Panther Fuel Controller Quick Reference Guide -1651
Included Accessories
Wall Mounting Instructions
497-0503689 Rev C
3) Secure the two captive screws with a straight blade screwdriver
1) Attach the bracket to the wall (refer to Mounting Bracket Installation section for additional info)
Qty 1 -6ft (2m) left
angle power cable
(U.S. plug)
2) Slide Panther housing onto the wall bracket side tabs
Qty 1 -2ft (0.7m)
flexible conduit
Qty 2 –conduit fitting
Qty 8 –black tie wraps
Qty varies –three
position connectors
Qty varies –two position
connectors
Note: Case and Wall bracket colors are
changed in some graphics to aid in detail clarity.
Qty 1 –cable label
sheet
Thank you for purchasing the NCR
Panther Fuel Controller.
The Panther Fuel Controller is designed to
offer direct connectivity to all major brands of
dispensers and outdoor payment terminals.
This high-performance solution replaces
multiple forecourt devices typically required by
most existing solutions and enables robust
marketing programs and credit card encryption
methods all while dramatically decreasing
transaction times.
Product Highlights
Open Door To Access Internal Boards/Connections
To open door, turn the slotted latch
with a coin or screw driver ¼ turn.
Once unlatched the door can be
opened. Please note that lifting up
on the door while opening will result
in the door coming off the hinges by
design.
Qty 1 –wall bracket
Disconnect A/C power cord from the
unit before opening door.
Page 1

Motherboard Internal Ports
To Remove Door
Panther Fuel Controller Quick Reference Guide -1651
To remove the door simply open
the door and lift the door upwards
off the hinges.
To install the door, simply align the
door hinges with the body hinges
and slide the door downward into
place.
Side Panel Ports and Slots
1
4
1 –Power 110-220V 50-60Hz
2–Power On/Off Button
3–Recovery Utility Button
4–DVI Port (remove cover if
needed) *
5–Cable Retention
2
3
5
To Lock Enclosure
With the Panther door closed, use one of the
following to secure the device:
1) Standard Padlock with a bolt diameter no
less than .200” and no greater than .280”
2) Tamper Evident Zip Tie
3) Kensington Lock (ensure lock is fully
seated)
*Note: Locks and tamper evident zip ties are
not included.
2
1
3
1 –2x Network LAN 10/100/1000 ports (E1, E2)
2 –4x RS232 Serial Ports (S3, S4, S5, S6)
3–2x Powered RS232 Serial Ports +12V/500mA each on RTS (S1, S2)
4–8x USB Ports +5V/500mA each
5–SSD, MO-297 SATA 3.0Gb/s
1
3
4
52
Page 2 497-0503689 Rev C
* Note: The DVI port should only be used for setup, maintenance and troubleshooting. It is not
intended for use during normal operation.

Forecourt Interface Board Ports
1
2
345
6
1–Power (to motherboard)
2 –USB (to motherboard)
3–Current Loop / 485 (ports 1-16)
4–EMAIL protocol (port 17)
5–PEC protocol (port18)
6–Tokheim / MSM (ports 19 & 20)
Panther Fuel Controller Quick Reference Guide -1651
Forecourt Interface Board Port LEDs
Port 1 …………Port 16
LED LED
Ports 1 to 16
Blue constant = 485 idle
Blue blinking = 485 Tx/Rx
Green constant = current loop idle
Green blinking = current loop Tx/Rx
Red constant = port error
Red blinking = communication error
Ports 17 & 18
Green constant = idle
Green blinking = Tx/Rx
Red constant = port error
Red blinking = communication error
Ports 19 & 20
Blue constant = 485 idle
Blue blinking = 485 Tx/Rx
Green constant = RSTOK idle
Green blinking = RSTOK Tx/Rx
Red constant = port error
Red blinking = communication error
Port 17
LED
Port 18
LED
Port 19
LED
Port 20
LED
Page 3 497-0503689 Rev C

Panther Fuel Controller Quick Reference Guide -1651
Cable Routing Process for Models with Two Forecourt
Interface Boards
2
3) Rotate lower board outward
4) Route cables underneath chassis as needed
5) Tie wrap cables as needed
6) Rotate lower board inward
7) Tighten thumb screws
8) Reconnect Power and USB cables to the lower board
4
3
To route cables under the lower Forecourt Interface Board:
1) Remove Power and USB cables from the lower board
2) Loosen thumb screws
1
Page 4
Lower
Board
5
497-0503689 Rev C

Essential Safety Precautions
•To avoid a possibility of electrical shock, be sure to connect the power cord to the Panther Fuel Controller before
connecting it to the A/C power outlet.
•A fire or electrical shock may result if the voltage used with the Panther Fuel Controller is beyond the specified range.
•Voltage and frequency rating: 100V –240V AC, 60 –50Hz, 2A.
•To prevent a possible explosion, do not install the Panther Fuel Controller in areas which contain flammable gases.
•Do not cover or install in an enclosed space.
•The Panther Fuel Controller is not water resistant and should not be installed in areas where it may be exposed to water
or other moisture.
•Use only 26AWG telecommunication line cord when connecting the optional modem.
•The operating temperature range of this device is 32 to 122 F (0 to 50 C). Do not operate the device if the ambient
temperature is not within this range.
IT Power System
The NCR Panther Fuel Controller is suitable for connection to an IT power system with a phase‐to‐phase voltage not
exceeding 240 V.
This device is not intended for use as a workstation.
Cet appareil n’est pas destine à servir d’ordinateur de travail.
Dieses Geräte kann nicht als Arbeitsplatz verwendet werden
Servicing
Warning: This product does not contain user serviceable parts. Servicing should only be performed by a qualified
service technician.
Attention: Ce produit ne contient pas de components reparable par l’utilisateur. Le service ne doit être fait que par un
technicien qualifié.
Warnung: Dieses Produkt enthält keine verbrauchbaren Teile. Service nur durch einen qualifizierten Fachmann.
Fuse Replacement
Warning: For continued protection against risk of fire, replace only with the same type and ratings of fuse.
Attention: Pour prévenir et vous protéger contre un risque de feu, remplacer la fusible avec une autre fusible de même
type, seulement.
Achtung: Gegen schutz vor feuer; ersetzen sie nur sicherungen der selben art und wertung
Power Supply Cord Used as Disconnect Means
Warning: The power supply cord is used as the main disconnect device. Ensure that the socket outlet is
located/installed near the equipment and is easily accessible.
Attention: Le cordon dʹalimentation est utilisé comme interrupteur général. La prise
de courant doit être située ou installée à proximité du matériel et être facile à acceder.
Warnung: Der Stromstecker sollte nahe dem Geräte installiert sein und sollte leicht
zugänglich sein.
AC Power Cord Usage
The attached power cord should only be used with this device. It must not be used with any other device.
Connecting to an AC Source
See the AC requirements in the Site Preparation Guide before connecting to the AC supply.
Voir les exigences de courant alternatif dans le Guide de Préparation de Site avant le fait de raccorder aux réserves de
courant alternatif.
Lithium Battery Warning
Warning: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type as
recommended by the manufacturer. Discard used batteries according to the manufacturerʹs instructions.
Attention: Il y a danger dʹexplosion sʹil y a remplacement incorrect de la batterie. Remplacer uniquement avec une
batterie du même type ou dʹun type recommandé par le constructeur. Mettre au rebute les batteries usagées
conformément aux
instructions du fabricant.
Warnung:: Gefahr von Explosionen wenn die Batterie falsch eingelegt wird. Ersetzen Sie nur mit gleichen oder
gleichwertigen Batterien wie vom Hersteller empfohlen. Entsorgen Sie die Batterien wie vom Hersteller empfohlen.
Battery Disposal (Switzerland)
Refer to Annex 4.10 of SR814.013 for battery disposal.
Peripheral Usage
This terminal should only be used with peripheral devices that are certified by the appropriate safety agency for the
country of installation (e.g. UL, CSA, TUV, VDE) or those which are recommended by NCR Corporation.
Ce terminal devrait être utilisé avec les mécanismes périphériques qui sont certifiés par l’agence appropriée pour le
pays d’installation (UL, CSA, TUV, VDE) ou ceux recommandés par la NCR Corporation. Dieses Terminal sollte nur mit
peripheren Geräten benutzt werden die von der geeigneten Sicherheitsagentur für das Land in dem es installiert wird
(UL, CSA, TUV, VDE) oder jenen die von der NCR empfohlen werden, angeschlossen werden.
Warning: DO NOT connect or disconnect a printer, keyboard, or any other terminal‐powered peripheral while the
terminal is powered on. Doing so may result in peripheral or system damage.
System Weight Considerations for Wall or Ceiling Mounted Equipment
Warning: NCR Panther Fuel Controller must be mounted securely to prevent a hazard. They must be installed in
accordance with local building codes. The location where the unit is installed should be able to withstand four times the
weight of the unit
Attention –Le NCR Panther Fuel Controller doit être installer précautionneusement afin d’éviter tout accident éventuel.
Il doit être installé dans le respect des codes de l’établissement.
Warnung: Der NCR Panther Fuel Controller muss sicher montiert werden um Gefahr zu verhindern. Es muss in
Übereinstimmung mit den örtlichen Bauvorschriften installiert werden.
Panther Fuel Controller Quick Reference Guide -1651
Follow the instructions below to ensure the safe mounting of the Panther Fuel Controller.
•The AC outlet should be installed near the Panther and be easily accessible.
•Appropriate Hex or Philips head screw driver is required to seat screws. Electric screw
driver and applicable bits are required to create pilot holes for either screw or wall anchor.
Wall Mounting
1) Verify the conduit coupling is tightly installed. If necessary, remove any additional knockout
holes and install additional conduit couplings.
2) Attach the wall mount bracket to the wall through the 4 wall mounting holes. Where
possible, ensure that at least one vertical pair of mounting holes will be mounted to a stud.
For stud mounting use ¼” diameter x 2” length wood screws. The other hole pair will be
mounted with¼” diameter x 2 ¼” length hollow wall anchors. If there are no studs available,
hollow wall anchors may be used for all mounting holes.
¼” diameter, 2 ¼” length Wood Screw ¼” diameter, 2 ¼” length Hollow Wall Anchor
Mounting Bracket Installation
Recovery Utility And Power Button Instructions
Pressing the Recovery Button on the side of the unit during initial boot will cause the Panther
Fuel Controller to boot to its Recovery Mode. This operation will automatically run a check disk
process to attempt to resolve any problems with the disk or file system and then reboot into
Normal Mode. A text file log of any changes will be created on the storage card.
Pressing the Power Button on the side of the unit will cause the Panther Fuel Controller to turn
on. To power off the unit, press and hold the Power Button for 4 to 5 seconds.
Recovery
Power
Page 5 497-0503689 Rev C

Panther Fuel Controller Quick Reference Guide -1651
The unit will not
power on
No network
connectivity
• Verify A/C outlet is on / breaker is not tripped.
•Verify power cord is firmly plugged in to A/C outlet and Panther.
•Verify cable is rated category 5e or higher.
•Verify hub / switch is 10/100/1000 and is powered on.
•Verify RJ-45 connector is properly pinned out and terminated.
•Verify cable is firmly plugged in to hub and Panther.
Support Information
Visit NCR on the World Wide Web http://www.ncr.com
Basic Troubleshooting
Problems Suggestions
Federal Communications Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause interference in which case the user
will be required to correct the interference at his own expense. NCR is not responsible for any radio or television
interference caused by unauthorized modification of this equipment or the substitution or attachment of connecting
cables and equipment other than those specified by NCR. The correction of interference caused by such unauthorized
modification, substitution or attachment will be the responsibility of the user. The user is cautioned that changes or
modifications not expressly approved by NCR may void the userʹs authority to operate the equipment.
Canadian Department of Communications
These digital apparatuses are Class A digital apparatuses that comply with Canadian ICES‐003. These digital
apparatuses do not exceed the Class A limits for radio noise emissions from digital apparatus set out in the Radio
Interference Regulations of the Canadian Department of Communications. Cet appareil numérique de la classe A est
conforme à la norme NMB‐003 du Canada. Le présent appareil numérique nʹémet pas de bruits radioélectriques
dépassant les limites applicables aux appareils numériques de la classe A prescrites dans le règlement sur le brouillage
radioélectriques édicté par le ministère des Communications du Canada.
International Radio Frequency Interference Statement
Warning: NCR EPC4 Terminal is a Class A products. In a domestic environment these products may cause radio
interference in which case the user may be required to take adequate measures.
Declaration of Conformity
Manufacturer's Name NCR Corporation
Manufacturer's Address NCR Corporation
Hospitality Division –Atlanta
2651 Satellite Boulevard
Duluth, GA 30096‐5810
Type of Equipment Information Technology Equipment—Electronic Payment Controller
Model Number 1651
NCR Corporation, 3097 Satellite Boulevard, Duluth, GA 30096, USA, declares that the equipment specified above
conforms to the referenced EU Directives and Harmonized Standards.
EU Directive Harmonized Standard (s)
2004/108/EC
EN 55022: 1998 + A1: 2000+ A2:2003
EN 55024: 1998 + A1: 2001+ A2:2003
EN 61000-3-2: 2000 + A2: 2005
EN 61000-3-3: 1995 + A1: 2001 + A2: 2005
2006/95/EC (Low Voltage)
EN 60 950-1; 2006/A11:2009
EN 60 825-1; 2007
Grounding Instructions
Warning: Grounding circuit continuity is vital for safe operation of the machine. Never operate the machine with the
grounding conductor disconnected.
In the event of a malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce
the risk of electric shock. This product is equipped with an electric cord having an equipment‐grounding conductor and a
grounding plug. The plug must be plugged into a matching outlet that is properly installed and grounded in accordance
with all local codes and ordinances. Do not modify the plug provided –if it will not fit the outlet, have the proper outlet
installed by a qualified electrician. Improper connection of the equipment‐grounding conductor can result in a risk of
electric shock. The conductor with insulation having an outer surface that is green with or without yellow stripes is the
equipment‐grounding conductor. If repair or replacement of the electric cord or plug is necessary, do not connect the
equipment‐grounding conductor to a live terminal. Check with a qualified electrician or service personnel if the grounding
instructions are not completely understood, or if you are in doubt as to whether the product is properly grounded. Use
only 3‐wire extension cords that have 3‐prong grounding plugs and 3‐pole receptacles that accept the product’s plug.
Repair or replace damaged or worn cords immediately.
Instruction pour Conducteurs
Attention: Assurer la continuité du circuit est essentiel pour un déroulement sécurisé des machines. Ne jamais opérer
les machines avec les conducteur de terre débranchés.
Au cas d’un mauvais fonctionnement ou d’une panne, le conducteur de protection offre une alternative de résistance au
courant électrique, permettant de réduire le choc. Ce produit est équipé dʹun câble électrique et dʹun conducteur de
protection et d’une prise de terre. La prise doit être branchée à un distributeur correspondant et installé en accord avec
les réglementations locales. Ne pas modifier la prise fournit, elle ne fonctionnera pas avec le distributeur et veuillez vous
assurer que le distributeur est installé par un technicien qualifié. Un mauvais branchement de l’équipement ou du
conducteur de protection peut provoquer l’électrocution. Le conducteur avec l’isolement possède une surface externe
qui est verte avec ou sans rayures jaunes est l’équipement de protection du conducteur. Au cas ou une réparation ou le
remplacement d’un des câbles serait nécessaire, veuillez ne pas brancher l’équipement de protection du conducteur au
terminal actif. Vérifiez qu’un électricien qualifié ou un membre du personnel s’en charge si les instructions ne sont pas
parfaitement comprises. Utilisez une extension de trois câbles de prise terrienne et trois pôles de réceptions qui sont
compatibles avec la prise. Réparer ou remplacer immédiatement tout câble endommagé.
ERDUNGSANWEISUNGEN
Warnung: Im Fall einer Funktionsstörung oder eines Zusammenbruchs stellt die Erdung einen Pfad des niedrigsten
Widerstandes für elektrische Strömung zur Verfügung, um das Risiko des Elektroschocks zu reduzieren. Dieses Produkt
ist ausgestattet mit einer elektrischen Schnur die eine Geräteerdungsletung und einen Erdungsstecker. Der Stecker
muss in einer dazugehörigen Steckdose, die geerdet ist, nach den örtlichen Voraussetzungen, eingesteckt werden.
Ändern Sie nicht den Stecker‐sollte der nicht in die Steckdose passen, installieren Sie eine angemessene Steckdose
durch Ihren Elektriker. Ein falscher Anschluß der Geräteerdungsleitung könnte einen elektrischen Schock verursachen.
Die Leitung, die isuliert ist , ist auf der Oberfläche grün mit oder ohne gelbe Streifen und ist die Erdung. Muss die Leitung
oder der Stecker repariert oder ersetzt werden, verbinden Sie nicht die Erdung des Gerätes zu dem Terminal, das in
Betrieb ist. Überprüfen Sie mit einem Elektriker oder einem Serviceangestellten, wenn Sie die Erdungsanweisungen
nicht verstehen, oder wenn Sie bedenken haben, dass das Gerät nicht richtig geerdet ist. Verwenden Sie nur Kabel mit
3 Adern, die eine drei‐Stift Erdung haben , und drei Pole, die den Stecker des Produktes einnehmen.
Reparieren oder ersetzen Sie beschädigte oder verbrauchte Kabel sofort.
Environmental Consciousness
NCR is demonstrating its concern for the environment by designing an intelligent power management system into this
terminal that operates efficiently whether the system is in a stand‐alone or network environment. Do not discard the unit
or its parts (e.g. batteries) with general household waste; recycle or dispose in accordance with your local regulations.
State of California Perchlorate Material Notification
Perchlorate Material —special handling may apply.
See: http://www.dtsc.ca.gov/hazardouswaste/perchlorate
The lithium coin cell batteries in this product contain Perchlorate and are subject to the State of California’s Best
Management Practices (BMP) Regulations for Perchlorate Materials. Please visit the above website for more
information.
Essential Safety Precautions Cont’d
Page 6 497-0503689 Rev C
