Navig8r WF20 User manual

USER M ANUAL DRONE-WF20
To help get you started, please refer to t he quick connection guide below
Action Drone Indicator Remote Indicat or
1 Turn on Drone Fast then slow flash -
2 Turn on Remote Slow flash Slow RED flash
Connection (Thrott le up then down before begin)
3 Connection successful Solid light RED light off
4 Press launch / land but ton, then throt tle up t o take off
5 Press the launch / land butt on / throt tle dow n to land
Note:
Drone Double flashes Drone not paired
Drone Fast flashes Flat batt ery / Cannot connect

USER M ANUAL DRONE-WF20
SAFETY PRECAUTIONS
Keep t he batt ery away from heat sources such as fire and sun
Store t he batt ery in a cool dry place
When recharging, only use t he bat tery charger intended for t hat purpose
Don’t over-charge the batt ery
Don’t charge the batt ery for more than tw o hours
Don’t leave a charging batt ery unattended
Please read t hrough the manual before use and st ore for later reference.
Please store small part s in a place well out of the reach of small children
Keep all body part s away from the drone while t he rot or blades are spinning
Never t ry to repair internal circuitry. This product has no serviceable parts
Keep small parts out of reach of children as they can be a choking hazard.
Do not rush your flight. Alw ays st ay in control.
After flight, turn the DRONE off first , then t urn the cont roller off.
Do not fly your Drone in prohibited areas, such as near airport s or near/ above people
Children should operate a drone only wit h adult supervision
Always keep sight of your drone while flying and resist t he urge t o fly t oo high
Always t urn the power off on the controller and DRONE w hen not in use.
BATTERY PROTECTION
This DRONE is equipped wit h low-voltage protection. When a bat tery is low on charge, the program med
cont rol system w ill st op the DRONE’s rotors. The batt ery will then need re-charging before use
M AINTENANCE
Clean the DRONE w it h a clean, dry soft cloth only. To avoid irreparable damage, keep the DRONE dry
and away from w ater such as rain. Check the DRONE and accessories for damage before flight . If
damage is found, do not use t he DRONE unt il it is repaired.
REM OTE CONTROL BATTERY INSTALLATION
Remove t he batt ery cover screw using the
supplied screw driver. Remove t he battery
cover and insert 4 X 1.5V AAA batt eries,
according to indicat ed polarit y (bat t eries
not included). Reatt ach t he cover and
tighten the screw.
Note: Batt ery inst allation should be done
under adult supervision. Do not mix old and new batteries inside the controller.

USER M ANUAL DRONE-WF20
CHARGING YOUR DRONE BATTERY
Connect your drone battery to a USB charger, such as a PC, using t he supplied USB cable. You can also
remove t he batt ery from the drone for charging. (See det ails below .)
Note: The bat tery is fully charged once the GREEN st at us indicat or on t he batt ery turns off.
HOW TO REM OVE THE BATTERY FROM THE DRONE
Depress both t op and bot t om locking latches toget her and carefully slide t he
bat tery out.

USER M ANUAL DRONE-WF20
REM OTE CONTROL
No.
Function
Description
1
Power
Indicator
Illuminates w hen power is turned on
2
Connection
indicator Flashes RED during t he connection process. Turns off when connected.
Camera Indicator
(Not available on
this model)
The light w ill blink once while t aking picture and remain on while recording
video (Not available on this model)
3
Take picture
/
record video
(Not available on
this model)
Press one t ime for taking picture, press for 3 seconds for recording video
(Not available on this model)
4 Flip
P
ush
the control stick in
(
as opposed to up or down). A
repeating
BEEP will
then sound alerting you that you are in FLIP mode. Then, use the right cont rol
stick to flip the drone in the selected direction. Once the flip is complet e, the
BEEP sound will stop. Repeat t his process for multiple flips.
5
Right St ick
D
rive
the drone forwards, backwards, left or right
6
Trim butt on
(See explanat ion below)
7
Trim butt on
(See explanat ion below)
8 Headless mode
Press once
to select
headless mode
. Press
again t o
exit
headless
mode.
Not e: Headless mode will always drive t he drone forwards, no mat t er which
way the front of the drone is facing.
9 One key ret urn
funct ion
Drives the drone back t o it s
original st art
area
(manua
l landing then required)
Note: The DRONE and user must stay in the same orientat ion from each
ot her, in order for t his function t o operate correctly.
10
Trim butt on
(See explanat ions below )
11
Left Stick
M ove up and down to control speed and side t o
side to rot at e
12 Speed Select
Press
in (as opposed to up or down) There are 3 different speeds; slow ,
medium and fast . These are indicated by one, two or three BEEPs)
13 Unlock / Take off /
Land / Emergency
Press once to unlock the drone and to start the rotors for take-off.
Press after your flight , to land t he drone.
Not e: During flight press and hold for 5 seconds for an emergency stop.
2
3
4
5
6
7
1
13
12
11
10
9 8

USER M ANUAL DRONE-WF20
SIM PLE OPERATING STEPS
BASIC OPERATION CONTROLS
Note: When the drone is flying t owards you, t he control directions are reversed.
Check t he left stick is in
t he cent er posit ion.
Turn on the cont roller
by
sliding the power but t on
across
Turn on the DRONE. (The
LED light on the drone w ill
flash rapidly
then, slowly
)
Place t he DRONE
on a level posit ion.
Slowly p
ush the
left stick
up
then
down. A double beep will sound
(w hen successful). The LED light on
the drone w ill t hen remain on. The
DRONE is ready to fly.
Press t he start
butt on
to start flying. Press
again after your flight
to begin your landing.

USER M ANUAL DRONE-WF20
AUTO TRIM FUNCTION
Press both cont rol sticks down and left t o 45 degree circle (image
right) for 10 second. The indicators on the drone will begin to
flash rapidly. When complet e, t he indicators will t hen st op flashing.
M ANUAL TRIM FUNCTION
From time t o t ime your drone can
benefit from a t rim adjust ment. Trim
adjustment can be used t o keep your
drone hovering in t he same place,
w hich is especially useful w hile t aking
phot os or manoeuvring in t ight
places.
Forw ard
/
B
ackw ard
Trim
Left / Right
rot at ion Trim Left / Right
side Trim

USER M ANUAL DRONE-WF20
M ANUAL TRIM EXPLAINED

USER M ANUAL DRONE-WF20
TRICKS: FLIPS & ROLLS
Press the right stick in once (as opposed to up or down) A continuous beep w ill t hen sound. Then m ove
the right stick again in t he direct ion you w ish the drone t o flip (Left , right, forwards or backw ards)
Note: Before you perform a flip t rick, alw ays make sure you have enough space bot h above and below
your DRONE.
ONE KEY RETURN FUNCTION
Press t he but ton as depict ed (right) for one key ret urn. You
can move the cont rol stick in any direction t o cancel t his
command.
Note: When t he drone is first turned on and the LED
indicat ors st op flashing, t his is when t he drone set s t he
forward facing side as the front of t he drone. If t he drone
isn’t pointing t he right w ay at t ake off, it will not be able t o
effectively ret urn to the start area. If you w ant t o reset the
front direction, you need to t urn your Drone off t hen on again
to reset .
HEADLESS FUNCTION
In headless mode, t he drone w ill alw ays fly forward if flow n
forward (and in any ot her direct ion) regardless of which way
the drone is facing. Essentially, t his feat ures removes the
drone’s awareness of orient at ion w hen it has been rotat ed.
To enter t his mode, press the controller but ton as depict ed
(right). A beep w ill cont inuously sound as a reminder. You are
then t hen in headless flying mode. To quit this mode, just press
the same butt on again. A beep w ill sound as confirmat ion.
Press the right stick in, and t hen steer t o
the left
Press t he ri
ght stick in, and then st eer t o
the
right
Press the right stick in, and t hen steer t o
the
front
Press t he right st ick in, and then st eer t o
the
rear

USER M ANUAL DRONE-WF20
APP DOW NLOAD AND INSTALLATION
Visit t he App St ore (for Apple devices) or Google
Play (for Android Devices).
Search for and inst all “ NAVIG[8]R WD” or
“ HELICUTE 720P FPV”
CONNECTING YOUR DRONE
Ensure you have a Wi-Fi connection on your smart device and that it is t urned on.
Find t he Wi-fi net work called “ NAVIG[8]R WD” or “ HELICUTE 720P FPV”
Click t he connect button
Open your App and press the “ Play” icon
The cont rol panel will t hen display as t he screen shots below.
A streaming image w ill t hen finally appear on screen.
REPLACING DAM AGED BLADES
Your drone w ill come wit h 4 replacement propellers, t wo
type “ A” and t wo t ype “ B” . Use the supplied screwdriver
to remove the rot ars. Att ached t he new propeller then,
tighten back down t he screws.
Note: "A" and "B" will be mark on your drone, next t o t he
propellers.
SPECIFICATIONS
Batt ery requirements for remote: 4 X 1.5V “ AAA” size bat teries (not included)

USER M ANUAL DRONE-WF20

USER M ANUAL DRONE-WF20

USER M ANUAL DRONE-WF20
NOT A
V
AILABLE ON THIS M ODEL
TAKE PICTURE / RECORD VIDEO
NOT AVAILABLE ON
THIS M ODEL
