Navitar HDSSW08 Guide

ROCHESTER, NEW YORK
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES AND
INCLUDE CHEMICALLY APPLIED
OR PLATED FINISHES
0.0 inch 1.0
0.0 mm 25.0 SIZE REV
SCALE:
DR:
CH:
PROJECT #:
DATE DR:
DO NOT SCALE DRAWING
SHEET OF
THE CONTENTS OF THIS
DOCUMENT ARE PROPRIETARY
TO NAVITAR, ITS USE IS
AUTHORIZED ONLY FOR
RESPONDING TO REQUEST FOR
QUOTATION OR PERFORMANCE
OF WORK FOR NAVITAR
2 2 A
1-17728
BJC
R. Podlena
E2269
3/13/2007
SCREEN STAR, HD, 0.8X
1:2
B
WEIGHT: 5.85 lbm
OUTLINE
4-40 UNC - 2B x.5002X
8-32 UNC - 2B2X
.30 [7.6] 2.48 [62.9]
4.95 [125.7]
4.00 [101.6]
.40 [10.2]
.80 [20.3]
3.52 [89.3]
n4.95 [125.7] n4.37 [111]
1.97 [50.1]
.10 [2.4]
