OPERATING INSTRUCTIONS AND SPECIFICATIONS
NI 9802
2 SD Card Memory Module
ni.com/manuals
DeutschFrançais
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

NI 9802 Operating Instructions and Specifications 2 ni.com
This document describes how to use the National Instruments 9802
and includes specifications for the NI 9802. Visit ni.com/info and
enter rdsoftwareversion to determine which software youneed
for the modules youare using. For information about installing,
configuring, and programming the system, refer to the system
documentation. Visit ni.com/info and enter cseriesdoc for
information about C Series documentation.
Note The NI 9802 is supported only in CompactRIO
reconfigurable chassis, such as the cRIO-910x, and
Single-Board RIO devices.
Note The safety guidelines and specifications in this
document are specific to the NI 9802. The other
components in the system might not meet the same safety
ratings and specifications. Refer to the documentation for
each component in the system to determine the safety
ratings and specifications for the entire system. Visit
ni.com/info and enter cseriesdoc for information
about C Series documentation.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

© National Instruments Corp. 3 NI 9802 Operating Instructions and Specifications
Safety Guidelines
Operate the NI 9802 only as described in these operating
instructions.
Hot Surface This icon denotes that the component may be
hot. Touching this component may result in bodily injury.
Safety Guidelines for Hazardous Locations
The NI 9802 is suitable for use in Class I, Division 2, Groups A, B,
C, D, T4 hazardous locations; Class I, Zone 2, AEx nA IIC T4, and
Ex nA IIC T4 hazardous locations; and nonhazardous locations
only. Follow these guidelines if youare installing the NI 9802 in a
potentially explosive environment. Not following these guidelines
may result in serious injury or death.
Caution Do not insert or remove SD Cards unless power
has been switched off or the area is known to be
nonhazardous.
Caution Do not remove modules unless power has been
switched off or the area is known to be nonhazardous.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

NI 9802 Operating Instructions and Specifications 4 ni.com
Caution Substitution of components may impair
suitability for Class I, Division 2.
Caution For Zone 2 applications, install the system
in an enclosure rated to at least IP 54 as defined by
IEC 60529 and EN 60529.
Special Conditions for Hazardous Locations Use in Europe
This equipment has been evaluated as Ex nA IIC T4 equipment
under DEMKO Certificate No. 07 ATEX 0626664X. Each module
is marked II 3G and is suitable for use in Zone 2 hazardous
locations, in ambient temperatures of –40 °C ≤Ta ≤70 °C. If you
are using the NI 9802 in Gas Group IIC hazardous locations, you
must use the device in an NI chassis that has been evaluated as
Ex nC IIC T4, EEx nC IIC T4, Ex nA IIC T4, or Ex nL IIC T4
equipment.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

© National Instruments Corp. 5 NI 9802 Operating Instructions and Specifications
Special Conditions for Marine Applications
Some modules are Lloyd’s Register (LR) Type Approved for
marine applications. To verify Lloyd’s Register certification, visit
ni.com/certification and search for the LR certificate, or
look for the Lloyd’s Register mark on the module.
Caution To meet radio frequency emission requirements
for marine applications, use shielded cables and install
the system in a metal enclosure. Suppression ferrites
must be installed on power supply inputs near power
entries to modules and controllers. Power supply and
module cables must be separated on opposite sides of the
enclosure and must enter and exit through opposing
enclosure walls.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

NI 9802 Operating Instructions and Specifications 6 ni.com
Inserting and Removing SD Cards
The NI 9802 is an SD Card storage module that can read from and
write to SD Cards. The NI 9802 has two SD Card slots into which
youcan insert NI-approved SD Cards.
Note Using SD Cards that are not approved by NI might
invalidate specifications and result in unreliable
performance.
Note The NI 9802 supports only SD Cards formatted in
FAT16.
The card slots each have a door to protect the SD Cards while in
the module. Each door is connected to a switch that indicates to the
NI 9802 software when it is safe to read from or write to the
SD Card.
The NI 9802 has four LEDs that indicate which slots contain an
SD Card and if the SD Card is active. Refer to Figure 1 for the
designation of SD Card slots and LEDs. Refer to Table 1 for
descriptions of each of the LEDs on the NI 9802 and when it is safe
to remove SD Cards from the NI 9802.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

© National Instruments Corp. 7 NI 9802 Operating Instructions and Specifications
Figure 1. NI 9802 Card Slots and LEDs
1 Present (Card 0)
2 Busy (Card 0)
3 Present (Card 1)
4 Busy (Card 1)
5 Card Slot Doors
6 SD Card Slot 1
7 SD Card Slot 0
5
6
7
2
4
1
3
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

NI 9802 Operating Instructions and Specifications 8 ni.com
LEDs
Table 1. LED Descriptions
LED SD Card Slot Description
Present (Card 0),
Green
SD Card Slot 0 This LED is lit when an SD Card is
in Slot 0 and the SD Card slot door
is closed.
Busy (Card 0),
Yellow
SD Card Slot 0 This LED is lit when the card in
Slot 0 is active. This LED is
flashing when the NI 9802 is
performing I/O on the card in
Slot 0. Do not remove the SD Card
while this LED is lit or flashing.
Present (Card 1),
Green
SD Card Slot 1 This LED is lit when an SD Card is
in Slot 1 and the SD Card slot door
is closed.
Busy (Card 1),
Yellow
SD Card Slot 1 This LED is lit when the card in
Slot 1 is active. This LED is
flashing when the NI 9802 is
performing I/O on the card in
Slot 1. Do not remove the SD Card
while this LED is lit or flashing.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

© National Instruments Corp. 9 NI 9802 Operating Instructions and Specifications
SD Card Slot Doors
Do not open an SD Card slot door or remove an SD Card while the
yellow LED for that card is lit or flashing. If youopen an SD Card
slot door while the yellow LED for that card is lit or flashing, the
NI 9802 software acts to protect the file system of the SD Card.
Refer to the software help for more information. Visit ni.com/
info and enter cseriesdoc for information about C Series
documentation.
Caution Opening an SD Card slot door or removing an
SD Card while the yellow LED for that card is lit or
flashing might result in incomplete or lost data.
Yo umust close the slot door for the NI 9802 software to read from
or write to the SD Card.
Note Screw the slot doors closed completely using a
#1 Phillips screwdriver. Do not overtighten.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

NI 9802 Operating Instructions and Specifications 10 ni.com
Sleep Mode
This module supports a low-power sleep mode. Support for sleep
mode at the system level depends on the chassis that the module is
plugged into. Refer to the chassis manual for information about
support for sleep mode. If the chassis supports sleep mode, refer to
the software help for information about enabling sleep mode. Visit
ni.com/info and enter cseriesdoc for information about
C Series documentation.
Caution Do not enable sleep mode while either of the
SD Card yellow LEDs are lit or flashing. Enabling sleep
mode while either of the SD Card yellow LEDs are lit or
flashing might result in incomplete data.
Typically, when a system is in sleep mode, youcannot
communicate with the modules. In sleep mode, the system
consumes minimal power and may dissipate less heat than it does
in normal mode. Refer to the Specifications section for more
information about power consumption.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

© National Instruments Corp. 11 NI 9802 Operating Instructions and Specifications
Specifications
The following specifications are typical for the range –40 to 70 °C
unless otherwise noted. Certification standards for some
specifications vary based on the system in which youuse the
module.
Data Storage Characteristics
Number of SD Cards ........................ 2
Storage .............................................. 2 GB max storage for
each SD Card
Data transfer...................................... 2 MB/s read/write for
one SD Card at a time
MTBF ............................................... 2,106,312 hours at 25 °C;
Bellcore Issue 2, Method 1,
Case 3, Limited Part Stress
Method
Note Contact NI for Bellcore MTBF specifications
at other temperatures or for MIL-HDBK-217F
specifications.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

NI 9802 Operating Instructions and Specifications 12 ni.com
Power Requirements
Power consumption from chassis
Active mode ............................... 400 mW max
Sleep mode ................................. 5 mW max
Physical Characteristics
If youneed to clean the module, wipe it with a dry towel.
Note For two-dimensional drawings and
three-dimensional models of the C Series module and
connectors, visit ni.com/dimensionsand search by
module number.
Weight............................................... 147 g (5.2 oz) without
SD Cards
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

© National Instruments Corp. 13 NI 9802 Operating Instructions and Specifications
Safety
Hazardous Locations
U.S. (UL) .......................................... Class I, Division 2,
Groups A, B, C, D, T4;
Class I, Zone 2,
AEx nA IIC T4
Canada (C-UL) ................................. Class I, Division 2,
Groups A, B, C, D, T4;
Class I, Zone 2,
Ex nA IIC T4
Europe (DEMKO)............................. Ex nA IIC T4
Safety Standards
This product meets the requirements of the following standards of
safety for electrical equipment for measurement, control, and
laboratory use:
• IEC 61010-1, EN 61010-1
• UL 61010-1, CSA 61010-1
Note For UL and other safety certifications, refer to the
product label or the Online Product Certification section.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

NI 9802 Operating Instructions and Specifications 14 ni.com
Electromagnetic Compatibility
This product meets the requirements of the following EMC
standards for electrical equipment for measurement, control,
and laboratory use:
• EN 61326 (IEC 61326): Class A emissions; Industrial
immunity
• EN 55011 (CISPR 11): Group 1, Class A emissions
• AS/NZS CISPR 11: Group 1, Class A emissions
• FCC 47 CFR Part 15B: Class A emissions
• ICES-001: Class A emissions
Note For the standards applied to assess the EMC of this
product, refer to the Online Product Certification section.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

© National Instruments Corp. 15 NI 9802 Operating Instructions and Specifications
CE Compliance
This product meets the essential requirements of applicable
European Directives as follows:
• 2006/95/EC; Low-Voltage Directive (safety)
• 2004/108/EC; Electromagnetic Compatibility Directive
(EMC)
Online Product Certification
Refer to the product Declaration of Conformity (DoC) for
additional regulatory compliance information. To obtain product
certifications and the DoC for this product, visit ni.com/
certification, search by module number or product line,
and click the appropriate link in the Certification column.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

NI 9802 Operating Instructions and Specifications 16 ni.com
Shock and Vibration
To meet these specifications, youmust panel mount the system.
Operating vibration
Random (IEC 60068-2-64)......... 5 grms, 10 to 500 Hz
Sinusoidal (IEC 60068-2-6) ....... 5 g, 10 to 500 Hz
Operating shock
(IEC 60068-2-27).............................. 30 g, 11 ms half sine,
50 g, 3 ms half sine,
18 shocks at 6 orientations
Environmental
National Instruments C Series modules are intended for indoor use
only but may be used outdoors if installed in a suitable enclosure.
Refer to the manual for the chassis youare using for more
information about meeting these specifications.
Operating temperature
(IEC 60068-2-1, IEC 60068-2-2) ..... –40 to 70 °C
Storage temperature
(IEC 60068-2-1, IEC 60068-2-2) ..... –40 to 85 °C
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

© National Instruments Corp. 17 NI 9802 Operating Instructions and Specifications
Ingress protection.............................. IP 401
Operating humidity
(IEC 60068-2-56).............................. 10 to 90% RH,
noncondensing
Storage humidity
(IEC 60068-2-56).............................. 5 to 95% RH,
noncondensing
Maximum altitude............................. 2,000 m
Pollution Degree ............................... 2
Environmental Management
National Instruments is committed to designing and manufacturing
products in an environmentally responsible manner. NI recognizes
that eliminating certain hazardous substances from our products is
beneficial to the environment and to NI customers.
1 When two SD Cards are inserted and both SD Card slot doors are closed.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

NI 9802 Operating Instructions and Specifications 18 ni.com
For additional environmental information, refer to the NI and the
Environment Web page at ni.com/environment. This page
contains the environmental regulations and directives with which
NI complies, as well as other environmental information not
included in this document.
Waste Electrical and Electronic Equipment (WEEE)
EU Customers At the end of the life cycle, all products
must be sent to a WEEE recycling center. For more
information about WEEE recycling centers and National
Instruments WEEE initiatives, visit ni.com/
environment/weee.
⬉ᄤֵᙃѻક∵ᶧ᥻ࠊㅵ⧚ࡲ⊩ ˄Ё೑ RoHS˅
Ё೑ᅶ᠋ National Instruments ヺড়Ё೑⬉ᄤֵᙃ
ѻકЁ䰤ࠊՓ⫼ᶤѯ᳝ᆇ⠽䋼ᣛҸ (RoHS)DŽ݇Ѣ
National Instruments Ё೑ RoHS ড়㾘ᗻֵᙃˈ䇋ⱏᔩ
ni.com/environment/rohs_chinaDŽ(For information
about China RoHS compliance, go to ni.com/
environment/rohs_china.)
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

© National Instruments Corp. 19 NI 9802 Operating Instructions and Specifications
Where to Go for Support
The National Instruments Web site is your complete resource for
technical support. At ni.com/support youhave access to
everything from troubleshooting and application development
self-help resources to email and phone assistance from
NI Application Engineers.
National Instruments corporate headquarters is located at
11500 North Mopac Expressway, Austin, Texas, 78759-3504.
National Instruments also has offices located around the world to
help address your support needs. For telephone support in the
United States, create your service request at ni.com/support
and follow the calling instructions or dial 512 795 8248. For
telephone support outside the United States, contact your local
branch office:
Australia 1800 300 800, Austria 43 662 457990-0,
Belgium 32 (0) 2 757 0020, Brazil 55 11 3262 3599,
Canada 800 433 3488, China 86 21 5050 9800,
Czech Republic 420 224 235 774, Denmark 45 45 76 26 00,
Finland 358 (0) 9 725 72511, France 01 57 66 24 24,
Germany 49 89 7413130, India 91 80 41190000,
Israel 972 3 6393737, Italy 39 02 41309277, Japan 0120-527196,
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
