GETTING STARTED GUIDE
NI cRIO-9037
Embedded CompactRIO Controller with Real-Time Processor and
Reconfigurable FPGA
This document describes how to begin using the National Instruments cRIO-9037.

Safety Guidelines
Caution Do not operate the cRIO-9037 in a manner not specified in this document.
Product misuse can result in a hazard. You can compromise the safety protection
built into the product if the product is damaged in any way. If the product is
damaged, return it to NI for repair.
Safety Guidelines for Hazardous Locations
The cRIO-9037 is suitable for use in Class I, Division 2, Groups A, B, C, D, T4 hazardous
locations; Class I, Zone 2, AEx nA IIC T4 Gc and Ex nA IIC T4 Gc hazardous locations; and
nonhazardous locations only. Follow these guidelines if you are installing the cRIO-9037 in a
potentially explosive environment. Not following these guidelines may result in serious injury
or death.
Caution Do not disconnect the power supply wires and connectors from the
controller unless power has been switched off.
Caution Do not disconnect I/O-side wires or connectors unless power has been
switched off or the area is known to be nonhazardous.
Caution Do not remove modules unless power has been switched off or the area is
known to be nonhazardous.
Caution Substitution of components may impair suitability for Class I, Division 2,
or Zone 2.
Caution The system must be installed in an enclosure certified for the intended
hazardous (classified) location, having a tool secured cover/door, where a minimum
protection of at least IP54 is provided.
Caution The USB host ports, USB device port, and mini DisplayPort require the
retention accessories listed in the following table for hazardous locations. All cables
must be used in a conduit or cable gland to wire to a nonhazardous location. Do not
disconnect a cable unless the cRIO-9037 is powered off or the area is known to be
nonhazardous.
Table 1. Hazardous Location Retention Accessories
Port Required Accessory Part Number
USB Host Port NI Industrial USB Extender Cable 152166-xx
USB Device Port NI Locking USB Cable 157788-01
Mini DisplayPort Mini DisplayPort Cable Retention Bracket 156866-01
2| ni.com | NI cRIO-9037 Getting Started Guide

Special Conditions for Hazardous Locations Use in Europe and
Internationally
The cRIO-9037 has been evaluated as Ex nA IIC T4 Gc equipment under DEMKO 12
ATEX 1202658X and is IECEx UL 14.0089X certified. Each device is marked II 3G and is
suitable for use in Zone 2 hazardous locations, in ambient temperatures of -20 °C ≤ Ta ≤
55 °C.
Caution Transient protection shall be provided that is set at a level not exceeding
140% of the peak rated voltage value of 85 V at the supply terminals to the
equipment.
Caution The system shall only be used in an area of not more than Pollution
Degree 2, as defined in IEC/EN 60664-1.
Caution The system shall be mounted in an ATEX/IECEx-certified enclosure with
a minimum ingress protection rating of at least IP54 as defined in IEC/EN 60079-15.
Caution The enclosure must have a door or cover accessible only by the use of a
tool.
Electromagnetic Compatibility Guidelines
This product was tested and complies with the regulatory requirements and limits for
electromagnetic compatibility (EMC) stated in the product specifications. These requirements
and limits provide reasonable protection against harmful interference when the product is
operated in the intended operational electromagnetic environment.
This product is intended for use in industrial locations. However, harmful interference may
occur in some installations, when the product is connected to a peripheral device or test object,
or if the product is used in residential or commercial areas. To minimize interference with
radio and television reception and prevent unacceptable performance degradation, install and
use this product in strict accordance with the instructions in the product documentation.
Furthermore, any changes or modifications to the product not expressly approved by National
Instruments could void your authority to operate it under your local regulatory rules.
Caution To ensure the specified EMC performance, operate this product only with
shielded cables and accessories. The DC power input cables may be unshielded.
Caution To ensure the specified EMC performance, you must use an isolated cable
with the RS-485 serial port, such as NI part number 184428-01.
Caution To ensure the specified EMC performance, the length of any cable
connected to the video and V2 ports must be no longer than 3 m (10 ft). The length
of any cable connected to the RS-232 and RS-485 ports must be no longer than
NI cRIO-9037 Getting Started Guide | © National Instruments | 3

30 m (100 ft). The length of any cable connected to the USB host ports must be no
longer than 5 m (16 ft).
Caution The USB device port is intended only for use in device configuration,
application deployment, debug, and maintenance.
Caution To ensure the specified EMC performance, product installation requires
either special considerations or user-installed, add-on devices. Refer to the following
sections for more information.
Related Information
Connecting the cRIO-9037 to Ground on page 8
Connecting the cRIO-9037 to Power on page 9
Special Conditions for Marine Applications
Some products are Lloyd’s Register (LR) Type Approved for marine (shipboard) applications.
To verify Lloyd’s Register certification for a product, visit ni.com/certification and search for
the LR certificate, or look for the Lloyd’s Register mark on the product.
Caution In order to meet the EMC requirements for marine applications, install the
product in a shielded enclosure with shielded and/or filtered power and input/output
ports. In addition, take precautions when designing, selecting, and installing
measurement probes and cables to ensure that the desired EMC performance is
attained.
Preparing the Environment
Ensure that the environment in which you are using the cRIO-9037 meets the following
specifications.
Operating temperature
(IEC 60068-2-1, IEC 60068-2-2)
-20 °C to 55 °C
Operating humidity (IEC 60068-2-78) 10% RH to 90% RH, noncondensing
Pollution Degree 2
Maximum altitude 5,000 m
Indoor use only.
Note Refer to the device specifications on ni.com/manuals for complete
specifications.
4| ni.com | NI cRIO-9037 Getting Started Guide

Unpacking the Kit
Caution To prevent electrostatic discharge (ESD) from damaging the device,
ground yourself using a grounding strap or by holding a grounded object, such as
your computer chassis.
1. Touch the antistatic package to a metal part of the computer chassis.
2. Remove the device from the package and inspect the device for loose components or any
other sign of damage.
Caution Never touch the exposed pins of connectors.
Note Do not install a device if it appears damaged in any way.
3. Unpack any other items and documentation from the kit.
Store the device in the antistatic package when the device is not in use.
Verifying the Kit Contents
Verify that the following items are included in the cRIO-9037 kit.
Figure 1. cRIO-9037 Kit Contents
1
6
3
2
5
4
1. cRIO Device with Power Connector
2. Antenna (x2)
3. USB A-to-B Cable
4. Ferrite (x2)
5. cRIO Device Drivers Media
6. Getting Started Guide
NI cRIO-9037 Getting Started Guide | © National Instruments | 5

Installing Software on the Host Computer
Before using the cRIO-9037, you must install the following application software and device
drivers on the host computer in this order:
1. LabVIEW 2015 SP1 or later
2. LabVIEW Real-Time Module 2015 SP1 or later
3. LabVIEW FPGA Module 2015 SP1 or later1
4. NI CompactRIO Device Drivers August 2016 or later
For minimum software support information, visit ni.com/info and enter the Info Code
swsupport.
Installing C Series Modules
Complete the following steps to install a C Series module.
3
2
2
1
1. Verify that power is not connected to the I/O connector(s) on the C Series module. If the
system is in a nonhazardous location, the cRIO-9037 can be powered on when you install
modules.
2. Press the latches on the C Series module.
1LabVIEW FPGA Module is not required when using Scan Interface mode. To program the user-
accessible FPGA on the cRIO-9037, LabVIEW FPGA Module is required.
6| ni.com | NI cRIO-9037 Getting Started Guide

3. Align the C Series module with a slot and seat it in the slot until the latches lock in place.
Removing C Series Modules
Verify that power is not connected to the I/O connector(s) on the C Series module before you
remove a module from the cRIO-9037. If the system is in a nonhazardous location, the
cRIO-9037 can be powered on when you remove modules.
Installing the Antennas
Complete the following steps to install the antennas on the cRIO-9037.
Note NI recommends connecting both antennas for optimal wireless performance
and reliability.
2
1
1. Screw an antenna to the primary wireless connector. Hand tighten the antenna to the
connector.
2. Screw an antenna to the secondary wireless connector. Hand tighten the antenna to the
connector.
NI cRIO-9037 Getting Started Guide | © National Instruments | 7

Connecting the cRIO-9037
The cRIO-9037 has the following connectors, LEDs, and buttons.
Figure 2. cRIO-9037 Front Panel
1 2 3
4
5
6
89
11
14
13
12
10 7
1. LEDs
2. Ethernet Ports
3. Power Connector
4. Antenna Port 2
5. Antenna Port 1
6. Ground Screw
7. WLAN LED
8. RS-232 Serial Port
9. RS-485/422 (DTE) Serial Port
10. USB Host Ports
11. Mini DisplayPort
12. Cable Retention Mounts
13. USB Device Port
14. Power and Reset Buttons
Connecting the cRIO-9037 to Ground
You must connect the cRIO-9037 grounding terminal to the grounding electrode system of the
facility.
What to Use
• Ring lug
• Wire, 1.3 mm2 (16 AWG) or larger
• Screwdriver, Phillips #2
What to Do
Complete the following steps to ground the cRIO-9037.
1. Attach the ring lug to the wire.
2. Remove the grounding screw from the grounding terminal on the cRIO-9037.
3. Attach the ring lug to the grounding terminal.
8| ni.com | NI cRIO-9037 Getting Started Guide

4. Tighten the grounding screw to 0.5 N · m (4.4 lb · in.) of torque.
5. Attach the other end of the wire to the grounding electrode system of your facility using a
method that is appropriate for your application.
Caution If you use shielded cabling to connect to a C Series module with a plastic
connector, you must attach the cable shield to the chassis grounding terminal using
1.3 mm2 (16 AWG) or larger wire. Attach a ring lug to the wire and attach the wire
to the chassis grounding terminal. Solder the other end of the wire to the cable
shield. Use shorter wire for better EMC performance.
For more information about ground connections, visit ni.com/info and enter the Info Code
emcground.
Connecting the cRIO-9037 to Power
The cRIO-9037 requires a 9 V to 30 V external power supply. The cRIO-9037 filters and
regulates the supplied power and provides power for the C Series modules. The cRIO-9037
has a primary power input, V1, and a secondary power input, V2.
The POWER LED on the cRIO-9037 indicates which power input is in use, as shown in the
following table.
Table 2. POWER LED Indicators
LED Color LED Pattern Indication
Green Solid The cRIO-9037 is powered from the V1 input.
Yellow Solid The cRIO-9037 is powered from the V2 input.
— Off The cRIO-9037 is powered off.
Caution Do not connect V2 to a DC mains supply or to any supply that requires a
connecting cable longer than 3 m (10 ft). A DC mains supply is a local DC
electricity supply network in the infrastructure of a site or building.
What to Use
• Ferrite
• Screwdriver, 2.54 mm (0.10 in.) flathead
• Primary power supply, 9 V to 30 V, 46 W minimum
• (Optional) Secondary power supply, 9 V to 30 V, 46 W minimum
NI recommends the power supplies listed in the following table for the cRIO-9037.
NI cRIO-9037 Getting Started Guide | © National Instruments | 9

Table 3. NI Power Supplies
Power Supply Part Number
NI PS-15 Industrial Power Supply
(24 VDC, 5 A, 100 VAC to 120 VAC/200 VAC to 240 VAC input)
781093-01
NI PS-10 Desktop Power Supply
(24 VDC, 5 A, 100 VAC to 120 VAC/200 VAC to 240 VAC input)
782698-01
What to Do
Complete the following steps to connect a power supply to the cRIO-9037.
1. Ensure that your power supply is powered off.
2. Install the ferrite on the negative and positive leads of the power supply, as shown in the
following figure.
Figure 3. Installing a Ferrite on the Power Leads
2
1
1. Pass the leads through the ferrite twice, leaving 50 mm to 75 mm (2 in. to 3 in.) between the ferrite and
the end of the leads.
2. Close the ferrite around the leads.
3. Remove the power connector from the cRIO-9037.
Caution Do not tighten or loosen the terminal screws on the power connector
while the cRIO-9037 is powered on.
4. Connect the primary power supply and optional secondary power supply to the power
connector, as shown in the following figure.
10 | ni.com | NI cRIO-9037 Getting Started Guide

Figure 4. cRIO-9037 Power Connections
Power Connector
V2
C
C
V1
Primary Power Supply
+
–
–
+
Secondary Power Supply
FerriteFerrite
Note The C terminals are internally connected to each other.
5. Tighten the terminal screws on the power connector to 0.20 N · m to 0.25 N · m
(1.8 lb · in. to 2.2 lb · in.) of torque.
6. Install the power connector on the front panel of the cRIO-9037.
7. Tighten the power connector screw flanges to 0.20 N · m to 0.25 N · m (1.8 lb · in. to
2.2 lb · in.) of torque.
8. Power on the primary power supply and optional secondary power supply.
Powering On the cRIO-9037
When you power on the cRIO-9037 for the first time, the device boots into safe mode. The
POWER LED illuminates, the STATUS LED illuminates briefly, and then the STATUS LED
blinks twice every few seconds.
Related Information
STATUS LED Indicators on page 17
Installing a Ferrite on the USB Cables
You must install a ferrite around all USB cables connected to the USB host ports to ensure that
the cRIO-9037 meets all EMC standards applicable to your country.
What to Use
• Ferrite (711849-01), included with the cRIO-9037
• USB cables
What to Do
Install the ferrite on the USB cables, as shown in the following figure.
NI cRIO-9037 Getting Started Guide | © National Instruments | 11

Figure 5. Installing a Ferrite on the USB Cables
2
1
1. Pass the cables through the ferrite, leaving 50 mm to 75 mm (2 in. to 3 in.) between the
ferrite and the end of the cables. The ferrite can accommodate up to two USB cables
depending on the diameter of each cable.
2. Close the ferrite around the cables.
Connecting the cRIO-9037 to the Host Computer
Complete the following steps to connect the cRIO-9037 to the host computer using the USB
device port.
1. Power on the host computer.
2. Connect the cRIO-9037 to the host computer using the USB A-to-B cable.
Caution NI requires the use of a locking USB cable (157788-01) to meet the
shock and vibration specifications. Refer to the specifications on ni.com/
manuals for shock and vibration specifications.
The device driver software automatically detects the cRIO-9037. If the device driver
software does not detect the cRIO-9037, verify that you installed the appropriate NI
software in the correct order on the host computer.
Tip You can also use the Ethernet port to connect directly to the host computer or
network. Refer to the user manual on ni.com/manuals for more information about
Ethernet connections.
Configuring the System in Measurement &
Automation Explorer (MAX)
Complete the following steps to find the system in MAX.
1. Launch MAX on the host computer.
2. Expand Remote Systems in the configuration tree and locate your system.
3. Select your target.
Tip MAX lists the system under the model number followed by the serial
number, such as NI-cRIO-9037-1856AAA.
12 | ni.com | NI cRIO-9037 Getting Started Guide

Setting a System Password
Complete the following steps to set a system password.
Note The default username for the cRIO-9037 is admin. There is no default
password for the cRIO-9037, so you must leave the password field blank when
logging in until you set a system password.
1. Right-click your system and select Web Configuration.
The NI Web-Based Configuration and Monitoring utility opens in your default browser
and is where you set the password. If you have not installed Microsoft Silverlight,
NI Web-based Configuration & Monitoring prompts you to do so.
2. Enter a unique name for your system in the Hostname field.
3. Click the Security Configuration icon.
4. Click Login.
5. In the Login dialog box, enter the username admin and leave the password field blank.
6. Click OK.
7. Click Change Password.
8. Enter and re-enter a new password.
9. Click OK.
10. Click Save.
11. Click OK to confirm you are changing the password.
Caution NI cannot recover lost system passwords. If you forget the password,
you must contact NI and reformat the controller.
Installing Software on the cRIO-9037
Complete the following steps to install software on the cRIO-9037.
1. In MAX, expand your system under Remote Systems.
2. Select the Systems Settings tab.
3. Click Update Firmware.
4. Select the latest firmware version.
5. Click Open.
6. Right-click Software.
7. Select Add/Remove Software to launch the LabVIEW Real-Time Software Wizard.
Tip You must log in if you set a system password.
8. Select the recommended software set for your LabVIEW and NI CompactRIO Device
Drivers versions.
9. Click Next.
10. Select NI Scan Engine from the software add-ons.
NI cRIO-9037 Getting Started Guide | © National Instruments | 13

Select any additional software to install. If you plan on using the cRIO-9037 with the
LabVIEW FPGA Module, you can click Next. Click NI Scan Engine if you plan on
using the cRIO-9037 without the LabVIEW FPGA Module.
Tip You can use this wizard at anytime to install additional software.
11. Click Next.
12. Verify that the summary of software to install is correct.
13. Click Next to start the installation.
14. Click Finish when the installation is complete.
Connecting the cRIO-9037 to a Wireless
Network
Complete the following steps to connect the cRIO-9037 to a wireless network.
1. Launch MAX on the host computer.
2. Expand Remote Systems in the configuration tree and locate your system.
3. Select your target.
Tip MAX lists the system under the model number followed by the serial
number, such as NI-cRIO-9037-1856AAA.
4. Click the Network Settings tab.
5. Select your country.
6. Select Connect to a wireless network as the Wireless Mode.
You may need to upload a certificate by clicking Certificate Management. Contact your
IT department for information about your network settings and configuration details.
7. Click Wireless Network to add a network from the scanned list or click Other Network
and enter settings for your network.
8. Click Save.
The Wireless Adapter wlan0 section displays the search status.
9. Click the System Settings tab and verify that the chassis has a wireless IP address (along
with the Ethernet IP address); if the System State reads Connected - Running, the
cRIO-9037 is connected to the wireless network.
Creating a Wireless Network with the
cRIO-9037
Complete the following steps to connect the cRIO-9037 to a wireless network.
1. Launch MAX on the host computer.
2. Expand Remote Systems in the configuration tree and locate your system.
14 | ni.com | NI cRIO-9037 Getting Started Guide

3. Select your target.
Tip MAX lists the system under the model number followed by the serial
number, such as NI-cRIO-9037-1856AAA.
4. Click the Network Settings tab.
5. Select your country.
6. Select Create wireless network as the Wireless Mode.
7. Enter the SSID, Channel, and Security type for the wireless network you are creating.
8. Select DHCP Only in the Configure IPv4 Address drop-down menu.
9. Click Save.
10. Verify that the Status reads Broadcasting.
Troubleshooting the cRIO-9037
The cRIO-9037 is Not Communicating with the
Network
• Ensure that the USB connections between the cRIO-9037 and the host computer and the
Ethernet connections between the host computer and the router are secure.
• Configure the IP and other network settings by completing the following steps.
1. Use a USB A-to-B cable to connect the cRIO-9037 USB device port to a host
computer. The USB driver creates a virtual network interface card and assigns an IP
address to the cRIO-9037 in the format of 172.22.11.x.
2. In MAX, expand your system under Remote Systems.
3. Select the Network Settings tab to configure the IP and other network settings.
4. (Optional) Use the RJ-45 Ethernet port 1 to reconnect the cRIO-9037 to the host
computer. The cRIO-9037 attempts to initiate a DHCP network connection at
powerup.
Note If the cRIO-9037 cannot obtain an IP address, it connects to the
network with a link-local IP address with the form 169.254.x.x. The host
computer communicates with the cRIO-9037 over a standard Ethernet
connection.
• Ensure that you have the correct version of NI CompactRIO Device Drivers installed on
the host computer. Visit ni.com/info and enter the Info Code swsupport for the
minimum supported versions of LabVIEW and NI CompactRIO Device Drivers.
Tip If you have recently upgraded LabVIEW, you must reinstall NI
CompactRIO Device Drivers.
• Ensure that the NI USBLAN adapter is recognized in the Device Manager. On
Windows 7, select Start»Control Panel»Device Manager»Network adapters»National
Instruments»USBLAN adapter. If the USBLAN adapter is not recognized, you must
reinstall NI CompactRIO Device Drivers.
• Temporarily disable any network firewalls or other security software.
NI cRIO-9037 Getting Started Guide | © National Instruments | 15

Verify the System IP Configuration
1. Put the cRIO-9037 in safe mode and enable the RS-232 serial port by holding the RESET
button down for 5 seconds.
The STATUS LED starts blinking three times every few seconds.
2. Use the RS-232 serial port terminal to read the IP address, or connect a monitor to the
mini DisplayPort to view the IP address.
Note Refer to the user manual on ni.com/manuals for more information about
serial port configuration.
3. Set a new DHCP connection by holding the RESET button down for 5 seconds. The
STATUS LED repeats the same behavior from Step 1.
If the cRIO-9037 fails to set a new DHCP address, it assigns itself a link-local IP address.
If the DHCP connection is successful and appropriate for your application, skip to Step 6.
4. In MAX, expand your system under Remote Systems.
5. Select the Network Settings tab to configure the IP and other network settings.
6. Reboot the cRIO-9037 by pressing the RESET button.
Configure the Windows Firewall
• Add an exception for MAX to your network firewall or other security software by
completing the following steps:
1. On Windows 7, select Start»Control Panel»System and Security»Windows
Firewall»Allow a program through Windows Firewall.
2. Click Allow another program.
3. Select Measurement & Automation.
4. Click Add.
5. Click OK.
• Ensure that UDP port 44525 is open to communication on the host computer. If you are
using an intelligent switch on the network, ensure that it is not disabling UDP port 44525.
System Reset
The following figure shows the reset behavior of the cRIO-9037.
16 | ni.com | NI cRIO-9037 Getting Started Guide

Figure 6. Reset Button Behavior
Press and hold RESET button for ≥5 s
Press and hold RESET button for <5 s
Run Mode
Safe Mode
Press and hold RESET button for <5 s
Press and hold RESET button for ≥5 s
Press and hold
RESET button for ≥5 s
Press and hold
RESET button for <5 s
• Console Out enabled
• Network settings reset
• RT Startup App disabled
• FPGA Startup App disabled
• Console Out enabled
• RT Startup App disabled
• FPGA Startup App disabled
Safe Mode
STATUS LED Indicators
The following table describes the STATUS LED indicators.
NI cRIO-9037 Getting Started Guide | © National Instruments | 17

Table 4. STATUS LED Indicators
LED
Color
LED Pattern Indication
Yellow Blinks twice and
pauses
The cRIO-9037 is in safe mode. Software is not installed,
which is the factory default state, or software has been
improperly installed on the cRIO-9037.
An error can occur when an attempt to upgrade the software
is interrupted. Reinstall software on the cRIO-9037. Refer
to the Measurement & Automation Explorer (MAX) Help for
information about installing software on the cRIO-9037.
Blinks three times
and pauses
The cRIO-9037 is in user-directed safe mode, or the
cRIO-9037 is in install mode to indicate that software is
currently being installed.
This pattern may also indicate that the user has forced the
cRIO-9037 to boot into safe mode by pressing the reset
button for longer than five seconds or by enabling safe
mode in MAX. Refer to the Measurement & Automation
Explorer (MAX) Help for information about safe mode.
Blinks four times
and pauses
The cRIO-9037 is in safe mode. The software has crashed
twice without rebooting or cycling power between crashes.
Continuously
blinks
The cRIO-9037 has not booted into NI Linux Real-Time.
The cRIO-9037 either booted into an unsupported operating
system, was interrupted during the boot process, or detected
an unrecoverable software error.
On momentarily The cRIO-9037 is booting. No action required.
Red Continuously
blinks
This indicates a hardware error. An internal power supply
has failed. Check front-panel I/O and C Series module
connections for shorts. Remove any shorts and cycle power
the cRIO-9037. If the problem persists, contact NI.
— Off The cRIO-9037 is in run mode. Software is installed and the
operating system is running.
WLAN Status LED Indicators
The following table describes the WLAN Status LED indicators.
18 | ni.com | NI cRIO-9037 Getting Started Guide

Table 5. WLAN Status LED Indicators
LED Color LED Pattern Indication
Green Continuously blinks The cRIO-9037 is attempting to connect to an existing
wireless network.
Solid The cRIO-9037 is connected to an existing wireless
network.
Yellow Solid The cRIO-9037 is operating as a wireless access point.
— Off The cRIO-9037 wireless radio is disabled.
Where to Go Next
APPLICATION
SUPPORT
Services NI Community
NI CompactRIO
Developer’s Guide
Software Support
ni.com/info swsupport
Support
ni.com/support
SOFTWARE
NI cRIO-9037 Specifications Configuring a Project
ni.com/manuals NI-RIO Help
ni.com/compactriodevguide
CompactRIO Sample
Projects
LabVIEW Create Project
HARDWARE
NI cRIO-9037 User Manual
ni.com/manuals
C Series Getting
Started Guides
ni.com/manuals
Learn LabVIEW Basics
ni.com/gettingstarted
CompactRIO Examples
NI Example Finder
ni.com/services ni.com/community
NI cRIO-9037 Getting Started Guide | © National Instruments | 19

Worldwide Support and Services
The NI website is your complete resource for technical support. At ni.com/support, you have
access to everything from troubleshooting and application development self-help resources to
email and phone assistance from NI Application Engineers.
Visit ni.com/services for NI Factory Installation Services, repairs, extended warranty, and
other services.
Visit ni.com/register to register your NI product. Product registration facilitates technical
support and ensures that you receive important information updates from NI.
A Declaration of Conformity (DoC) is our claim of compliance with the Council of the
European Communities using the manufacturer’s declaration of conformity. This system
affords the user protection for electromagnetic compatibility (EMC) and product safety. You
can obtain the DoC for your product by visiting ni.com/certification. If your product supports
calibration, you can obtain the calibration certificate for your product at ni.com/calibration.
NI corporate headquarters is located at 11500 North Mopac Expressway, Austin, Texas,
78759-3504. NI also has offices located around the world. For telephone support in the United
States, create your service request at ni.com/support or dial 1 866 ASK MYNI (275 6964). For
telephone support outside the United States, visit the Worldwide Offices section of ni.com/
niglobal to access the branch office websites, which provide up-to-date contact information,
support phone numbers, email addresses, and current events.
Information is subject to change without notice. Refer to the NI Trademarks and Logo Guidelines at ni.com/trademarks for
information on NI trademarks. Other product and company names mentioned herein are trademarks or trade names of their
respective companies. For patents covering NI products/technology, refer to the appropriate location: Help»Patents in your
software, the patents.txt file on your media, or the National Instruments Patent Notice at ni.com/patents. You can find
information about end-user license agreements (EULAs) and third-party legal notices in the readme file for your NI product. Refer
to the Export Compliance Information at ni.com/legal/export-compliance for the NI global trade compliance policy and how
to obtain relevant HTS codes, ECCNs, and other import/export data. NI MAKES NO EXPRESS OR IMPLIED WARRANTIES AS
TO THE ACCURACY OF THE INFORMATION CONTAINED HEREIN AND SHALL NOT BE LIABLE FOR ANY ERRORS. U.S.
Government Customers: The data contained in this manual was developed at private expense and is subject to the applicable
limited rights and restricted data rights as set forth in FAR 52.227-14, DFAR 252.227-7014, and DFAR 252.227-7015.
© 2016—2017 National Instruments. All rights reserved.
376978D-01 Mar17
