National Instruments R Series User manual

USER MANUAL
NI PXIe-7868R
R Series Reconfigurable I/O Module (AI, AO, DIO) for PXI Express,
6 AI, 18 AO, 48 DIO, 1 MS/s AIO, 512 MB DRAM,
Kintex-7 325T FPGA
This document provides compliance, pinout, connectivity, mounting, and power information
for the NI PXIe-7868R.
Hardware Overview
The following high-level block diagram represents the NI PXIe-7868R.
Figure 1. NI PXIe-7868R Block Diagram
Device
Temperature
NI ASIC
Kintex-7
FPGA
Flash
Memory
DIO
CONNECTOR 0
(RMIO)
CONNECTOR 1
(RDIO)
Data/
Address/
Control
Overvoltage
Protection
+5 V
Reference
AO
AO (x18)
DAC
ADC AI
AI (x6)
INA
DIO (x16)
DIO (x32)
DDR3 RAM 100 MHz
OSC
Overvoltage
Protection
Overvoltage
Protection
Overvoltage
Protection
NI PXIe-7868R
CONNECTOR 2
(RAO)
Overvoltage
Protection
(x8)
(x10)
PXIe Connector

Pinout
+5V
DIO0
DIO1
DIO2
DIO3
DIO4
DIO5
DIO6
DIO7
DIO9
DIO11
DIO13
DIO15
AO7
AO6
AO5
AO4
AO3
AO2
AO1
AO0
AISENSE
NC
AIGND6
NC
AI5+
AIGND4
AI4+
AI3+
AIGND2
AI2+
AI1+
AIGND0
AI0+
+5V
DGND
DGND
DGND
DGND
DGND
DGND
DGND
DGND
DIO8
DIO10
DIO12
DIO14
AOGND7
AOGND6
AOGND5
AOGND4
AOGND3
AOGND2
AOGND1
AOGND0
NC
NC
AIGND7
NC
AI5–
AIGND5
AI4–
AI3–
AIGND3
AI2–
AI1–
AIGND1
AI0–
68 34
67 33
66 32
65 31
64 30
63 29
62 28
61 27
60 26
59 25
58 24
57 23
56 22
55 21
54 20
53 19
52 18
51 17
50 16
49 15
48 14
47 13
46 12
45 11
44 10
43 9
42 8
41 7
40 6
39 5
38 4
37 3
36 2
35 1
CONNECTOR 0
(RMIO)
TERMINAL 34 TERMINAL 1
TERMINAL 35
TERMINAL 68
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
AO15
AO14
AO13
AO12
AO11
AO10
AO9
AO8
NC
AO17
NC
AO16
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
AOGND15
AOGND14
AOGND13
AOGND12
AOGND11
AOGND10
AOGND9
AOGND8
NC
AOGND17
NC
AOGND16
NC
NC
NC
NC
NC
NC
NC
NC
NC
68 34
67 33
66 32
65 31
64 30
63 29
62 28
61 27
60 26
59 25
58 24
57 23
56 22
55 21
54 20
53 19
52 18
51 17
50 16
49 15
48 14
47 13
46 12
45 11
44 10
43 9
42 8
41 7
40 6
39 5
38 4
37 3
36 2
35 1
CONNECTOR 2
(RAO)
TERMINAL 68
TERMINAL 34 TERMINAL 1
TERMINAL 35
DIO30
GND
DIO28
GND
DIO26
GND
DIO24
GND
DIO22
GND
DIO20
GND
DIO18
GND
DIO16
GND
DIO14
GND
DIO12
GND
DIO10
GND
DIO8
GND
DIO6
GND
DIO4
GND
DIO2
GND
DIO0
GND
EXTCLKIN
GND
DIO31
DIO29
GND
GND
DIO25
GND
DIO23
GND
DIO27
GND
DIO21
GND
DIO19
GND
DIO17
GND
DIO15
GND
DIO13
GND
DIO11
GND
DIO9
GND
DIO7
GND
DIO5
GND
DIO3
GND
DIO1
GND
GND
GND
68 34
67 33
66 32
65 31
64 30
63 29
62 28
61 27
60 26
59 25
58 24
57 23
56 22
55 21
54 20
53 19
52 18
51 17
50 16
49 15
48 14
47 13
46 12
45 11
44 10
43 9
42 8
41 7
40 6
39 5
38 4
37 3
36 2
35 1
CONNECTOR 1
(RDIO)
TERMINAL 68
TERMINAL 34 TERMINAL 1
TERMINAL 35
Table 1. NI PXIe-7868R Signal Descriptions
Signal Description
AI+ Positive analog input signal connection
AI- Negative analog input signal connection
AISENSE Reference connection for NRSE measurements
AIGND Ground reference for the analog input signal
AO Analog output signal connection
AOGND Ground reference for the analog output signal
2| ni.com | NI PXIe-7868R User Manual

Table 1. NI PXIe-7868R Signal Descriptions (Continued)
Signal Description
DIO Digital input/output signal connection
DGND Ground reference for the digital signal
EXTCLKIN External clock input source that can be used for source synchronous
acquisitions. The provided clock source must be stable and glitch-free.
GND Ground connection
Supply (+5 Vout) 5 V power output connection for external devices
NC No connection
The NI PXIe-7868R is protected from overvoltage and overcurrent conditions.
Note Refer to the device specifications, available at ni.com/manuals for more
information.
Connectivity Options
Use the following connection accessories and cables to access the signals on the I/O
connectors.
Table 2. Connection Accessories and Cables
Connector
Type Accessory Description
NI Part
Number
RDIO
NI SCB-68 HSDIO
Shielded 68-Pin Connector
Block for R Series DIO and
HSDIO Products
782914-01
NI SHC68-C68-RDIO2
Shielded R Series High Speed
Digital Cable (1 m) 156166-01
Shielded R Series High Speed
Digital Cable (2 m) 156166-02
RMIO/RAO
NI SCB-68A Noise Rejecting, Shielded I/O
Connector Block 782536-01
NI SHC68-68-RMIO
RMIO Shielded Cable, 68 pin
D-Type to 68 pin VHDCI (1 m) 189588-01
RMIO Shielded Cable, 68 pin
D-Type to 68 pin VHDCI (2 m) 189588-02
NI PXIe-7868R User Manual | © National Instruments | 3

Analog Input
The NI PXIe-7868R provides connections for six AI channels. Each channel has an AI+ pin,
AI- pin, and AIGND pin to which you can connect both single-ended or differential voltage
signals. Use the AISENSE pin to connect non-referenced single-ended signals.
Connecting Single-Ended Voltage Signals
To connect referenced single-ended voltage signals to the NI PXIe-7868R, you must connect
the voltage ground signal to AI GND in order to keep the common-mode voltage in the
specified range.
Figure 2. Connecting Referenced Single-Ended Signals to the NI PXIe-7868R
PGIA ADC
AI+
NI PXIe-7868R
Connection
Accessory
AISENSE
AIGND
V1
+
–
Overvoltage
Protection
AI– Overvoltage
Protection
Overvoltage
Protection
To connect non-referenced single-ended voltage signals to the NI PXIe-7868R, you must
connect the voltage ground signal to AI SENSE in order to keep the common-mode voltage in
the specified range.
Figure 3. Connecting Non-Referenced Single-Ended Signals to the NI PXIe-7868R
PGIA ADC
AI+
NI PXIe-7868R
Connection
Accessory
AISENSE
AIGND
Vcm
V1
+
–
+
–
Overvoltage
Protection
AI– Overvoltage
Protection
Overvoltage
Protection
4| ni.com | NI PXIe-7868R User Manual

Connecting Differential Voltage Signals
You can connect grounded or floating differential signal sources to the NI PXIe-7868R.
Connect the positive voltage signal to the AI+ and the negative voltage signal to AI-. To
connect grounded differential signals to the NI PXIe-7868R, you must also connect the signal
reference to AI GND.
Figure 4. Connecting Grounded Differential Signals to the NI PXIe-7868R
PGIA ADC
AI+
NI PXIe-7868R
Connection
Accessory
AISENSE
AIGND
Vcm
V1
+
–
+
–
Overvoltage
Protection
AI– Overvoltage
Protection
Overvoltage
Protection
To connect floating differential signals to the NI PXIe-7868R, you must connect the negative
and positive signals to AI GND through 1 MΩ resistors to keep the voltage within the
common-mode voltage range. If the voltage source is outside the common-mode voltage
range, the NI PXIe-7868R does not read data accurately.
Figure 5. Connecting Floating Differential Signals to the NI PXIe-7868R
PGIA ADC
AI+
NI PXIe-7868R
Connection
Accessory
AISENSE
AIGND
V1
+
–
Overvoltage
Protection
AI– Overvoltage
Protection
Overvoltage
Protection
Analog Output
The NI PXIe-7868R provides connections for eighteen analog output channels. Each channel
has an AO pin and AOGND pin to which you can connect a load.
NI PXIe-7868R User Manual | © National Instruments | 5

Figure 6. Connecting a Load
NI PXIe-7868R
Connection
Accessory
AOGND
LOAD
AO
DAC
Digital I/O
The NI PXIe-7868R provides connections for 48 digital input/output (DIO) channels.
Connector 0 contains 16 low-speed channels that can run up to 10 MHz signal frequencies and
Connector 1 contains 32 high-speed DIO channels that can run up to 80 MHz signal
frequencies. Each connector has a fixed logic level of 3.3 V. You can configure each channel
as input or output.
Figure 7. Connecting to the DIO Channels
NI PXIe-7868R
Power
FPGA
Connection
Accessory
DIO0
DIO1
DIO30
DIO15
Connecter 0 (MIO)
1
Connection
Accessory
DIO0
DIO1
DIO14
DIO31
Connecter 1 (DIO)
2
3
1. Low-speed signal frequencies up to 10 MHz with logic levels configured as 3.3 V.
2. High-speed signal frequencies up to 80 MHz with logic levels configured as 3.3 V.
3. LED
6| ni.com | NI PXIe-7868R User Manual

The DIO channels connect to the FPGA through buffers, which have overvoltage and
undervoltage protection as well as over current protection. Refer to the device specifications
on ni.com/manuals for more information about the maximum voltage and current.
When the system powers on, the DIO channels are set as input low with pull-down resistors.
To set another power-on state, you can configure the NI PXIe-7868R to load a VI when the
system powers on. The VI can then set the DIO lines to any power-on state. Visit ni.com/info
and enter RSeries_PowerUpStates to learn more about configuring the power-up states
for the NI PXIe-7868R.
All the high-speed DIO channels on Connector 1 are routed with a 50 Ω characteristic trace
impedance. Route all external circuitry with a similar impedance to ensure best signal quality.
NI recommends performing signal integrity measurements to test the affect of signal routing
with the cable and connection accessory for your application.
Field Wiring Considerations
Environmental noise can seriously affect the measurement accuracy of the device if you do not
take proper care when running signal wire between signal sources and the device. The
following recommendations mainly apply to AI signal routing to the device, as well as signal
routing in general.
Take the following precautions to minimize noise pickup and maximize measurement
accuracy:
• Use differential AI connections to reject common-mode noise.
• Use individually shielded, twisted-pair wires to connect AI signals to the device. With
this type of wire, the signal attached to the positive and negative inputs are twisted
together and then covered with a shield. You then connect this shield only at one point to
the signal source ground. This kind of connection is required for signals traveling through
areas with large magnetic fields or high electromagnetic interference.
• Route signals to the device carefully. Keep cabling away from noise sources, such as
video monitors and analog signals.
Use the following recommendations for all signal connections to the NI PXIe-7868R:
• Separate NI PXIe-7868R signal lines from high-current or high-voltage lines. These lines
can induce currents in or voltages on the NI PXIe-7868R signal lines if they run in
parallel paths at a close distance. To reduce the magnetic coupling between lines, separate
them by a reasonable distance if they run in parallel or run the lines at right angles to each
other.
• Do not run signal lines through conduits that also contain power lines.
• Protect signal lines from magnetic fields caused by electric motors, welding equipment,
breakers, or transformers by running them through special metal conduits.
+5 V Power Source
Use the +5 V terminals on the I/O connector supply +5 V referenced to DGND to power
external circuitry.
NI PXIe-7868R User Manual | © National Instruments | 7

Caution Never connect the +5 V power terminals to analog or digital ground or
any other voltage source on the NI PXIe-7868R or any other device. Doing so can
damage the device and the computer. National Instruments is not liable for damage
resulting from such a connection.
The power rating is 4.75 to 5.1 V DC at 0.5 A.
Worldwide Support and Services
The NI website is your complete resource for technical support. At ni.com/support, you have
access to everything from troubleshooting and application development self-help resources to
email and phone assistance from NI Application Engineers.
Visit ni.com/services for NI Factory Installation Services, repairs, extended warranty, and
other services.
Visit ni.com/register to register your NI product. Product registration facilitates technical
support and ensures that you receive important information updates from NI.
A Declaration of Conformity (DoC) is our claim of compliance with the Council of the
European Communities using the manufacturer’s declaration of conformity. This system
affords the user protection for electromagnetic compatibility (EMC) and product safety. You
can obtain the DoC for your product by visiting ni.com/certification. If your product supports
calibration, you can obtain the calibration certificate for your product at ni.com/calibration.
NI corporate headquarters is located at 11500 North Mopac Expressway, Austin, Texas,
78759-3504. NI also has offices located around the world. For telephone support in the United
States, create your service request at ni.com/support or dial 1 866 ASK MYNI (275 6964). For
telephone support outside the United States, visit the Worldwide Offices section of ni.com/
niglobal to access the branch office websites, which provide up-to-date contact information,
support phone numbers, email addresses, and current events.
Information is subject to change without notice. Refer to the NI Trademarks and Logo Guidelines at ni.com/trademarks for
information on NI trademarks. Other product and company names mentioned herein are trademarks or trade names of their
respective companies. For patents covering NI products/technology, refer to the appropriate location: Help»Patents in your
software, the patents.txt file on your media, or the National Instruments Patent Notice at ni.com/patents. You can find
information about end-user license agreements (EULAs) and third-party legal notices in the readme file for your NI product. Refer
to the Export Compliance Information at ni.com/legal/export-compliance for the NI global trade compliance policy and how
to obtain relevant HTS codes, ECCNs, and other import/export data. NI MAKES NO EXPRESS OR IMPLIED WARRANTIES AS
TO THE ACCURACY OF THE INFORMATION CONTAINED HEREIN AND SHALL NOT BE LIABLE FOR ANY ERRORS. U.S.
Government Customers: The data contained in this manual was developed at private expense and is subject to the applicable
limited rights and restricted data rights as set forth in FAR 52.227-14, DFAR 252.227-7014, and DFAR 252.227-7015.
© 2017 National Instruments. All rights reserved.
378036A-03 May 3, 2017
