Naxa NAP-5003 User manual
Page 2 Naxa Electronics
Thank You
We know you have many choices when it comes to
technology; thank you for choosing us here at Naxa
Electronics. Established in 2001 in Los Angeles, Califor-
nia, we are dedicated to delivering products that en-
tertain and delight.
We trust that you will be happy with your purchase.
Please read this manual carefully and save it for refer-
and other product material at our website. Come visit
us on the web at www.naxa.com and see all that we
have to offer!
In the Box
Please take a moment to make sure that you have ev-
erything in the list below. Although we make every ef-
fort to ensure that each Naxa device is securely packed
and sealed, we know a lot can happen in between us and
you. If anything is missing, check back with your local
retailer to get immediate assistance. If they cannot help
you, please contact our Naxa Support team at www.
naxa.com/naxa_support.
NAP-5003
User manual
18W fast charge wall charger
1M USB A to C cable
www.naxa.com Page 3
Key Features
• Charges multiple devices at the same time with
ease, allowing the whole family to refill their
battery with one stand.
• Standing QI wireless charging pad offers a quick
and easy fast-charging experience.
• 3W QI wireless charging pad gives you a
convenient and quick place to charge your airpods.
• Apple Watch cable holder provides a secure and
efficient spot to place your watch while it charges.
• USB port and Type-C port offer fast-charging
capabilities for all your smartphone devices.
• Smart IC technology allows the unit to
automatically identify your devices and distribute
the safest current at the fastest possible speed
• Built with overcurrent and overload protection,
ensuring your charging experience is a safe one.
• Accessories Included: 18W fast charge wall charger,
1M USB A to C cable, User Manual
Before You Start
Safety Instructions
1. Keep the unit from heat sources, direct sunlight,
humidity, water or any other form of liquid.
2. Do not operate the unit if it has been wet or ex-
posed to moisture to prevent electric shock, ex-
plosion, and/or injury to yourself or damage to the
unit.
3. Do not use the unit with wet hands.
4. Keep the unit free from dust, lint and other small
particles.
5. Do not use the unit for anything other than its in-
tended use.
6. Keep the unit out of reach of children. This unit is
not a toy.
Care and Maintenance
Read the following recommendations before using the
portable battery pack.
Page 4 Naxa Electronics
1. Do not expose the battery to liquid, moisture or
humidity. This may adversely affect the internal
circuit of the device.
2. Do not use abrasive cleaning solvents to clean the
device.
3. Do not expose the device to extremely high or low
temperatures. Extreme temperatures may destroy
the battery or distort some of the plastic parts.
4. Do not incinerate or otherwise dispose of the de-
5. Do not expose the device to contact with sharp to
prevent scratches and other damage.
6. Do not drop the device. Drops and other hard shocks
may damage the internal circuit.
7. Do not attempt to disassemble the device. There
are no user-serviceable parts inside.
At a Glance
www.naxa.com Page 5
Using the Charging Station
Getting Started
Wireless Charging Pad
1. Place your Airpods on the Wireless charging pad. The
RIGHT indicator light will turn solid blue and your
devices will light up indicating that charging has
begun successfully.
NOTE: If charging does not begin. Adjust the
positioning of your Airpods/ earbuds on the
charging pad.
2. If the RIGHT LED indicator light of the charging pad
start flashing light blue after your devices is placed
on it. Then you should remove your devices, unplug
the 3 in 1 Smart Wireless Charging Stand, and repeat
Plug the provided TYPE-C USB Cable into the charging
Stand TYPE-C USB port. Plug the other end into a local
power source(Suggest to use Original Adaptor). You
will see the LED indicator on the charging stand turn
BLUE, GREEN, and then turn off. This means that it is
ready for use.
the setup process. If, after placing your device the
indicator flashes blue, remove your device and
repeat the setup process. If flashing continues,
your device may not be Qi-compatible.
Wireless Charging Stand
1. Place yourphone on the Wireless charging stand.
2. The left charging indicator light will turn solid
blue and your devices will light up indicating that
charging has begun successfully.
iWatch Charging Holder
Page 6 Naxa Electronics
Support
If you have problems with your device, please consult
the instructions in this manual. Please also visit us
on the web at www.naxa.com to get up to the minute
news, alerts, and documentation for your device. For
additional assistance, please contact Naxa Technical
Support.
NAXA Technical Support
2320 East 49th St.
Vernon, CA 90058
http://www.naxa.com/naxa_support/
MADE IN CHINA
• Input: USB-C
• Outputs: USB and USB-C
• Wireless charger: 2 pads; 15W Phone Pad and 3W
Airpod Pad
• Total Output: 15W max
• Indicator Lights: LED
www.naxa.com Page 7
Warnings and Precautions
triangle is intended to alert the user to the presence of unin-
sulated “dangerous voltage” within the product’s enclosure that
shock
The exclamation point within an equilateral triangle is intended
to alert the userto the presence of important operation and ser-
vicing instructions in the literature accompanying the appliance.
Important Safety Information
1. Read Instructions: All the safety and operating instructions should be
read before the product is operated.
2. Retain Instructions: The safety and operating instruction should be
retained for future reference.
3. Heed Warnings: All warnings on the product and in the operating in-
structions should be adhered to.
4. Follow Instructions: All operating and usage instructions should be
followed.
5. Cleaning: Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for
cleaning.
6. Attachments: Use only attachments recommended by the manufac-
turer. Use of other attachments may be hazardous.
7. Water and Moisture: Do not use this product near water (e.g., near a
bathtub, washbowl, kitchen sink, laundry tub, in wet basements, or
near a swimming pool and the like).
8. Ventilation: Slots and openings in the cabinet are provided for ven-
tilation to ensure reliable operation of the product and to protect it
from overheating. These openings should never be blocked by placing
the product on a bed, sofa, rug, or other similar surface. This product
should not be placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or the manufacturer in-
structions have been adhered to.
9. Power Sources: This product should be operated only from the type of
power source indicated on the rating label. If you are not sure of the
type of power supply to your home, consult your product dealer or
local power company. For products intended to operate from battery
power or other sources, refer to the operating instructions.
10. Grounding or Polarization: This product may be equipped with a po-
larized alternating-current line plug that has one blade wider than
This is a safety feature. If you are unable to insert the plug fully into
the outlet, try reversing the direction of the plug. If the plug should
Page 8 Naxa Electronics
not defeat the safety purpose of the polarized plug.
11. Power-Cord Protection: Power supply cords should be routed so that
they are not likely to be walked on or pinched by items placed upon
or against them, paying particular attention to cords at plugs, conve-
nience receptacles, and at the point which they exit from the product.
12. Protective Attachment Plug: The product may be equipped with an at-
tachment plug with overload protection. This is a safety feature. See
the operating instructions for replacement or directions to reset the
protective device. If replacement of the plug is required, be sure the
service technician has used a replacement plug that has the same over-
13. Lightning: For added protection for this product, unplug it from the
wall outlet during a lightning storm or when it is left unattended and
unused for long periods oftime. This will prevent damageto the prod-
uct due to lightning or power-line surges.
14. Overloading: Do not overload wall outlets, extension cords, or inte-
-
tric shock.
15. Object and Liquid Entry: Never push objects of any kind into this prod-
uct through openings as they may touch dangerous voltage points or
liquid of any kind on the product.
16. Servicing: Do not attempt to service this product yourself as open-
ing or removing covers may expose you to dangerous voltage or other
17. Damage Requiring Service: Unplug this product from the wall outlet
-
ing conditions: a) when the power-supply or plug is damaged; b) if
liquid has been spilled or if objects have fallen into the product; c) if
the product has been exposed to rain or water; d) if the product does
not operate normally by following the operating instructions. Adjust
only those controls that are covered by the operating instructions as
improper adjustment of other controls may result in damage and will
product to its normal operation; e) if the product has been dropped or
damaged in any way; f) when the product exhibits a distinct change in
performance—this indicates a need for service.
18. Replacement Parts: When replacement parts are required, be sure
by the manufacturer or have the same characteristics as the original
other hazards.
19. Safety Check: Upon completion of any service or repairs to this prod-
uct, ask the service technician to perform safety checks to ensure
that the product is in proper operating condition.
20. Heat: The product should be situated away from heat sources such as
radiators,heat registers, stoves, or other products (including ampli-
WARNING
This product contains lead, a chemical known to the State of California to
cause cancer and birth defects or other reproductive harm. Wash hands
after handling.
FCC NOTICE
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the lim-
www.naxa.com Page 9
its for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful in-
terference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to ra-
dio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be de-
termined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION ON MODIFICATIONS
this device may void the authority granted by the FCC to operate the
equipment.
Table of contents
Other Naxa Batteries Charger manuals
