NB EX2904 User manual

User Manual www.newbalance-watch.com
904
NM-707.1
EX2

Back View of the Watch Front View of the Watch
back
sensor
Stainless Steel
Top Cover
[HR]
Start/Stop/Lap
[S/S]
Start/Stop/Lap
[S/S]
Reset
[R]
Light
[EL]
Mode
[M]
Design of the Watch
1
Thank you for purchasing this watch. Please read this manual thoroughly before using
the watch!
WARNING !
• DO NOT use this Watch for commercial or professional purposes.
• Make sure that you fully understand the functions and limitations of this watch before
using it.
• This Watch is a supplementary device for measuring heart rate; it is NOT a substitute
for medical devices. You should periodically compare the heart rate reading acquired
by this watch with the reading from a doctor.
• Consult a doctor or trainer before setting your Upper and Lower heart rate limits.

Mode Button [M]
• Press to select one of the functional modes
• In function modes: Hold to select setting display
• In any setting display: Press to choose between different settings.
• Press and hold the button to exit setting sequence.
Start/Stop/Lap Button [S/S]
• In Current Time Mode: Press to show Alarm Time and Hold to enter the setting of
Daily Alarm Mode
• In Heart Rate Chronograph Mode: Press to start the counting or take Laps,
Hold to stop counting.
• In Timer Mode: Press to start or stop counting.
• In setting displays: Press to change the settings.
Reset Button [R]
• In Heart Rate Chronograph Mode: Press to select sub-functional modes.
When the counting is stopped, Hold to reset display to zero
• In Timer Mode (Stop Counting): Hold to reset the timer to target time
• In setting displays: press to change the settings.
Light Button [EL]
• In any mode/display, press to turn ON the EL back light for about 3 seconds.
Note: The button operations are summarized above, for detailed operating instructions,
please continue reading.
Buttons Operation Summary
2

Current Time Mode
• Time System: am, pm, hour, minute,
second
• Time Format: 12-hour or 24-hour format
• Calendar: date and day of week display
(Auto-Calendar function for day of week
and leap year)
Daily Alarm
• Daily alarm and hourly chime
• Alarm Sound: 1 minute
Timer Mode
• Resolution: 1 second
• Measuring range:
9 hours 59 minutes 59 seconds
• Timer sounds: Last 10 seconds will beep
every second and beep for 15 seconds
when count to zero.
Memory Mode
• Lap recall / Total lap time recall
• Lap average heart rate recall
• Total average heart rate recall
Back Light
• Back Light Type: Electro-Luminescent
(EL) back light
Heart Rate Chronograph Mode
Heart Rate Measurement
• Range for chest strap: 40 to 240 bpm
• Range for finger touch: 40 to 200 bpm
• Heart Rate Zone Alert
• 4 Heart Rate Zone selectable
• 3 Activity Level selectable
Chronograph
• Resolution: 1/100 second
• Measuring range:
9 hours 59 minutes 59.99 seconds
• Maximum: 25 Laps
Heart Rate Zone Timer
• Resolution: 1 second
• Measuring range:
9 hours 59 minutes 59 seconds
Calorie Consumption
• Range: 0 to 9999 kilo-calorie
Fat Burnt
• Range: 0 to 9999 gram
Others
• 5 ATM water resistance
Specifications
3

Finger-Touch HR
Measurement Display
Heart Rate Chronograph
Mode Memory Mode Timer ModeCurrent Time Mode
Hold [HR] Release [HR]
[M]
[M][M][M]
Major Function Modes
4

Current Time Mode
• Current Time Mode includes two
functional displays:
1) Current Time Display
2) Daily Alarm Display
Current Time Display
• The day of week and date exhibits
on the 1st row of display.
• The current time (hour, minute,
second) exhibits on the 2nd row of
display.
Daily Alarm Display
• The preset daily alarm time (hours,
minutes) exhibits on the display.
To Select between the Current Time
Display and Daily Alarm Display
• Press and hold the [S/S] button to
show the Daily Alarm Display.
• When you release the [S/S] button
within 2 seconds, it will go back to
the Current Time Display.
• If you hold more than 2 seconds, it
will go to alarm setting display.
hold
[S/S]
release
[S/S]
Day of
week
Date
current
time
Current Time Display
Daily Alarm Display
Current Time Mode
5

Increase /
Decrease the
setting by 1
scroll
the setting
faster
Current Time Mode - Setting Sequence
5.1
[M]
[M]
[M]
[M]
[M]
[M]
[M]
[M]
[M]
[M]
[M]
[M]
[M]
[M]
[M]
hold
[M]
hold
[M]
[S/S]
or [R]
hold
[S/S]
or [R]
Current Time Mode
Second
Minute
Hour
Year
chime
ON/OFF
Time
format
day
month
beep
ON/OFF
gender
Height
Unit
year of
birth
Weight
Weight
Unit
Height

To Set the Current Time Mode
• To set the current time, date, and other settings, press and hold the [M] button for
about 2 seconds to select the setting display (the second digits will start flashing).
The Setting Sequence
• When the second digits start flashing, press the [M] button to move the flashing
following the setting sequence of the diagram in previous page or press the [S/S] or
[R] button to reset the second digits to zero.
• If one of the settings (minute, hour, year, month, day, 'BIRTH'-birth year, 'HGT'-height,
'WGT'-weight) is flashing, press the [S/S] or [R] button to scroll through the setting
(hold the button down to scroll the setting at a faster pace).
• When the '12Hr' or '24Hr' icon is flashing, press the [S/S] or [R] button to switch
between '12Hr' (12 hour format) and '24Hr' (24 hour format).
• When the hourly chime (CHIME) or beep tone (BEEP) 'on' or 'oFF' icon is flashing,
press the [S/S] or [R] button to turn ON ('on') or OFF ('oFF'). And when the hourly
chime is ON, indicator ' ' will be appeared and the watch will beep once on every
hour.
• When the Gender 'F' or 'M' icon is flashing, press the [S/S] or [R] button to switch
between 'F' (Female) and 'M' (Male).
• When the Height Unit 'In' or 'CM' icon is flashing, press the [S/S] or [R] button to
switch between 'In' (Inch) and 'CM' (Centimeter).
• When the Weight Unit 'kG' or 'LB' icon is flashing, press the [S/S] or [R] button to
switch between 'kG' (Kilogram) and 'LB' (Pound).
• When the setting is completed, press and hold the [M] button for about 2 seconds to
exit the setting sequence. The setting display will return to Current Time Mode
automatically if there is NO key-stroke for about 1 minute.
Current Time Mode - Setting Sequence
5.1

Daily Alarm Display
• In the Daily Alarm Display, Alarm Time
(hours, minutes) appears on the 2 row of the
display.
Daily Alarm ON and OFF
• When the Daily Alarm Indicator ' '
appears (which means the daily alarm is ON),
the watch starts beeping at the alarm time.
Daily Alarm Sound
• The alarm beeps for 1 minute when the daily
alarm function is turned ON.
• You can stop the beeping by pressing any
button.
release
[S/S]
Normal Time Mode
Daily Alarm Display
daily alarm time
(hours, minutes)
Hold
[S/S]
Current Time Mode - Daily Alarm
5.2

Current Time Mode - Setting the Daily Alarm
5.3
To Set the Daily Alarm Function
• In the Current Time Mode: Press and hold the
[S/S] button for more than 2 seconds to enter
the alarm setting display (the 'on' or 'oFF' will
start flashing).
The Setting Sequence
• Press the [M] button to select between Alarm
ON/OFF, hour and minute setting.
• When the 'on' or 'oFF' flashes on the display,
press the [S/S] or [R] button to turn ON or
OFF the alarm.
• When the 'hour' or 'minute' digit flashes on
the display, press the [S/S] or [R] button to
scroll through the setting (hold down the
button to scroll the setting at a faster pace).
• Press and hold the [M] button for about 2
seconds to exit the setting sequence.
• The setting display will change to Current
Time Mode automatically if there is NO
key-stroke for about 1 minute.
Current Time Mode
Daily Alarm Setting Sequence
Hold
[M]
Hold [S/S]
more than 2 sec.
[M]
[M]
[M]
hold
[S/S] or [R]
[S/S]
or [R]
scroll
the setting
faster
Increase /
Decrease the
setting by 1
Alarm
ON/OFF
Hour Minute

Watch
Back View
Watch
Front View
back
sensor
Stainless Steel
Top Cover
[HR]
Battery DoorElastic band
contact contact
release slot
Soft Belt
Chest Strap
Front View
Chest Strap
Back View
Heart Rate Measuring - Sensors Configurations
6.0

• In exercise or sports, your heart naturally speeds up in pumping blood to the
body in accordance with your increased energy level. This watch can calculate
that increase expressed as the number of beats per minute (bpm) to determine a
safe target heart rate for each individual.
PRECAUTIONS/TIPS
1. A heart rate sensor is located on the back of the watch. The back sensor must
make firm contact with the user’s skin during Finger-Touch measurement.
2. There are 2 contacts located on the back of the chest strap. The sensors must
make firm contact with user’s skin during Chest-Strap measurement.
3. DO NOT take heart rate measurement when diving or under water.
4. Clean the back cover of the watch and the back of the chest strap occasionally by
applying a few drops of water and wipe it dry with a paper towel. It can help
removing any residual grease.
5. DO NOT use hand cream; it will insulate the signal between the skin and the
sensors.
6. Clean fingers with soap and water for better signal transmission.
7. Clean skin around chest area with soap and water for better signal transmission.
8. DO NOT use the fingertips where the skin is dry and thick.
9. For those with extremely dry skin, moisten the skin with tap water or apply a
conductive gel may help.
10. Hold the watch firmly when taking Finger-Touch measurement in motion.
11. Adjust the Chest Strap with the supplied elastic band until it is hold on your chest
firmly to avoid loosen it when doing exercise.
12. During the measurement, avoid any awkward motion. Awkward motion creates
undesired muscle noise; hence an incorrect heart rate reading may result.
Heart Rate Measuring - Precautions and Tips
6.1

What is Heart Rate Zone?
Some particular training/exercise
objectives like ‘aerobics’, ‘fat burnt’ or
‘health’ that require trainees/exercisers
maintaining their heart rates (exercise
paces) within one particular heart rate
zone during the exercise.
WARNING: Consult a doctor or trainer
prior to set the heart rate alert zone for a
serious cardio-fitness training.
How to Select a Zone (for Heart Rate Zone Alert)?
In general, users may get the cardio-fitness training advices from those prestigious
organizations’ website, for example:
• http://www.heart.org/HEARTORG/Conditions/CongenitalHeartDefects/
CareTreatmentforCongenitalHeartDefects/Congenital-Heart-
Defects-and-PhysicalActivity_UCM_307738_Article.jsp
by American Heart Association.
• http://en.wikipedia.org/wiki/Heart_rate#Training_zones
by Wikipedia.
• This Watch includes three pre-defined heart rate zones (“AROBIC”, “FAT-B” and
“HEALTH”) and one user-defined heart rate zone (”USR”) for user selection.
• The upper and lower limit of these Zones is shown on the adjacent diagram.
Check chapter 6.6 for the details on how to select a Zone.
Heart Rate Zone
AROBIC
(Aerobic)
HLTH
(Health)
USR
(User-
defined)
FAT-B
(Fat
burnt)
%
EMHR
Upper
Limit
Lower
Limit
User
defined
Above Zone
Below Zone
In Zone
80% 75% 65%
65% 55% 50%
Heart Rate Measuring - Heart Rate Zone
6.2

Note:
• When taking a heart rate measurement, various visual indicators will be displayed
according to the different zones. A single beep will sound to alert whether heart
rate is out of the present zone.
• Please refer chapter 6.6 for details on turn ON/OFF Zone Alert.
Heart rate
(beats per minute)
the upper
limit
the lower
limit
Audio
Indication
Visual
Indication
‘ ’ indicator shown
‘ ’ indicator shown
‘ ’ indicator shown
‘beep’
‘beep’
NO beep sound
The Above Heart Rate Zone
The Below Heart Rate Zone
The Desirable Heart Rate Zone
The Different Heart Rate Zones and
the Corresponding Indications
Heart Rate Measuring - Heart Rate Zone Alert
6.2.1

• During exercise or sports, your heart
naturally speeds up pumping blood to the
body in accordance with your increased
energy level.
• The Heart Rate Chronograph Mode and
Instant Heart Rate Mode shows the
current heart rate in terms of:
• Heart Rate (e.g 78) : The number of
heart beats per minute (bpm), and
• Percentage of Estimated Maximum
Heart (e.g 40%): The percentage of
the acquired heart rate with respect to
one's estimated maximum heart rate.
Percentage of Estimated Maximum Heart
Rate
• It is a useful figure for analysing the
cardio-fitness of a person.
• It can be used to define a heart rate zone
for cardio-fitness training.
• Consult your doctor for more information
on the implications of Percentage of
Estimated Maximum Heart Rate.
NOTE: The user MUST input his/her age and
gender into the watch. Check chapter 5.1 for
the details on age and gender settings.
Estimated Maximum Heart Rate (EMHR):
• EMHR = 220 - user age.
• Example: What is Tom's EMHR at his
age of 27?
• EMHR = 220 - 27 = 193.
NOTE: This Watch can calculate the EMHR
for user the age up to 99.
Percentage of Estimated Maximum Heart
Rate (%EMHR):
• %EMHR =
Acquired heart rate ÷ EMHR X 100%
• Example: What is Tom's %EMHR if he
has acquired a heart rate of 78.
• %EMHR = 78 ÷ 193 X 100% = 40%
percentage
of estimated
maximum
heart rate
Heart Rate
Chronograph Mode
heart
rate
in bpm
Heart Rate Measuring - About EMHR and %EMHR
6.2.2

NOTE:
• You can exit this mode by
pressing any button. (Except
[EL] button)
• For more detail of viewing
different exercise information,
please refer chapter 6.5. / For
more details on Zone Setting,
please refer chapter 6.6.
Measuring Heart Rate by Finger-Touch
Following the steps below, you can measure your heart rate
by touching the sensor on the watch.
(1) Make sure the sensor on the back of the watch sits firmly
on your skin.
(2) Place your index finger on the stainless steel top cover
[HR].
(3) Keep holding for about 5 seconds. When the heart rate is
detected, the heart rate will be displayed on the screen.
user's
wrist
flashing
segments
Heart Rate
is sampling Heart Rate Result Display
result
heart rate
5 to 8
seconds
beep
Heart Rate Measuring - Finger-Touch Measurement
6.3

How to Wear the Chest Strap
• Refer to the below steps to wear the
chest strap on one’s chest:
1) Extend the elastic band for allowing a
loose fitting the chest strap on your
chest.
2) Connect one connector with the chest
strap. Ensure that the connector is
completely lodged into the chest strap.
3) Fit the chest strap on your chest with
one hand.
4) Connect the opposite connector to the
chest strap with the another hand.
5) Fasten the elastic band until it is fitted
on your chest comfortably.
6) Adjust the chest strap until the two
contacts are firmly contacted with
your skin.
IMPORTANT: DO NOT wearing the chest
strap over your cloth, otherwise the chest
strap CANNOT get the heart rate signal.
NOTE: In dry seasons, wetting the contacts
with some water can make the signal
transmission better.
Heart Rate Measuring - Wearing the chest strap
6.4

Measuring Heart Rate by Chest Strap
• Beside Finger-Touch, users can also measure
their heart rate by using chest strap.
• To measure heart rate by chest strap, first,
wear the chest strap following the instruction
of chapter 6.4.
• Go to “Heart Rate Chronograph Mode” and
the watch will start measuring automatically.
• When heart rate signal detected, the heart
rate measured will be exhibited on the
screen. Percentage of Estimated Maximum
Heart Rate (%EMHR) will also be exhibited
on the left.
• The Maximum heart rate and the Average
heart rate during measurement will also be
shown on the 1st row.
NOTE:
• The Maximum and Average Heart Rate
calculation will include the result from
finger-touch measurement.
• Hold the [R] button in Heart Rate
Chronograph Mode will reset all the
calculations and records stored in the watch,
including Chronograph, Zone Timer, Fat and
Calorie consumption.
Heart Rate Captured
Heart Rate Scanning
Heart Rate Signal
detected
%EMHR
Average
Heart rate
Result
Heart rate
Maximum
Heart rate
Heart Rate Measuring - Chronograph Display
6.4.1

Heart Rate Chronograph Mode and the
Sub-Function Displays
• In the Heart Rate Chronograph Mode,
there are 8 different displays for
showing the exercise information.
They are:
• Maximum / Average Heart Rate
Display,
• Chronograph Display,
• Below Zone Timer Display,
• In Zone Timer Display,
• Above Zone Timer Display,
• Calorie Consumption Display,
• Fat Burnt Display and,
• Current Time Display.
• Press [R] to scroll different
Sub-Function Displays from the top
row of the display.
[R]
[R]
[R]
[R]
[R]
[R]
[R]
In Zone Timer
Above Zone Timer
Calorie Consumption
Fat Burnt
Below Zone Timer
Chronograph
Max. / Avg. Heart Rate
Current Time
Heart Rate Chronograph
Sub-Function Display
Heart Rate Measuring - Heart Rate Chronograph Mode
6.5

To Use the Chronograph
• In 'Zero' Display, press the [S/S]
button once to start the counting.
When it is counting, hold the [S/S]
button to stop the counting, and
the accumulative elapsed time will
appear.
• Press the [S/S] button once to
take a Lap Record.
To Reset the Chronograph
• When the chronograph is stopped,
hold the [R] button to reset the
chronograph (ready for a new
counting).
NOTE
• Once start counting, it will
measure chest strap heart rate. In
order to measure Finger-Touch
heart rate at this moment, re-enter
Chronograph Mode by key [M].
• While taking Lap Time, the
average heart rate for the Lap is
also recorded.
• When the Chronograph is reset,
the records will also be reset.
Note:
This diagram illustrates
the flow among different
functional displays only,
hence, these displays
DO NOT conform to fact
in all instances.
Heart Rate Measuring - Chronograph Display
6.5.1
[S/S]
Hold [R]
Hold [S/S]
[S/S]
the chronograph
stop counting
Auto Return
after 5 sec.
Lap
Number
(flashing)
Running
Chronograph
'Zero' Display
Chronograph
Counting Display
Chronograph
Lap Display
Chronograph
Stop Counting Display
