National Instruments IMAQ PXI-1409 User manual

IMAQTM
IMAQ PXI/PCI-1409 User Manual
High-Quality Monochrome Image Acquisition Devices
for PXI, PCI, and CompactPCI Bus
IMAQ PXI/PCI-1409 User Manual
June 2003 Edition
Part Number 322811B-01

Support
Worldwide Technical Support and Product Information
ni.com
National Instruments Corporate Headquarters
11500 North Mopac Expressway Austin, Texas 78759-3504 USA Tel: [phone]
Worldwide Offices
Australia1800300800,Austria4306624579900,Belgium32027570020,Brazil551132623599,
Canada (Calgary) 403 274 9391, Canada (Montreal) 514 288 5722, Canada (Ottawa) 613 233 5949,
Canada (Québec) 514 694 8521, Canada (Toronto) 905 785 0085, Canada (Vancouver) 514 685 7530,
China 86 21 6555 7838, Czech Republic 420 2 2423 5774, Denmark 45 45 76 26 00,
Finland3850972572511,France330148142424,Germany490897413130,Greece302104296427,
India918051190000,Israel972036393737,Italy3902413091,Japan81354722970,
Korea820234513400,Malaysia60391310918,Mexico0018000100793,Netherlands310348433466,
NewZealand1800300800,Norway47066907660,Poland480223390150,Portugal351210311210,
Russia 7 095 238 7139, Singapore 65 6226 5886, Slovenia 386 3 425 4200, South Africa 27 0 11 805 8197,
Spain34916400085,Sweden460858789500,Switzerland41562005151,Taiwan886225287227,
Thailand 662 992 7519, United Kingdom 44 0 1635 523545
For further support information, refer to the Technical Support and Professional Services appendix. To comment
on the documentation, send email to [email protected].
©2000–2003 National Instruments Corporation. All rights reserved.

Important Information
Warranty
The IMAQ PXI-1409 and PCI-1409 are warranted against defects in materials and workmanship for a period of one year from the date of
shipment, as evidenced by receipts or other documentation. National Instruments will, at its option, repair or replace equipment that proves to
be defective during the warranty period. This warranty includes parts and labor.
The media on which you receive National Instruments software are warranted not to fail to execute programming instructions, due to defects
in materials and workmanship, for a period of 90 days from date of shipment, as evidenced by receipts or other documentation. National
Instruments will, at its option, repair or replace software media that do not execute programming instructions if National Instruments receives
notice of such defects during the warranty period. National Instruments does not warrant that the operation of the software shall be
uninterrupted or error free.
A Return Material Authorization (RMA) number must be obtained from the factory and clearly marked on the outside of the package before
any equipment will be accepted for warranty work. National Instruments will pay the shipping costs of returning to the owner parts which are
covered by warranty.
National Instruments believes that the information in this document is accurate. The document has been carefully reviewed for technical
accuracy. In the event that technical or typographical errors exist, National Instruments reserves the right to make changes to subsequent
editions of this document without prior notice to holders of this edition. The reader should consult National Instruments if errors are suspected.
In no event shall National Instruments be liable for any damages arising out of or related to this document or the information contained in it.
EXCEPT AS SPECIFIED HEREIN, NATIONAL INSTRUMENTS MAKES NO WARRANTIES, EXPRESS OR IMPLIED, AND SPECIFICALLY DISCLAIMS ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR APARTICULAR PURPOSE. CUSTOMER’SRIGHT TO RECOVER DAMAGES CAUSED BY FAULT OR NEGLIGENCE ON THE PART OF
NATIONAL INSTRUMENTS SHALL BE LIMITED TO THE AMOUNT THERETOFORE PAID BY THE CUSTOMER. NATIONAL INSTRUMENTS WILL NOT BE LIABLE FOR
DAMAGES RESULTING FROM LOSS OF DATA, PROFITS, USE OF PRODUCTS, OR INCIDENTAL OR CONSEQUENTIAL DAMAGES, EVEN IF ADVISED OF THE POSSIBILITY
THEREOF. This limitation of the liability of National Instruments will apply regardless of the form of action, whether in contract or tort, including
negligence. Any action against National Instruments must be brought within one year after the cause of action accrues. National Instruments
shall not be liable for any delay in performance due to causes beyond its reasonable control. The warranty provided herein does not cover
damages, defects, malfunctions, or service failures caused by owner’s failure to follow the National Instruments installation, operation, or
maintenance instructions; owner’s modification of the product; owner’s abuse, misuse, or negligent acts; and power failure or surges, fire,
flood, accident, actions of third parties, or other events outside reasonable control.
Copyright
Under the copyright laws, this publication may not be reproduced or transmitted in any form, electronic or mechanical, including photocopying,
recording, storing in an information retrieval system, or translating, in whole or in part, without the prior written consent of National
Instruments Corporation.
Trademarks
CVI™, IMAQ™, LabVIEW™, Measurement Studio™, MITE™, National Instruments™, NI™, ni.com™, NI-DAQ™, NI-IMAQ™, and RTSI™
are trademarks of National Instruments Corporation.
Product and company names mentioned herein are trademarks or trade names of their respective companies.
Patents
For patents covering National Instruments products, refer to the appropriate location: Help»Patents in your software, the patents.txt file
on your CD, or ni.com/patents.
WARNING REGARDING USE OF NATIONAL INSTRUMENTS PRODUCTS
(1) NATIONAL INSTRUMENTS PRODUCTS ARE NOT DESIGNED WITH COMPONENTS AND TESTING FOR A LEVEL OF
RELIABILITY SUITABLE FOR USE IN OR IN CONNECTION WITH SURGICAL IMPLANTS OR AS CRITICAL COMPONENTS IN
ANY LIFE SUPPORT SYSTEMS WHOSE FAILURE TO PERFORM CAN REASONABLY BE EXPECTED TO CAUSE SIGNIFICANT
INJURY TO A HUMAN.
(2) IN ANY APPLICATION, INCLUDING THE ABOVE, RELIABILITY OF OPERATION OF THE SOFTWARE PRODUCTS CAN BE
IMPAIRED BY ADVERSE FACTORS, INCLUDING BUT NOT LIMITED TO FLUCTUATIONS IN ELECTRICAL POWER SUPPLY,
COMPUTER HARDWARE MALFUNCTIONS, COMPUTER OPERATING SYSTEM SOFTWARE FITNESS, FITNESS OF COMPILERS
AND DEVELOPMENT SOFTWARE USED TO DEVELOP AN APPLICATION, INSTALLATION ERRORS, SOFTWARE AND
HARDWARE COMPATIBILITY PROBLEMS, MALFUNCTIONS OR FAILURES OF ELECTRONIC MONITORING OR CONTROL
DEVICES, TRANSIENT FAILURES OF ELECTRONIC SYSTEMS (HARDWARE AND/OR SOFTWARE), UNANTICIPATED USES OR
MISUSES, OR ERRORS ON THE PART OF THE USER OR APPLICATIONS DESIGNER (ADVERSE FACTORS SUCH AS THESE ARE
HEREAFTER COLLECTIVELY TERMED “SYSTEM FAILURES”). ANY APPLICATION WHERE A SYSTEM FAILURE WOULD
CREATE A RISK OF HARM TO PROPERTY OR PERSONS (INCLUDING THE RISK OF BODILY INJURY AND DEATH) SHOULD
NOT BE RELIANT SOLELY UPON ONE FORM OF ELECTRONIC SYSTEM DUE TO THE RISK OF SYSTEM FAILURE. TO AVOID
DAMAGE, INJURY, OR DEATH, THE USER OR APPLICATION DESIGNER MUST TAKE REASONABLY PRUDENT STEPS TO
PROTECT AGAINST SYSTEM FAILURES, INCLUDING BUT NOT LIMITED TO BACK-UP OR SHUT DOWN MECHANISMS.
BECAUSE EACH END-USER SYSTEM IS CUSTOMIZED AND DIFFERS FROM NATIONAL INSTRUMENTS' TESTING
PLATFORMS AND BECAUSE A USER OR APPLICATION DESIGNER MAY USE NATIONAL INSTRUMENTS PRODUCTS IN
COMBINATION WITH OTHER PRODUCTS IN A MANNER NOT EVALUATED OR CONTEMPLATED BY NATIONAL
INSTRUMENTS, THE USER OR APPLICATION DESIGNER IS ULTIMATELY RESPONSIBLE FOR VERIFYING AND VALIDATING
THE SUITABILITY OF NATIONAL INSTRUMENTS PRODUCTS WHENEVER NATIONAL INSTRUMENTS PRODUCTS ARE
INCORPORATED IN A SYSTEM OR APPLICATION, INCLUDING, WITHOUT LIMITATION, THE APPROPRIATE DESIGN,
PROCESS AND SAFETY LEVEL OF SUCH SYSTEM OR APPLICATION.

Compliance
FCC/Canada Radio Frequency Interference Compliance
Determining FCC Class
The Federal Communications Commission (FCC) has rules to protect wireless communications from interference. The FCC
places digital electronics into two classes. These classes are known as Class A (for use in industrial-commercial locations only)
or Class B (for use in residential or commercial locations). All National Instruments (NI) products are FCC Class A products.
Depending on where it is operated, this Class A product could be subject to restrictions in the FCC rules. (In Canada, the
Department of Communications (DOC), of Industry Canada, regulates wireless interference in much the same way.) Digital
electronics emit weak signals during normal operation that can affect radio, television, or other wireless products.
All Class A products display a simple warning statement of one paragraph in length regarding interference and undesired
operation. The FCC rules have restrictions regarding the locations where FCC Class A products can be operated.
Consult the FCC Web site at www.fcc.gov for more information.
FCC/DOC Warnings
This equipment generates and uses radio frequency energy and, if not installed and used in strict accordance with the instructions
in this manual and the CE marking Declaration of Conformity*, may cause interference to radio and television reception.
Classification requirements are the same for the Federal Communications Commission (FCC) and the Canadian Department of
Communications (DOC).
Changes or modifications not expressly approved by NI could void the user’s authority to operate the equipment under the FCC
Rules.
Class A
Federal Communications Commission
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user is required to correct the interference
at their own expense.
Canadian Department of Communications
This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.
Compliance to EU Directives
Readers in the European Union (EU) must refer to the manufacturer’s Declaration of Conformity (DoC) for information*
pertaining to the CE marking compliance scheme. The manufacturer includes a DoC for most hardware products except for those
bought from OEMs. In addition, DoCs are usually not provided if compliance is not required, for example electrically benign
apparatus or cables.
To obtain the DoC for this product, click Declarations of Conformity Information at ni.com/hardref.nsf/. This Web site
lists the DoCs by product family. Select the appropriate product family, followed by your product, and a link to the DoC appears
in Adobe Acrobat format. Click the Acrobat icon to download or read the DoC.
* The CE marking Declaration of Conformity contains important supplementary information and instructions for the user or
installer.

Conventions
The following conventions are used in this manual:
<> Angle brackets that contain numbers separated by an ellipsis represent a
range of values associated with a bit or signal name—for example,
DIO<3..0>.
»The »symbol leads you through nested menu items and dialog box options
to a final action. The sequence File»Page Setup»Options directs you to
pull down the File menu, select the Page Setup item, and select Options
from the last dialog box.
This icon denotes a note, which alerts you to important information.
This icon denotes a caution, which advises you of precautions to take to
avoid injury, data loss, or a system crash.
bold Bold text denotes items that you must select or click in the software, such
as menu items and dialog box options. Bold text also denotes parameter
names.
italic Italic text denotes variables, emphasis, a cross reference, or an introduction
to a key concept. This font also denotes text that is a placeholder for a word
or value that you must supply.
monospace Text in this font denotes text or characters that you should enter from the
keyboard, sections of code, programming examples, and syntax examples.
This font is also used for the proper names of disk drives, paths, directories,
programs, subprograms, subroutines, device names, functions, operations,
variables, filenames and extensions, and code excerpts.

©National Instruments Corporation vii IMAQ PXI/PCI-1409 User Manual
Contents
Chapter 1
Introduction
About the IMAQ 1409 Device.......................................................................................1-1
Using PXI with CompactPCI.........................................................................................1-2
Software Overview ........................................................................................................1-3
NI-IMAQ Driver Software ..............................................................................1-3
National Instruments Application Software ....................................................1-4
Vision Builder for Automated Inspection.........................................1-4
Vision Development Module ............................................................1-5
Integration with DAQ......................................................................................1-5
Vision and Motion...........................................................................................1-6
Chapter 2
Installation
Necessary Items .............................................................................................................2-1
Optional Equipment.......................................................................................................2-2
Unpacking......................................................................................................................2-2
Safety Information .........................................................................................................2-3
Installation .....................................................................................................................2-5
PXI-1409 .........................................................................................................2-5
PCI-1409..........................................................................................................2-6
Chapter 3
Hardware Overview
Functional Overview......................................................................................................3-1
Video Multiplexer ...........................................................................................3-2
Programmable Gain and Offset .......................................................................3-2
Analog Bandwidth Control Circuitry ..............................................................3-2
10-Bit ADC .....................................................................................................3-3
Digital Filter and LUT.....................................................................................3-3
Onboard Memory ............................................................................................3-3
Scatter-Gather DMA Controllers ....................................................................3-3
PCI Interface....................................................................................................3-3
Genlock Circuit and SYNC Mux ....................................................................3-3
Acquisition and Region-of-Interest (ROI) Control .........................................3-4
RTSI Bus .........................................................................................................3-4
Digital Input/Output Circuitry.........................................................................3-4

Contents
IMAQ PXI/PCI-1409 User Manual viii ni.com
Acquisition Modes......................................................................................................... 3-4
Analog Front End Considerations ................................................................................. 3-5
10-Bit/8-Bit Mode........................................................................................... 3-5
Clamping......................................................................................................... 3-6
Chapter 4
Signal Connections
BNC Connector ............................................................................................................. 4-1
Digital I/O Connector.................................................................................................... 4-1
Digital I/O Connector Signal Connection Descriptions.................................. 4-3
Appendix A
Specifications
Appendix B
Custom Cables
Appendix C
Technical Support and Professional Services
Glossary
Index

©National Instruments Corporation 1-1 IMAQ PXI/PCI-1409 User Manual
1
Introduction
This chapter describes the PXI-1409 and PCI-1409 devices and your
software programming choices.
About the IMAQ 1409 Device
The PXI-1409 and PCI-1409 devices are high-accuracy, monochrome
image acquisition (IMAQ) devices for PXI, PCI, or CompactPCI chassis
that support RS-170, CCIR, NTSC, and PAL video standards, as well
as some nonstandard cameras from any of four input sources. The
IMAQ 1409 features a 10-bit analog-to-digital converter (ADC) that
converts video signals to digital formats. The IMAQ 1409 device acquires
images in real time and stores them in onboard frame memory or transfers
them directly to system memory.
The IMAQ 1409 is easy to install and configure. It ships with NI-IMAQ,
the National Instruments complete image acquisition driver software you
can use to directly control the IMAQ 1409 device and other National
Instruments IMAQ devices. With NI-IMAQ, you can quickly and easily
start your applications without having to program the device at the register
level.
As a standalone device, the IMAQ 1409 device supports four
general-purpose control lines that are configurable to generate precise
timing signals for controlling camera acquisition. The IMAQ 1409 device
also supports four video sources and four external I/O lines to use as
triggers or digital I/O lines.
Easily synchronizing several functions to a common trigger or timing event
is a common challenge with image acquisition devices. The IMAQ 1409
uses its Real-Time System Integration (RTSI) bus to solve this problem.
The RTSI bus uses the National Instruments RTSI bus interface and ribbon
cable to route additional timing and trigger signals between the IMAQ 1409
device and up to four National Instruments DAQ, Motion Control, or other
IMAQ devices. The RTSI bus can even synchronize multiple IMAQ
hardware captures.

Chapter 1 Introduction
IMAQ PXI/PCI-1409 User Manual 1-2 ni.com
For detailed PXI/PCI-1409 specifications, refer to Appendix A,
Specifications.
Refer to Figure 1-1 for the location of the IMAQ 1409 W1 jumper and the
connectors discussed in this manual.
Figure 1-1. PCI-1409 Parts Locator Diagram
Using PXI with CompactPCI
Using PXI-compatible products with standard CompactPCI products is an
important feature provided by the PXI Specification, Revision 1.0. If you
use a PXI-compatible plug-in device in a standard CompactPCI chassis,
you cannot use PXI-specific functions, but you can still use the basic
plug-in device functions. For example, the RTSI bus on the PXI-1409
device is available in a PXI chassis, but not in a CompactPCI chassis.
The CompactPCI specification enables vendors to develop sub-buses that
coexist with the basic PCI interface on the CompactPCI bus. Compatible
operation is not guaranteed between CompactPCI devices with different
1 68-Pin VHDCI Connector
2 BNC Connector
3 W1 Jumper
4 RTSI Bus Connector
43
1
2

Chapter 1 Introduction
©National Instruments Corporation 1-3 IMAQ PXI/PCI-1409 User Manual
sub-buses or between CompactPCI devices with sub-buses and PXI.
The standard implementation for CompactPCI does not include these
sub-buses. The PXI-1409 device works in any standard CompactPCI
chassis adhering to the PICMG 2.0 R2.1 CompactPCI core specification
using the 64-bit definition for J2.
PXI-specific features are implemented on the J2 connector of the
CompactPCI bus. Table 1-1 lists the J2 pins the PXI-1409 device uses.
The PXI device is compatible with any CompactPCI chassis with a sub-bus
that does not drive these lines.
Caution Even if the sub-bus is capable of driving these lines, the PXI device is still
compatible as long as those pins on the sub-bus are disabled by default and are never
enabled. Damage may result if these lines are driven by the sub-bus.
Software Overview
Programming the IMAQ 1409 device requires the NI-IMAQ driver
software for controlling the hardware and one of the following application
software packages for image processing:
•Vision Builder for Automated Inspection (AI)—for configuring
solutions to common inspection tasks
•National Instruments Vision Development Module—for more
customized control over hardware and algorithms
The following sections provide an overview of the driver software and the
application software. For detailed information about individual software
packages, refer to the documentation specific to the package.
NI-IMAQ Driver Software
The NI-IMAQ driver software ships with the IMAQ 1409 device.
NI-IMAQ has an extensive library of functions you can call from your
application programming environment, such as routines for video
Table 1-1. Pins Used by the PXI-1409 Device
PXI-1409 Signal PXI Pin Name PXI J2 Pin Number
RTSI Trigger <0..6> PXI Trigger <0..6> B16, A16, A17, A18,
B18, C18, E18

Chapter 1 Introduction
IMAQ PXI/PCI-1409 User Manual 1-4 ni.com
configuration, image acquisition (continuous and single-shot), memory
buffer allocation, trigger control, and device configuration.
NI-IMAQ performs all functions required for acquiring and saving images
but does not perform image analysis. For image analysis functionality, refer
to the NationalInstruments ApplicationSoftware sectionofthis chapter.
NI-IMAQ is also the interface path between LabVIEW,
LabWindows™/CVI™, or a text-based programming environment and the
IMAQ device. The NI-IMAQ software kit includes a series of libraries for
image acquisition for LabVIEW, LabWindows/CVI, and Measurement
Studio, which contains libraries for Visual Basic.
For maximum flexibility and performance, NI-IMAQ features both
high-level and low-level functions. Examples of high-level functions
include the sequences to acquire images in multi-buffer, single-shot, or
continuous mode. An example of a low-level function is configuring an
image sequence, since it requires advanced understanding of the IMAQ
device and image acquisition.
NI-IMAQ handles many of the complex issues between the computer and
the IMAQ device, such as programming interrupts and camera control.
National Instruments Application Software
Vision Builder for Automated Inspection
NI Vision Builder for Automated Inspection (AI) is configurable machine
vision software that you can use to prototype, benchmark, and deploy
applications. Vision Builder AI does not require programming, but is
scalable to powerful programming environments.
Vision Builder AI allows you to easily configure and benchmark a
sequence of visual inspection steps, as well as deploy the visual inspection
system for automated inspection. With Vision Builder AI you can perform
powerful visual inspection tasks and make decisions based on the results of
individual tasks. With Vision Builder AI, you can migrate your configured
inspection to LabVIEW, extending the capabilities of your applications if
necessary.
Vision Builder AI is available for LabVIEW, LabWindows/CVI, and
Measurement Studio, which includes support for Visual Basic.

Chapter 1 Introduction
©National Instruments Corporation 1-5 IMAQ PXI/PCI-1409 User Manual
Vision Development Module
The Vision Development Module is an image acquisition, processing, and
analysis library of more than 270 functions for grayscale, color, and binary
image display, image processing, pattern matching, particle analysis,
gauging, and measurement.
For unique image processing, you can use the Vision Development Module
functions individually or in combination. With the Vision Development
Module you can acquire, display, manipulate, and store images, as well as
perform image analysis, processing, and interpretation. Using the Vision
Development Module, imaging novices and experts can program the most
basic or complicated image applications without knowledge of particular
algorithm implementations.
NI Vision Assistant is included with the Vision Development Module.
Vision Assistant is an interactive prototyping tool for machine vision and
scientific imaging developers. With Vision Assistant, you can prototype
vision applications quickly and test how various vision image processing
functions work.
Vision Assistant generates a builder file, which is a text description
containing a recipe of the machine vision and image processing functions.
This builder file provides a guide you can use for developing applications
into any development environment, such as LabWindows/CVI or Visual
Basic, using the Vision Assistant machine vision and image processing
libraries. Using the LabVIEW VI creation wizard, Vision Assistant can
create LabVIEW VI diagrams that perform the prototype you created in
Vision Assistant. Using LabVIEW, you can add functionality to this
generated VI.
Integration with DAQ
Platforms that support NI-IMAQ also support NI-DAQ and a variety of
National Instruments DAQ boards. This allows integration between IMAQ
devices and National Instruments DAQ products.

Chapter 1 Introduction
IMAQ PXI/PCI-1409 User Manual 1-6 ni.com
Vision and Motion
With National Instruments IMAQ hardware and Vision Assistant pattern
matching software, you can quickly and accurately locate objects that vary
in size, orientation, focus, and illumination. Use National Instruments
high-performance stepper and servo motion control products with pattern
matching software in inspection and guidance applications, such as
locating alignment markers on semiconductor wafers, guiding robotic
arms, inspecting the quality of manufactured parts, and locating cells.

©National Instruments Corporation 2-1 IMAQ PXI/PCI-1409 User Manual
2
Installation
This chapter contains information about getting started with the
IMAQ 1409 device.
Necessary Items
The following items are necessary for setting up and configuring the
IMAQ 1409 device:
❑PXI/PCI-1409 device
❑NI-IMAQ driver software and documentation
❑Getting Started with Your IMAQ System
❑NI-IMAQ for Windows 2000/NT/XP/Me/98
❑Optional software packages and documentation:
– NI Vision Builder for Automated Inspection
– NI Vision Assistant
–LabVIEW
–LabWindows/CVI
– Measurement Studio
❑IMAQ BNC-1 shielded, 75 ΩBNC cable for VIDEO0, included with
the IMAQ 1409
❑BNC to RCA adapter, included with the IMAQ 1409
❑A video camera or other video source
❑Pentium-based PXI, PCI, or CompactPCI computer running
Windows 2000, Windows NT, Windows XP, Windows Me, or
Windows 98

Chapter 2 Installation
IMAQ PXI/PCI-1409 User Manual 2-2 ni.com
Note The IMAQ 1409 devices rely on the computer’s PCI interface chipset for the highest
throughput to system memory. For the best results, the computer should have a Pentium or
faster processor and an Intel 430 or 440 series or compatible PCI interface chipset.
Optional Equipment
National Instruments offers the following products for use with the
IMAQ 1409 device:
• IMAQ 6822 BNC breakout box and cable for trigger and additional
camera support
• RTSI bus cables for connecting the IMAQ 1409 device to DAQ,
Motion Control, and IMAQ hardware
• Other National Instruments DAQ devices for enhanced triggering,
timing, or input/output
For specific information about these products, refer to the National
Instruments catalog, visit ni.com, or call the office nearest you.
Unpacking
The IMAQ 1409 device ships in an antistatic package to prevent
electrostatic discharge from damaging device components. To avoid such
damage in handling the device, take the following precautions:
• Ground yourself via a grounding strap or by holding a grounded object,
such as your computer chassis.
• Touch the antistatic package to a metal part of your computer chassis
before removing the device from the package.
Caution Never touch the exposed pins of connectors.
• Remove the device from the package and inspect it for loose
components or any other signs of damage. Notify National Instruments
if the device appears damaged in any way. Do not install a damaged
device in your computer.

Chapter 2 Installation
©National Instruments Corporation 2-3 IMAQ PXI/PCI-1409 User Manual
Safety Information
Caution The following paragraphs contain important safety information you must follow
when installing and operating the device.
Do not operate the device in a manner not specified in the documentation.
Misuse of the device may result in a hazard and may compromise the safety
protection built into the device. If the device is damaged, turn it off and do
not use it until service-trained personnel can check its safety. If necessary,
return the device to National Instruments for repair.
Keep away from live circuits. Do not remove equipment covers or shields
unless you are trained to do so. If signal wires are connected to the device,
hazardous voltages can exist even when the equipment is turned off. To
avoid a shock hazard, do not perform procedures involving cover or shield
removal unless you are qualified to do so. Disconnect all field power prior
to removing covers or shields.
If the device is rated for use with hazardous voltages (>30 Vrms, 42.4 Vpk,
or 60 Vdc), it may require a safety earth-ground connection wire. Refer to
the device specifications for maximum voltage ratings.
Because of the danger of introducing additional hazards, do not install
unauthorized parts or modify the device. Use the device only with the
chassis, modules, accessories, and cables specified in the installation
instructions. All covers and filler panels must be installed while operating
the device.
Do not operate the device in an explosive atmosphere or where flammable
gases or fumes may be present. Operate the device only at or below the
pollution degree stated in the specifications. Pollution consists of any
foreign matter—solid, liquid, or gas—that may reduce dielectric strength
or surface resistivity. Pollution degrees are listed below.
• Pollution Degree 1—No pollution or only dry, nonconductive
pollution occurs. The pollution has no effect.
• Pollution Degree 2—Normally only nonconductive pollution occurs.
Occasionally, nonconductive pollution becomes conductive because of
condensation.
• Pollution Degree 3—Conductive pollution or dry, nonconductive
pollution occurs. Nonconductive pollution becomes conductive
because of condensation.

Chapter 2 Installation
IMAQ PXI/PCI-1409 User Manual 2-4 ni.com
Clean the device and accessories by brushing off light dust with a soft,
nonmetallic brush. Remove other contaminants with a stiff, nonmetallic
brush. The unit must be completely dry and free from contaminants before
returning it to service.
You must insulate signal connections for the maximum voltage for which
the device is rated. Do not exceed the maximum ratings for the device.
Remove power from signal lines before connection to or disconnection
from the device.
Caution National Instruments measurement products may be classified as either
Installation Category I or II. Operate products at or below the Installation Category level
specified in the hardware specifications.
Installation Category1: Measurement circuits are subjected to working
voltages2and transient stresses (overvoltage) from the circuit to which they
are connected during measurement or test. Installation Category establishes
standardized impulse withstand voltage levels that commonly occur in
electrical distribution systems. The following is a description of Installation
(Measurement3) Categories:
• Installation Category I is for measurements performed on circuits not
directly connected to the electrical distribution system referred to as
MAINS4voltage. This category is for measurements of voltages from
specially protected secondary circuits. Such voltage measurements
include signal levels, special equipment, limited-energy parts of
equipment, circuits powered by regulated low-voltage sources, and
electronics.
• Installation Category II is for measurements performed on circuits
directly connected to the electrical distribution system. This category
refers to local-level electrical distribution, such as that provided by a
standard wall outlet (e.g., 115 V for U.S. or 230 V for Europe).
Examples of Installation Category II are measurements performed on
household appliances, portable tools, and similar products.
• Installation Category III is for measurements performed in the building
installation at the distribution level. This category refers to
measurements on hard-wired equipment such as equipment in fixed
1 Installation Categories as defined in electrical safety standard IEC 61010-1.
2 Working voltage is the highest rms value of an AC or DC voltage that can occur across any particular insulation.
3 Installation Category is also referred to as Measurement Category.
4 MAINS is defined as the (hazardous live) electrical supply system to which equipment is designed to be connected for the
purpose of powering the equipment. Suitably rated measuring circuits may be connected to the MAINS for measuring
purposes.

Chapter 2 Installation
©National Instruments Corporation 2-5 IMAQ PXI/PCI-1409 User Manual
installations, distribution boards, and circuit breakers. Other examples
are wiring, including cables, bus-bars, junction boxes, switches,
socket-outlets in the fixed installation, and stationary motors with
permanent connections to fixed installations.
• Installation Category IV is for measurements performed at the primary
electrical supply installation (<1,000V). Examples include electricity
meters and measurements on primary overcurrent protection devices
and on ripple control units.
Installation
Before getting started, refer to the electrostatic discharge guidelines in the
Unpacking section of this chapter.
PXI-1409
You can install a PXI-1409 in any available 5 V peripheral slot in your PXI
or CompactPCI chassis.
Note The PXI-1409 has connections to several reserved lines on the CompactPCI J2
connector. Before installing a PXI-1409 in a CompactPCI system that uses J2 connector
lines for purposes other than PXI, refer to the Using PXI with CompactPCI section of
Chapter 1, Installation.
1. Power off and unplug the PXI or CompactPCI chassis.
2. Verify that the W1 jumper is intact. The PXI-1409 device ships with
this jumper intact.
3. Choose an unused PXI or CompactPCI 5 V peripheral slot that
supports bus arbitration or bus-master cards. PXI-compliant chassis
must have bus arbitration for all slots.
4. Remove the filler panel for the peripheral slot you have chosen.
5. Touch a metal part on the chassis to discharge any static electricity that
might be on your clothes or body.
6. Insert the PXI-1409 in the selected 5 V slot. Use the injector/ejector
handle to fully inject the device into place.
7. Screw the front panel of the PXI-1409 to the front panel mounting rails
of the PXI or CompactPCI chassis.
8. Visually verify the installation.
9. Plug in and power on the PXI or CompactPCI chassis.

Chapter 2 Installation
IMAQ PXI/PCI-1409 User Manual 2-6 ni.com
Note Yo u must install the NI-IMAQ driver software before installing the
IMAQ 1409 device.
PCI-1409
Install the PCI-1409 in any available PCI expansion slot in your computer.
To achieve the best noise performance, leave as much room as possible
between the PCI-1409 and other boards and hardware.
Complete the following instructions to install the PCI-1409.
1. Verify that the NI-IMAQ driver software is installed on your computer.
2. Verify that the W1 jumper is intact. The PCI-1409 device ships with
this jumper intact.
3. Power off and unplug your computer.
Caution To protect both yourself and the computer from electrical hazards, the computer
should remain off and unplugged until you finish installing the 1409 device.
4. Remove the computer cover. Make sure there are no lit LEDs on the
motherboard. If any are lit, wait until they go out before continuing
installation.
5. Touch the metal part of the power supply case inside the computer to
discharge any static electricity that might be on your clothes or body.
6. Locate the metal bracket that covers the cut-out in the back panel of
the chassis for the slot you have selected. Remove and save the
bracket-retaining screw and the bracket cover.
7. Line up the PCI-1409 card-edge connector with the expansion slot
receptacle. Using slow, evenly distributed pressure, press the PCI-1409
straight down until it seats in the expansion slot.
8. Reinstall the bracket-retaining screw to secure the PCI-1409 to the
back panel rail.
9. Visually verify the installation.
10. Replace the computer cover, and plug the computer in.

©National Instruments Corporation 3-1 IMAQ PXI/PCI-1409 User Manual
3
Hardware Overview
This chapter describes the features of the IMAQ 1409 device and includes
information about acquisition modes, analog front-end considerations, and
clamping.
Functional Overview
The IMAQ 1409 features a flexible, high-speed data path optimized for the
acquisition and formatting of video data from analog cameras. The
IMAQ 1409 device can acquire from RS-170/NTSC, CCIR/PAL, VGA,
and progressive scan cameras, as well as from non-standard cameras such
as line scan cameras. The IMAQ 1409 device digitizes analog video signals
to 8 or 10 bits of resolution at sampling frequencies up to 40 MHz.
The IMAQ 1409 has a factory-calibrated gain circuit to improve
measurement accuracy and board-to-board consistency. It uses a PCI
interface for high-speed data transfer, 16 MB of SDRAM for data
buffering, and region-of-interest control circuitry for optimizing the data
transfer. The 16 MB of SDRAM also allows you to acquire entire images
into onboard memory when necessary. The IMAQ 1409 includes
four external triggers, four camera control signals, seven RTSI bus triggers,
and six video synchronization signals.
