Nature Power Power Bank Elite 25 User manual

SAVE THESE INSTRUCTIONS
Power Bank Elite 25
User Manual
WARNING: Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
Item #80026
V1.2-M 29Jul2020

Page 2 of 6
⚠WARNING
Important Safety Information
Thank you for choosing a Nature Power Product.
Save the receipt and these instructions. It is important that you read the entire manual to become
familiar with this product before you begin using it.
This product is designed for certain applications only. the distributor cannot be responsible for
issues arising from modification. We strongly recommend this product not be modified and/or used
for any application other than that for which it was designed. If you have any question relative to a
particular application, Do not use the product until you have first contacted the distributor to
determine if it can or should be performed on the product.
For technical question please call 1800-588-0590
vUse only with the supplied AC Charger to charge the Power Bank Elite. Use of non-supplied AC
charger will damage or overcharge the battery and may cause fire hazard.
vDo not store unit in high temperature environment, including intense sunlight heat. Do not place unit
near fire or other excessively hot environments.
vBe cautious of excessive drops, bumps, abrasions or other impurities. If there is any damage to the
battery such as dents, punctures, tears, deformities of corrosion, due to any cause, discontinue use
and contact manufacturer or dispose of in an appropriate manner.
vDo not disassemble or attempt to modify it or replace any part of this unit.
vDo not expose unit to moisture, snow or submerge it in liquid.
vDo not use unit in the vicinity of flammable fumes or gases (such as propane tanks or large engines).
vDo not attempt to charge unit using any other method, or connection other than the supplied
accessories.
vDo not cover or obstruct any air vent openings and/or install in a zero-clearance compartment.
vDo not use in connection with life support systems or other medical equipment or devices.
vDo not plug surge-protected power bars into the unit’s 120 VAC outlets. The surge protected
components on the surge-protected power bar may not like the modified sine wave output generated
by the inverter.
vIf this unit is intended by purchaser to be used by a minor, an adult should agree to provide detailed
instructions and warnings to any minor prior to use. Failure to do so is sole responsibility of
purchaser. Purchaser agrees to indemnify manufacturer for any unintended use of misuse by a
minor.
vAll units have gone through a thorough quality assurance. If you find that your unit is excessively hot,
is emitting odor, is deformed, abraded, cut or is experiencing or demonstrating an abnormal
phenomenon, immediately stop use.
vNever dispose of units in the garbage. Disposal of units in the garbage is unlawful under state and
federal environmental laws and regulations. Always take used unit to your local battery recycling
center.
vUnit provides 120 VAC, treat AC output socket as you would regular wall AC sockets at home.
vAC Output is with modified sine wave, some appliances like speed controllers found in some fans
and some power tools’ or their AC charger may not like the modified sine wave generated by the
inverter. Those appliances may not work or may be damaged if they are connected to the inverter. If
you are unsure about powering any device with the inverter, contact the manufacturer of the device.
This unit is meant for use only in conjunction with the appropriate mobile device. Manufacturer
shall not in any way be liable to you or to any third party for any damages you or any third party
may suffer as a result of use, intended or unintended, or misuse of this unit in conjunction with
any device or accessory other than the appropriate mobile device for which this unit is designed.
Manufacturer will not be responsible for any damages you or any third party may suffer as a result
of misuse of this unit as outlined above. If you are responsible for unit use with an unintended
mobile device and damages result from such use, you agree to indemnify manufacturer for any
resulting injuries to any third part(ies).

WARNING
This product can expose you to chemicals, including Di (2-ethylhexyl) phthalate (DEHP)
which is known to the State of California to cause cancer, birth defects or other reproductive
harm. For more information, go to www.p65warnings.ca.gov
ADVERTENCIA
Este producto puede exponerlo a productos químicos, incluidos Di (2-etilhexil) ftalato (DEHP)
que el estado de California sabe que causa cáncer, defectos de nacimiento u otros daños
reproductivos. Para obtener más información, vaya a www.p65warnings.ca.gov
Regulations and laws pertaining to the recycling and disposal of lithium ion batteries
vary from country to country as well as by state and local governments. Lithium Ion
batteries are classified by the U.S. federal government as non--‐hazardous waste.
While there are no federal regulations for disposal of lithium batteries, individual
states or localities can establish their own guidelines for battery disposal, and should
be contacted for any disposal guidelines.
Reference Part Description Quantity
Parts List
11 Power Bank 11
AC Charger with charging cable 1
2
vInternal microprocessor control
vLow static power consumption
vIntelligent capacity indication by LEDs with the press of a button
vSeparate LED indicators to show USB and AC Output
vDual 2.1A and single 1A USB with high conversion efficiency.
vIntelligent tri-color indicator to represent AC Output (Green - normal, Amber-warning for battery
capacity low, high internal temperature, Red-shutdown for overload, over temperature, battery is
empty)
vThermally activated internal fan control
Features
Technical Specifications
Property Specification
AC output 120Vac/60 Hz 90W
DC Output (USB) 2.1A, 2.1A,1.0A
DC input 12.6-22.0Vdc,2A max
Battery type Li-ion Polymer
Battery capacity 25600mA/93.2Wh
Regulatory Approval cETLus
Regulatory Standard UL1741 CSA22.2 No.107.1-01
Page 3 of 6

Page 4 of 6
Operating Instructions
On/Off button
vQuickly press the button to indicate
the battery capacity.
vHold the ‘On/Off’ button once to switch
USB ports On or hold it longer to
switch both AC and USB outputs On.
vHold on the switch again to switch unit
Off.
To Switch USB Ports ON
vHold the ‘On/Off’ button once to switch
USB Ports On until the Green USB
indicator illuminates.
vUSB Ports will automatically switch off
after 30 seconds when the device is
fully charged or when nothing is
connected to the USB ports.
To Switch AC Output and USB Ports ON
vHold the ‘On/Off’ button until both
USB and AC Output green indicators
are illuminated.
vThis will now make the AC Output and
USB ports active.
Note: In this mode, the USB output is continuously On and the USB auto-turn-off feature is disabled.
To Charge the Power Bank Elite
vConnect the DC plug from the supplied AC Charger to the DC Input port located on the side of the
unit.
vIt is recommended to charge this unit after each use and once every 90 days.
vThe Power Bank Elite can also be charge through the optional accessory, 18 Watt Folding Solar
Panel (Sold Separately), for off grid power.
Note: Use only with the supplied AC Charger to charge the Power Bank Elite. Use of non-supplied AC
charger will damage or overcharge the battery and may cause fire hazard.

Page 5 of 6
Output & Compatibility
Devices (Battery Capacity
or Load) Elite 25
iPhone® (~ 5.2 Wh) ~ 8.3 charges
iPad® (~ 43 Wh) ~ 1.6 charges
MacBook Air® 11” ((~ 35 Wh) ~ 1.9 charges
MacBook Air® 13” (~ 50 Wh) ~ 1.4 charges
MacBook Pro® 13” (~64 Wh) ~ 1.1 charges
MacBook Pro® 15” (~ 78 Wh) ~ 90%
MacBook Pro® 17” (~95 Wh) ~ 75%
Samsung GalaxyS III® (~ 7.8 Wh) ~ 6.4 charges
Samsung Galaxy Tab®
10.1” (25Wh) ~ 2.5 charges
BlackBerry Torch® (~ 4.7 Wh) ~ 8.7 charges
BlackBerry Curve® (~3.7 Wh) ~ 10 charges
Incandescent light (40W) 1.7 hours
DC Output 1.0A: 5V/1A for iPod, iPhone and mobile phones etc.
DC Output 2.1A: 5V/2.1A for iPad, Samsung P1000, Moto MH900 and MID etc.
AC Output: (Model MP50) 120V/60Hz for MacBook Air or AC load less than 50W
(Model MP100) 120V/60Hz for MacBook Pro or AC load less than 90W
Number of charges available on one charge of Nature Power Power Bank Elite
Number of charges available or run time is an estimate. Actual number of charges may vary
vRecharge the unit after each use and once every three months when not in use.
vKeep the unit dry and away from moisture and corrosive materials.
vDo not wash the unit with harsh chemicals, soaps or detergents.
vIf the unit needs cleaning, Wipe with a lightly damp cloth only, making sure not to let moisture into
the unit
Maintenance
To keep your Power Bank Elite operating to its fullest potential, make sure to do the following:

Nature Power warrants our products to the original purchaser that this product is free from defects in
materials and workmanship for the period of one year from date of purchase. In the case of product
defect, contact Nature Power customer service to receive troubleshooting. If defective part or unit
should be returned, a Return Authorization Number must be issued by Nature Power and the defective
part or unit should be returned to the authorized location at the purchasers’ expense. A dated proof of
purchase is required to receive warranty service. Once received at authorized location and defect
proves to be the result of defective material and workmanship, the defective part or unit will be replaced
at warrantors’ option and returned to the original purchaser at warrantors’ expense. No refunds will be
granted by the warrantor, in the event of buyer’s remorse please contact your point of purchase within
and in adherence to their return policy. Refunds are granted at the retailers’ discretions.
Limited Warranty
Please&contact&Nature&Power&Products&to&acquire&more&information:!
1-800-588-0590
[email protected]!
www.naturepowerproducts.com!
