National Flooring Equipment DL2000 User manual

Read this manual before servicing machine
403082 Rev H
DL2000 DUST COLLECTOR
SERVICE MANUAL

Introduction
The manual must be kept with the dust collector at all times.
This manual provides all the information needed to use and service your dust collector. Good operation and
durability depend on proper maintenance and careful use.
Before leaving the factory, this particular model has undergone stringent tests to ensure utmost reliability.
Always check however to make sure the dust collector has not been damaged during transport in such a
way as to affect operation and safety.
This manual should be considered an integral part of the dust collector and must be kept together with the
unit. In case of loss of or damage to the manual, ask National Flooring Equipment (NFE) for a new copy.
Some details shown in the illustrations in this manual may be different from those of your dust collector.
Some component parts may have been removed for greater clarity.
The subjects dealt with in this manual are those expressly required by "Machine Directive 2006/42/CE"and
the technical details shown are those provided by the manufacturer at the time of compilation.
This manual must be kept in a place accessible to all the personnel charged with operating and servicing the
dust collector.
In case of any doubts, immediately contact NFE Technical Service.
NFE CUSTOMER SERVICE
Our engineers are available to help you in case any problem occurs.
Please call 1-800-245-0267

Table of Contents
Information Section
1.1 Identification of main parts ..............................................................................................................1
1.2 Replaceable filters ............................................................................................................................2
1.3 Technical details ...............................................................................................................................3
1.4 Warranty...........................................................................................................................................4
Safety Section
2.1 Safety details ....................................................................................................................................5
2.2 Safety warnings ................................................................................................................................6
2.3 Electrical practices............................................................................................................................9
2.4 Safety plates and symbols ..............................................................................................................11
2.5 Outstanding risks............................................................................................................................12
2.6 Applied directives ...........................................................................................................................12
Maintenance Section
3.1 Informative notes ...........................................................................................................................13
3.2 General safety warnings.................................................................................................................13
3.3 Maintenance operations ................................................................................................................14
3.4 Replacing the filter .........................................................................................................................15
3.5 Filter replacement schedule...........................................................................................................16
3.6 Troubleshooting .............................................................................................................................17
Parts Section
4.1 Recommended spare parts ............................................................................................................18
4.2 Accessories .....................................................................................................................................20
4.3 Parts lists and diagrams..................................................................................................................22

Information
- 1 -
403082 Rev H
1.1 Identification of main parts
1) Motor head
2) Push handle
3) DUSTOP flap for filter cleaning
4) Filtering chamber
5) Removable Longopac® container
6) Fixed wheels
7) Casters
8) Longopac® bag
9) Suction inlet with slide damper
10) Filter access clamp
1
5
4
6
3
2
7
9
10
8

Information
- 2 -
403082 Rev H
1.2 Replaceable filters
402467 – Filter, Primary
(ONLY REPLACEMENT FILTER)

Information
- 3 -
403082 Rev H
1.3 Technical details
Product Specifications
Vacuum
Pressure
Air
Movement
Noise
Emission
Filter Efficiency Filter Area Inlet
88.6” H
2
O
(2,250 mm H2O)
206 CFM
(350 m
3/
h)
75 dBA 99.995 @ .18 microns
32.3 ft2
(30,000 cm
2
)
2” (50 mm)
Product Specifications
Width Height Length Weight
22” (56 cm) 51.2” (130 cm) 20.9” (53 cm) 125.7 lbs (57 kg)
Machine Variants
Region Serial Number Input Power Power
Domestic 10XXXX 120V / 60 Hz 2.7 hp (2 kW)
International
11XXXX 230V / 50 Hz 2.7 hp (2 kW)
20XXXX 110V / 50 Hz 2.7 hp (2 kW)
28XXXX 100V / 50/60 Hz 2.0 hp (1.5 kW)

Information
- 4 -
403082 Rev H
1.4 Warranty
National Flooring Equipment Inc. (referred to as “The Company”) warrants that each new unit
manufactured by The Company to be free from defects in materials and workmanship in normal use and
service for a period of twelve (12) months from date of shipment from The Company to the end user. If
shipment to end user is from a Distributor, The Company may honor warranty for up to 15 months from
initial shipment from the Company if the end user can provide documentation of receipt date. Accessories
or equipment furnished and installed on the product by the Company but manufactured by others,
including but not limited to: engines, motors, electrical components, transmissions etc., shall carry the
accessory manufacturers own warranty. Battery warranties are prorated over the warranty period.
Customer is responsible for the inspection of equipment or parts upon delivery. Freight damages are
excluded from this warranty.
The Company, at its determination of defect, will repair or replace any product or part deemed to be
defective in material or workmanship within specified warranty time period. All product determinations and
/ or repairs will take place at The Company repair facility or at a certified warranty location designated by
The Company. The Company will coordinate and be responsible for all freight expenses associated with
valid warranty claims. Freight and shipping expenses associated with abuse or misuse will be back charged
to the Distributor/Customer. The Company reserves the right to modify, alter or improve any part / parts
without incurring any obligation to replace any part / parts previously sold without such modified, altered
or improved part / parts. In no event shall the seller or manufacturer of the product be liable for special,
incidental, or consequential damages, including loss of profits, whether or not caused by or resulting from
the negligence of seller and / or the manufacturer of the product unless specifically provided herein. This
warranty shall not apply to any products or portions there of which have been subjected to abuse,
misuse, improper installation or operation, lack of recommended maintenance, electrical failure or
abnormal conditions, and to products which have been tampered with, altered, modified, repaired,
reworked by anyone not approved or authorized by the Company or used in any manner inconsistent
with the provisions of the above or any instructions or specifications provided with or for the product.
Any and all unauthorized onsite warranty work conducted by unauthorized personnel or any outside
person(s), is not covered by The Company unless the work has been pre-authorized by a predetermined
manufacturer representative. This warranty excludes wearable parts and/or consumables.
Defective or failed material or equipment shall be held at the purchaser’s premises until authorization has
been granted by The Company to return or dispose of defective products. Products returned to The
Company for inspection must be returned with a manufacturer authorized Return Material Authorization
(RMA), and must be packaged to The Company’s specifications to avoid damage during shipment. Any
unauthorized return of equipment will be declined at the dock by The Company. Any non-approved items
returned with approved returned items are subject to rejection and will not be credited. Credit will be
issued for material found to be defective upon The Company’s inspection based on prices at time of
purchase.
To obtain a Material Safety Data Sheet and/or a copy of the CE Declaration of Conformity please contact
National. This product is CE compliant.
TO OBTAIN SERVICE CONTACT NATIONAL FLOORING EQUIPMENT, INC. TOLL FREE AT 800-245-0267 FOR A
REPAIR AUTHORIZATION NUMBER. COD FREIGHT RETURNS WILL NOT BE ACCEPTED. FREIGHT COLLECT
SHIPMENTS WILL NOT BE ACCEPTED. WARRANTY REPAIRS MUST BE ACCOMPANIED BY DATE OF
PURCHASE RECEIPT AND A RETURN/REPAIR AUTHORIZATION NUMBER.
RETURN/REPAIR AUTHORIZATION NUMBER: _____________________________
MACHINE SERIAL NUMBER: ____________________________________________

Safety
- 5 -
403082 Rev H
2.1 Safety details
The person in charge of safety shall be responsible for informing workers about the risks associated with
dust collector operation.
The obligation also exists of training workers so they are able to protect themselves and others.
Failure to observe basic safety regulations and warnings could cause accidents during dust collector
operation, maintenance and repair. Accidents can often be avoided by recognizing potentially dangerous
situations before these occur. Operators should be aware of potential hazards and be trained and skilled
enough. They should also have the tools necessary to perform these duties properly.
NFE shall under no circumstances be deemed liable for accidents or damage caused by use of the dust
collector by personnel not properly trained or who use it in an improper manner, as well as by even partial
failure to comply with the safety regulations and intervention procedures indicated in this manual.
The safety warnings and warning notices are indicated in this manual and on the product.
Unless these hazard messages are heeded, the operator could become involved in accidents with serious
consequences for him/herself and for other people.
The safety messages are highlighted by the following symbols:
Warning!
Unless these messages are heeded, operator injuries could occur.
Caution!
Unless these messages are heeded, dust collector damage could occur.
NFE cannot foresee all possible circumstances capable of representing a potential hazard. The warnings in
this manual and on the products should not therefore be deemed exhaustive. In the event of tools,
procedures, work or machining methods being used that are not explicitly recommended by NFE, make sure
no hazards exist for operators and others.
Only ever use original NFE spare parts.
NFE declines all liability in the event of non-original spare parts being used.

Safety
- 6 -
403082 Rev H
2.2 Safety warnings
Warning!
The following indications are, by themselves, not enough to fully protect against all the hazards that
could arise during dust collector operation. These will have to be integrated with common sense and the
experience of the operator, both of which are crucial factors for preventing accidents. Each section of this
manual lists further specific safety warnings for the various operations.
Maintenance jobs must always be performed with the power plug detached from the power source.
The employer must inform and train the user according to the provisions of applicable laws.
Before using the machine, prepare and train yourself by reading this manual carefully. Use of the machine
by untrained and unauthorized persons is forbidden.
Using the machine to vacuum toxic substances is forbidden unless this has been equipped with special
filters required for the specific type of dusts. Such filters must be explicitly requested by you.
If the machine is used to vacuum toxic-harmful substances, the Longopac® bag must be emptied and the
filters cleaned using adequate individual protection devices, selected according to the type of substances to
be vacuumed.
Do not vacuum flammable materials or substances which could cause explosions (fuels, solvents, etc.). To
vacuum such materials, the machine must be built with Anti-explosion Motor and Electric System and this
must be requested by you explicitly.
Do not vacuum corrosive substances unless the machine is equipped with containers suitable for this
purpose (Stainless-steel AISI 304).
Use of the machine without the supplied filters is not recommended.
If the filters are correctly fitted, the machine will not emit any dust.
Never rest miscellaneous materials on the horizontal protection guard.
The machine casing containing moving parts must not be removed by the user.
When using the machine, mind other people, especially children.
Use the machine cautiously on slopes and ramps.
Do not change direction on gradients.
Make sure the parked machine remains stable by operating the braked wheel.
During cleaning operations, maintenance jobs or when changing parts, the starter switch must be off and
the machine must be disconnected from the power mains by removing the cable from the socket.
Only skilled persons should carry out repairs.
During use, protect the power supply cables from damage and avoid crushing or pulling the cables.

Safety
- 7 -
403082 Rev H
Periodically check the main power cable to ensure this is not damaged.
In the event of the cable being damaged, the machine must not be used.
In the event of the cable, plugs or couplings being replaced, make sure these are protected against water
spray and check mechanical strength.
Never pull the machine by means of the power cable and the vacuum hose.
Replace the motor brushes every 800 hours. Always use original spare parts.
The user is responsible for disposing of vacuumed substances in accordance with applicable laws.
In the event of customers fitting a tool to the machine not supplied by NFE, make sure the safety conditions
required by Machine Directive 2006/42/CE are complied with and in any event, NFE is unable to accept
liability for any problems arising from use of such tool.
The dust collector must not be operated in a corrosive or explosive environment.
Always make sure the dust collector is free of all foreign materials such as debris, oil, equipment and other
objects that could affect operation and cause injury to persons.
Avoid using flammable or toxic solvents such as gasoline, benzene, ether and alcohol for cleaning.
Avoid prolonged contact with solvents and inhaling their vapours. Avoid use close to open flames or sources
of heat.
Never use the dust collector without the filter.
Do not vacuum lit cigarette ends or burning material. The filter could be damaged and the machine could
start on fire.
Do not vacuum gasoline or flammable liquids in general.
Make sure all the guards and protection devices are in place and that all the safety devices are in place and
working properly.
Do not wear loose or hanging clothing such as ties, scarves or torn garments that could become trapped
and be sucked up by the cleaner.
Do not open the Longopac® bag with the machine running.
Structural damage and improper alterations or repairs could change the protection capacity of the dust
collector and therefore void the warranty.
Any alterations to the machine must only be made by NFE technical support.
During maintenance jobs, affix a notice to the appliance indicating "MACHINE BEING SERVICED, DO NOT
START".

Safety
- 8 -
403082 Rev H
Climbing on the dust collector is forbidden.
Never touch electric wires, switches, buttons, etc. with wet hands.
Before connecting to the power mains, make sure the power voltage and frequency are those shown on the
machine plate.
Make power connections to a mains supply with proper grounding.
If an extension cord is used, make sure it is the appropriate wire gage and insulation level for the dust
collector input.
After service or maintenance is performed, the appointed personnel should make sure all removed parts
are properly reinstalled.
Only adult persons should use the dust collector.
During vacuuming operations, always use the caster wheel brakes to prevent the machine from rolling.
For LONGOPAC Dust Collectors:
•If the machine is used to vacuum toxic-harmful substances, the Longopac® bag must be emptied and
the filters cleaned using adequate individual protection devices, selected according to the type of
substances to be vacuumed.
•Do not open the Longopac® bag with the machine running.

Safety
- 9 -
403082 Rev H
2.3 Electrical Practices
Extension Cord Requirements
•Ensure the cord type is suitable for the application and location. If you are unsure about your cord type,
consult a qualified electrical professional or electrician.
•FULLY INSERT plug into outlet.
•Do not use excessive force to make connections.
•Never unplug by pulling the cord from the outlet. Pull plug rather than cord to reduce the risk of
damage.
•Regularly examine your extension cord and ensure it is in good electrical condition. Never use a
damaged cord—either replace it or have it repaired by a qualified person.
•Protect your extension cords from sharp objects, excessive heat and damp or wet areas. Keep the
cord away from oil, cutting edges and moving parts.
•Do not drive, drag or place objects over cord.
•Avoid overheating. Uncoil cord and do not cover it with any material.
•Avoid accidental starting. Be sure equipment is turned off before plugging in. Do not use equipment
if the power switch does not turn the equipment on and off.
•Make sure equipment is not running before disconnecting cord.
•Unplug equipment. When not in use and before changing accessories or performing maintenance,
unplug the machine.
Extension Cord Selection
All cords should be sized appropriately to reduce the risk of damage, fire or reduced performance.
Reference the tables in this section for cord sizes.
WARNING:
Electrical cords can be hazardous. Misuse can result in fire or death by electrical
shock. Read carefully and follow all directions.
CAUTION: Always follow applicable electrical codes, standards and/or regulations. Consult your
local electrical authority or a licensed electrician before attempting to modify an electrical
installation. Ensure that circuit and ground fault protection devices and all other electrical safety
equipment are functioning properly.
WARNING: Ground your equipment. The equipment must be plugged into an appropriate outlet
which is properly installed and grounded in accordance with all codes and ordinances. Do NOT
modify the plug provided with the equipment. Never remove the grounding prong from the plug.
WARNING:
Do not remove, bend or modify any metal prongs or pins of the plug. Modifications
to power cords and/or plugs may result in injury and/or equipment damage.

Safety
- 10 -
403082 Rev H
How to Use the Table
1. Determine your supply voltage.
2. Determine the total length of your cord including all extension cords.
3. Determine the maximum amp draw for your machine.
4. Trace your voltage across the top of the table to the first length that is greater than or equal to your
cord length.
5. Follow the column down to the first row that contains a maximum amp draw greater than or equal to
yours.
6. This cell contains the minimum wire size for your application.
Example
Application: Max Amps = 11A, Length = 80ft, Voltage = 230V 1ph
Solution: 80ft is between the 50ft and 100ft columns, so the
larger of the two columns is chosen. Likewise, 11A is between the
10A and 12A rows, so the larger of the two rows is chosen. 14
AWG (2.5mm2) is the minimum wire size for this example.
Extension Cord Sizes
Note: The table is based on a ˂10% voltage loss, data from the U.S. National Electrical Code Tables 400.5(A)
& 400.5(B) and typical resistances for copper wire.

Safety
- 11 -
403082 Rev H
2.4 Safety plates and symbols
Plates are affixed to the dust collector showing safety symbols and/or messages.
Warning!
Make sure all the safety messages are legible.
Clean these with a cloth, soap and water. Do not use solvents, diesel fuel or gasoline.
Replace the damaged plates with new ones supplied by National Flooring Equipment.
If a plate is affixed to a replaced part, make sure a new plate is affixed to the new part.
Warning!
Read the operator's and maintenance manual carefully before using the machine or doing any
maintenance jobs.
Warning!
Risk of crushing upper limbs while fitting and locking the material Longopac® container on the dust
collector.
Never place hands between the material Longopac® container and dust collector while locking.
Do not place hands on sides of Longopac® container near the guide pins while locking.
Perform the Longopac® container locking operation by means of the levers located on the side, USING
BOTH HANDS!
WARNING!
DO NOT BREATHE IN FLAMMABLE AND/OR
EXPLOSIVE LIQUIDS OR POWDERS

Safety
- 12 -
403082 Rev H
2.5 Outstanding risks
Careful analysis of risks performed by the manufacturer and stored in the technical file has made it possible
to eliminate most of the risks associated with dust collector operation.
The manufacturer advises carefully following the instructions, procedures and advice contained in this
manual as well as applicable safety regulations, including the use of the envisaged protection devices, both
those integrated in the dust collector and individual.
Outstanding risks associated with the dust collector could be:
Risk of improper use in the presence of explosive and flammable substances.
The dust collector must not be used in environments containing substances in the form of liquids that could
vaporize at room temperature and flammable dusts and gas.
Risks of operation in humid environments.
Keep to the limits shown in the operating manual at section 1.5 Allowed environmental conditions.
Risk of erroneous interpretation of the safety pictograms.
Having identified the various outstanding risks, the manufacturer has affixed to the dust collector a number
of hazard labels in compliance with regulations relating to the graphic symbols to be used. The user must
immediately replace any safety plates that become illegible due to wear or damage.
Warning!
Removing the safety plates on the dust collector is strictly forbidden. The manufacturer declines all
liability in relation to dust collector safety in the event of failure to comply with the above indications.
2.6 Applied directives
The following directives apply to the vacuum cleaner described in this manual:
2006/42/CE Machine Directive
2004/108/CE Electromagnetic compatibility directive
2006/95/CE Low-voltage directive

Maintenance
- 13 -
403082 Rev H
3.1 Informative notes
In the case of major repairs, contact NFE or an authorized dealer.
3.2 General safety warnings
Maintenance must always be performed by skilled technicians. Contact NFE for authorized service center.
Before doing any maintenance job:
Make sure the technician is equipped with all approved individual protection equipment needed for
the specific operation (mask, eyewear, gloves, shoes, etc.).
Make sure the technician has carefully read the instructions contained in this manual and knows how
the dust collector works.
Make sure there are no unauthorized persons in the work area.
Make sure the necessary tools are on hand and that these are in good condition.
Make sure the lighting is adequate.
Before carrying out maintenance:
Disconnect the plug from the power socket.
Work done on motors or other electrical component parts must only be performed by a specifically trained
electrician.

Maintenance
- 14 -
403082 Rev H
3.3 Maintenance operations
Warning!
All the described operations must be done with the plug disconnected from the power socket.
Before starting any maintenance or cleaning job, always wear adequate protective clothing, eyewear
and/or gloves according to the type of job to be done.
For smooth dust collector operation, the following periodic maintenance is necessary:
Check to see whether the filter is worn or clogged.
Make sure the sealing gaskets of the motor head base, of the filter-holder ring and of the container are
working efficiently.
The electrical parts (plugs, switches, cables, etc.) must not be damaged.
The screws and nuts must always be tight.
Make sure the Longopac bag is not overfilled. The bag should be replaced when the filled portion
reaches 1/2 - 3/4 of the distance between the support plate and the Longopac holder.
Check the integrity of the flexible vacuum hose and accessories to be used.
If the flexible hose is perforated, the power of the dust collector will be reduced and dust and liquids
will leak into the environment.
Attention!
It is recommended that this machine be serviced by NFE or its authorized dealers.

Maintenance
- 15 -
403082 Rev H
3.4 Replacing the filter
1. Turn off the dust collector by pressing the motor STOP buttons.
2. Disconnect the dust collector plug from the power socket.
Warning!
Wear appropriate personal protection equipment.
3. Release the two retainers that hold the motor head in place. Lift the motor head and rest on a flat
surface being careful not to damage the power cable.
4. Remove the five retaining screws.
5. If the filter is stuck to the chamber, use a prying tool around the entire perimeter of the filter to loosen
the filter from the chamber.
Attention!
Be careful not to damage the filter or chamber when prying loose the filter.

Maintenance
- 16 -
403082 Rev H
6. Remove the filter.
Important!
All the material trapped by the filter and the filter itself must be disposed of through authorized channels
in the country where the dust collector is used.
3.5 Filter replacement schedule
402467 Filter Cartridge:Replace every 750 hours or as needed.
Important!
All wear parts must be inspected regularly, as replacement time varies with conditions of use. Also check
gaskets regularly for air leaks.

Maintenance
- 17 -
403082 Rev H
3.6 Troubleshooting
Fault found
Possible cause
Recommended remedy
The dust collector fails to start
No power
Thermal magnetic switch
tripped
Check the power mains supply
Check the integrity of the plug
and power cable
Reset the thermal magnetic
switch
Dust is leaking out
Perforated vacuum hose
Filter unsuitable for type of job
Replace the hose
Use a suitable filter for the type
of material to be vacuumed
The dust collector does not work as it should
Hose perforated or blocked
Longopac® bag is full
Filter blocked
Slide damper is closed
Longopac flap not closing
Seals worn
Air leak
Check the hose and, if
necessary, replace it
Replace bag
Perform filter cleaning cycle
and, if necessary, replace filter
Open slide damper
Contact NFE technical support
Check the seals and, if
necessary, replace them
Check for any air leaks out of
closing fasteners, tightening
screws, Longopac® bag or filter
chamber
Motor very noisy Contact NFE technical support
Warning!
For any other problems, contact the NFE technical support.
