NCR 7362-K094 Manual

Kit Instructions
GSR50 Note Recycler Locks
7362-K094
Issue C

The product described in this document is a licensed product of NCR Corporation.
NCR is a registered trademark of NCR Corporation. NCRFastLane SelfServ™ (7362) Cash Tender Module is a trademark of NCR
Corporation in the United States and/or other countries. Other product names mentioned in this publication may be trademarks
or registered trademarks of their respective companies and are hereby acknowledged.
Where creation of derivative works, modifications or copies of this NCR copyrighted documentation is permitted under the
terms and conditions of an agreement you have with NCR, NCR's copyright notice must be included.
It is the policy of NCR Corporation (NCR) to improve products as new technology, components, software, and firmware become
available. NCR, therefore, reserves the right to change specifications without prior notice.
All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances,
photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR
office for information that is applicable and current.
Copyright © 2018-2023
By NCR Corporation
Global Headquarters
864 Spring St. NW
Atlanta, GA 30308
United States
All Rights Reserved

i
Revision Record
Issue Date Remarks
AOct 2018 First issue.
BApr 2020 Updated Kit Contents.
CMay 2023 • Modified Installing GSR50 Loader Cassette Lock on
page11.
• Added the following sections:
•Removing GSR50 Recycler Stacker Lock on page3.
•Removing GSR50 Loader Cassette Lock on page8.
•Removing GSR50 Notebox (Cashbox) Lock on
page15.
•Removing GSR50 Notebox (Cashbox) Security Door
on page19.

GSR50 Note Recycler Locks
This publication provides procedures for installing locks on the GSR50 Note Recycler
modules.
Kit Contents
The GSR50 Note Recycler Locks Installation Kit contains the following:
Part Number Description
497-0527919 7362-K094 GSR50 Note Recycler Locks
497-0524869 Notebox (Cashbox) Security Door Assembly
006-8627781 Loader Mini Lock Assembly Standard Keyed
006-8627782 Recycler Mini Lock Assembly Standard Keyed (3 pcs)
006-8627784 Notebox (Cashbox) Mini Lock Assembly Standard Keyed
006-8627786 Notebox (Cashbox) Door Mini Lock Assembly Standard
Keyed
* 497-0423108 Instructions-Kit (Reference Sheet)
* Items marked with an asterisk are not called out on the image.

2 7362-K094 GSR50 Note Recycler Locks
Installation Procedure
Installing the locks on the GSR50 Note Recycler modules involves the following
procedures:
Note: It is highly recommended to use screw and nut drivers with torque limiter.
•Removing GSR50 Recycler Stacker Lock on the facing page.
•Installing GSR50 Recycler Stacker Lock on page5
•Removing GSR50 Loader Cassette Lock on page8.
•Installing GSR50 Loader Cassette Lock on page11.
•Removing GSR50 Notebox (Cashbox) Lock on page15.
•Installing GSR50 Notebox (Cashbox) Lock on page17.
•Removing GSR50 Notebox (Cashbox) Security Door on page19.
•Installing GSR50 Notebox (Cashbox) Security Door on page22.

7362-K094 GSR50 Note Recycler Locks 3
Removing GSR50 Recycler Stacker Lock
To remove the GSR50 Recycler Stacker lock, follow these steps:
1. Loosen and remove the screw to detach the Recycler Module Cam from the lock
assembly.
2. Loosen and remove the retainer nut from the Lock Mini Cam.

4 7362-K094 GSR50 Note Recycler Locks
3. Pull out the Lock Mini Cam and Key from the Recycler Frame.

7362-K094 GSR50 Note Recycler Locks 5
Installing GSR50 Recycler Stacker Lock
To install the GSR50 Recycler Stacker lock, follow these steps:
1. Remove the existing GSR50 Recycler Stacker Lock, if necessary. For more
information, refer to Removing GSR50 Recycler Stacker Lock on page3.
2. Insert the Lock Mini Cam to the Recycler frame using a key in a horizontal position
as shown in the image below. Ensure that the key can rotate to 1/4 turn counter
clockwise as shown in the image below.

6 7362-K094 GSR50 Note Recycler Locks
3. Secure the Lock Mini Cam using a retainer nut and torque the nut to 4Nm or
35in/lbs.

7362-K094 GSR50 Note Recycler Locks 7
4. Attach the Recycler Module Cam in a vertical position to the Lock Mini Cam using a
screw and torque the screw to 4Nm or 35 in/lbs. Note the orientation of the cam in
relation to the key position as shown in the image below.

8 7362-K094 GSR50 Note Recycler Locks
Removing GSR50 Loader Cassette Lock
To remove the GSR50 Loader Cassette lock, follow these steps:
1. Open the Loader Cassette by pressing the green button on the back of the Loader
Cassette and then lift the lid.
2. Remove two (2) screws to detach the bill guide from the Loader Cassette, as shown
in the image below.

7362-K094 GSR50 Note Recycler Locks 9
Note: The two (2) hex nuts may fall out of the cassette. Ensure not to lose these
nuts.
3. Loosen and remove the cam screw to detach the Loader Cassette Cam from the
Lock.

10 7362-K094 GSR50 Note Recycler Locks
4. Loosen and remove the retainer nut from the Lock, as shown in the image below.
5. Remove the Lock from slot of the Loader Cassette.

7362-K094 GSR50 Note Recycler Locks 11
Installing GSR50 Loader Cassette Lock
To install the GSR50 Loader Cassette lock, follow these steps:
1. Open the Loader Cassette by pressing the green button on the back of the Loader
Cassette and then lift the lid.
2. Remove two (2) screws to detach the bill guide from the Loader Cassette, as shown
in the image below.

12 7362-K094 GSR50 Note Recycler Locks
Note: The two (2) hex nuts may fall out of the cassette. Ensure not to lose these
nuts.
3. Insert the lock into the cassette lock slot.
Note: Ensure correct orientation of the key as shown in the image below.

7362-K094 GSR50 Note Recycler Locks 13
4. Secure the lock by attaching a nut, as shown in the image below.
Note: Use a 15 mm socket to torque the nut to 3 Nm.
5. Attach the Loader Cassette Cam in a horizontal position to the Lock using a cam
screw, and then torque the screw to 2 Nm.
Note: Ensure correct orientation of the key and the Loader Cassette cam. The
Loader Cassette cam must be in horizontal position blocking the latch when the key
is in vertical or locked position.

14 7362-K094 GSR50 Note Recycler Locks
6. Verify the locked and unlocked positions of the key and cam.
7. Attach the bill guide to the Loader Cassette using two (2) screws, as shown in the
image below.
8. Close the Loader Cassette by pushing down the lid until it snaps in place.

7362-K094 GSR50 Note Recycler Locks 15
Removing GSR50 Notebox (Cashbox) Lock
To remove the GSR50 Notebox (Cashbox) Lock and Security Door, follow these steps:
1. Open the Notebox by sliding the cover and then lifting it, as shown in the image
below.
Note: Do not let go of the cover. If you slide the cover and then let go, the spring
pulls it back in place and you can't lift it.
2. Loosen and remove the screw to detach the Notebox (Cashbox) Cam from the Lock
Mini Cam, as shown in the image below.

16 7362-K094 GSR50 Note Recycler Locks
3. Loosen and remove the retainer nut to detach the Lock Mini Cam from the lock hole
of the Notebox (Cashbox).

7362-K094 GSR50 Note Recycler Locks 17
Installing GSR50 Notebox (Cashbox) Lock
To install the GSR50 Notebox (Cashbox) Lock and Security Door, follow these steps:
1. Remove the existing GSR50 Notebox (Cashbox) Lock, if necessary. For more
information, refer to Removing GSR50 Notebox (Cashbox) Lock on page15.
2. Insert the Lock Mini Cam into the lock hole of the Notebox (Cashbox) using a key.
Make sure that the key can rotate to 1/4 turn counter clockwise as shown in the
image below.
