National Instruments NI 9220 User manual

NI-9220 Getting
Started
2022-07-06

Contents
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety Guidelines for Hazardous Voltages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety Guidelines for Hazardous Locations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Electromagnetic Compatibility Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Special Conditions for Marine Applications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Preparing the Environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
NI 9220 Pinout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Grounded Dierential Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Floating Dierential Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Single-Ended Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
NI-9220 Connection Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Connecting to a Spring-Terminal Connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
High-Vibration Application Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Overvoltage Protection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
NI Services. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
ni.com
2
NI-9220 Getting Started

Overview
This document explains how to connect to the NI-9220.
Note Before you begin, read the NI-9220 Safety, Environmental, and
Regulatory Information document on ni.com/manuals and complete the
soware and hardware installation procedures in your chassis
documentation.
Note The guidelines in this document are specific to the NI-9220. The
other components in the system might not meet the same safety ratings.
Refer to the documentation for each component in the system to
determine the safety and EMC ratings for the entire system.
Safety Guidelines
Caution Observe all instructions and cautions in the user documentation.
Using the product in a manner not specified can damage the product and
compromise the built-in safety protection.
Attention Suivez toutes les instructions et respectez toutes les mises
en garde de la documentation d'utilisation. L'utilisation du produit de
toute autre façon que celle spécifiée risque de l'endommager et de
compromettre la protection de sécurité intégrée.
Safety Guidelines for Hazardous Voltages
If hazardous voltages are connected to the product, take the following precautions.
A hazardous voltage is a voltage greater than:
■ 30 V RMS, 42.4 V peak, or 60 V DC in DRY LOCATIONS
■ 16 V RMS, 22.6 V peak, or 35 V DC in WET LOCATIONS
© National Instruments 3
NI-9220 Getting Started

Caution Ensure that hazardous voltage wiring is performed only by
qualified personnel adhering to local electrical standards.
Attention S'assurer que le câblage à tension dangereuse est eectué par
du personnel qualifié respectant les normes électriques locales.
Caution Do not mix hazardous voltage circuits and human-accessible
circuits on the same product.
Attention Ne pas combiner des circuits avec des tensions dangereuses et
des circuits accessibles aux personnes sur le même produit.
Caution When product terminals are hazardous voltage LIVE, you must
ensure that devices and circuits connected to the product are properly
insulated from human contact.
Attention Lorsqu'une haute tension dangereuse est appliquée aux
bornes du produit, vous devez vous assurer que les appareils et les circuits
auxquels il est connecté sont correctement isolés de tout contact humain.
Caution You must use the connector backshell kit to ensure that the
terminals are not accessible.
Safety Guidelines for Hazardous Locations
The NI-9220 is suitable for use in hazardous locations; , and hazardous locations;
and nonhazardous locations only. Follow these guidelines if you are installing the
NI-9220 in a potentially explosive environment. Not following these guidelines may
result in serious injury or death.
ni.com
4
NI-9220 Getting Started

Caution Do not disconnect I/O-side wires or connectors unless power has
been switched o or the area is known to be nonhazardous.
Caution Do not remove modules unless power has been switched o or
the area is known to be nonhazardous.
Caution Substitution of components may impair suitability for Class I,
Division 2, or Zone 2.
Caution The system must be installed in an enclosure certified for the
intended hazardous (classified) location, having a tool secured cover/door,
where a minimum protection of at least IP54 is provided.
Caution For Division 2 and Zone 2 applications, connected signals must
be within the following limits.
Capacitance 0.2 µF maximum
Special Conditions for Hazardous Locations Use in Europe and
Internationally
The NI-9220 has been evaluated as equipment under DEMKO ATEX and is IECEx
certified. Each NI-9220 is marked and is suitable for use in Zone 2 hazardous
locations, in ambient temperatures of -40 °C ≤ Ta ≤ 70 °C. If you are using the NI-9220
in Gas Group IIC hazardous locations, you must use the device in an NI chassis that
has been evaluated as Ex nC IIC T4, Ex IIC T4, Ex nA IIC T4, or Ex nL IIC T4 equipment.
Caution Transient protection shall be provided that is set at a level not
exceeding 140% of the peak rated voltage value of 85 V at the supply
terminals to the equipment.
© National Instruments 5
NI-9220 Getting Started

Caution The system shall only be used in an area of not more than
Pollution Degree 2, as defined in IEC/EN 60664-1.
Caution The system shall be mounted in an ATEX/IECEx-certified
enclosure with a minimum ingress protection rating of at least IP54 as
defined in IEC/EN 60079-15.
Caution The enclosure must have a door or cover accessible only by the
use of a tool.
Electromagnetic Compatibility Guidelines
This product was tested and complies with the regulatory requirements and limits
for electromagnetic compatibility (EMC) stated in the product specifications. These
requirements and limits provide reasonable protection against harmful interference
when the product is operated in the intended operational electromagnetic
environment.
This product is intended for use in industrial locations. However, harmful
interference may occur in some installations, when the product is connected to a
peripheral device or test object, or if the product is used in residential or
commercial areas. To minimize interference with radio and television reception and
prevent unacceptable performance degradation, install and use this product in strict
accordance with the instructions in the product documentation.
Furthermore, any changes or modifications to the product not expressly approved
by National Instruments could void your authority to operate it under your local
regulatory rules.
Special Conditions for Marine Applications
Some products are approved for marine (shipboard) applications. To verify marine
approval certification for a product, visit ni.com/product-certifications, search by
model number, and click the appropriate link.
ni.com
6
NI-9220 Getting Started

Notice In order to meet the EMC requirements for marine applications,
install the product in a shielded enclosure with shielded and/or filtered
power and input/output ports. In addition, take precautions when
designing, selecting, and installing measurement probes and cables to
ensure that the desired EMC performance is attained.
Preparing the Environment
Ensure that the environment in which you are using the NI-9220 meets the following
specifications.
Operating temperature (IEC 60068-2-1, IEC 60068-2-2) -40 °C to 70 °C
Operating humidity (IEC 60068-2-78) 10% RH to 90% RH, noncondensing
Pollution Degree 2
Maximum altitude 2,000 m
Indoor use only.
Note Refer to the device datasheet on ni.com/manuals for complete
specifications.
NI 9220 Pinout
© National Instruments 7
NI-9220 Getting Started

AI0-
AI1-
AI2-
AI3-
AI4-
AI5-
AI6-
AI7-
COM
COM
AI8-
AI9-
AI10-
AI11-
AI12-
AI13-
AI14-
AI15-
AI0+
AI1+
AI2+
AI3+
AI4+
AI5+
AI6+
AI7+
COM
COM
AI8+
AI9+
AI10+
AI11+
AI12+
AI13+
AI14+
AI15+
COM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
AI0+
AI1+
AI3+
AI5+
AI7+
AI9+
AI11+
AI13+
AI15+
COM
AI2+
AI4+
AI6+
AI8+
AI10+
AI12+
AI14+
COM
AI1-
AI0-
AI2-
AI4-
AI6-
AI8-
AI10-
AI12-
AI14-
COM
AI3-
AI5-
AI7-
AI9-
AI11-
AI13-
AI15-
COM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
Signal Description
AI+ Positive analog input signal connection
AI- Negative analog input signal connection
COM Common reference connection to isolated ground
Table 1. Signal Descriptions
Grounded Dierential Connections
Floating Dierential Connections
Single-Ended Connections
NI-9220 Connection Guidelines
Make sure that devices you connect to the NI-9220 are compatible with the module
specifications.
ni.com
8
NI-9220 Getting Started

Connecting to a Spring-Terminal Connector
What to Use
■ NI-9220 spring-terminal connector
■ copper conductor wire with of insulation stripped from the end
■Flathead screwdriver with a 2.3 mm x 1.0 mm (0.09 in. x 0.04 in.) blade,
included with the NI-9220
What to Do
Complete the following steps to connect wires to the spring-terminal connector.
1. Insert the screwdriver into a spring clamp activation slot to open the
corresponding connector terminal.
2. Press a wire into the open connector terminal.
3. Remove the screwdriver from the activation slot to clamp the wire into place.
High-Vibration Application Connections
If your application is subject to high vibration, NI recommends that you use the
backshell kit to protect connections to the NI-9220 with spring terminal.
Overvoltage Protection
The NI-9220 provides overvoltage protection for each channel.
Note Refer to the NI-9220 Specifications on ni.com/manuals for more
information about overvoltage protection.
NI Services
Visit ni.com/support to find support resources including documentation,
downloads, and troubleshooting and application development self-help such as
tutorials and examples.
© National Instruments 9
NI-9220 Getting Started

Visit ni.com/services to learn about NI service oerings such as calibration options,
repair, and replacement.
Visit ni.com/register to register your NI product. Product registration facilitates
technical support and ensures that you receive important information updates from
NI.
NI corporate headquarters is located at 11500 N Mopac Expwy, Austin, TX,
78759-3504, USA.
