INSTALLATION GUIDE
NI RMC-8354
This guide includes installation information for the NI RMC-8354. For more information about
configuring, using, and maintaining the NI RMC-8354, refer to the NI RMC-8354 User Manual.
You can download the user manual in PDF format at ni.com/manuals.
Contents
Related Documentation ............................................................................................................ 2
Unpacking................................................................................................................................. 2
What You Need to Get Started ................................................................................................. 2
Key Features ............................................................................................................................. 3
Mainboard Features .......................................................................................................... 3
CPU .......................................................................................................................... 3
Chipset ...................................................................................................................... 3
Memory .................................................................................................................... 3
Slots .......................................................................................................................... 4
Video ........................................................................................................................ 4
HDD.......................................................................................................................... 4
DVD-ROM ............................................................................................................... 4
Onboard LAN ........................................................................................................... 4
Onboard I/O.............................................................................................................. 4
Power Management Features.................................................................................... 4
Front Panel LEDs ..................................................................................................... 4
System Management................................................................................................. 5
NI RMC-8354 Description ....................................................................................................... 5
Optional Equipment.................................................................................................................. 6
Memory Upgrades ............................................................................................................ 6
Rack Mount Kit ................................................................................................................ 6
USB Floppy Disk Drive ................................................................................................... 6
NI RMC-8354 Overview .......................................................................................................... 6
Safety Information.................................................................................................................... 7
Chassis Cooling Considerations ............................................................................................... 8
Providing Adequate Clearance ......................................................................................... 8
Installation ................................................................................................................................ 8
Connecting Safety Ground ....................................................................................................... 9
Connecting to Power Source .................................................................................................... 9
Rack Mounting ......................................................................................................................... 9
Installing the Inner Slides ................................................................................................. 10
Assembling the Outer Slide Assemblies .......................................................................... 11
Installing the Outer Slide Assemblies in the Rack ........................................................... 12
Installing the Chassis into the Rack.................................................................................. 13

2|ni.com |NI RMC-8354 Installation Guide
OS Reinstallation and Recovery ...............................................................................................14
Cleaning ....................................................................................................................................15
Exterior Cleaning .............................................................................................................. 15
Specifications............................................................................................................................ 15
Electrical ...........................................................................................................................15
Mainboard.........................................................................................................................16
CPU................................................................................................................................... 16
Hard Disk Drive................................................................................................................17
Memory.............................................................................................................................17
Mechanical........................................................................................................................17
Environmental...................................................................................................................17
Acoustic Emissions........................................................................................................... 18
Safety ................................................................................................................................18
Electromagnetic Compatibility ......................................................................................... 18
CE Compliance ................................................................................................................. 19
Online Product Certification.............................................................................................19
Environmental Management............................................................................................. 19
Worldwide Support and Services .............................................................................................20
Related Documentation
The following documents contain information that you may find helpful as you read this manual:
•CompactPCI Specification PICMG 2.0 R 3.0
•PXI Hardware Specification,Revision 2.1
•PXI Software Specification,Revision 2.1
• ANSI/IEEE Standard 1014-1987, IEEE Standard for a Versatile Backplane Bus: VMEbus
• ANSI/VITA 1-1994, VME64
•NI-VISA User Manual
•NI-VISA Programmer Reference Manual
•Read Me First: Safety and Electromagnetic Compatibility, National Instruments
Unpacking
Carefully inspect the shipping container and the NI RMC-8354 for damage. Check for visible
damage to the metal work. Check to make sure all hardware and switches are undamaged. If
damage appears to have been caused during shipment, file a claim with the carrier. Retain the
packing material for possible inspection and/or reshipment.
What You Need to Get Started
The NI RMC-8354 kit contains the following items:
NI RMC-8354 rack mount controller
NI RMC-8354 User Manual

NI RMC-8354 Installation Guide |© National Instruments |3
Windows recovery CD/DVD
Rack mount kit
Front bezel
AC power cable (refer to Table 1 for a list of AC power cables)
The unit comes with the standard 120 V (USA) cable. If you have the incorrect AC power cable,
contact National Instruments.
Key Features
The NI RMC-8354 offers the performance of a high-end PC in a compact 1U rack-mountable
form factor for controlling a PXI or PXI Express system using a National Instruments remote
controller.
Mainboard Features
CPU
• Intel Core i7-860 Quad Core 2.8 GHz, 8 MB Cache, LGA1156
Chipset
• Intel 3420 chipset
Memory
• 1/2 GB DDR3 memory standard (1/2 × 1 GB)
• Maximum memory supported: 16 GB DDR3-1333 in 4 DIMM sockets
Table 1. AC Power Cables
Power Cable Reference Standards
Standard 120 V (USA) ANSI C73.11/NEMA 5-15-P/IEC83
Switzerland 220 V SEV
Australia 240 V AS C112
Universal Euro 230 V CEE (7), II, IV, VII IEC83
North America 240 V ANSI C73.20/NEMA 6-15-P/IEC83
United Kingdom 230 V BS 1363/IEC83
Japan 100 V ANSI C73.11/NEMA 5-15-P/IEC83

4|ni.com |NI RMC-8354 Installation Guide
Slots
• One PCI Express 2.0 x16 slot
Video
• Matrox G200eW 16 MB DDR2 (max resolution 1280 × 1024)
HDD
• 1 × 500 GB or 4 × 500 GB SATA (3 Gbps) hard drive JBOD/RAID5
DVD-ROM
• Slim DVD-ROM drive
Onboard LAN
• 2x Intel 82574L Gigabit Ethernet controller
Onboard I/O
• PS/2 keyboard port
• PS/2 mouse port
• Serial port
• VGA port
• Two USB 2.0 ports (rear)
• Two USB 2.0 ports (front)
• Two RJ-45 ports
Power Management Features
• ACPI/ACPM power management
• Main switch override mechanism
• Wake-On-LAN (WOL) header
• Wake up on keyboard/mouse from Soft-Off
• Power-on mode from AC power recovery
• Internal/external modem ring-on
Front Panel LEDs
• Power indicator
• LAN status indicators
• HDD indicator
• System temp (overheat) and fan (fail) warning indicator

NI RMC-8354 Installation Guide |© National Instruments |5
System Management
• Monitoring for CPU and chassis environment
• CPU thermal trip support
• +5 V standby alert LED
• Fan speed control
NI RMC-8354 Description
Figure 1 shows the key features of the NI RMC-8354 front panel. For detailed information about
the NI RMC-8354 rear panel, refer to Chapter 3, I/O Information, in the NI RMC-8354 User
Manual.
Figure 1. Front View of the NI RMC-8354
The front panel includes the following LEDs:
•Power indicator—glows when the NI RMC-8354 is powered on.
•LAN status indicators—flash when there is activity on LAN1 or LAN2.
•Overheat/FanFail LED
– Off—Normal
– On—Overheat
– Flashing—Fan failure warning
1USBPorts
2 Reset Switch
3 Power Switch
4 Hard Drive Activity Indicator
5 Hard Drive Error Indicator
6 Power Indicator
7 HDD Indicator
8 LAN1 Status Indicator
9 LAN2 Status Indicator
10 System Temp and Fan Warning Indicator
RESET
123
4
5
6
7
8
9
10

6|ni.com |NI RMC-8354 Installation Guide
Optional Equipment
Memory Upgrades
You can upgrade the NI RMC-8354 memory to a maximum of 16 GB.
Note A 32-bit operating system such as Windows XP Pro addresses a maximum
of 4 GB.
The NI RMC-8354 supports dual-channel DDR-3 SDRAM unbuffered memory in four 240-pin
DIMM sockets. The NI RMC-8354 is compatible with ECC memory.
Note Supported DIMM sizes are 1 GB, 2 GB, and 4 GB.
Note National Instruments has tested and verified that the DDR-3 DIMMs we sell
work with the NI RMC-8354. We recommend you purchase your DDR-3 DIMM
modules from National Instruments. Other off-the-shelf DDR-3 DIMM modules
are not guaranteed to work properly.
Rack Mount Kit
A rack mount kit is included for mounting the NI RMC-8354 chassis into a 26 in. instrument
cabinet.
Note If your cabinet is less than 26 in. deep, refer to KnowledgeBase 4GCEKKMT
at ni.com/support for rack mount modification.
USB Floppy Disk Drive
A USB floppy drive is available from National Instruments, part number 778492-02.
NI RMC-8354 Overview
The NI RMC-8354 is a 1U PC-server-based controller for remote control of PXI chassis. The
controller provides leading-edge processing power with Intel Core i7 Quad Core processors,
high disk bandwidth with hardware RAID support, high I/O bandwidth with a PCI Express 2.0
x16 slot, and up to 16 GB of memory.

NI RMC-8354 Installation Guide |© National Instruments |7
Safety Information
Caution Before undertaking any troubleshooting, maintenance, or exploratory
procedure, carefully read the following caution notices.
Caution Overloading the circuits may damage supply wiring. Do not exceed the
ratings on the equipment nameplate when connecting equipment to the supply circuit.
Caution Risk of explosion if battery is replaced by an incorrect type. dispose of
used batteries according to instructions.
This equipment contains voltage hazardous to human life and safety, and is capable of inflicting
personal injury.
•Chassis Grounding—The NI RMC-8354 requires a connection from the premise wire
safety ground to the NI RMC-8354 chassis ground. The earth safety ground must be
connected during use of this equipment to minimize shock hazards. Refer to the Connecting
Safety Ground section for instructions on connecting safety ground.
•Live Circuits—Operating personnel and service personnel must not remove protective
covers when operating or servicing the NI RMC-8354. Adjustments and service to internal
components must be undertaken by qualified service technicians. During service of
this product, the mains connector to the premise wiring must be disconnected. Dangerous
voltages may be present under certain conditions; use extreme caution.
•Explosive Atmosphere—Do not operate the chassis in conditions where flammable gases
are present. Under such conditions, this equipment is unsafe and may ignite the gases or gas
fumes.
•Parts Replacement—Service this equipment only with parts that are exact replacements,
both electrically and mechanically. Contact National Instruments for replacement part
information. Installation of parts with those that are not direct replacements may cause
harm to personnel operating the chassis. Furthermore, damage or fire may occur if
replacement parts are unsuitable.
•Modification—Do not modify any part of the NI RMC-8354 from its original condition.
Unsuitable modifications may result in safety hazards.

8|ni.com |NI RMC-8354 Installation Guide
Chassis Cooling Considerations
The NI RMC-8354 is designed to operate in an instrument rack. Follow the installation
instructions.
Caution If installed in a closed or multiunit rack assembly, the rack environment
operating ambient temperature may be greater than room ambient temperature.
Therefore, install the equipment in an environment compatible with the maximum
ambient operating temperature (Tma) specified in Appendix A, Specifications, in the
NI RMC-8354 User Manual.
Providing Adequate Clearance
Apertures in the front, top, rear, and along both sides of the chassis facilitate power supply and
motherboard cooling. Air enters through the front and top inlets of the chassis and exits through
the fans on the rear of the chassis. Place the NI RMC-8354 in an instrument rack so that the fans
(air outlets) and the air inlet apertures along the top and front of the chassis have adequate
ventilation. Keep other equipment a minimum of 76.2 mm (3 in.) away from the air outlets on
the rear of the chassis.
Installation
Follow these steps to connect devices to the NI RMC-8354:
Caution Because of the risk of high energy (>240VA), the unit must be installed
only in a Restricted Access Location.
1. Connect a keyboard and mouse to the appropriate connectors on the NI RMC-8354 rear
panel.
2. Connect the VGA monitor video cable to the VGA connector on the rear panel.
3. (Optional) To boot into LabVIEW RT, connect the network cable to LAN jack 1 on the rear
panel. (Refer to Figure 3-1, NI RMC-8354 Rear Panel Layout, in the NI RMC-8354 User
Manual for the location of LAN jack 1.)
4. Connect the USB, serial, and parallel devices as necessary to the NI RMC-8354 front and
rear panel ports.
Caution To minimize shock hazard, make sure the electrical power outlet you use
to power the NI RMC-8354 has an appropriate earth safety ground. Refer to the
Connecting Safety Ground section for more information.
5. Connect the AC power cable to the AC inlet on the rear panel and to an AC power outlet.
For more information, refer to the Connecting to Power Source section.

NI RMC-8354 Installation Guide |© National Instruments |9
6. Power on the NI RMC-8354.
7. Verify that the NI RMC-8354 boots. If it does not boot, refer to the What if the
NI RMC-8354 does not boot? section of Chapter 5, Troubleshooting, in the
NI RMC-8354 User Manual.
Connecting Safety Ground
The NI RMC-8354 is designed with a three-position NEMA 5-15 style plug for the U.S. that
connects the ground line to the chassis ground. To minimize shock hazard, make sure the
electrical power outlet you use to power the chassis has an appropriate earth safety ground.
Connecting to Power Source
Attach input power through the rear AC inlet using the appropriate AC power cable supplied.
Caution Overloading the circuits may damage supply wiring. Do not exceed the
ratings on the equipment nameplate when connecting equipment to the supply circuit.
Caution To completely remove power, you must disconnect the AC power cable.
The power switch allows you to power on the chassis or place it in standby mode. Push the power
switch to the On position (if not already on). Observe that all fans become operational and the
power indicator is lit.
Rack Mounting
Note The rack mount kit provided with the NI RMC-8354 is intended to work with
racks that are 26 to 33 in. deep. For information about installing the NI RMC-8354
into a rack that is less than 26 in. deep, refer to KnowledgeBase 4GCEKKMT at
ni.com/support.
The rack mounting hardware includes:
• One pair of inner slides to be installed on the chassis.
• One pair of outer slides to be installed in the rack.
• Three pairs of short brackets for the outer slides.
• Bag of assorted fasteners.
• One pair of long brackets for the rear of the outer slides.
Caution When mounting the equipment in the rack, do not create a hazardous
condition due to uneven mechanical loading.
Note One pair of short brackets includes screw threads, and the other two pairs
have slots. If the short brackets are required for your specific rack mounting
configuration, use the pair(s) that fits into your rack best.

10 |ni.com |NI RMC-8354 Installation Guide
Note Rack mounting hardware provided in the accessory kit, but not specifically
described in the following instructions, is for other possible rack mounting
configurations not mentioned in this manual. Consult any relevant literature provided
with the intended rack for specific mounting information before attempting to install
the NI RMC-8354.
Installing the Inner Slides
Follow these steps to install the inner slides to the NI RMC-8354:
1. Locate the right inner slide (the slide used on the right side of the chassis when facing the
chassis front panel).
2. Align the four square holes on the right inner slide against the hooks on the right side of the
chassis, as shown in Figure 2.
3. Securely attach the slide to the chassis with two M4 flathead screws.
4. Repeat steps 1 to 3 to install the left inner slide to the left side of the chassis.
Figure 2. Installing Inner Slides
1 Hooks on Chassis 2 Square Holes on Right Inner Slide 3 Holes for M4 Screws
1
3
2

NI RMC-8354 Installation Guide |© National Instruments |11
Assembling the Outer Slide Assemblies
Follow these steps to assemble the outer slide assemblies:
1. Measure the distance from the front rail of the rack to the rear rail of the rack.
2. Attach a long bracket to the rear of the right outer slide, as shown in Figure 3.
3. Adjust the outer slide assembly to the proper distance so that the chassis fits snugly into
the rack.
4. Repeat steps 1 to 3 for the left outer slide.
Figure 3. Assembling Outer Slide Assemblies
1 Outer Slide 2 Long Bracket
1
2

12 |ni.com |NI RMC-8354 Installation Guide
Installing the Outer Slide Assemblies in the Rack
Use the M5 screws and washers to secure the slide assemblies to the rack, as shown in Figure 4.
Figure 4. Installing Slide Assemblies into Rack
1 M5 Screws and Washers 2 Slide Assemblies
1
1
2

NI RMC-8354 Installation Guide |© National Instruments |13
Installing the Chassis into the Rack
Follow these steps to install the chassis in the rack:
1. Push the inner slides, attached to the chassis, into the grooves of the outer slide assemblies
installed in the rack, as shown in Figure 5.
Figure 5. Installing Inner Slides into Outer Slides
1 Inner Slides 2 Grooves of Outer Slide Assemblies
1
2

14 |ni.com |NI RMC-8354 Installation Guide
2. Push the chassis all the way to the back of the outer slide assemblies, as shown in Figure 6.
Figure 6. Installing Chassis Into Rack
OS Reinstallation and Recovery
Caution Recovering the OS using the hard drive-based recovery or the OS
recovery CD/DVD erases the contents of your hard disk. Before recovering the OS,
back up any files you want to keep.
The NI RMC-8354 includes a preinstalled OS from the factory. The NI RMC-8354 also includes
two methods of restoring/reinstalling the OS to your system.
• Hard drive-based recovery stores a factory backup on a separate portion of your hard drive,
allowing you to restore your server without additional media.
Note The hard drive recovery hot key is <F4>. To access the hard drive-based
recovery tool, press and hold <F4> when video first appears during the boot process.

NI RMC-8354 Installation Guide |© National Instruments |15
• The NI RMC-8354 also ships with an OS recovery CD/DVD you can use to reinstall your
operating system onto your hard drive.
If you need to reinstall your operating system, you can use the included OS recovery
CD/DVD. Boot the NI RMC-8354 using the OS recovery CD/DVD to recover the OS.
Note You also may need to update or reinstall software after using the OS
reinstallation CD/DVD to recover your OS. The OS reinstallation CD/DVD may
contain drivers that are older or newer than the factory-installed version of the OS and
may not contain the latest RAID drivers. To ensure you have the latest drivers, go to
www.intel.com and install the Intel Rapid Storage Technology (Intel RST) RAID
software package.
Note After you reinstall or recover your OS, you may find shortcuts on the desktop
that require you to install specific drivers or software (for example, video drivers).
Due to driver and software packaging, it was not possible to preinstall this software
during the OS installation.
Cleaning
Caution Always disconnect the AC power cable before cleaning or servicing the
chassis.
Exterior Cleaning
Caution Avoid getting moisture inside the chassis during exterior cleaning,
especially through the top vents.
Do not wash the front- or rear-panel connectors or switches. Cover these components
while cleaning the chassis.
Do not use harsh chemical cleaning agents; they may damage the chassis. Avoid
chemicals that contain benzene, toluene, xylene, acetone, or similar solvents.
Clean the exterior surfaces of the chassis with a dry lint-free cloth or a soft-bristle brush. Do not
use abrasive compounds on any part of the chassis.
Specifications
This section lists the NI RMC-8354 electrical, mechanical, and environmental specifications.
Electrical
AC Input
Input voltage range ........................................... 100 to 240 VAC
Operating voltage range1.................................. 90 to 264 VAC

16 |ni.com |NI RMC-8354 Installation Guide
Input frequency .................................................50/60 Hz
Operating frequency range1..............................47 to 63 Hz
Input current rating ...........................................5 A max
Power disconnect ..............................................The AC power cable provides main power
disconnect. Depressing the front panel power
switch enables or inhibits the internal power
supply.
Caution Overloading the circuits may damage supply wiring. Do not exceed the
ratings on the equipment nameplate when connecting equipment to the supply circuit.
Power Requirements
Measured, peak inrush (power ON)..................197 W
Measured, idle...................................................92 W
Measured, active (100% CPU) .........................203 W
Mainboard
Socket................................................................LGA 1156
Chipset ..............................................................Intel 3420 chipset
Memory Slots....................................................Four 240-pin DIMM slots, three per channel,
1066/1333 16 GB max memory
PCI Express.......................................................One PCI Express 2.0 x16 slot
SATA.................................................................Six SATA ports compliant with the Serial-ATA
2.0 specification.
USB ports..........................................................Four USB 2.0 ports
Keyboard...........................................................PS/2 keyboard port
Mouse................................................................PS/2 mouse port
Video .................................................................VGA port, onboard Matrox G200eW 16 MB
DDR2 (max resolution 1280 × 1024)
Serial .................................................................One RS-232 serial port
LAN ..................................................................Two RJ45 LAN jacks
Onboard LAN controller...................................Intel 82574L Gigabit Ethernet controller
CPU
CPU...................................................................Intel i7 860 Quad Core
Clock speed.......................................................2.86 GHz
1 Operating range is guaranteed by design.

NI RMC-8354 Installation Guide |© National Instruments |17
Max turbo frequency (single core) ................... 3.46 GHz
Intel Smart Cache ............................................. 8 MB
Package............................................................. LGA 1156
Hard Disk Drive
Capacity ............................................................ 500 GB in one, two, or four-drive configurations
for maximum capacity of 2 TB (maximum
usable capacity shown by Windows in RAID 5 is
1.36 TB)
Interface ............................................................ Serial-ATA
Memory
Standard memory.............................................. 1/2 × 1 GB (128 M × 72 bit),
DDR-III SDRAM, ECC 1333 MHz
4 GB memory upgrade ..................................... 2 × 2 GB (128 M × 72 bit),
DDR-III SDRAM, ECC 1333 MHz
8 GB memory upgrade (64-bit OS) .................. 4 × 2 GB (128 M × 72 bit),
DDR-III SDRAM, ECC 1333 MHz
16 GB memory upgrade (64-bit OS) ................ 4 × 4 GB (512 M × 72 bit),
DDR-III SDRAM, ECC 1333 MHz
Mechanical
Overall dimensions (standard chassis)
Height ....................................................... 1U
Width ........................................................ 437 mm (17.2 in.)
Depth ........................................................ 503 mm (19.8 in.)
Weight (with four 500 GB drives) .................... 10.75 kg (23.7 lbs)
Environmental
Caution If installed in a closed or multiunit rack assembly, the rack environment
operating ambient temperature may be greater than room ambient temperature.
Therefore, install the equipment in an environment compatible with the maximum
ambient temperature (Tma) the manufacturer specifies.
Operating temperature ...................................... 5 to 35 °C
(Tested in accordance with IEC 60068-2-1.)
Storage temperature .......................................... -40 to 70 °C
(Tested in accordance with IEC 60068-2-1 and
IEC 60068-2-2.)

18 |ni.com |NI RMC-8354 Installation Guide
Relative humidity (tested in accordance with IEC 60068-2-56)
Operating ..................................................10 to 90% noncondensing
Nonoperational (storage) ..........................5 to 95% noncondensing
Installation Category.........................................II
Pollution Degree ...............................................2
Altitude .............................................................2,000 m
Operating location.............................................Indoor use only
Acoustic Emissions1
Sound pressure level (at operator position)
Minimum ..................................................53.9 dBA
Maximum..................................................64.9 dBA
Sound power
Minimum ..................................................61.6 dBA
Maximum..................................................72.0 dBA
Safety
This product is designed to meet the requirements of the following standards of safety for
information technology equipment:
• IEC 60950-1, EN 60950-1
• UL 60950-1, CSA 60950-1
Note For UL and other safety certifications, refer to the product label or the Online
Product Certification section.
Electromagnetic Compatibility
This product meets the requirements of the following EMC standards for electrical equipment
for measurement, control, and laboratory use:
• EN 61326 (IEC 61326): Class A emissions; Basic immunity
• EN 55011 (CISPR 11): Group 1, Class A emissions
• AS/NZS CISPR 11: Group 1, Class A emissions
• FCC 47 CFR Part 15B: Class A emissions
• ICES-001: Class A emissions
Note For the standards applied to assess the EMC of this product, refer to the
Online Product Certification section.
Note For EMC compliance, operate this device with shielded cabling.
1 Typical data. Tested in accordance with ISO 7779; meets MIL-PRF-28800F requirements.

NI RMC-8354 Installation Guide |© National Instruments |19
CE Compliance
This product meets the essential requirements of applicable European Directives as follows:
• 2006/95/EC; Low-Voltage Directive (safety)
• 2004/108/EC; Electromagnetic Compatibility Directive (EMC)
Online Product Certification
Refer to the product Declaration of Conformity (DoC) for additional regulatory compliance
information. To obtain product certifications and the DoC for this product, visit ni.com/
certification, search by model number or product line, and click the appropriate link in the
Certification column.
Environmental Management
NI is committed to designing and manufacturing products in an environmentally responsible
manner. NI recognizes that eliminating certain hazardous substances from our products is
beneficial to the environment and to NI customers.
For additional environmental information, refer to the Minimize Our Environmental Impact web
page at ni.com/environment. This page contains the environmental regulations and
directives with which NI complies, as well as other environmental information not included in
this document.
Waste Electrical and Electronic Equipment (WEEE)
EU Customers At the end of the product life cycle, all products must be sent to
a WEEE recycling center. For more information about WEEE recycling centers,
National Instruments WEEE initiatives, and compliance with WEEE Directive
2002/96/EC on Waste and Electronic Equipment, visit ni.com/environment/
weee.
Battery Replacement and Disposal
Caution Risk of explosion if battery is replaced by an incorrect type. Dispose of
used batteries according to instructions.
Battery Directive This device contains a long-life coin cell battery. If you need
to replace it, use the Return Material Authorization (RMA) process or contact an
authorized National Instruments service representative. For more information
about compliance with the EU Battery Directive 2006/66/EC about Batteries
and Accumulators and Waste Batteries and Accumulators, visit ni.com/
environment/batterydirective.
Cd/Hg/Pb

© 2010–2014 National Instruments. All rights reserved.
373190B-01 Jun14
Refer to the NI Trademarks and Logo Guidelines at ni.com/trademarks for more information on National Instruments trademarks. Other
product and company names mentioned herein are trademarks or trade names of their respective companies. For patents covering National
Instruments products/technology, refer to the appropriate location: Help»Patents in your software, the patents.txt file on your media, or the
National Instruments Patents Notice at ni.com/patents. You can find information about end-user license agreements (EULAs) and third-party
legal notices in the readme file for your NI product. Refer to the Export Compliance Information at ni.com/legal/export-compliance
for the National Instruments global trade compliance policy and how to obtain relevant HTS codes, ECCNs, and other import/export data. NI MAKES
NO EXPRESS OR IMPLIED WARRANTIES AS TO THE ACCURACY OF THE INFORMATION CONTAINED HEREIN AND SHALL NOT BE LIABLE FOR
ANY ERRORS. U.S. Government Customers: The data contained in this manual was developed at private expense and is subject to the applicable
limited rights and restricted data rights as set forth in FAR 52.227-14, DFAR 252.227-7014, and DFAR 252.227-7015.
Worldwide Support and Services
The National Instruments website is your complete resource for technical support. At ni.com/
support you have access to everything from troubleshooting and application development
self-help resources to email and phone assistance from NI Application Engineers.
Visit ni.com/services for NI Factory Installation Services, repairs, extended warranty, and
other services.
Visit ni.com/register to register your National Instruments product. Product registration
facilitates technical support and ensures that you receive important information updates from NI.
A Declaration of Conformity (DoC) is our claim of compliance with the Council of the European
Communities using the manufacturer’s declaration of conformity. This system affords the user
protection for electromagnetic compatibility (EMC) and product safety. You can obtain the DoC
for your product by visiting ni.com/certification. If your product supports calibration,
you can obtain the calibration certificate for your product at ni.com/calibration.
National Instruments corporate headquarters is located at 11500 North Mopac Expressway,
Austin, Texas, 78759-3504. National Instruments also has offices located around the world. For
telephone support in the United States, create your service request at ni.com/support or dial
1 866 ASK MYNI (275 6964). For telephone support outside the United States, visit the
Worldwide Offices section of ni.com/niglobal to access the branch office websites, which
provide up-to-date contact information, support phone numbers, email addresses, and current
events.
⬉ᄤֵᙃѻક∵ᶧ᥻ࠊㅵ⧚ࡲ⊩ ˄Ё೑ RoHS˅
Ё೑ᅶ᠋ National Instruments ヺড়Ё೑⬉ᄤֵᙃѻકЁ䰤ࠊՓ⫼ᶤѯ᳝ᆇ⠽䋼ᣛҸ
(RoHS)DŽ݇Ѣ National Instruments Ё೑ RoHS ড়㾘ᗻֵᙃˈ䇋ⱏᔩ ni.com/
environment/rohs_chinaDŽ(For information about China RoHS compliance,
go to ni.com/environment/rohs_china.)
