REV CHANGERECORD AND DATECH
ROCHESTER,NEWYORK
REV
SIZE
B
P/NSUFFIXDEFINITION
-1CONVERSIONCOATING
-2PAINTING
-3MARKING
-RREWORK
UNLESS OTHERWISE
SPECIFIED
DIMENSIONSAREININCHES
AND INCLUDECHEMICALLY
APPLIEDORPLATEDFINISHES
DEC..XXX `.005
DEC..XX `.010
FRACT.`1/64
ANGLES `30'
CONCENTRICITY.003 TIR
BREAK ALL SHARPEDGES
.005 MIN..010 MAX
MAX.SURF.ROUGHNESS 32
TOLERANCES:
MATERIAL:
FINISH:
CHAMFERALL THREADS
30~TOROOTDIAM.
USEDON:
SCALE:
DR.:
CH.:
APP.:
DATEDR.:
DONOTSCALEDRAWING
0.0mm 25.0
0.0inch1.0
SHEETOF
THECONTENTSOFTHIS
DOCUMENTAREPROPRIETARY
TONAVITAR,ITSUSE IS
AUTHORIZEDONLYFOR
RESPONDINGTOREQUEST
FORQUOTATIONOR
PERFORMANCEOFWORKFOR
NAVITAR
1-62517 A
11
R.PODLENA
P.BONAFEDE
P.BONAFEDE
11/22/2002
MOTORIZED(STEPPER)6x
ULTRAZOOMw/2POS.LS(HE)&
MANUAL12mm FF
1:1
OUTLINE
2-PHASE MOTORPINOUT
PIN3=+5Vdc
PIN13 =COMMON
PIN8=FARLIMIT
PIN12 =NEARLIMIT
PIN1=MOTORA+
PIN7=MOTORA-
PIN6=MOTORB+
PIN11 =MOTORB-15 PINHIGHDENSITY
D-SUB
4-40 UNC -2B(4)x
2.13 [54.2]
1.82 [46.2]
1.02 [25.8]
1.33 [33.8]
3.19 [81.0] .80 [20.3]
.32 [8.3]
.75 [19.1]
.38 [9.5]
M25x.75
n1.25 [31.8]
n1.44 [36.5]
n1.60 [40.6]
.52 [13.3]
4.31 [109.6]
4.84 [122.9]
1.312n-.001
.000+
