nawras E5 II User manual

1
Thank you for choosing Nawras E5 II Wi-Fi modem
Nawras E5 II Wi-Fi modem is a high-speed packet access (HSPA) USB
modem You can connect E5 II with the USB interface of a computer, or via
Wi-Fi It is a multi-mode wireless terminal for SOHO (Small Office and
Home Office) and business professionals connecting up to 5 users
wirelessly and can access Internet, send and receive emails, SMS, manage
your phonebook contacts, check balance, recharge and even subscribe to
our Prepaid Internet products
Note:
The supported functions and actual appearance are subject to product
purchased The following pictures are displayed for illustration
purpose only For details of your product selection, consult your
service provider
This guide briefly describes the function of the device For advance
configuration, see Help on web management page of E5 II modem by
logging to http://192 168 1 1

2
E5 II can be kept in a reasonable closed environment such as handbag
or laptop bag, however if the ambient temperature increases as a
safety precaution the device will switch off automatically or disconnect
In such event please restart your device
Getting to Know Your E5 II
Packing List
The E5 II box contains the following items If any of the items are lost or
damaged, contact your local dealer

3
Quick Start
Safety
Information
Main unit Battery Power adapter
& data cable
Application Scenarios
The Wi-Fi device or computer can be connected to the Internet through the
E5 II The actual connecting procedure depends on the operating system
of the Wi-Fi device or computer You can perform the connection
operations as prompted
Scenario 1: Multi-device access via Wi-Fi Scenario 2:
One-device access via USB

4
Laptop
Digital camera
Game machine
Smart phone
Scenario : Multi-device access via Wi-Fi and USB at the same time

5
Smart phone
Game machine
Laptop
Digital camera

7
2
1
3
4
5
6
8
7
Appearance
No.
Item
1
Screen
2
microSD card
slot
USB
port
4
Power
button
5
Wi
-
Fi
/WPS
button
6
Dial
ing
button
7
Strap hole
8
Battery
button
Wi-Fi: Wireless Fidelity
WPS: Wi-Fi Protected Setup

8
7
8
1
2
4
3
5
6
Screen
No.
Item
1
Signal s
trength
2
Network

Wi
-
Fi
enabled
Number of devices
connected
4
I
nternet connection
5 
New messages
Number of new messages
6
P
ower level
7
Roaming stat
e
8 
M
: Manual mode
A: Auto mode

9
efore you start
Before inserting the SIM card and battery, please
note down Wi-Fi network name (SSID) and password
(Wi-Fi key) which is printed on the label next to SIM
card slot
Installing the SIM card and the battery
Hold the E5 II modem with USB connector facing down and press the top
button to remove the back cover and battery and insert the SIM as shown

10
1
234
Installing the microSD card
1. Pull the rubber cap from the microSD
card slot and insert the card
Note:
The microSD card is an optional accessory If the microSD card is not
provided in the package, you can buy one yourself
To remove the microSD card, open the rubber cap and press the
microSD card gently
Do not remove the card when it is being used Otherwise, the card and
the E5 II may be damaged, and the data stored on the card may be

11
lost
Charging the Battery
Note: If you have not used the E5 II modem for a long time, please charge
the battery first
Method 1: By using the power adapter
Caution:
Use the compatible power adapter priovided inside the box only
Nawras is not responsible for any damage caused due to incompatible
power adapter

12
Method 2: By connecting to a PC
1. Power off the E5 II modem
2. Connect it with PC using compatible
data cable
Accessing the Internet through a Wi-Fi Connection
Note: Your E5 II modem is preconfigured with Wi-Fi network name (SSID)
and password (Wi-Fi key) You can follow the steps below to quickly access
the internet For the details about how to set the parameters, see the Help
on the Web management page (http://192 168 1 1)
Step1: Power ON the modem.
Step2: Establish a Wi-Fi Connection.

13
Step : Access the Internet.
1. Power ON the modem
Press and hold to switch ON/OFF
the modem
2. Establish a Wi-Fi Connection (considering Windows XP
as an example)
1. Make sure that the Wi-Fi function is
enabled
2. Select Start > Control Panel >
Network Connections >
Wireless Network
Connection
Note: To set up a Wi-Fi connection, the

14
PC must be configured with a wireless network adapter If Wireless
Network Connection is displayed, the wireless network adapter is
available
. Click View available Wireless Networks to display the wireless
network list
4. Select the Nawras E5832-xxxx from the list and click

15
5. Please enter the password (Wi-Fi key)
once the Wireless Network Connection
dialog box is displayed
Note:
You can find Wi-Fi network name (SSID) and password
(Wi-Fi key) on the E5 II exactly below the battery
Wait until the wireless connection icon is displayed in
the status area
. Access the Internet

16
After you establish a Wi-Fi connection successfully, you can access the
Internet in either of the following two modes By default, the mode is set
to Auto
Mode
Operations
Auto
In this mode, E5 II will
connect a
utomatically to the
Internet when data transmission is requested If data
transmission is not performed over a period of time, the
E5 II automatically disconnects from the Internet
Manual
Press and hold
CONNECT
until
is displayed on the screen
When is displayed on the
screen, it indicates that the
connection is set up successfully Then you can enjoy the
Internet service
Press and hold
CONNECT
until disappears When
disappears, it indicates that the connection to the

17
Mode
Operations
Internet
is
disconnected
Note: You can use web management page to connect to or
disconnect from the network as prompted
Note:
You can launch the web management page to select the mode of
accessing the Internet
While roaming E5 II automatically disconnects from the established
network and then you have to manually connect by pressing and
holding
CONNECT
button
The dialing button does not work in Auto mode

18
Accessing the Web Management Page
1. Make sure that the connection between the E5 II and your PC is
established either by USB cable or over Wi-Fi
2. Start the Internet browser and enter http://192.168.1.1 in the
address bar
. Enter the password, and then click Login
Note: The default password is admin
Verifying the PIN Code
Please launch the web management page by typing http://192.168.1.1
and then enter the correct PIN code as prompted Both the PIN and PUK
are delivered with the SIM card For details, consult your service provider
Sharing data stored on the microSD card
E5 II supports data sharing using web management page You can store

19
data on the card and share it with the group
1. Insert the microSD card
2. Access the web management page
. Click SD Card to manage the data stored on the microSD card
SMS
You can enjoy the short message (SMS) service on the web management
page
1. Access the web management page
2. Click SMS to view, write, reply, or send a message

20
Daily Use
Saving Power mode
If no operation is performed for a while, E5 II screen will be off
It will go into deep sleep mode if not accessed for 30 minutes In this state,
you can press any key to activate the Wi-Fi function.
Enabling/Disabling the Wi-Fi
Function
To switch ON Wi-Fi, press and hold
until is displayed on the screen
Note: To switch OFF Wi-Fi, press and hold until
disappears
