NDD Easy on-PC User manual

Easy on-PC | Quick Start Guide
Doc 0327 iss02
n d d
1
4
7
2
5
3
6
Double click on the EasyOne
Connect software icon on the
Desktop to open the software.
From the main menu, click on
“Patients”
You have a choice of 5 tests. The only tests that you
will use are“SVC” and“FVC”(ex only). To perform a slow
VC rst click on“SVC”. On the next screen the ambient
temperature etc will be shown. Click Conrm.
You will then be asked to block the spirette. Place
your palm over the end of the spirette (as shown) and
click“OK”. This will set the baseline for the spirometer.
When the message‘Start test’ appears you are ready to
perform the relaxed test.
This step by step guide is designed to show users how to add patient details and perform a basic
spirometry test using the EasyOne Connect software. IMPORTANT: Please ensure the software
is fully installed and congured correctly before use. Refer to conguration guide
(document reference 0318).
Plug the Easy On Flowhead
into the USB port of the PC.
Click on“New”on the bottom
left hand side of your screen.
Fill in the patient details as
required. Then click“OK”
Insert the Spirette‘M’into the
ow head. Attach adaptor
and insert a clean one way
valve mouthpiece.
The patient you have just
added will be already
highlighted in the patient list.
Click on“Test”to proceed.
For use in Primary Care

Doc 0327 iss02
8
10
9
11
Perform the test. When the manoeuvre has ended the results will be
shown at the bottom left of the screen of the screen.
To perform a second manoeuvre click“Add Trial”and perform the second
test. When the second manoeuvre has been performed you will also be
able to see a % variation between the tests and also the variation in mls.
Do as many tests as required.
If after any manoeuvres you would like to delete them or
mark them as acceptable, double-click on the column of
that test.
A new window will appear. Press the“Delete”button to
delete that trial. A login prompt will appear. Type your
name into the box and click“login”.
If the test was deemed to be unacceptable by the software
but you felt that the test was of good enough quality then
you may also override this by ticking“Acceptable”.
This will then allow that test to be used in the results.
When you have nished the required number of SVC tests
click on“Test”(on the right side of the screen.
Then click on FVC (ex \only) on the main menu.
Conrm the temperature etc. and set the baseline by
blocking the Spirette (as per point 7) and then perform the
FVC tests as required.
Again after each test you will see the results appear at the
bottom of the screen and the variation between tests.
When you have nished the required number of FVC tests click on either
“print”to print or if you wish to save the test as a pdf click on“report”then
“print menu”and then“pdf” and you can save it to the required folder.
