Quick Start Guide for the SoundStation®IP 7000 When Operating with a NEC UNIVERGE®Switch
Quick Start Guide for the SoundStation®IP 7000 Phone
When Operating with a NEC UNIVERGE®Switch
Thank you for choosing the Polycom®
SoundStation IP 7000, a conference
telephone that provides high quality
audio conferencing over an IP network.
These items are included in your
SoundStation IP 7000 package. If you
are missing any items, contact your
SoundStation IP 7000 reseller.
Parts List
Optional Accessories
External Microphones
Quick Start Guide*
* Polycom Guide
Network Cable
SoundStation IP 7000
Power Interface Cable
Power Adapter
(Not shown: Country-Specific Power Cable)

Quick Start Guide for the SoundStation®IP 7000 When Operating with a NEC UNIVERGE®Switch
To install the SoundStation IP 7000, plug
one end of the network cable into the
network port on the bottom of the
SoundStation IP 7000 console, and plug
the other end of the network cable into
your data port with PoE.
Installation
External Microphone
Connect external microphones (optional
accessory), as shown below.

Quick Start Guide for the SoundStation®IP 7000 When Operating with a NEC UNIVERGE®Switch
After it has been connected to the
network, the SoundStation IP 7000
automatically powers up via Power over
Ethernet (PoE), and begins a process of
establishing itself on the network. When
this is complete, the Idle screen is
displayed (as shown on the right).
For more information, refer to the
SoundStation IP 7000 User Guide,
available online at:
http://www.necunified.com
Soft Keys
Call Key
Menu Key Volume Up/
Down Keys
End Call Key
Microphone
Mute
Navigation and
Select Keys
Features
Startup
Conference
Key*
Redial Key
Speaker
LED Indicator
LED Indicator
Microphone
Keypad
Microphone
Microphone
LED Indicator
Graphic LCD Display
Dialing Keypad
Idle Screen
