NI-9260

GETTING STARTED GUIDE
NI 9260
2 AO, 3 Vrms, 24 Bit, 51.2 kS/s/ch Simultaneous

This document explains how to connect to the NI 9260. In this
document, the NI 9260 with BNC and the NI 9260 with mini
XLR are referred to inclusively as the NI 9260.
Note Before you begin, complete the software and
hardware installation procedures in your chassis
documentation.
Note The guidelines in this document are specific to
the NI 9260. The other components in the system might
not meet the same safety ratings. Refer to the
documentation for each component in the system to
determine the safety and EMC ratings for the entire
system.
Safety Guidelines
Operate the NI 9260 only as described in this document.
Caution Do not operate the NI 9260 in a manner not
specified in this document. Product misuse can result in
a hazard. You can compromise the safety protection
built into the product if the product is damaged in any
2| ni.com | NI 9260 Getting Started Guide

way. If the product is damaged, return it to NI for
repair.
Safety Voltages
Channel-to-earth ground ±30 V maximum
Isolation Voltages
Channel-to-channel None
Channel-to-earth ground None
Safety Guidelines for Hazardous Voltages
If hazardous voltages are connected to the device, take the
following precautions. A hazardous voltage is a voltage greater
than 42.4 Vpk voltage or 60 VDC to earth ground.
Caution Ensure that hazardous voltage wiring is
performed only by qualified personnel adhering to local
electrical standards.
Caution Do not mix hazardous voltage circuits and
human-accessible circuits on the same module.
Caution Ensure that devices and circuits connected to
the module are properly insulated from human contact.
NI 9260 Getting Started Guide | © National Instruments | 3

Caution When module terminals are hazardous
voltage LIVE (>42.4 Vpk/60 VDC), you must ensure
that devices and circuits connected to the module are
properly insulated from human contact.
Safety Guidelines for Hazardous Locations
The NI 9260 is suitable for use in Class I, Division 2, Groups A,
B, C, D, T4 hazardous locations; Class I, Zone 2, AEx nA IIC T4
and Ex nA IIC T4 hazardous locations; and nonhazardous
locations only. Follow these guidelines if you are installing the
NI 9260 in a potentially explosive environment. Not following
these guidelines may result in serious injury or death.
Caution Do not disconnect I/O-side wires or
connectors unless power has been switched off or the
area is known to be nonhazardous.
Caution Do not remove modules unless power has
been switched off or the area is known to be
nonhazardous.
Caution Substitution of components may impair
suitability for Class I, Division 2.
4| ni.com | NI 9260 Getting Started Guide

Caution For Division 2 and Zone 2 applications,
install the system in an enclosure rated to at least IP54
as defined by IEC/EN 60079-15.
Special Conditions for Hazardous Locations Use in
Europe and Internationally
The NI 9260 has been evaluated as Ex nA IIC T4 Gc equipment
under DEMKO Certificate No. 12 ATEX 1202658X and is
IECEx UL 14.0089X certified. Each NI 9260 is marked II 3G
and is suitable for use in Zone 2 hazardous locations, in ambient
temperatures of -40 °C ≤ Ta ≤ 70 °C. If you are using the NI 9260
in Gas Group IIC hazardous locations, you must use the device in
an NI chassis that has been evaluated as Ex nC IIC T4, Ex IIC
T4, Ex nA IIC T4, or Ex nL IIC T4 equipment.
Caution You must make sure that transient
disturbances do not exceed 140% of the rated voltage.
Caution The system shall only be used in an area of
not more than Pollution Degree 2, as defined in
IEC 60664-1.
Caution The system shall be mounted in an
ATEX/IECEx-certified enclosure with a minimum
NI 9260 Getting Started Guide | © National Instruments | 5

ingress protection rating of at least IP54 as defined in
IEC/EN 60079-15.
Caution The enclosure must have a door or cover
accessible only by the use of a tool.
Electromagnetic Compatibility Guidelines
This product was tested and complies with the regulatory
requirements and limits for electromagnetic compatibility (EMC)
stated in the product specifications. These requirements and
limits provide reasonable protection against harmful interference
when the product is operated in the intended operational
electromagnetic environment.
This product is intended for use in industrial locations. However,
harmful interference may occur in some installations, when the
product is connected to a peripheral device or test object, or if the
product is used in residential or commercial areas. To minimize
interference with radio and television reception and prevent
unacceptable performance degradation, install and use this
product in strict accordance with the instructions in the product
documentation.
6| ni.com | NI 9260 Getting Started Guide

Furthermore, any changes or modifications to the product not
expressly approved by National Instruments could void your
authority to operate it under your local regulatory rules.
Special Conditions for Marine Applications
Some products are Lloyd’s Register (LR) Type Approved for
marine (shipboard) applications. To verify Lloyd’s Register
certification for a product, visit ni.com/certification and search
for the LR certificate, or look for the Lloyd’s Register mark on
the product.
Caution In order to meet the EMC requirements for
marine applications, install the product in a shielded
enclosure with shielded and/or filtered power and
input/output ports. In addition, take precautions when
designing, selecting, and installing measurement probes
and cables to ensure that the desired EMC performance
is attained.
NI 9260 Getting Started Guide | © National Instruments | 7

Preparing the Environment
Ensure that the environment in which you are using the NI 9260
meets the following specifications.
Operating temperature
(IEC 60068-2-1, IEC 60068-2-2)
-40 °C to 70 °C
Operating humidity
(IEC 60068-2-78)
10% RH to 90% RH,
noncondensing
Pollution Degree 2
Maximum altitude 5,000 m
Indoor use only.
Note Refer to the device datasheet on ni.com/manuals
for complete specifications.
8| ni.com | NI 9260 Getting Started Guide

NI 9260 Pinout
CHASSIS GND
AO0-
AO0+ AO0+
AO0-
AO1+
AO1-
CHASSIS GND
A10-
A10+
NI 9260 Getting Started Guide | © National Instruments | 9

Table 1. Signal Descriptions
Signal Description
AO+ Positive analog output signal connection
AO- Negative analog output signal connection
Chassis GND Chassis ground connection
NI 9260 with mini XLR Analog Output
Connection
Load
NI 9260
with mini XLR
AO+
AO-
IN+
IN-
CHASSIS
GND
3
21
10 | ni.com | NI 9260 Getting Started Guide

Note You can only use the NI 9260 with mini XLR
with differential instruments.
Caution Do not connect AO- to chassis ground on the
NI 9260 with mini XLR. Connecting this pin to chassis
ground will short circuit the output.
Caution Do not connect the NI 9260 with mini XLR
to a ground referenced single-ended instrument. Refer
to the Circuitry section in the device datasheet on
ni.com/manuals for further information.
NI 9260 with BNC Analog Output
Connections
NI 9260 with BNC Load
AO+
AO-
IN+
IN-/GND
50 Ω
NI 9260 Getting Started Guide | © National Instruments | 11

NI 9260 Connection Guidelines
• Make sure that devices you connect to the NI 9260 are
compatible with the module specifications.
• To minimize ground noise, make sure you connect the chassis
ground to earth ground.
Overvoltage Protection
The NI 9260 provides overvoltage protection for each channel.
Note Refer to the device datasheet on ni.com/manuals
for more information about overvoltage protection.
12 | ni.com | NI 9260 Getting Started Guide

Where to Go Next
CompactRIO NI CompactDAQ
Located at ni.com/manuals
RELATED INFORMATION
C Series Documentation
& Resources
ni.com/info cseriesdoc
Services
ni.com/services
Installs with the software
NI 9260 Datasheet
NI-RIO Help
LabVIEW FPGA Help
NI 9260 Datasheet
NI-DAQmx Help
LabVIEW Help
