Navitar 1-62607 Guide

ROCHESTER,NEWYORK
UNLESS OTHERWISE SPECIFIED
DIMENSIONSAREININCHES AND
INCLUDECHEMICALLYAPPLIED
ORPLATEDFINISHES
0.0inch1.0
0.0mm 25.0
P/NSUFFIXDEFINITION
-1CONVERSIONCOATING
-2PAINTING
-3MARKING
-RREWORK
SIZE
REV
TOLERANCES AS FOLLOWS
DEC..XXX
DEC..XX
FRACT.
ANGLES
CONCENTRICITY
BREAK ALL SHARPEDGES
.005 MIN..010 MAX.
MAX.SURF.ROUGHNESS:32
`.005
`.010
`1/64
`30'
.003 TIR
USEDON:
MATERIAL:
FINISH:
CHAMFERALL THREADS30~
TOROOTDIAMETER
SCALE:
DR:
CH:
APP:
DATEDR:
DONOTSCALEDRAWINGSHEETOF
THECONTENTSOFTHIS
DOCUMENTAREPROPRIETARY
TONAVITAR,ITSUSE IS
AUTHORIZEDONLYFOR
RESPONDINGTOREQUESTFOR
QUOTATIONORPERFORMANCE
OFWORKFORNAVITAR
11A
1-62607
R.PODLENA
P.BONAFEDE
8/22/2003
MOTORIZED(5PH)6xw/2POSITIONLS
(HE)&COAX.PORT
1:1
B
OUTLINE
5-PHASE MOTORPINOUT
PIN3=+5Vdc
PIN13 =COMMON
PIN8=FARLIMIT
PIN12 =NEARLIMIT
PIN15 =MOTOR1
PIN5=MOTOR2
PIN10 =MOTOR3
PIN4=MOTOR4
PIN14 =MOTOR515 PINHIGHDENSITY
D-SUB
2.19 [55.7]
2.99 [76.0]
2.02 [51.3]
1.05 [26.8]
1.312n-.001
.000+
n1.60 [40.6]
.72 [18.4]4.97 [126.2]
4.08 [103.7]
n1.50 [38.1]
n1.24 [31.5]
1.093-32 UN -2A
11/16-32 UN -2B
3.84 [97.6] .80 [20.3]
.32 [8.3]
.75 [19.1]
.38 [9.5]
4-40 UNC -2B(4)x
