAL
LHD50NT
MODEL PROPANE
LHD50PT
SERIALNUMBER/NO. DE SÉRIE: LV50
ELECTRICALRATING: 115V0.82AMP, 60HZ
REFERENCE#
W/N16131
*MAXIMUM HORIZONTAL EXTENSION / L'EXTENSION
HORIZONTALEMAXIMALE: 2". SEE INSTRUCTION MANUAL FOR GREATEREXTENSIONS.
SEEOWNER'S INSTRUCTION MANUAL FOR MINIMUM AND MAXIMUM VENT LENGTHS.
DESSUS,COTÉS&ARRIÈRE:SELONLESESPACEURSDEDÉGAGEMENTPOURLES MATÉRIAUXD'OSSATURE
SELONLEMANUELDEPROPRIÉTAIREPOURLESMATÉRIAUXDEFINITION.
*L'EXTENSIONHORIZONTALEMAXIMALE: 2". RÉFÉRERAU MANUELD'INSTRUCTIONPOURDESEXTENSIONS
PLUSGRANDES.RÉFÉRERAUMANUELD'INSTALLATION DE PROPRIÉTAIRE.
CAUTION:
Hot while in operation. Do not touch. Severe
burns may result. Keep children, clothing,
furniture, gasoline and other liquids having
flammable vapors away.
ATTENTION:
L’appareil est chaud lorsqu’il fonctionne. Ne pas
toucher l’appareil. Risque de brûlures graves.
Surveiller les enfants. Garder les vêtements, les
meubles, l’essence ou autres liquides produisant
des vapeur inflammables loin de l’appareil.
TITLE: RATING PLATE (C)GX42(N)TRE / (C)GX42(P)TRE
DWG#:W385-2246
DATE:06.25.18_JDP
PAGE 2 OF 2
WOLF STEEL LTD.
S’assurer que le brûleur et
le compartiment des
commandes sont propres.
Voir les instructions
d’installation et
d’utilisation qui
accompagnent l’appareil.
Par mesure de sécurité,
cet appareil doit être
alimenté en air frais et
avec d’air
comburant et de
ventilation suffisant.
This appliance is only for use with the type of gas
indicated on the rating plate and may be installed
in an aftermarket, permanently located, manufac-
tured home (USA only) or mobile home where not
prohibited by local codes. See owner’s manual
for details. This appliance is not convertible for
use with other gases, unless a certified kit is
used.
Cet appareil doit être utilisé uniquement avec le
type de gaz indiqué sur la plaque signalétique.
Cet appareil peut être installé dans une maison
préfabriquée ou mobile (É.U. seulement) installée
à demeure si les règlements locaux le permettent.
Voir la notice de l’utilisateur pour plus de
renseignements. Cet appareil ne peut pas être
utilisé avec d’autres gaz sauf si une trousse de
conversion certifiée est fournie.
FOR YOUR SAFETY:
Do not store or use gasoline or
other flammable vapors and liquids
in the vicinity of this or any other
appliance.
CAUTION:
Do not operate the appliance with
the glass removed, cracked or
broken.
Replacement of the glass should
be done by a licensed or qualified
person.
POUR VOTRE
SÉCURITÉ:
Ne pas entreposer ni utiliser
d’essence ni d’autres vapeurs ou
liquides inflammables dans le
voisinage de cet appareil ou de
tout autre appareil.
ATTENTION:
N’utiliser pas l’appareil si le
panneau frontal en verre est
enlevé, craqué ou brisé.
Remplacement du panneau frontal
en verre doit être fait par un
technicien agréé.
WARNING:
Improper installation,
adjustment, alteration,
service or maintenance can
cause property damage,
personal injury or loss of life.
Refer to owner’s manual.
Installation and service must
be performed by a qualified
installer, service agency or
the gas supplier.
AVERTISSEMENT:
Un installation
ou une modification
inappropriée du réglage, du
service et de l’entretien
pourraient être la cause de
dommages à la propriété de
blessures corporelles ou
même la mort. Consulter le
manuel d’information,
l’installation et le service
doivent être exécutés par un
installateur qualifié pour le
gaz, un entreprise de
service ou le fournisseur de
gaz seulement.
Keep burner and control
compartment clean. See
installation and
operating instructions
accompanying
appliance. Appliance
needs fresh air for safe
operation and must be
installed with adequate
provisions for
combustion and
ventilation air.
REVISION: C: Updated recessed depth || 08.08.18_ JFK
MAX SIZE: 8.5" X 4.75"
HOLE IS 0.250” Ø / 0.312“ FROM EDGES
MATERIAL: CLASS III A-2, PERMANENT LABEL, WATERPROOF, .010MIL VELVET MATTE LEXAN AND/OR .050 HI-TEMP POLYESTER, CAPABLE OF WITHSTANDING A MAXIMUM
TEMPERATURE OF 175°F (79°C).
MIN. LETTERING FOR "NOT FOR USE WITH SOLID FUEL. ", "NE CONVIENT PAS AUX COMBUSTIBLES SOLIDES. " TO BE 10 POINT VOGUE, BOLD FACE, UPPER CASE AND 2
POINT LEADING SPACING OR EQUIVALENT.
BLACK LETTERING ON WHITE BACKGROUND.
SERIAL NUMBERS TO BE ASCENDING FROM GX42 023218
SAMPLE
VALVE

EN
W415-1853 / A / 08.17.18 7
operating your appliance
2.0 operating your appliance
To turn the appliance on:
When operating your appliance for the first time, there is a required burn-in process that cures materials used
to manufacture the appliance that may emit both vapors and an odor. These are normal when operating a new
appliance for the first time. Ensure adequate air circulation is provided during burn-in process, if this was not
completed by the installer during installation.
2.1 using your appliance
A Turn the on/off switch on (see below).
B After 3-5 seconds, the control will start a spark at the pilot, light the pilot and then the burner. The spark
period will last 60 seconds, or until the pilot has lit.
C When used for the first time, if the burn-in process was not completed by the installer; run appliance
continuously for 4 hours (burn-in).
D Turn the appliance off. Wait until appliance is completely cool before moving to the next step.
E Remove the safety barrier and firebox glass door. Clean firebox glass door (see “maintenance” section).
Replace firebox glass door and safety barrier.
For more detailed information, see your installation manual or contact your authorized dealer.
2.2 on/off components
Batteries must be disposed of according to the local laws and regulations. Some batteries may be
recycled, and may be accepted for disposal at your local recycling center. Check with your
municipality for recycling instructions.
Les piles doivent être mises au rebut conformément aux lois et à la réglementation locales.
Certaines piles peuvent être recyclées et acceptées dans votre centre de recyclage local. Rensei-
gnez-vous auprès de votre municipalité au sujet des directives de recyclage.
Las baterías deben desecharse de acuerdo con las leyes y regulaciones locales. Algunas baterías
pueden reciclarse, y es posible que su centro de reciclado local las acepte para desecharlas.
Consulte en su municipalidad sobre las instrucciones para el reciclado.
| On/off switch | Battery holder | Battery holder (including switch) | Remote control
(Optional for GX36-1 and
GX42)
(Not supplied)
(Standard for GX70-1) (Standard for GX70-1)
(Optional for GX36-1 and
GX42)

W415-1853 / A / 08.17.18
EN
8
operating your appliance
2.2.1 changing the batteries in the battery holder
• Ensure the gas and electrical power to the appliance is turned off.
• Appliance may be hot, do not service until the appliance has cooled.
!WARNING
A. Turn off the gas and disconnect the electrical power supply from the appliance.
B. Remove the safety barrier, control cover and door trim to easily access the control compartment (see
“maintenance” section for instructions on how to remove these components).
C. Locate the battery housing located near the control board (see illustration below).
D. Open the battery housing by sliding the back piece upwards and off of the battery housing. Remove the
four “AA” alkaline batteries and install four new “AA” alkaline batteries into the battery housing. Ensure the
positive and negative ends correspond with those identified on the holder.
E. Place the battery housing back into the control compartment, ensure that the battery housing is placed in
a clean and easily accessible location.
F. Reinstall the safety barrier. The safety barrier must be installed at all times during the appliance operation.
G. Turn the gas and electrical power back on to begin operating the appliance.
In the event of a power failure, your appliance can be operated using the supplied battery back-up. If a power
failure occured, remove the batteries from the holder once the power has been restored.
note:
Control module
Battery housing
Red wire
Black wire
Red wire
Black wire
Control module
Battery housing

EN
W415-1853 / A / 08.17.18 9
operating your appliance
L
O
H
I
Flame adjustment
Manual adjustments to your appliance must only be made when the appliance is off and completely
cool. Allow safety barrier to cool before making adjustment.
The GX36-1 and GX42 models are equipped with a manual gas control knob (located on the valve) that adjusts
the flame height to suit your preference. To access the gas control knob, remove your safety barrier, control cover
and door trim (see “maintenance” section for instructions on how to remove these components.
Use only your hand to turn the gas control knob (never use tools). If the knob will not turn by hand, do not try to
repair it. Contact a qualified technician.
2.2.2 turndown (GX36-1 & GX42 only)
An optional remote control is available to turn the appliance on and off and to adjust the flame height without the
need to remove the safety barrier, refer to the instructions provided with the remote control.

W415-1853 / A / 08.17.18
EN
10
clearances around fireplace
!WARNING
• Your appliance, gas/electrical connections, venting and various key components are hidden behind the wall. It is
critical that no screws penetrate these components. Failure to follow instructions may cause improper operation,
damage, personal injury or fire. Always use a stud finder and only screw into studs.
3.0 clearances around appliance
Without making adequate provisions to account for the heat, the temperatures above the appliance will be hot,
making it unsuitable for mounting a TV or other objects sensitive to heat without risk of damage.
Installing a mantel between this appliance and electronics or other materials that may be sensitive to heat will reduce
the effect of direct heat on them.
The size and material of the mantel will affect the allowable clearance above your appliance and incorrect placement
could become a fire hazard. Consult your installation manual and/or authorized dealer for more information before
mounting a mantel, a shelf or any other object above your appliance.
Your appliance, gas/electrical connections and vent are hidden directly behind the finished wall. Great care should be
taken to avoid screwing or nailing into these components. Always use a stud finder to determine stud location and
only screw into studs.
Do not screw into the area around the appliance opening as some of your appliance may be hidden behind the
finished wall. Refer to your installation manual and/or contact your local dealer for more information.
Fireplaces
generate radiant
heat. Do not put
objects in front
of the appliance
(minimum
distance of 4 feet
[1.21m]).
The area above an appliance gets hot.
Combustible objects or materials must
never be placed in this area. For mini-
mum clearances, refer to installation
manual or your authorized dealer.
!WARNING

EN
W415-1853 / A / 08.17.18 11
clearances around fireplace
6” min.
A
Top of finishing flange
(fireplace opening)
2.5” min.
2” min. (3” max. recommended)
6” min.
A
2.5” min.
6” min.
2.5” min.
A
See “minimum clearance
to mantle” section
(installation manual).
Enclosure
Enclosure
Enclosure
TV bracket
TV bracket
TV bracket
Flush installation with mantel
Partially recessed installation with mantel
Recessed installation with protrusion
Top of finishing flange
(fireplace opening)
Top of finishing flange
(fireplace opening)
2” min. (3” max. recommended)
2” min. (3” max. recommended)
Top of
finishing
flange
(fireplace
opening)
Enclosure
TV bracket
Flush installation without mantel
Appliance Appliance
Appliance
Appliance
• These are recommended minimum clearances only and are in supplied in good faith and not a guarantee
of compliance with TV manufacturers’ maximum allowable operating temperatures. Always comply to TV
manufacturers’ requirements.
• TV temperatures must be validated at the time of installation as air flow characteristics within the
room can vary and maximum acceptable operating temperatures can vary from appliance to appliance.
TVs cannot be used where the TV temperature exceeds the manufacturer’s maximum allowable operating
temperatures (see TV manufacturer’s specifications).
• Mantel height and depth must conform to mantel clearance requirements specified in this manual, see
“minimum clearance to combustible mantel” section in installation manual.
• Dimension “A” the gap between the top of the finishing flange and the bottom of the TV are taken from the
top of the appliance opening.
• TV temperatures may be further reduced by increasing the horizontal distance between the front of the TV
and the front edge of the mantel or by increasing dimension “A”. However, increasing the gap between the
top of the mantel and the bottom of the TV beyond the maximum recommended figure, typically results in
higher temperatures. Minimum clearance between the mantel and bottom of the TV should be maintained to
allow air circulation below and behind the TV.
note:

W415-1853 / A / 08.17.18
EN
12
maintenance4.0 maintenance
!WARNING
• Turn off the gas and electrical power before servicing the appliance.
• Appliance may be hot. Do not service until appliance has cooled.
For qualified technicians only:
• Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous
operation. Verify proper operation after servicing.
• This appliance and its venting system should be inspected before use and at least annually by a qualified service
person.
• The flow of combustion and ventilation air must not be obstructed.
DOS
• Clean your safety barrier or regularly to prevent
the build up of excessive lint/dust from carpeting,
pet hair, etc. Simply vacuum using the brush
attachment.
• Always use ammonia-free glass cleaners.
• Service your appliance annually and/or as
required. Service must be conducted by a qualified
technician.
• Keep your appliance area clear and free of
