GETTING STARTED GUIDE
PXIe-6570
32-Channel Digital Pattern Instrument
Note Before you begin, install and configure your chassis and controller.
This document explains how to install, configure, and test the PXIe-6570. The PXIe-6570 is a
32-channel digital pattern instrument.
Caution You can impair the protection provided by the PXIe-6570 if you use it in
a manner not described in this document.
Contents
Electromagnetic Compatibility Guidelines...............................................................................2
Verifying the System Requirements..........................................................................................2
Unpacking the Kit..................................................................................................................... 2
Kit Contents...................................................................................................................... 3
Preparing the Environment....................................................................................................... 3
Installing the Software.............................................................................................................. 3
Digital Pattern Editor........................................................................................................ 4
NI-Digital Pattern Driver.................................................................................................. 4
Associated Drivers............................................................................................................ 5
Installing the PXIe-6570........................................................................................................... 5
Connecting Signals................................................................................................................... 7
PXIe-6570 Front Panel......................................................................................................7
Connecting to a Device Under Test.................................................................................. 9
PXIe-6570 Accessories................................................................................................... 10
Configuring the PXIe-6570 in MAX...................................................................................... 11
Operating the Digital Pattern Instrument................................................................................ 11
Digital Pattern Instrument Examples.............................................................................. 12
Troubleshooting...................................................................................................................... 13
What Should I Do if the PXIe-6570 Doesn't Appear in MAX?......................................13
What Should I Do if the Module Fails the Self-Test?.....................................................13
Why Is the ACCESS LED Off When the Chassis Is On?...............................................14
Where to Go Next................................................................................................................... 15
Worldwide Support and Services............................................................................................ 15

Electromagnetic Compatibility Guidelines
This product was tested and complies with the regulatory requirements and limits for
electromagnetic compatibility (EMC) stated in the product specifications. These requirements
and limits provide reasonable protection against harmful interference when the product is
operated in the intended operational electromagnetic environment.
This product is intended for use in industrial locations. However, harmful interference may
occur in some installations, when the product is connected to a peripheral device or test object,
or if the product is used in residential or commercial areas. To minimize interference with
radio and television reception and prevent unacceptable performance degradation, install and
use this product in strict accordance with the instructions in the product documentation.
Furthermore, any changes or modifications to the product not expressly approved by National
Instruments could void your authority to operate it under your local regulatory rules.
Caution To ensure the specified EMC performance, operate this product only with
shielded cables and accessories. Do not use unshielded cables or accessories unless
they are installed in a shielded enclosure with properly designed and shielded input/
output ports and connected to the product using a shielded cable. If unshielded
cables or accessories are not properly installed and shielded, the EMC specifications
for the product are no longer guaranteed.
Caution To ensure the specified EMC performance, the length of all I/O cables
must be no longer than 3 m (10 ft).
Caution To ensure the specified EMC performance, you must install PXI EMC
Filler Panels, National Instruments part number 778700-01, in all open chassis slots.
Verifying the System Requirements
To use the NI-Digital Pattern Driver and Digital Pattern Editor, your system must meet certain
requirements.
Refer to the product readme, which is available online at ni.com/manuals or on the
NI-Digital Pattern Driver and Digital Pattern Editor Media (NI part number 785249-03), for
more information about minimum system requirements, recommended system, and supported
application development environments (ADEs).
Unpacking the Kit
Caution To prevent electrostatic discharge (ESD) from damaging the module,
ground yourself using a grounding strap or by holding a grounded object, such as
your computer chassis.
1. Touch the antistatic package to a metal part of the computer chassis.
2| ni.com | PXIe-6570 Getting Started Guide

2. Remove the module from the package and inspect it for loose components or other signs
of damage.
Caution Never touch the exposed pins of connectors.
Note Do not install a module if it appears damaged in any way.
3. Unpack any other items and documentation from the kit.
Store the module in the antistatic package when the module is not in use.
Kit Contents
The kit contains the following items:
• PXIe-6570 Digital Pattern Instrument
•PXIe-6570 Getting Started Guide (this document)
Note You can download the NI-Digital Pattern Driver and Digital Pattern Editor at
ni.com/downloads or purchase the NI-Digital Pattern Driver and Digital Pattern
Editor media (NI part number 785249-03) separately.
Preparing the Environment
Ensure that the environment in which you are using the PXIe-6570 meets the following
specifications:
Operating Environment
Ambient temperature range 0 °C to 45 °C (Tested in accordance with
IEC 60068-2-1 and IEC 60068-2-2. Meets
MIL-PRF-28800F Class 3 low temperature
limit and MIL-PRF-28800F Class 4 high
temperature limit.)
Relative humidity range 10% to 90%, noncondensing (Tested in
accordance with IEC 60068-2-56.)
Maximum altitude 2,000 m (800 mbar) (at 25 °C ambient
temperature)
Pollution Degree 2
Indoor use only.
Installing the Software
You must be an Administrator to install NI software on your computer.
1. Install an ADE, such as LabVIEW or Microsoft Visual Studio.
PXIe-6570 Getting Started Guide | © National Instruments | 3

2. Insert the software media USB or download the NI-Digital Pattern Driver and Digital
Pattern Editor at ni.com/downloads. The installer should open automatically after
inserting the software media USB.
If the installation window does not appear, navigate to the drive, double-click it, and
double-click autorun.exe.
3. Follow the instructions in the installation prompts.
a) Select .NET Framework 4.0 Languages Support or .NET Framework 4.5
Languages Support in the NI-Digital Pattern Driver installer to install .NET
support for the NI-Digital Pattern Driver software.
Note Windows users may see access and security messages during
installation. Accept the prompts to complete the installation.
4. When the installer completes, select Restart in the dialog box that prompts you to restart,
shut down, or restart later.
Digital Pattern Editor
Use the Digital Pattern Editor to view, create, modify, and debug pin and channel maps,
specifications, levels, timing, pattern, source waveform, and capture waveform files. You can
also use the Digital Pattern Editor to configure the state of the digital pattern instrument.
The Digital Pattern Editor is installed when you install NI-Digital Pattern Driver. For more
information, refer to the Digital Pattern Help.
To access Digital Pattern Editor documentation, in the Start menu, navigate to
NI Digital Pattern Documentation in the National Instruments folder. The primary help file
is digipat.chm, and all other help files in the folder are embedded in digipat.chm.
Related Information
Digital Pattern Instrument Examples on page 12
Operating the Digital Pattern Instrument on page 11
You can operate the PXIe-6570 through use of the Digital Pattern Editor or the supported
ADE of your choice.
Digital Pattern Help
NI-Digital Pattern Driver
NI-Digital Pattern Driver LabVIEW API
Use the NI-Digital VIs and properties in LabVIEW to configure and control the digital pattern
instrument. The NI-Digital Pattern Driver LabVIEW API is installed by default when you run
the installer. For more information, refer to the Digital Pattern Help.
NI-Digital Pattern Driver .NET API
You can optionally install and use the NI-Digital Pattern Driver .NET API to configure and
control the digital pattern instrument. For more information, refer to the Digital Pattern Help.
4| ni.com | PXIe-6570 Getting Started Guide

To access NI-Digital Pattern Driver documentation, in the Start menu, navigate to
NI Digital Pattern Documentation in the National Instruments folder. The primary help file
is digipat.chm, and all other help files in the folder are embedded in digipat.chm.
Related Information
Digital Pattern Instrument Examples on page 12
Operating the Digital Pattern Instrument on page 11
You can operate the PXIe-6570 through use of the Digital Pattern Editor or the supported
ADE of your choice.
Digital Pattern Help
Associated Drivers
NI-DCPower
The NI-DCPower driver is required to use NI-DCPower modules within the Digital Pattern
Editor. For more information about using NI-DCPower modules within the Digital Pattern
Editor, refer to the Digital Pattern Help. Visit ni.com/downloads to download NI-DCPower.
NI-Sync
The NI-Sync driver is required to support operations using the PXIe-6674T timing and
synchronization module, such as combining comparison results across digital pattern
instruments. For more information about using the PXIe-6674T with digital pattern
instruments, refer to the Digital Pattern Help. Visit ni.com/downloads to download NI-Sync.
Installing the PXIe-6570
Caution To prevent damage to the PXIe-6570 caused by ESD or contamination,
handle the module using the edges or the metal bracket.
1. Ensure the AC power source is connected to the chassis before installing the module.
The AC power cord grounds the chassis and protects it from electrical damage while you
install the module.
2. Power off the chassis.
3. Inspect the slot pins on the chassis backplane for any bends or damage prior to
installation. Do not install a module if the backplane is damaged.
4. Remove the black plastic covers from all the captive screws on the module front panel.
5. Identify the slots you will use in the chassis.
The PXIe-6570 is a two-slot module with two PXI Express backplane connectors. The
module must be installed into two adjacent PXI Express-compatible slots. If you plan to
use the optional PXIe-6674T Timing and Synchronization Module, reserve the PXI
Express System Timing Slot for its placement in the chassis. The following figure shows
the symbols that indicate the slot types.
PXIe-6570 Getting Started Guide | © National Instruments | 5

Figure 1. Chassis Compatibility Symbols
NI PXIe-1062Q
1
2
3
4
5
1. PXI Express System Controller Slot
2. PXI Peripheral Slot
3. PXI Express Hybrid Peripheral Slot
4. PXI Express System Timing Slot
5. PXI Express Peripheral Slot
6. Touch any metal part of the chassis to discharge static electricity.
7. Place the module edges into the module guides at the top and bottom of the chassis. Slide
the module into the slots until it is fully inserted.
Figure 2. PXIe-6570 Installation
4
3
2
1
1. PXI Express Chassis
2. Ejector Handle in Down Position
3. NI PXI Express Two-Slot Module
4. Captive Screw
8. Secure the module front panel to the chassis using the front-panel mounting screws.
Note Tightening the top and bottom mounting screws increases mechanical
stability and also electrically connects the front panel to the chassis, which can
improve the signal quality and electromagnetic performance.
9. Cover all empty slots using EMC filler panels or fill using slot blockers to maximize
cooling air flow, depending on your application.
10. Power on the chassis.
6| ni.com | PXIe-6570 Getting Started Guide

Connecting Signals
PXIe-6570 Front Panel
The PXIe-6570 front panel has a single 68-pin VHDCI Digital Data and Control (DDC)
connector. The following figure shows the front panel and pinout of the PXIe-6570 digital
pattern instrument.
Figure 3. PXIe-6570 Front Panel
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
68
67
66
65
64
63
62
61
60
59
58
57
56
55
54
53
52
51
50
49
48
47
46
45
44
43
42
41
40
39
38
37
36
35
GND
CAL FORCE
GND
DIO 0
CAL GND, DGS
DIO 2
GND
DIO 4
RESERVED
DIO 6
GND
DIO 8
GND
DIO 10
GND
DIO 12
GND
DIO 14
GND
DIO 16
GND
DIO 18
GND
DIO 20
GND
DIO 22
GND
DIO 24
GND
DIO 26
GND
DIO 28
GND
DIO 30
GND
CAL SENSE
GND
DIO 1
RESERVED
DIO 3
GND
DIO 5
CAL MEASURE
DIO 7
GND
DIO 9
GND
DIO 11
GND
DIO 13
GND
DIO 15
GND
DIO 17
GND
DIO 19
GND
DIO 21
GND
DIO 23
GND
DIO 25
GND
DIO 27
GND
DIO 29
GND
DIO 31
PXIe-6570 Getting Started Guide | © National Instruments | 7

Table 1. PXIe-6570 Digital Data and Control Connector Pins
Pins Signal Name Signal Type Signal Description
1, 3, 5, 7, 9, 11, 13, 15,
17, 19, 21, 23, 25, 27,
29, 31, 35, 37, 39, 41,
43, 45, 47, 49, 51, 53,
55, 57, 59, 61, 63, 65
DIO <0..31> Data Bidirectional PPMU-capable
digital I/O data channels 0
through 31.
2, 4, 6, 8, 10, 12, 14, 16,
18, 20, 22, 24, 28, 32,
34, 36, 38, 40, 42, 44,
46, 48, 50, 52, 54, 56,
58, 62, 66, 68
GND Ground Instrument ground. Also default
ground reference if DUT Ground
Sense (DGS) is not connected.
26 CAL MEASURE Analog Resource for external calibration.
33 CAL SENSE Analog Resource for external calibration.
64 DGS Ground Optional DGS for improved
accuracy at higher currents in
some configurations.
CAL GND Analog Resource for external calibration.
67 CAL FORCE Analog Resource for external calibration.
30, 60 RESERVED N/A These terminals are reserved for
future use. Do not connect to
these pins.
Note The 32 digital I/O data channels on the digital pattern instrument are split
into banks for PPMU operation efficiency: DIO<0..7>, DIO<8..15>, DIO<16..23>,
DIO<24..31>. PPMU measurements run in parallel when you take measurements on
channels in different banks.
LED Status Indicators
Status indicators on the front panel of the PXIe-6570 provide feedback about instrument
operation.
Use the following table to determine the PXIe-6570 state using the Access LED status
indicator.
8| ni.com | PXIe-6570 Getting Started Guide

Table 2. Access LED Status Indicator
Color Indications
Off Instrument not yet functional.
Amber Instrument being accessed by software.
Green Instrument ready to be programmed.
Use the following table to determine the PXIe-6570 state using the Active LED status
indicator.
Table 3. Active LED Status Indicator
Color Indications
Off Instrument is not waiting for a trigger, not bursting a pattern, and not experiencing
an error. During PPMU operations, the Active LED remains off.
Amber Instrument awaiting Start trigger.
Green Instrument received Start trigger and is bursting a pattern.
Red Instrument error condition.
Possible error conditions:
• Self-test failed on the instrument. This error condition will persist until the
instrument is reset or self-test succeeds.
• Self-calibration or external calibration adjustment failed on the instrument. This
error condition will persist until the instrument is reset or calibration succeeds.
• The instrument has detected an unlocked condition on a PLL that might result
in incorrect data. To clear this error condition, reset the instrument
programmatically or through Measurement & Automation Explorer (MAX).
• The instrument has been disabled because it exceeded its overall power limit.
To re-enable the instrument, reset it programmatically or through MAX.
• The instrument has been disabled because it exceeded its overall temperature
limit. To re-enable the instrument, cool the instrument to an acceptable range
and resolve the environmental condition that caused the shutdown. Reset the
instrument programmatically or through MAX, or power cycle the instrument.
Connecting to a Device Under Test
To connect a device under test (DUT) to the PXIe-6570, you can create a custom device
interface board to access the signals of the DUT. For more information, refer to the Interfacing
to the Digital Pattern Instrument or Digital Waveform Instrument using the VHDCI Connector
PXIe-6570 Getting Started Guide | © National Instruments | 9

application note. Go to ni.com/info and enter the info code rdinwa to locate the application
note.
Note If you plan to use the PXIe-6570 as part of an integrated system, such as a
Semiconductor Test System (STS), refer to the system documentation for guidance
on device interface board design and connection guidelines. For system
documentation, contact your NI sales engineer.
To connect a custom device interface board to the VHDCI Digital Data and Control connector
on the PXIe-6570, use a mating connector for the VHDCI cable from NI.
PXIe-6570 Accessories
Caution To ensure the specified EMC performance, operate this product only with
shielded cables and accessories. Do not use unshielded cables or accessories unless
they are installed in a shielded enclosure with properly designed and shielded input/
output ports and connected to the product using a shielded cable. If unshielded
cables or accessories are not properly installed and shielded, the EMC specifications
for the product are no longer guaranteed.
Description NI Part Number
NI CB-2162 Connector Block and Prototyping Board 778592-01
SCB-68 HSDIO Shielded Connector Block for R Series
and HSDIO Devices
782914-01
SMB-2163 SMB Breakout Box for High-Speed Digital
Devices
778747-01
NI SHC68-C68-D4 Shielded Single-Ended Cable for
High-Speed Digital Devices
781013-01 - 0.55 m
196275-01 - 1 m
152870-01 - 1 m
Low Leakage
781293-01 - 2 m
SHC68-H1X38 High-Speed Digital Flying-Lead Cable,
1.5 m
192681-1R5
VHDCI connectors 780389-01
778914-01
780390-01
NI-Digital Pattern Driver and Digital Pattern Editor
Media
785249-03
Note For more information on recommended accessories for use within a system
such as STS, contact your NI Sales Engineer.
10 | ni.com | PXIe-6570 Getting Started Guide

Configuring the PXIe-6570 in MAX
Use Measurement & Automation Explorer (MAX) to configure your NI hardware. MAX
informs other programs about which NI hardware products are in the system and how they are
configured. MAX is automatically installed with NI-Digital Pattern Driver.
1. Launch MAX.
2. In the configuration tree, expand Devices and Interfaces to see the list of installed NI
hardware.
Installed modules appear under the name of their associated chassis.
3. Expand your Chassis tree item.
MAX lists all modules installed in the chassis. Your default names may vary.
Note If you do not see your module listed, press <F5> to refresh the list of
installed modules. If the module is still not listed, power off the system, ensure
the module is correctly installed, and restart.
4. Record the identifier MAX assigns to the hardware. Use this identifier when
programming the PXIe-6570.
5. Self-test the hardware by selecting the item in the configuration tree and clicking Self-
Test in the MAX toolbar.
The MAX self-test of the PXIe-6570 performs a basic verification of hardware resources
and lasts several minutes.
Operating the Digital Pattern Instrument
You can operate the PXIe-6570 through use of the Digital Pattern Editor or the supported ADE
of your choice.
Table 4. PXIe-6570 Interactive Use Options
Application
Software
Location Description
Digital Pattern
Editor
In the Start menu, navigate
to NI Digital Pattern
Editor in the National
Instruments folder.
Use the Digital Pattern Editor to view,
create, modify, and debug pin and channel
maps, specifications, levels, timing,
pattern, source waveform, and capture
waveform files. You can also use the
Digital Pattern Editor to configure the
state of the digital pattern instrument.
PXIe-6570 Getting Started Guide | © National Instruments | 11

Table 5. PXIe-6570 Programming Options
Application Programming
Interface (API)
Location Description
NI-Digital Pattern Driver
LabVIEW API
For versions prior to
LabVIEW 2016,
available on the
LabVIEW
Functions palette at
Instrument I/O»
Instrument
Drivers»NI-Digital.
For LabVIEW 2016
and later, the palette
is also available at
Measurement I/O»
NI-Digital.
NI-Digital Pattern Driver
LabVIEW API provides access to
the configuration and control
options for applications using the
PXIe-6570.
NI-Digital Pattern Driver .NET
API
Available in
Microsoft Visual
Studio.
The NI-Digital Pattern Driver .NET
API provides access to the
configuration and control options
for applications using the
PXIe-6570.
Digital Pattern Instrument Examples
To locate programming and operating examples, refer to the following table.
Table 6. NI-Digital Pattern Driver Example Locations
Application
Software or
Application
Development
Environment (ADE)
Location
Getting Started Use the getting started examples, located by default in the <Public
Documents>\National Instruments\NI-Digital
\Examples\Getting Started directory, to help you learn key
concepts or to serve as a starting point for applications you create.
Digital Pattern Editor In the Start menu, navigate to NI Digital Pattern Editor in the
National Instruments folder to launch the Digital Pattern Editor. In
the Welcome window, click Examples or click the Learning tab to
launch the Learning window, which includes examples of common
usages of digital patterns.
12 | ni.com | PXIe-6570 Getting Started Guide

Table 6. NI-Digital Pattern Driver Example Locations (Continued)
Application
Software or
Application
Development
Environment (ADE)
Location
LabVIEW Use the NI Example Finder to locate LabVIEW examples. In
LabVIEW, select Help»Find Examples to launch the NI Example
Finder.
Microsoft Visual
Studio
The Microsoft .NET examples are located in the <Public
Documents>\National Instruments\NI-Digital
\Examples\DotNET 4.x directory. In the Start menu, navigate to
NI Digital Pattern Examples in the National Instruments folder.
Troubleshooting
If an issue persists after you complete a troubleshooting procedure, contact NI technical
support or visit ni.com/support.
What Should I Do if the PXIe-6570 Doesn't Appear in
MAX?
1. In the MAX configuration tree, expand Devices and Interfaces.
2. Expand the Chassis tree to see the list of installed hardware, and press <F5> to refresh
the list.
3. If the module is still not listed, power off the system, ensure that all hardware is correctly
installed, and restart the system.
4. Navigate to the Device Manager.
Operating System Description
Windows 10 Right-click the Start button, and select Device Manager.
Windows 7 Select Start»Control Panel»Device Manager.
5. If you are using a PXI or PXI Express controller, verify that a National Instruments
entry appears in the System Devices list. Reinstall NI-Digital Pattern Driver and the
module if error conditions appear in the list. If you are using an MXI controller, right-
click PCI-to-PCI Bridge, and select Properties from the shortcut menu to verify that the
bridge is enabled.
What Should I Do if the Module Fails the Self-Test?
1. Restart the system.
2. Launch MAX, and perform the self-test again.
PXIe-6570 Getting Started Guide | © National Instruments | 13

3. Power off the chassis.
4. Reinstall the failed module in a different slot.
5. Power on the chassis.
6. Perform the self-test again.
Why Is the ACCESS LED Off When the Chassis Is
On?
The LEDs may not illuminate until the module has been configured in MAX. Before
proceeding, verify that the PXIe-6570 appears in MAX.
If the ACCESS LED fails to illuminate after you power on the PXI Express chassis, a problem
may exist with the PXI Express power rails, a hardware module, or the LED.
1. Caution Apply external signals only while the PXIe-6570 is powered on.
Applying external signals while the module is powered off may cause damage.
Disconnect any signals from the PXI Express module front panels.
2. Remove any front panel connections from the PXIe-6570.
3. Power off the PXI Express chassis.
4. Remove the module from the PXI Express chassis and inspect it for damage. Do not
reinstall a damaged module.
5. Install the module in a different PXI Express chassis slot from which you removed it.
6. Power on the PXI Express chassis.
7. Verify that the module appears in MAX.
8. Reset the module in MAX and perform a self-test.
If the ACCESS LED still fails to illuminate and failures continue, contact NI technical support
or visit ni.com/support.
14 | ni.com | PXIe-6570 Getting Started Guide

Where to Go Next
more about your products through ni.com.
*This item is also installed with the driver software.
DISCOVER
Services
ni.com/services
NI Community
ni.com/community
Support
ni.com/support
PROGRAM
Located online at ni.com/manuals Located using the NI Example Finder
Digital Pattern Help*
NI-Digital Pattern
Examples*
NI-Digital Pattern
Driver
DEVELOP +DEBUGEXPLORE
PXIe-6570 Specifications*
Getting Started
with LabVIEW
Develop pin and channel
map files, specifications
files, pin levels, time sets,
and pattern files using the
Digital Pattern Editor.
Debug with pin view pane,
History RAM results,
Shmoo plots, and
digital scope.
the Digital Pattern Editor,
application development
environment (ADE)
and instrument specifications.
patterns and configuration files
for the digital pattern instrument.
custom applications with
NI-Digital Pattern Driver
LabVIEW or .NET API.
Digital Instruments
ni.com/digital-instruments
National Instruments
.NET Support
Digital Pattern Help*
Worldwide Support and Services
The NI website is your complete resource for technical support. At ni.com/support, you have
access to everything from troubleshooting and application development self-help resources to
email and phone assistance from NI Application Engineers.
Visit ni.com/services for NI Factory Installation Services, repairs, extended warranty, and
other services.
Visit ni.com/register to register your NI product. Product registration facilitates technical
support and ensures that you receive important information updates from NI.
A Declaration of Conformity (DoC) is our claim of compliance with the Council of the
European Communities using the manufacturer’s declaration of conformity. This system
affords the user protection for electromagnetic compatibility (EMC) and product safety. You
can obtain the DoC for your product by visiting ni.com/certification. If your product supports
calibration, you can obtain the calibration certificate for your product at ni.com/calibration.
PXIe-6570 Getting Started Guide | © National Instruments | 15

NI corporate headquarters is located at 11500 North Mopac Expressway, Austin, Texas,
78759-3504. NI also has offices located around the world. For telephone support in the United
States, create your service request at ni.com/support or dial 1 866 ASK MYNI (275 6964). For
telephone support outside the United States, visit the Worldwide Offices section of ni.com/
niglobal to access the branch office websites, which provide up-to-date contact information,
support phone numbers, email addresses, and current events.
Refer to the NI Trademarks and Logo Guidelines at ni.com/trademarks for information on NI trademarks. Other product and
company names mentioned herein are trademarks or trade names of their respective companies. For patents covering NI
products/technology, refer to the appropriate location: Help»Patents in your software, the patents.txt file on your media, or the
National Instruments Patent Notice at ni.com/patents. You can find information about end-user license agreements (EULAs)
and third-party legal notices in the readme file for your NI product. Refer to the Export Compliance Information at ni.com/
legal/export-compliance for the NI global trade compliance policy and how to obtain relevant HTS codes, ECCNs, and other
import/export data. NI MAKES NO EXPRESS OR IMPLIED WARRANTIES AS TO THE ACCURACY OF THE INFORMATION
CONTAINED HEREIN AND SHALL NOT BE LIABLE FOR ANY ERRORS. U.S. Government Customers: The data contained in
this manual was developed at private expense and is subject to the applicable limited rights and restricted data rights as set forth
in FAR 52.227-14, DFAR 252.227-7014, and DFAR 252.227-7015.
© 2016 National Instruments. All rights reserved.
376528A-01 Sep16
