OPERATING INSTRUCTIONS AND SPECIFICATIONS
NI 9263
4-Channel, ±10 V, 16-Bit Analog Voltage Output Module
ni.com/manuals
DeutschFrançais

NI 9263 Operating Instructions and Specifications 2 ni.com
This document describes how to use the National Instruments 9263
and includes specifications and terminal assignments for the NI 9263.
Visit ni.com/info and enter rdsoftwareversion to determine
which software youneed for the modules youare using. For
information about installing, configuring, and programming the
system, refer to the system documentation. Visit ni.com/info and
enter cseriesdoc for information about C Series documentation.
Note The safety guidelines and specifications in this
document are specific to the NI 9263. The other
components in the system might not meet the same safety
ratings and specifications. Refer to the documentation for
each component in the system to determine the safety
ratings and specifications for the entire system. Visit
ni.com/info and enter cseriesdoc for information
about C Series documentation.
Safety Guidelines
Operate the NI 9263 only as described in these operating
instructions.
Hot Surface This icon denotes that the component may be
hot. Touching this component may result in bodily injury.

© National Instruments Corp. 3 NI 9263 Operating Instructions and Specifications
Safety Guidelines for Hazardous Voltages
If hazardous voltages are connected to the module, take the
following precautions. A hazardous voltage is a voltage greater
than 42.4 Vpk or 60 VDC to earth ground.
Caution Ensure that hazardous voltage wiring is
performed only by qualified personnel adhering to local
electrical standards.
Caution Do not mix hazardous voltage circuits and
human-accessible circuits on the same module.
Caution Make sure that devices and circuits connected to
the module are properly insulated from human contact.
Caution When module terminals are hazardous voltage
LIVE (>42.4 Vpk/60 VDC), youmust ensure that devices
and circuits connected to the module are properly
insulated from human contact. Youmust use the NI 9932
connector backshell kit to ensure that the terminals are
not accessible.

NI 9263 Operating Instructions and Specifications 4 ni.com
Figure 1 shows the NI 9932 connector backshell.
Figure 1. NI 9932 Connector Backshell
Safety Guidelines for Hazardous Locations
The NI 9263 is suitable for use in Class I, Division 2, Groups A, B,
C, D, T4 hazardous locations; Class I, Zone 2, AEx nA IIC T4, and
Ex nA IIC T4 hazardous locations; and nonhazardous locations
only. Follow these guidelines if youare installing the NI 9263 in a
potentially explosive environment. Not following these guidelines
may result in serious injury or death.

© National Instruments Corp. 5 NI 9263 Operating Instructions and Specifications
Caution Do not disconnect I/O-side wires or connectors
unless power has been switched off or the area is known
to be nonhazardous.
Caution Do not remove modules unless power has been
switched off or the area is known to be nonhazardous.
Caution Substitution of components may impair
suitability for Class I, Division 2.
Caution For Zone 2 applications, install the system
in an enclosure rated to at least IP 54 as defined by
IEC 60529 and EN 60529.
Special Conditions for Hazardous Locations Use in Europe
This equipment has been evaluated as Ex nA IIC T4 equipment
under DEMKO Certificate No. 07 ATEX 0626664X. Each module
is marked II 3G and is suitable for use in Zone 2 hazardous
locations, in ambient temperatures of –40 °C ≤Ta ≤70 °C. If you
are using the NI 9263 in Gas Group IIC hazardous locations, you
must use the device in an NI chassis that has been evaluated as
Ex nC IIC T4, EEx nC IIC T4, Ex nA IIC T4, or Ex nL IIC T4
equipment.

NI 9263 Operating Instructions and Specifications 6 ni.com
Special Conditions for Marine Applications
Some modules are Lloyd’s Register (LR) Type Approved for
marine applications. To verify Lloyd’s Register certification, visit
ni.com/certification and search for the LR certificate, or
look for the Lloyd’s Register mark on the module.
Caution To meet radio frequency emission requirements
for marine applications, use shielded cables and install
the system in a metal enclosure. Suppression ferrites
must be installed on power supply inputs near power
entries to modules and controllers. Power supply and
module cables must be separated on opposite sides of the
enclosure and must enter and exit through opposing
enclosure walls.

© National Instruments Corp. 7 NI 9263 Operating Instructions and Specifications
Connecting the NI 9263
The NI 9263 has a 10-terminal, detachable screw-terminal
connector that provides connections for 4 analog output channels.
Figure 2. NI 9263 Terminal Assignments
AO0
COM
AO1
COM
AO2
COM
AO3
COM
NC
COM
0
1
2
3
4
5
6
7
8
9

NI 9263 Operating Instructions and Specifications 8 ni.com
Each channel of the NI 9263 has an AO terminal to which youcan
connect the positive lead of a load. Each channel also has a
common terminal, COM, and there is an additional COM terminal
at the bottom of the connector. All of the COM terminals are
internally connected to the isolated ground reference of the
module. When connecting a load to the NI 9263, connect the
positive lead of the load to the AO terminal, and the ground of the
load to the corresponding COM terminal. Refer to Figure 3 for an
illustration of connecting a load to the NI 9263.
Figure 3. Connecting a Load to the NI 9263
Note Youmust use 2-wire ferrules to create a secure
connection when connecting more than one wire to a
single terminal on the NI 9263.
NI 9263 COM
AO
Load

© National Instruments Corp. 9 NI 9263 Operating Instructions and Specifications
Each channel has a digital-to-analog converter (DAC) that
produces a voltage signal. Each channel also has overvoltage
and short-circuit protection. Refer to the Specifications section
for more information about the overvoltage and short-circuit
protection. Refer to Figure 4 for an illustration of the output
circuitry for one channel of the NI 9263.
Figure 4. Output Circuitry for One Channel of the NI 9263
When the module powers on, the channels output the startup
voltage. Refer to the Specifications section for more information
about startup voltage. Refer to the software help for information
about configuring startup output states in software.
AO
COM
NI 9263
Amplifier
Isolated DAC
Overvoltage/
Short-Circuit
Protection

NI 9263 Operating Instructions and Specifications 10 ni.com
Wiring for High-Vibration Applications
If an application is subject to high vibration, National Instruments
recommends that youeither use ferrules to terminate wires to the
detachable screw-terminal connector or use the NI 9932 backshell
kit to protect the connections. Refer to Figure 5 for an illustration
of using ferrules. Refer to Figure 1 for an illustration of the
NI 9932 connector backshell.
Figure 5. 10-Terminal Detachable Screw-Terminal Connector with Ferrule

© National Instruments Corp. 11 NI 9263 Operating Instructions and Specifications
Sleep Mode
This module supports a low-power sleep mode. Support for sleep
mode at the system level depends on the chassis that the module is
plugged into. Refer to the chassis manual for information about
support for sleep mode. If the chassis supports sleep mode, refer to
the software help for information about enabling sleep mode. Visit
ni.com/info and enter cseriesdoc for information about
C Series documentation.
Typically, when a system is in sleep mode, youcannot
communicate with the modules. In sleep mode, the system
consumes minimal power and may dissipate less heat than it does
in normal mode. Refer to the Specifications section for more
information about power consumption and thermal dissipation.

NI 9263 Operating Instructions and Specifications 12 ni.com
Specifications
The following specifications are typical for the range –40 to 70 °C
unless otherwise noted. All voltages are relative to COM unless
otherwise noted.
Output Characteristics
Number of channels .......................... 4 analog output channels
DAC resolution ................................. 16 bits
Type of DAC ..................................... String
Power-on output state ....................... Channels off
Startup/power-down voltage ............. 0 V
Output voltage range
Nominal ...................................... ±10 V
Minimum.................................... ±10.3 V
Typical ........................................ ±10.7 V
Maximum ................................... ±11 V

© National Instruments Corp. 13 NI 9263 Operating Instructions and Specifications
Current drive ..................................... ±1 mA per channel max
Output impedance ............................. 0.1 Ω
Accuracy
Stability
Gain drift .................................... 6 ppm/°C
Offset drift .................................. 80 μV/°C
Protection
Overvoltage ................................ ±30 V
Short-circuit................................ Indefinitely
Measurement Conditions
Percent of
Reading
(Gain Error)
Percent of
Range*
(Offset Error)
Calibrated, max (–40 to 70 °C) 0.35% 0.75%
Calibrated, typ (25 °C, ±5 °C) 0.01% 0.1%
Uncalibrated, max (–40 to 70 °C) 2.2% 1.7%
Uncalibrated, typ (25 °C, ±5 °C) 0.3% 0.25%
* Range equals ±10.7 V

NI 9263 Operating Instructions and Specifications 14 ni.com
Update time
Noise................................................. 260 μVrms
Slew rate ........................................... 4 V/μs
Crosstalk ........................................... 76 dB
Settling time (100 pF load, to 1 LSB)
Full-scale step............................. 20 μs
3 V step....................................... 10 μs
0.1 V step.................................... 8 μs
Glitch energy
(256 steps, worst case)...................... 2 mV for 2 μs
Number of
Channels
Update Time for
cRIO-9151 R Series
Expansion Chassis
Update Time for
All Other Chassis
13.5 μs 3 μs
26.5 μs 5 μs
3 9 μs7.5 μs
412 μs9.5 μs

© National Instruments Corp. 15 NI 9263 Operating Instructions and Specifications
Capacitive drive ................................ 1,500 pF min
Monotonicity..................................... 16 bits
DNL .................................................. –1 to 2 LSBs max
INL (endpoint) .................................. 16 LSBs max
MTBF ............................................... 1,732,619 hours at 25 °C;
Bellcore Issue 2, Method 1,
Case 3, Limited Part Stress
Method
Note Contact NI for Bellcore MTBF specifications
at other temperatures or for MIL-HDBK-217F
specifications.
Power Requirements
Power consumption from chassis
Active mode ............................... 625 mW max
Sleep mode ................................. 25 μW max
Thermal dissipation (at 70 °C)
Active mode ............................... 625 mW max
Sleep mode ................................. 25 μW max

NI 9263 Operating Instructions and Specifications 16 ni.com
Physical Characteristics
If youneed to clean the module, wipe it with a dry towel.
Note For two-dimensional drawings and
three-dimensional models of the C Series module and
connectors, visit ni.com/dimensionsand search by
module number.
Screw-terminal wiring ...................... 12 to 24 AWG copper
conductor wire with 10 mm
(0.39 in.) of insulation
stripped from the end
Torque for screw terminals ............... 0.5 to 0.6 N · m
(4.4 to 5.3 lb · in.)
Ferrules ............................................. 0.25 mm2to 2.5 mm2
Weight............................................... 150 g (5.3 oz)

© National Instruments Corp. 17 NI 9263 Operating Instructions and Specifications
Safety
Safety Voltages
Connect only voltages that are within the following limits.
Isolation
Channel-to-channel .................... None
Channel-to-earth ground
Continuous ........................... 250 Vrms,
Measurement Category II
Withstand ............................. 2,300 Vrms, verified by a 5 s
dielectric withstand test
Measurement Category II is for measurements performed on
circuits directly connected to the electrical distribution system.
This category refers to local-level electrical distribution, such as
that provided by a standard wall outlet, for example, 115 V for U.S.
or 230 V for Europe.
Caution Do not connect the NI 9263 to signals or use
for measurements within Measurement Categories III
or IV.

NI 9263 Operating Instructions and Specifications 18 ni.com
Hazardous Locations
U.S. (UL) .......................................... Class I, Division 2,
Groups A, B, C, D, T4;
Class I, Zone 2,
AEx nA IIC T4
Canada (C-UL) ................................. Class I, Division 2,
Groups A, B, C, D, T4;
Class I, Zone 2,
Ex nA IIC T4
Europe (DEMKO)............................. Ex nA IIC T4
Safety Standards
This product meets the requirements of the following standards of
safety for electrical equipment for measurement, control, and
laboratory use:
• IEC 61010-1, EN 61010-1
• UL 61010-1, CSA 61010-1
Note For UL and other safety certifications, refer to the
product label or the Online Product Certification section.

© National Instruments Corp. 19 NI 9263 Operating Instructions and Specifications
Electromagnetic Compatibility
This product meets the requirements of the following EMC
standards for electrical equipment for measurement, control,
and laboratory use:
• EN 61326 (IEC 61326): Class A emissions; Industrial
immunity
• EN 55011 (CISPR 11): Group 1, Class A emissions
• AS/NZS CISPR 11: Group 1, Class A emissions
• FCC 47 CFR Part 15B: Class A emissions
• ICES-001: Class A emissions
Note For the standards applied to assess the EMC of this
product, refer to the Online Product Certification section.
Note For EMC compliance, operate this device with
shielded cabling.

NI 9263 Operating Instructions and Specifications 20 ni.com
CE Compliance
This product meets the essential requirements of applicable
European Directives as follows:
• 2006/95/EC; Low-Voltage Directive (safety)
• 2004/108/EC; Electromagnetic Compatibility Directive
(EMC)
Online Product Certification
Refer to the product Declaration of Conformity (DoC) for
additional regulatory compliance information. To obtain
product certifications and the DoC for this product, visit
ni.com/certification, search by module number or product
line, and click the appropriate link in the Certification column.
Shock and Vibration
To meet these specifications, youmust panel mount the system and
either affix ferrules to the ends of the terminal wires or use the
NI 9932 backshell kit to protect the connections.
Operating vibration
Random (IEC 60068-2-64)......... 5 grms, 10 to 500 Hz
Sinusoidal (IEC 60068-2-6) ....... 5 g, 10 to 500 Hz
