Navico BSM-1 User manual

Installation Manual
Navico BSM-1
Broadband Sounder Module
English
www.simrad-yachting.com
www.northstarnav.com.
Brands by Navico - Leader in Marine Electronics

Introduction | 1
EN
Industry Canada
Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including
interference that may cause undesired operation of the device.
CE Declaration of conformity
Hereby, Navico Holding AS declares that this BSM-1 is in
compliance with the essential requirements and other
relevant provisions of Directive 1999/5/EC.
Navico Holding AS vakuuttaa täten että BSM-1 tyyppinen
laite on direktiivin 1999/5/EY oleellisten vaatimusten ja
sitä koskevien direktiivin muiden ehtojen mukainen.
Hierbij verklaart Navico Holding AS dat het toestel BSM-
1 in overeenstemming is met de essentiële eisen en de
andere relevante bepalingen van richtlijn 1999/5/EG.
Par la présente, Navico Holding AS déclare que ce BSM-1
est conforme aux exigences essentielles et aux autres
dispositions de la directive 1999/5/CE qui lui sont
applicables.
Härmed intygar Navico Holding AS att denna BSM-1 står
i överensstämmelse med de väsentliga egenskapskrav
och övriga relevanta bestämmelser som framgår av
direktiv 1999/5/EG.
Undertegnede Navico Holding AS erklærer herved, at
følgende udstyr BSM-1 overholder de væsentlige krav og
øvrige relevante krav i direktiv 1999/5/ EF.
Hiermit erklärt Navico Holding AS dass sich dieses BSM-
1 in Übereinstimmung mit den grundlegenden Anforder-
ungen und den anderen relevanten Vorschriften der
Richtlinie 1999/5/EG befindet. (BMWi)
Navico Holding AS -1


Con la presente Navico Holding AS New Zealand dichiara
che questo BSM-1 è conforme ai requisiti essenziali ed
alle altre disposizioni pertinenti stabilite dalla direttiva
1999/5/CE.
Preface

2| Introduction
EN
Por medio de la presente Navico Holding AS declara que
el BSM-1 cumple con los requisitos esenciales y
cualesquiera otras disposiciones aplicables o exigibles de
la Directiva 1999/5/CE.
Navico Holding AS declara que este BSM-1 está
conforme com os requisitos essenciais e outras provisões
da Directiva 1999/5/CE.
The equipment named in this declaration, is intended for use in
international waters as well as coastal sea areas administered
by countries of the E.U. and E.E.A.
Disclaimer
As Navico is continuously improving this product, we retain the
right to make changes to the product at any time which may
not be reflected in this version of the manual. Please contact
your nearest distributor if you require any further assistance.

instrument and tranducer(s) in a manner that will not cause
accidents, personal injury or property damage. The user of this
product is solely responsible for observing safe boating
practices.
NAVICO HOLDING AS. AND ITS SUBSIDIARIES, BRANCHES
AND AFFILIATES DISCLAIM ALL LIABILITY FOR ANY USE OF
THIS PRODUCT IN A WAY THAT MAY CAUSE ACCIDENTS,
DAMAGE OR THAT MAY VIOLATE THE LAW.
Governing Language: This statement, any instruction manuals,
user guides and other information relating to the product
(Documentation) may be translated to, or has been translated
from, another language (Translation). In the event of any
conflict between any Translation of the Documentation, the
English language version of the Documentation will be the
official version of the Documentation.
This manual represents the product as at the time of printing.
Navico Holding AS. and its subsidiaries, branches and affiliates
reserve the right to make changes to specifications without
notice.
Copyright © 2009 Navico Holding AS .

Introduction | 3
EN
Warranty
In case of any queries, refer to the brand web site of your
display or system.
www.northstarnav.com
www.simrad-yachting.com
Feedback from you
Your feedback is important and helps Navico ensure that this
manual is a valuable resource for all marine technicians. E-mail
your comments or suggestions about this manual to the
following address: [email protected]

4| Introduction
EN
Contents
1 Introduction ................................................... 5
Parts List ......................................................... 5
2 Installation ..................................................... 7
Mounting location ............................................. 8
Mounting the BSM-1 module .............................. 9
3 Connecting BSM-1 .......................................... 10
Connect the transducer ..................................... 11
Connect BSM-1 to your display........................... 12
Simrad NSE8/NSE12 ......................................... 12
Simrad GB40 / Northstar 8000i .......................... 13
Connect power ................................................. 15
BSM-1 Indicator lights....................................... 17
4 Parts List ........................................................ 18
Ethernet cables RJ45 type ................................. 18
Transducer options ........................................... 18
Optional parts .................................................. 19
Spare parts for service ...................................... 19
5 Drawings ........................................................ 21
6 Specifications ................................................. 22

Introduction | 5
EN
This document explains how to connect the Navico BSM-1
sounder module to a compatible navigation system or display
unit. The BSM-1 connects directly between the transducer and
display unit or with a network switch (Ethernet Linker). Read
the following instructions carefully before attempting any
installation.
The BSM-1 is compatible with the following displays and
systems:
GB40
NSE8/NSE12
8000i
Parts List
Part Number
Description
Item
000-0132-05
BSM-1
Complete
Sounder
003-8072-00
BSM-1 sounder
module
1Introduction

6| Introduction
EN
Part Number
Description
Item
003-8256-00
Installation kit
including:
019-0009-00
Terminal plug
043-0037-00
Fuse BK/ATC-3
089-0431-00
Fuse holder ATC
BLD TYPE IN LINE
083-0011-21
Screw #10 X 3/4
PN HD SS selftap
000-0127-51
1.5 m (5 ft)
Ethernet
extension cable
032-0167-02
Power cable 2 m
(6.5 ft)
988-0170-08
This installation
manual

Installation | 7
EN
The BSM-1 sounder module connects between the transducer
and display unit or via a network switch.
Before installing the BSM-1, consider location and cable runs
necessary to connect the module to the display unit and power
source.
You will need to attach the power cable, Ethernet cable and a
transducer to the BSM-1.
The transducer and Ethernet cables are not included.
Do not run the transducer cabling near the BSM-1 DC
power cables or any VHF antenna coax cables or any VHF
DC power cables.
The BSM-1 conforms to the appropriate Electromagnetic
Compatibility (EMC) standards; but proper installation is
required to get the best use and performance from this product.
2Installation

8| Installation
EN
Mounting location
When installing the module certain factors that could affect its
operation should be considered. Ensure you have as much
separation as possible between different electrical equipment,
(see diagram below).
The BSM-1 conforms to the appropriate Electromagnetic
Compatibility (EMC) standards but proper installation is
required to get the best use and performance from this product.

Installation | 9
EN
Mounting the BSM-1 module
Preferably mount the BSM-1 module on a vertical surface so
that cables exit downwards.
Secure using suitable fasteners for the surface.
4 SS self tapping screws are supplied with the equipment.

10 | Connecting BSM-1
EN
Key
Port
Description
A
Power
Connect dedicated power cable (see
"Connect power" page 15)
B
Network
Ethernet network: Connect to your
display or Ethernet switch connector
(see "Connect BSM-1 to your display"
page 11)
C
Transducer
Connect your transducer (see "Parts
List" page 18) for a list of compatible
transducers
Removing the transducer cable from the BSM-1 while the
module is powered on can cause sparks. Remove the
transducer cable only after the module has been
disconnected from its power source.
3Connecting BSM-1

Connecting BSM-1 | 11
EN
Connect the transducer
For a list of compatible transducers (see "Parts List" page 18),
or contact your dealer.
Transducer connector pin assignments
Pin
Assignment
1
Depth +
2
Speed
3
Speed power
4
Temp.
5
Depth -
6
shield
7
Temp / speed ground

12 | Connecting BSM-1
EN
Connect BSM-1 to your display
The BSM-1 connects to your display over an Ethernet network,
either directly or via an Ethernet network switch.
Simrad NSE8/NSE12

Connecting BSM-1 | 13
EN
Key
Description
A
Ethernet cable yellow 5 pin.
Cable can be connected directly to NSE or via a Network
Expansion Port. See the NSE Installation manual for
more information.
B
Power cable, 12 or 24 V DC
C
Navico 8 port Ethernet Linker AA010009
Simrad GB40 / Northstar 8000i
BSM-1 direct connection to display
Connect power of BSM-1 to same power source as the display.
If BSM-1 is connected directly to the display, it is important
that the BSM-1 is powered on when the GB40 or 8000i is on so
that the display can see a functioning network. C is a standard
Ethernet cable. No X-over cable is required.

14 | Connecting BSM-1
EN
BSM-1 connection via Ethernet switch
Key
Description
A
BSM-1
B
Ethernet adapter cable 5 pin to RJ45 (not included)
C
Ethernet cable RJ45 type (not included)
D
GB40 / 8000i NavComputer network port
E
Navico 8 port Ethernet Linker AA010009

Connecting BSM-1 | 15
EN
Connect power
Power cable connections
Key
Item
Pin
Description
A
Power cable
2 m (6.5 ft) (032-0167-02)
B
BLACK
Pin 1
Connect to DC supply negative.
C
BLUE
Pin 2
No connect.
D
RED
Pin 4
Connect to DC supply positive
12-24 V DC use supplied fuse
E
YELLOW
Pin 3+4
* Ignition sense. Connect to
DC supply positive 12-24 V DC
via a on/off switch (pin 3).
** Connect to DC positive in
common with RED. Use
supplied fuse
NOTE:
GB-40 and 8000i Power cable ignition sense wire is gray,
NSE Displays Power cable ignition wire is yellow
F
Fuses
3 A
G
Switch
Connect via a switch at console
(not included) to turn off BSM-
1 when not in use.
H
Battery
12 or 24 V DC (Max range 9-32
V DC)
* BSM-1 connected GB40 or 8000i network via an Ethernet
Linker.

16 | Connecting BSM-1
EN
** BSM-1 connected directly to a GB40 or 8000i display
If the BSM-1 is connected directly to the vessel’s battery, the
module will continue to draw power even when it is not in
operation. It is recommended that the yellow power cable wire
be fitted with an optional on/off switch, allowing the BSM-1 to
be powered off when not in use. (except GB40 / 8000i direct
network connection –no Ethernet Linker).
It is recommended that the BSM-1 power cable be connected to
a separate power source other than the one starting the engine.
Doing so will prevent voltage drop. Voltage drop will not harm
the module, but it can cause the BSM-1 to reset. If the BSM-1
resets, some information could be lost and it may change the
operation mode of the unit.
This system is not intended for use on a “positive”
ground vessel.
The BSM-1 contains high voltages and specialized parts;
the operator should never remove the module’s cover or
attempt to service the device.

Connecting BSM-1 | 17
EN
BSM-1 Indicator lights
The Power, Network and Transducer status lights are located on
top of the module.
LED
Color
Code 1
Code 2
Code 3
Power
red/green
solid green
- all okay
solid red -
system
starting
blinking
red - internal
error
Network
green
traffic
indicator
n/a
n/a
Transducer
green
solid green
- all okay
blinking
green -
searching
for signal
n/a

18 | Parts List
EN
Ethernet cables RJ45 type
Part no
Description
AA010079
0.5 m (1.6 ft)
AA010080
2 m (6.5 ft)
AA010081
5 m (16.4 ft)
AA010082
10 m (32.8 ft)
Transducer options
Below is a list of standard transducers. Consult your dealer for
more information.
Part no
Description
000-0136-02
P319 Low Profile Thru Hull 50/200Khz
D.
12 m (39.4 ft) cable
000-0136-03
P79 Plastic In-Hull 50/200Khz Depth Only w
.
12 m (39.4 ft) cable
000-00021-001
B60 Bronze Thru Hull 50/200Khz Depth/Temp
.
12 m (39.4 ft) cable
000-0136-04
B60 Bronze Thru Hull 50/200Khz Depth/Temp
12.
12 m (39.4 ft) cable
000-0136-05
B744V Bronze Thru Hull 50/200Khz

high Speed Fairing Block.
12 m (39.4 ft) cable
000-0136-06
B164 Bronze Low Profile Thru Hull 1kW
50/200Khz Depth/Temp w 22/20
.
12 m (39.4 ft) cable
00-0136-000
B258 Bronze Thru Hull 50/200Khz Depth/Temp
w 15/21
Speed Fairing Block.
12 m (39.4 ft) cable
4Parts List
