Nautilus Hyosung MS500 User manual

Installation Manual
MS500
V01.00.05 (2016.06.17)
© 2016 Nautilus Hyosung Inc. All Rights Reserved.

© 2016 Nautilus Hyosung Inc. All Rights Reserved. I
Revision History
Installation Manual –MS500 System
No.
Version
Date
Description of Change
Chapter
1
V01.00.00
2014/08/01
New Publication
All
2
V01.00.01
2014/12/18
Added System Identification Label
2
Updated Dimension / Installation and Service Clearance
3
Updated Anchor Bolts Location Sheet Sample
4
3
V01.00.02
2015/01/09
Updated Dimension / Installation and Service Clearance
3
4
V01.00.03
2015/04/11
Added the weight of MS500
3
Updated the anchor bolts location sheet sample
4
5
V01.00.04
2015/04/30
Added the security bolts
4
6
V01.00.05
2016/06/17
Updated the installation drawing
3
© 2016 Nautilus Hyosung All Rights Reserved.
The content of this specification is protected by copyright laws.
2016. 06. 17. 6th Release

© 2016 Nautilus Hyosung Inc. All Rights Reserved. II
Contents
Chapter1. Preface...........................................................................................................................1-1
Purpose.........................................................................................................................................................1-1
Audience .......................................................................................................................................................1-1
Support Information.......................................................................................................................................1-1
What is in This Manual...................................................................................................................................1-1
Terminologies ................................................................................................................................................1-2
Abbreviations.................................................................................................................................................1-2
Safety Precautions.........................................................................................................................................1-4
Related Document.........................................................................................................................................1-6
Chapter2. Introduction...................................................................................................................2-1
About the MS500 ..........................................................................................................................................2-1
System Identification Label...........................................................................................................................2-2
Chapter3. Installation Information ................................................................................................3-1
Installation Environment and Spacing...........................................................................................................3-1
Exterior..........................................................................................................................................................3-2
Service Area..................................................................................................................................................3-4
Installation Frame..........................................................................................................................................3-7
Chapter4. System Installation.......................................................................................................4-1
Unpacking.....................................................................................................................................................4-1
Bolting Down the MS500 ..............................................................................................................................4-2
Notes.......................................................................................................................................Notes-1

Installation Manual Chapter1.Preface
© 2016 Nautilus Hyosung Inc. All Rights Reserved. 1-1
Chapter1. Preface
Purpose
►This manual explains how to install the Nautilus Hyosung America’s (NHA) MS500
Teller Cash Recycler hardware.
Audience
►This manual has been written for anyone responsible for installing the MS500 Teller
Cash Recycler (TCR) in bank branches or similar locations.
Support Information
►If any question or installation error occurs while preparing for and installing MS500 in
compliance with this manual, please contact maintenance staffs of Nautilus Hyosung.
For the contact of maintenance staffs of Nautilus Hyosung, see the E-mail addresses
and telephone numbers provided separately.
What is in This Manual
►This manual provides detailed installation guidelines and important warnings that
should be followed while installing the MS500.
All measurements in this manual are in metric with inches provided in braces [ ].
All information described in this manual refers to licensed products of Nautilus
Hyosung. It is the policy of Nautilus Hyosung to improve products as new technology,
components, software, and firmware become available. Therefore Nautilus Hyosung
America reserves the right to change specifications without notice.

Installation Manual Chapter1.Preface
© 2016 Nautilus Hyosung Inc. All Rights Reserved. 1-2
Terminologies
►In this document the terminology listed below is used as follows:
▪Customer and consumer refer to any person who transacts business through the
ATM.
▪Device and unit refer to the standard and optional equipment.
▪Fascia refers to the entire front portion of the unit, including the portion where the
customer transacts business.
▪Module refers to a plug-in device that can be serviced or replaced.
▪Note(s) and bill(s) refer to the individual documents loaded into and dispensed from
the dispenser.
▪Servicing and maintenance refer to the supervisor, operator and technician’s tasks
performed to keep the operational.
▪Screen refers to the text appearing on the customer display.
Abbreviations
►In this document the abbreviations listed below is used as follows:
#
Abbreviations
Description
1
AD board
Analog Digital Board
2
ADA
The American Disabilities Act
3
AP
Application Program
4
Assy
Assembly
5
BRM
Bill Recycle Machine
5-1
BC
Bill Checker
5-2
BMD
Body Module-Down (Lower Body of the Module)
5-3
BMU
Body Module-Up (Upper Body of the Module)
5-4
BRM
Bill Recycle Machine
5-5
CSM
Customer Service Module
5-6
DPC
Deposit Cassette
5-7
RC
Recycle Cassette
5-8
RJC
Reject Cassette
5-9
TE
Tape Escrow
5-10
UTC
Utility Cassette
6
BATT S/W
Battery Switch
7
CAM
Camera Unit
8
CE
Control Electronics
9
EP
Elementary Program
10
H/W
Hardware
