NI-9209 Getting
Started
2022-07-06

Contents
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
NI-9209 with Spring Terminal Safety Voltages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
NI-9209 with DSUB Safety Voltages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Safety Guidelines for Hazardous Locations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Electromagnetic Compatibility Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Special Conditions for Marine Applications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Preparing the Environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
NI 9209 Pinout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Signals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Grounded Dierential Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Floating Dierential Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Single-Ended Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
NI-9209 Connection Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
High-Vibration Application Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Overvoltage Protection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Where to Go Next. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
NI Services. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
ni.com
2
NI-9209 Getting Started

Overview
This document explains how to connect to the NI-9209. In this document, the
NI-9209 with spring terminal and the NI-9209 with DSUB are referred to inclusively
as the NI-9209.
Note Before you begin, read the NI-9209 Safety, Environmental, and
Regulatory Information document on ni.com/manuals and complete the
soware and hardware installation procedures in your chassis
documentation.
Note The guidelines in this document are specific to the NI-9209. The
other components in the system might not meet the same safety ratings.
Refer to the documentation for each component in the system to
determine the safety and EMC ratings for the entire system.
Safety Guidelines
Caution Observe all instructions and cautions in the user documentation.
Using the product in a manner not specified can damage the product and
compromise the built-in safety protection.
Attention Suivez toutes les instructions et respectez toutes les mises
en garde de la documentation d'utilisation. L'utilisation du produit de
toute autre façon que celle spécifiée risque de l'endommager et de
compromettre la protection de sécurité intégrée.
NI-9209 with Spring Terminal Safety Voltages
Connect only voltages that are within the following limits:
Isolation
© National Instruments 3
NI-9209 Getting Started

Channel-to-channel None
Channel-to-earth ground
Continuous 250 V RMS, Measurement Category II
Withstand up to 5,000 m 3,000 V RMS, verified by a 5 s dielectric withstand test
NI-9209 with DSUB Safety Voltages
Connect only voltages that are within the following limits:
Isolation
Channel-to-channel None
Channel-to-earth ground
Continuous 60 V DC, Measurement Category I
Withstand 1,000 V RMS up to 3,000 m, verified by a 5 s dielectric withstand test; 860 V RMS up
to 5,000 m
Safety Guidelines for Hazardous Locations
The NI-9209 is suitable for use in hazardous locations; , and hazardous locations;
and nonhazardous locations only. Follow these guidelines if you are installing the
NI-9209 in a potentially explosive environment. Not following these guidelines may
result in serious injury or death.
Caution Do not disconnect I/O-side wires or connectors unless power has
been switched o or the area is known to be nonhazardous.
Caution Do not remove modules unless power has been switched o or
the area is known to be nonhazardous.
ni.com
4
NI-9209 Getting Started

Caution Substitution of components may impair suitability for Class I,
Division 2, or Zone 2.
Caution The system must be installed in an enclosure certified for the
intended hazardous (classified) location, having a tool secured cover/door,
where a minimum protection of at least IP54 is provided.
Special Conditions for Hazardous Locations Use in Europe and
Internationally
The NI-9209 has been evaluated as equipment under DEMKO ATEX and is IECEx
certified. Each NI-9209 is marked and is suitable for use in Zone 2 hazardous
locations, in ambient temperatures of -40 °C ≤ Ta ≤ 70 °C. If you are using the NI-9209
in Gas Group IIC hazardous locations, you must use the device in an NI chassis that
has been evaluated as Ex nC IIC T4, Ex IIC T4, Ex nA IIC T4, or Ex nL IIC T4 equipment.
Caution Transient protection shall be provided that is set at a level not
exceeding 140% of the peak rated voltage value of 85 V at the supply
terminals to the equipment.
Caution The system shall only be used in an area of not more than
Pollution Degree 2, as defined in IEC/EN 60664-1.
Caution The system shall be mounted in an ATEX/IECEx-certified
enclosure with a minimum ingress protection rating of at least IP54 as
defined in IEC/EN 60079-15.
Caution The enclosure must have a door or cover accessible only by the
use of a tool.
© National Instruments 5
NI-9209 Getting Started

Electromagnetic Compatibility Guidelines
This product was tested and complies with the regulatory requirements and limits
for electromagnetic compatibility (EMC) stated in the product specifications. These
requirements and limits provide reasonable protection against harmful interference
when the product is operated in the intended operational electromagnetic
environment.
This product is intended for use in industrial locations. However, harmful
interference may occur in some installations, when the product is connected to a
peripheral device or test object, or if the product is used in residential or
commercial areas. To minimize interference with radio and television reception and
prevent unacceptable performance degradation, install and use this product in strict
accordance with the instructions in the product documentation.
Furthermore, any changes or modifications to the product not expressly approved
by National Instruments could void your authority to operate it under your local
regulatory rules.
Special Conditions for Marine Applications
Some products are approved for marine (shipboard) applications. To verify marine
approval certification for a product, visit ni.com/product-certifications, search by
model number, and click the appropriate link.
Notice In order to meet the EMC requirements for marine applications,
install the product in a shielded enclosure with shielded and/or filtered
power and input/output ports. In addition, take precautions when
designing, selecting, and installing measurement probes and cables to
ensure that the desired EMC performance is attained.
Preparing the Environment
Ensure that the environment in which you are using the NI-9209 meets the following
specifications.
Operating temperature (IEC 60068-2-1, IEC 60068-2-2) -40 °C to 70 °C
ni.com
6
NI-9209 Getting Started

Operating humidity (IEC 60068-2-30) 10% RH to 90% RH, noncondensing
Pollution Degree 2
Maximum altitude 5,000 m
Indoor use only.
Note Refer to the NI-9209 Specifications on ni.com/manuals for
complete specifications.
NI 9209 Pinout
Signal Description
AI Analog input signal connection
COM Common reference connection to isolated ground
NC No connection
Table 1. Signal Descriptions
Signals
You can connect single-ended or dierential signals to the NI-9209. Use a dierential
measurement configuration to attain more accurate measurements and less noise.
The following table shows the signal pairs that are valid for dierential connection
configurations with the NI-9209.
Channel AI + AI-
0 AI0 AI8
1 AI1 AI9
2 AI2 AI10
© National Instruments 7
NI-9209 Getting Started

Channel AI + AI-
3 AI3 AI11
4 AI4 AI12
5 AI5 AI13
6 AI6 AI14
7 AI7 AI15
16 AI16 AI24
17 AI17 AI25
18 AI18 AI26
19 AI19 AI27
20 AI20 AI28
21 AI21 AI29
22 AI22 AI30
23 AI23 AI31
Table 2. Dierential Pairs
Grounded Dierential Connections
Voltage
Source
+
–
AI+
AI–
COM
NI 9209
Floating Dierential Connections
1 MΩ
Resistor
NI 9209
AI+
AI–
COM
Voltage
Source
+
–
ni.com
8
NI-9209 Getting Started

Single-Ended Connections
+
–
AI
COM
Voltage
Source
NI 9209
NI-9209 Connection Guidelines
■ Make sure that devices you connect to the NI-9209 are compatible with the
module specifications.
■ You must use 2-wire ferrules to create a secure connection when connecting
more than one wire to a single terminal on the NI-9209 with spring terminal.
■ Push the wire into the terminal when using a solid wire or a stranded wire
with a ferrule.
■ Open the terminal by pressing the push button when using stranded wire
without a ferrule.
High-Vibration Application Connections
If your application is subject to high vibration, NI recommends that you use the
NI-9940 backshell kit to protect connections to the NI-9209 with spring terminal.
Overvoltage Protection
The NI-9209 provides overvoltage protection for each channel.
Note Refer to the NI-9209 Specifications on ni.com/manuals for more
information about overvoltage protection.
Where to Go Next
© National Instruments 9
NI-9209 Getting Started

Located at ni.com/manuals Installs with the software
CompactRIO NI CompactDAQ
RELATED INFORMATION
NI 9209 Datasheet
NI-RIO Help
LabVIEW FPGA Help
NI 9209 Datasheet
NI-DAQmx Help
LabVIEW Help
Services
ni.com/services
C Series Documentation
& Resources
ni.com/info cseriesdoc
NI Services
Visit ni.com/support to find support resources including documentation,
downloads, and troubleshooting and application development self-help such as
tutorials and examples.
Visit ni.com/services to learn about NI service oerings such as calibration options,
repair, and replacement.
Visit ni.com/register to register your NI product. Product registration facilitates
technical support and ensures that you receive important information updates from
NI.
NI corporate headquarters is located at 11500 N Mopac Expwy, Austin, TX,
78759-3504, USA.
