National Instruments PA5080L User manual

USER GUIDE AND SPECIFICATIONS
USB Flash Drive
User Guide
Installation
(Windows 8.1/8/7/Vista/XP/Server) No drivers are required. Windows automatically detects
and installs drivers for the USB flash drive when you insert the drive into a USB port.
(Mac OS X 10.7/10.8/10.9) No drivers are required. OS X displays an icon representing the
USB flash drive on your desktop when you insert the drive into a USB port.
Disconnection
(Windows 8.1/8/7/Vista/XP/Server) Complete the following steps to disconnect the USB flash
drive.
1. Double-click the Unplug/Safely Remove/or Eject Hardware icon in the system tray in
the lower right of your screen.
2. Select the name of the device that you want to remove in the window that appears.
3. Click Stop. Windows displays the following message:
This device can now be safely removed from the computer
4. Click OK.
5. Remove the USB flash drive from the USB port.
(Mac OS X 10.7/10.8/10.9) Complete the following steps to disconnect the USB flash drive.
1. Drag the icon representing the USB flash drive into the trash bin.
2. Remove the USB flash drive only after the icon disappears from the desktop.

© 2014 National Instruments. All rights reserved.
376284A-01 May14
Refer to the NI Trademarks and Logo Guidelines at ni.com/trademarks for more information on National Instruments trademarks. Other
product and company names mentioned herein are trademarks or trade names of their respective companies. For patents covering National
Instruments products/technology, refer to the appropriate location: Help»Patents in your software, the patents.txt file on your media, or the
National Instruments Patents Notice at ni.com/patents. You can find information about end-user license agreements (EULAs) and third-party
legal notices in the readme file for your NI product. Refer to the Export Compliance Information at ni.com/legal/export-compliance
for the National Instruments global trade compliance policy and how to obtain relevant HTS codes, ECCNs, and other import/export data. NI MAKES
NO EXPRESS OR IMPLIED WARRANTIES AS TO THE ACCURACY OF THE INFORMATION CONTAINED HEREIN AND SHALL NOT BE LIABLE FOR
ANY ERRORS. U.S. Government Customers: The data contained in this manual was developed at private expense and is subject to the applicable
limited rights and restricted data rights as set forth in FAR 52.227-14, DFAR 252.227-7014, and DFAR 252.227-7015.
Specifications
Compatible with USB specification revision 1.1, 2.0 and 3.0.
Hot Plug & Play.
No external power is required...........................DC 4.5 V to 5.5 V from USB port.
Transfer rate for USB interface
Super speed ...............................................up to 5 Gbit/s for USB 3.0
High speed ................................................up to 480 Mbits/s for USB 2.0
Full speed ..................................................up to 12 Mbits/s for USB 1.1
Shock resistance................................................1,000 G (maximum)
Power consumption...........................................<110 mA when in use.
Suspend current.................................................<500 μA.
Altitude .............................................................80,000 ft (relative to sea level)
Acoustic noise...................................................0 dB (at one meter)
Vibration ...........................................................15 G peak-to-peak max
Operating temperature ......................................0 °C to 70 °C
Humidity ...........................................................20% to 90%
Korea Certification
MSIP-REM-NAT-PA5080L
Company Name ................................................National Instruments Corporation
Product Name ...................................................USB Flashdrive for NI Software
Model name ......................................................PA5080L
Manufacturer.....................................................National Instruments Corporation
Origin ................................................................Taiwan
