36206
N85 - N120 50mm Port Adaptor
(With Zoom Control for N120 DSL Zoom
Gears for Tokina 10-17)
Instruction Manual
F
O EWO D
Thank you for your purchase of a NAUTICAM product.
At NAUTICAM, we pride ourselves in the ability to recognise the re uirements
of professional as well as amateur underwater photographers and fulfill them
through the innovative designs of our products. We strive to achieve a high
level of user-friendliness by allowing stress-free installation and easy
operation of all important functions of the camera.
Please read this manual carefully before using the product, this will maximise
its performance as well as its lifetime.
W
A ANTY
All NAUTICAM Products are warranted against any material and
manufacturing defects for two years from the date of purchase for consumer
use.
This warranty only applies to products purchased from authorised
NAUTICAM dealers and does not extend beyond the original retail purchaser.
To return your product for service, please contact your regional authorized
service centre(s). Please note that this warranty only applies when the product
is purchased in the territory where the service centre is located.
NAUTICAM does not hold responsibility for damage, of any nature, to any
e uipment used with and/or placed within our products.
NAUTICAM accepts no liability for any loss of captured images or the inability
to capture images even if it is due to the malfunctioning of our products.
Unauthorised modifications and/or repairs of our products will automatically
invalidate the warranty.
I
DENTIFICATION OF
P
A TS
I
NSTALLATION
Install the camera body only into the housing and attach the optical fiber
cables to the housing.
Mount the N85 to N120 port adaptor to the housing.
*Please refer to the housing manual for installing camera and mounting port
to the housing.
Mount the lens (with gear attached) on the camera.
ATT NTION: Make sure that the knob on the adaptor is at its most outward
position before mounting/ dismounting the lens. The knob should be left at this
position until it is made sure that the lens and gear is properly installed.
Lift the Port lock/ release latch on the other side of the adaptor.
Press and hold the port release safety button, turn the port lock/release latch
clockwise until it stops.
--- continue on next page ---
Port
Release
Safety Button
Rear Cap
Zoom Knob
Port Lock Lever
Press
Current as of 2016-08-05
--- continued from front page ---
Align the "I" mark on the adaptor with the WHITE dot on the port. Gently push
the port towards the adaptor until it cannot go in any further.
Turn the port anti-clockwise until the white dot on the adaptor aligns with the
white dot on the port.
To lock the port in place, turn the port lock/release latch anti-clockwise to the
original position and then flip it down.
Engage the gear on the lens by pushing the knob inwards, then turn the knob
both ways to check if the lens is functioning
To unlock, reverse the above procedures.
S
PECIFICATIONS
Constructions:
Hard anodized aluminium alloy
Dimensions:
Dia132mm x 60mm (Exclude knob)
Weight:
Approx.
0.3kg
Depth Rating:
100m
Port Mount:
N85 to N120
