NEC POWERMATE P2166 User manual

First Printing — January 1997
Copyright 1997
NEC Computer Systems Division
Packard Bell NEC, Inc.
1414 Massachusetts Avenue
Boxborough, MA 01719-2298
All Rights Reserved
PROPRIETARY NOTICE AND LIABILITY DISCLAIMER
The information disclosed in this document, including all designs and related materials, is
the valuable property of NEC Computer Systems Division, Packard Bell NEC, Inc.
(hereinafter “NECCSD”) and/or its licensors. NECCSD and/or its licensors, as appropriate,
reserve all patent, copyright and other proprietary rights to this document, including all de-
sign, manufacturing,reproduction, use, and sales rights thereto, except to the extent said
rights are expressly granted to others.
The NECCSD product(s) discussed in this document are warranted in accordance with the
terms of the Warranty Statement accompanying each product. However, actual
performance of each such product is dependent upon factors such as system configuration,
customer data, and operator control. Since implementation by customers of each product
may vary, the suitability of specific product configurations and applications must be
determined by the customer and is not warranted by NECCSD.
To allow for design and specification improvements, the information in this document is
subject to change at any time, without notice. Reproduction of this document or portions
thereof without prior written approval of NECCSD is prohibited.
NEC is a registered trademark of NEC Corporation and FastFacts, MultiSync, and PowerMate are either trademarks or registered trademarks
of NEC Technologies, Inc.; these trademarks are used under license by Packard Bell, NEC.
All other product, brand, or trade names used in this publication are the trademarks or registered trademarks of their respective trademark
owners.

iii
Contents
Preface.........................................................................................................................xvii
Abbreviations...............................................................................................................xix
Section 1 Technical Information
Desktop System Chassis...............................................................................................1-3
Minitower System Chassis ...........................................................................................1-4
System Board ..............................................................................................................1-5
Processor..............................................................................................................1-8
Secondary Cache ..................................................................................................1-8
System and Video BIOS .......................................................................................1-9
System Memory....................................................................................................1-10
Integrated Graphics...............................................................................................1-10
Video Memory...............................................................................................1-11
Video Resolutions and Refresh Rates....................................................................1-11
Interrupt Controller...............................................................................................1-12
I/O Addressing......................................................................................................1-13
ISA Bus................................................................................................................1-14
PCI Local Bus ......................................................................................................1-14
PCI Auto Configuration........................................................................................1-14
PCI/IDE Ports ......................................................................................................1-14
Parallel Interface...................................................................................................1-15
Serial Interface......................................................................................................1-15
USB Interface.......................................................................................................1-16
Infrared Interface..................................................................................................1-17
Power Supply ..............................................................................................................1-17
Diskette Drive..............................................................................................................1-17
Hard Disk Drive...........................................................................................................1-17
Keyboard.....................................................................................................................1-18
Mouse .........................................................................................................................1-18
Multimedia Components..............................................................................................1-18
Integrated Audio...................................................................................................1-18
CD-ROM Reader..................................................................................................1-19
Speakers...............................................................................................................1-19
Microphone ..........................................................................................................1-19
Plug and Play...............................................................................................................1-20

iv Contents
Power Management.....................................................................................................1-20
LANDesk Client Manager............................................................................................1-21
PC Health Indicator ..............................................................................................1-21
Managing Workstations .................................................................................1-21
PC Health Meter............................................................................................1-22
PC Health Description....................................................................................1-22
Inventory..............................................................................................................1-23
Using DMI............................................................................................................1-24
Heceta Capabilities................................................................................................1-24
Specifications...............................................................................................................1-25
Section 2 Setup and Operation
Unpacking and Repacking............................................................................................2-1
Setup...........................................................................................................................2-1
Desktop Setup......................................................................................................2-1
Minitower Setup...................................................................................................2-4
Power Management.....................................................................................................2-7
NEC Setup Icon...........................................................................................................2-8
CD-ROM Reader.........................................................................................................2-8
System Configuration...................................................................................................2-10
Setup Utility..........................................................................................................2-10
How to Start Setup........................................................................................2-11
How to Use Setup..........................................................................................2-12
Main Menu ...........................................................................................................2-12
System Date/Time..........................................................................................2-13
Diskette Drive................................................................................................2-13
IDE Devices...................................................................................................2-13
IDE Device Configuration Submenu...............................................................2-14
IDE Device Configuration..............................................................................2-14
IDE Translation Mode ...................................................................................2-14
Language.......................................................................................................2-15
Boot Options .................................................................................................2-16
Boot Options Submenu..................................................................................2-16
Boot Sequence...............................................................................................2-16
System Cache.................................................................................................2-16
Boot Speed....................................................................................................2-16
Num Lock......................................................................................................2-17

Contents v
Setup Prompt.................................................................................................2-17
Hard Disk Pre-Delay......................................................................................2-17
Typematic Rate Programming........................................................................2-17
Scan User Flash Area.....................................................................................2-18
Boot Virus Detection.....................................................................................2-18
Video Mode...................................................................................................2-18
Mouse............................................................................................................2-18
Base Memory.................................................................................................2-19
Extended Memory..........................................................................................2-19
BIOS Version ................................................................................................2-19
Advanced Menu....................................................................................................2-19
Processor Type..............................................................................................2-19
Processor Speed.............................................................................................2-20
Cache Size.....................................................................................................2-20
Peripheral Configuration ................................................................................2-20
Peripheral Submenu .......................................................................................2-20
IDE Interface (Primary and Secondary)..........................................................2-20
Floppy Interface.............................................................................................2-20
Serial Port (1 and 2) Address .........................................................................2-21
Serial Port 2 IR Mode....................................................................................2-21
Parallel Port Interface.....................................................................................2-21
Parallel Port Type ..........................................................................................2-21
Audio Interface..............................................................................................2-22
Hardware Monitor Interface...........................................................................2-22
PCI LAN Interface.........................................................................................2-22
Advanced Chipset Configuration....................................................................2-22
Advanced Chipset Submenu...........................................................................2-22
Base Memory Size.........................................................................................2-22
ISA LFB Size.................................................................................................2-23
ISA LFB Base Address..................................................................................2-23
Video Palette Snoop ......................................................................................2-23
Latency Timer (PCI Clock)............................................................................2-23
Banks 0, 1 and 2 SIMM Detected ..................................................................2-23
Power Management Configuration.................................................................2-24
Power Management Submenu........................................................................2-24
IDE Drive Power Down.................................................................................2-24
Inactivity Timer (Minutes)..............................................................................2-24

vi Contents
Hot Key.........................................................................................................2-24
Plug and Play Configuration...........................................................................2-25
Plug and Play Submenu..................................................................................2-25
Boot with PnP OS..........................................................................................2-26
ISA Shared Memory Size...............................................................................2-26
ISA Shared Memory Base Address ................................................................2-26
Event Logging Configuration.........................................................................2-27
Security Menu.......................................................................................................2-28
Set User Password and Set Administrative Password .....................................2-29
Unattended Start............................................................................................2-29
Security Hot Key (CTRL-ALT-)....................................................................2-30
Exit Menu.............................................................................................................2-30
Exit Saving Changes ......................................................................................2-30
Exit Discarding Changes ................................................................................2-30
Load Setup Defaults.......................................................................................2-31
Discard Changes ............................................................................................2-31
BIOS Update Utility ....................................................................................................2-31
NECCSD Bulletin Board Service..........................................................................2-31
Using the BIOS Update Utility..............................................................................2-33
CD Restore..................................................................................................................2-33
Selecting CD Restore Options...............................................................................2-33
Restore Individual Files..................................................................................2-34
System Recovery ...........................................................................................2-34
Restoring Individual Files......................................................................................2-35
Selecting Files................................................................................................2-35
Checking Selected Files..................................................................................2-36
Restoring the Files .........................................................................................2-36
Recovering the System..........................................................................................2-36
LANDesk Client Manager Setup..................................................................................2-38
Using LANDesk Client Manager...........................................................................2-38
Accessing the LANDesk Client Online Guide.................................................2-38
“Discover” Feature.........................................................................................2-38
Heavy Network Use with Other PowerMate Models......................................2-39
Multiple Admin Sessions................................................................................2-39
Audio Not Listed in DMI...............................................................................2-39

Contents vii
Section 3 Option Installation
General Rules for Installing Options.............................................................................3-1
Precautions..................................................................................................................3-1
Removing and Replacing the System Unit Cover..........................................................3-2
Removing the Desktop Cover ...............................................................................3-3
Replacing the Desktop Cover................................................................................3-4
Removing the Minitower Cover ............................................................................3-5
Replacing the Minitower Cover.............................................................................3-6
Expansion Boards.................................................................................................3-7
Locating Expansion Slots...............................................................................3-8
Installing an Expansion Board........................................................................3-9
Installing an Expansion Board in the Inside Slot .............................................3-11
Removing an Expansion Board from the Inside Slot.......................................3-13
System Board Options ..........................................................................................3-14
SIMM Upgrade.....................................................................................................3-15
Checking System Memory..............................................................................3-15
Removing a SIMM.........................................................................................3-17
Installing a SIMM..........................................................................................3-18
Video Upgrade .....................................................................................................3-19
OverDrive Processor Upgrade...............................................................................3-20
Removing the Processor.................................................................................3-20
Installing the OverDrive Processor.................................................................3-21
Data Storage Devices...................................................................................................3-22
Device Slots..........................................................................................................3-22
Device Preparation................................................................................................3-24
Device Cables.......................................................................................................3-24
Diskette Drive Signal Cable............................................................................3-25
IDE Signal Cables..........................................................................................3-26
System Power Cables.....................................................................................3-27
Cabling Storage Devices ................................................................................3-27
IDE Device Cabling .......................................................................................3-28
Diskette Drive Cabling...................................................................................3-28
Installing Desktop Storage Devices................................................................3-29
Removing the Desktop 3 1/2-Inch Drive Bracket ...........................................3-29
Installing the Desktop 3 1/2-Inch Drive..........................................................3-30
Removing the Desktop Front Panel................................................................3-31

viii Contents
Installing the Desktop 5 1/4-Inch Device........................................................3-32
Replacing the Desktop Front Panel.................................................................3-33
Replacing the Desktop 3 1/2-Inch Drive Bracket............................................3-34
Installing Minitower Storage Devices.............................................................3-35
Installing the Minitower 3 1/2-Inch Drive.......................................................3-36
Removing the Minitower Side Panel...............................................................3-38
Removing the Minitower Front Panel.............................................................3-38
Installing the Minitower 5 1/4-Inch Device.....................................................3-40
Replacing the Minitower Side and Front Panels..............................................3-41
Adding External Options.......................................................................................3-42
Connecting a Parallel Printer..........................................................................3-42
Connecting an RS-232C Device.....................................................................3-43
Section 4 Maintenance and Troubleshooting
Online Services............................................................................................................4-2
NEC’s FastFacts Service.......................................................................................4-2
NECCSD Bulletin Board Service..........................................................................4-3
America Online Service.........................................................................................4-4
CompuServe Online Service..................................................................................4-5
Internet.................................................................................................................4-6
Maintenance ................................................................................................................4-6
System Cleaning....................................................................................................4-7
Keyboard Cleaning................................................................................................4-7
Mouse Cleaning....................................................................................................4-8
Troubleshooting...........................................................................................................4-9
Diagnosing and Solving Problems .........................................................................4-9
CMOS Battery Replacement.................................................................................4-14
Section 5 Repair
Disassembly and Reassembly........................................................................................5-1
Desktop Disassembly............................................................................................5-1
System Unit Cover Removal ..........................................................................5-2
Expansion Board Removal.............................................................................5-3
PCI/ISA Backboard Removal.........................................................................5-4
3 1/2-inch Diskette and Hard Disk Drive Removal..........................................5-5
Front Panel Assembly Removal......................................................................5-7
Blank Panel Removal .....................................................................................5-8

Contents ix
Speaker Assembly Removal ...........................................................................5-9
SIMM Removal .............................................................................................5-10
5 1/4-Inch Device Removal............................................................................5-12
Power Supply Removal..................................................................................5-13
System Board Removal..................................................................................5-14
Minitower Disassembly.........................................................................................5-16
System Unit Cover Removal ..........................................................................5-17
Side Panel Removal........................................................................................5-19
Expansion Board Removal.............................................................................5-20
SIMM Removal .............................................................................................5-20
Front Panel Assembly Removal......................................................................5-22
Blank Panel and Metal Cover Plate Removal..................................................5-22
3 1/2-inch Diskette Drive Removal.................................................................5-23
3 1/2-inch Hard Disk Drive Removal..............................................................5-25
5 1/4-Inch Device Removal............................................................................5-26
Power Supply Removal..................................................................................5-28
System Board Removal..................................................................................5-29
Illustrated Parts Breakdown.........................................................................................5-31
Desktop Illustrated Parts Breakdown....................................................................5-31
Minitower Illustrated Parts Breakdown.................................................................5-34
Appendix A Connector Pin Assignments
CD Audio Connector Pin Assignments.........................................................................A-2
Serial Interface Connectors..........................................................................................A-3
Parallel Interface Connector.........................................................................................A-3
VGA Interface Connector Pin Assignments..................................................................A-4
Speaker Connector Pin Assignments ............................................................................A-5
Power Supply Connector .............................................................................................A-5
Keyboard and Mouse Connectors.................................................................................A-6
IrDA Connector...........................................................................................................A-7
Suspend Button Connector ..........................................................................................A-7
Fan Connector.............................................................................................................A-7
Diskette Drive Interface Pin Assignments.....................................................................A-8
IDE Interface Connectors ............................................................................................A-9
SIMM Sockets.............................................................................................................A-10
ISA/PCI-Bus Backboard Connector Pin Assignments...................................................A-11
ISA Expansion Bus Connector Pin Assignments...........................................................A-13

x Contents
Appendix B Setting System Board Jumpers
Changing Processor Jumper Settings............................................................................B-1
BIOS Recovery............................................................................................................B-4
Clearing CMOS...........................................................................................................B-5
Denying Access To Setup............................................................................................B-6
Clearing the Password..................................................................................................B-7
PCI Expansion Slots ....................................................................................................B-8
Appendix C Hard Disk Drive Specifications and Jumper Settings
Hard Disk Drive Specifications ....................................................................................C-1
3.2-GB IDE Hard Disk Drive Jumper Settings.............................................................C-2
Appendix D CD-ROM Reader Specifications and Jumper Settings
CD-ROM Reader Specifications...................................................................................D-1
NEC CD-ROM Reader.........................................................................................D-1
Lucky Goldstar CD-ROM Reader.........................................................................D-2
CD-ROM Reader Connectors and Jumper Settings ......................................................D-3
List of Figures
1-1 Desktop System Controls and Storage Device Slots.......................................1-3
1-2 Minitower System Controls and Storage Device Slots....................................1-4
2-1 Desktop Voltage Selector Switch...................................................................2-2
2-2 Desktop Peripheral Connections.....................................................................2-2
2-3 Desktop Speaker and Microphone Jacks ........................................................2-3
2-4 Desktop Power Button, Lamps, and System Controls.....................................2-4
2-5 Minitower Voltage Selector Switch................................................................2-5
2-6 Minitower Peripheral Connections..................................................................2-5
2-7 Minitower Speaker and Microphone Jacks .....................................................2-6
2-8 Minitower Power Button, Lamps, and System Controls..................................2-7
2-9 Buttons and Lamps - Desktop Model.............................................................2-7
2-10 Buttons and Lamps - Minitower Model..........................................................2-8
2-11 Typical CD-ROM Reader Controls and Indicators..........................................2-9
2-12 Main Menu ....................................................................................................2-11
3-1 Removing Cover Screws................................................................................3-3

Contents xi
3-2 Releasing the Cover .......................................................................................3-4
3-3 Replacing the System Unit Cover...................................................................3-4
3-4 Loosening Minitower Cover Screws...............................................................3-6
3-5 Releasing the Minitower Cover ......................................................................3-6
3-6 Replacing the Minitower Cover......................................................................3-7
3-7 Locating Desktop Expansion Slots.................................................................3-8
3-8 Locating Minitower Expansion Slots..............................................................3-9
3-9 Removing a Desktop Slot Cover ....................................................................3-10
3-10 Removing a Minitower Slot Cover.................................................................3-10
3-11 Installing an Expansion Board in the Desktop.................................................3-11
3-12 Installing an Expansion Board in the Minitower..............................................3-11
3-13 Removing the Slot Cover Support Screws......................................................3-12
3-14 Attaching the Slot Cover Support ..................................................................3-13
3-15 Removing the Slot Cover Screw.....................................................................3-14
3-16 System Board Sockets and Connectors ..........................................................3-14
3-17 Removing a SIMM.........................................................................................3-18
3-18 Inserting the SIMM........................................................................................3-19
3-19 Aligning the Video SGRAM Module with the Sockets...................................3-20
3-20 Releasing the Processor..................................................................................3-21
3-21 Aligning the Processor ...................................................................................3-22
3-22 Locating Desktop Device Slots ......................................................................3-23
3-23 Locating Minitower Device Slots ...................................................................3-24
3-24 System Board Cable Connectors ....................................................................3-25
3-25 Diskette Drive Signal Cable............................................................................3-26
3-26 IDE Device Signal Cable................................................................................3-27
3-27 Power Cable Connectors................................................................................3-27
3-28 Connecting IDE Device Cables ......................................................................3-28
3-29 Connecting 1.2-MB Diskette Drive Cables.....................................................3-29
3-30 Removing the 3 1/2-Inch Drive Bracket .........................................................3-30
3-31 Securing a 3 1/2-Inch Drive............................................................................3-31
3-32 Removing the Desktop Front Panel................................................................3-31
3-33 Locating the Blank Panel Tabs.......................................................................3-32
3-34 Securing the Device .......................................................................................3-33
3-35 Aligning the Front Panel.................................................................................3-34
3-36 Securing the 3 1/2-Inch Drive Bracket............................................................3-34
3-37 Locating the Power Supply............................................................................3-36
3-38 Removing the Power Supply..........................................................................3-37

xii Contents
3-39 Securing the 3 1/2-Inch Drive.........................................................................3-37
3-40 Removing the Minitower Side Panel...............................................................3-38
3-41 Removing the Front Panel..............................................................................3-39
3-42 Removing the Slot Cover...............................................................................3-39
3-43 Attaching Device Rails...................................................................................3-40
3-44 Securing the Device .......................................................................................3-41
3-45 Aligning the Front Panel.................................................................................3-41
3-46 Connecting a Printer Cable to the Desktop.....................................................3-42
3-47 Connecting a Printer Cable to the Minitower..................................................3-43
3-48 Connecting an RS-232C Cable to the Desktop ...............................................3-43
3-49 Connecting an RS-232C Cable to the Minitower ............................................3-44
4-1 Removing the Mouse Ball Cover....................................................................4-8
4-2 Battery Socket Location.................................................................................4-14
4-3 Battery Removal ............................................................................................4-15
5-1 System Unit Cover Screws.............................................................................5-3
5-2 Removing the System Unit Cover...................................................................5-3
5-3 Expansion Slot Screw ....................................................................................5-4
5-4 Inside Expansion Slot Screw..........................................................................5-4
5-5 PCI/ISA Backboard Screws...........................................................................5-5
5-6 Hard Disk and Diskette Drive Cabling............................................................5-6
5-7 3 1/2-Inch Drive Bracket................................................................................5-6
5-8 3 1/2-Inch Diskette and Hard Disk Drive Screws............................................5-7
5-9 Front Panel Tabs............................................................................................5-8
5-10 Blank Panel Tabs ...........................................................................................5-9
5-11 Internal Speaker.............................................................................................5-10
5-12 System Board Upgrade Sockets and Connectors............................................5-11
5-13 SIMM Socket................................................................................................5-11
5-14 5 1/4-Inch Device Screws...............................................................................5-12
5-15 Power Button Screws ....................................................................................5-13
5-16 Power Supply Screws ....................................................................................5-14
5-17 System Board Connectors and Screws ...........................................................5-15
5-18 Cover Screws.................................................................................................5-18
5-19 Releasing the System Unit Cover....................................................................5-18
5-20 Removing Side Panel Screws .........................................................................5-19
5-21 Expansion Board Removal.............................................................................5-20

Contents xiii
5-22 System Board Upgrade Sockets and Connectors............................................5-21
5-23 Removing a SIMM.........................................................................................5-21
5-24 Removing the Front Panel..............................................................................5-22
5-25 Removing the Slot Cover...............................................................................5-23
5-26 3 1/2-Inch Diskette Drive Cables....................................................................5-23
5-27 Diskette Drive Screws....................................................................................5-24
5-28 Diskette Drive Removal.................................................................................5-24
5-29 3 1/2-Inch Hard Disk Drive Cables.................................................................5-25
5-30 Removing the 3 1/2-Inch Drive ......................................................................5-26
5-31 Removing the5 1/4-inch Device......................................................................5-27
5-32 Removing the Device Rails.............................................................................5-27
5-33 Power Button Screws ....................................................................................5-28
5-34 Power Supply Screws ....................................................................................5-29
5-35 System Board Removal..................................................................................5-30
5-36 PowerMate P2166M/P2200M Desktop Illustrated Parts Breakdown..............5-33
5-37 PowerMate P2166M/P2200M Minitower Illustrated Parts Breakdown...........5-37
A-1 System Board Layout.....................................................................................A-1
A-2 Detailed Front System Board Connectors.......................................................A-1
A-3 Power Supply Connector Pin Assignments.....................................................A-6
B-1 Locating System Configuration Jumpers.........................................................B-2
B-2 Processor/Bus Speed Jumper Settings............................................................B-3
B-4 Clear CMOS Jumper .....................................................................................B-6
B-3 BIOS Recovery Jumper..................................................................................B-4
B-5 Setup Access Jumper .....................................................................................B-7
B-6 Clear Password Jumper..................................................................................B-8
B-7 Change PCI slot setting..................................................................................B-9
D-1 CD-ROM Connector and Jumper Locations...................................................D-4
List of Tables
1-1 PowerMate P2200M Minitower System Configurations.................................1-1
1-2 PowerMate P2166M System Configurations ..................................................1-2
1-3 System Board Chips.......................................................................................1-7
1-4 System Memory Map.....................................................................................1-9
1-5 Interrupt Assignments ....................................................................................1-12

xiv Contents
1-6 I/O Address Map ...........................................................................................1-13
1-7 Parallel Port Addressing and Interrupts ..........................................................1-15
1-8 Serial Port Addressing and Interrupts.............................................................1-16
1-9 Specifications.................................................................................................1-25
2-1 Navigation Keys.............................................................................................2-12
2-2 Hot Key Parameters.......................................................................................2-25
2-3 Security Passwords........................................................................................2-28
3-1 Recommended Memory Upgrade Path ...........................................................3-16
4-1 NECCSD Service and Information Telephone Numbers .................................4-1
4-2 Problems and Solutions..................................................................................4-9
5-1 Desktop Disassembly Sequence......................................................................5-1
5-2 Minitower System Unit Disassembly Sequence...............................................5-16
5-3 PowerMate P2166M/P2200M Desktop Field-Replaceable Parts List..............5-31
5-4 PowerMate P2166M/P2200M Desktop Documentation and Packaging..........5-34
5-5 PowerMate P2166M/P2200M Minitower Field-Replaceable Parts List...........5-35
5-6 PowerMate P2166M/P2200M Minitower Documentation and Packaging.......5-38
A-1 System Board Connectors..............................................................................A-2
A-2 CD Audio In Connector.................................................................................A-2
A-3 Serial Port Connector Pin Assignments ..........................................................A-3
A-4 Parallel Port Connector Pin Assignments........................................................A-4
A-5 VGA Interface Connector Pin Assignments....................................................A-5
A-6 Speaker Connector Pin Assignments ..............................................................A-5
A-7 Keyboard and Mouse Connector Pin Assignments..........................................A-6
A-8 IRDA Connector Pin Assignments .................................................................A-7
A-9 Suspend Connector Pin Assignments..............................................................A-7
A-10 Fan Connector Pin Assignments.....................................................................A-7
A-11 Diskette Drive Connector Pin Assignments ....................................................A-8
A-12 IDE Connector Pin Assignments ....................................................................A-9
A-13 SIMM Socket Pin Assignments......................................................................A-10
A-14 ISA/PCI Backboard Connector Pin Assignments............................................A-11
A-15 ISA Expansion Slot Pin Assignments..............................................................A-13

Contents xv
C-1 Hard Disk Drive Specifications.......................................................................C-1
C-2 IBM 3.2-GB IDE Hard Disk Jumper Settings.................................................C-3
D-1 Specifications for Sixteen-Speed NEC CD-ROM Reader................................D-1
D-2 Specifications for Sixteen-Speed Lucky Goldstar CD-ROM Reader ...............D-2
D-3 Jumper A Settings (NEC CD-ROM Reader Only)..........................................D-4
D-4 Jumper B Settings..........................................................................................D-5

xvii
Preface
This service and reference manual contains the technical information necessary to set up,
maintain, troubleshoot, and repair the NEC PowerMateP2166/P2200M Series computer
systems. It also provides hardware and interface information for users who need an
overview of the computer system design. The manual is written for NECCSD-trained
customer engineers, system analysts, service center personnel, and dealers.
The manual is organized as follows:
Section 1, Technical Information, provides an overview of the computer features,
hardware design, interface ports, internal devices and system unit specifications.
Section 2, Setup and Operation, gives general setup and operation information. Included
is a description of the system Setup utility and the factory default configuration settings. A
procedure is provided for logging onto the NECCSD Bulletin Board and obtaining the
latest Flash ROM BIOS.
Section 3, Options, provides safety precautions and installation procedures for installing
options.
Section 4, Maintenance and Troubleshooting, includes a list of NECCSD service
information and telephone numbers that provide access to the NECCSD Bulletin Board
System (BBS), FastFacts, and Technical Information Bulletins. Recommended maintenance
information and solutions to possible problems that may occur, are also provided.
Section 5, Repair, provides desktop and minitower disassembly and reassembly procedures
along with an illustrated parts breakdown. NECCSD service and spare parts ordering
information is also provided.
Appendix A, Connector Pin Assignments, provides a list of the system board’s internal
connector pin assignments and a list of external pin assignments for the keyboard/mouse,
serial port, parallel port, and video port.
Appendix B, Setting System Board Jumpers, provides jumper information for
configuring the system for a particular requirement.
Appendix C, Hard Disk Drive Specifications and Jumper Settings, provides
specifications and jumper settings for the hard disk drives that ship with the PowerMate
P2166M/P2200M Series systems.
Appendix D, CD-ROM Reader Specifications and Jumper Settings, provides
specifications and jumper settings for the CD-ROM readers that ship with the PowerMate
P2166M/P2200M Series systems.

xix
Abbreviations
A ampere
AC alternating current
AT advanced technology (IPM PC)
BBS Bulletin Board System
BIOS basic input/output system
bit binary digit
bpi bits per inch
bps bits per second
C capacitance
C centigrade
Cache high-speed buffer storage
CD-ROM compact disk-ROM
clk clock
cm centimeter
CMOS complementary metal oxide
semiconductor
COM communication
CPU central processing unit
DAC digital-to-analog converter
DACK DMA acknowledge
db decibels
DC direct current
DIP dual in-line package
DMA direct memory access
DMAC DMA controller
DOS disk operating system
DRAM dynamic RAM
ECC error checking and correction
ECP enhanced capabilities port (ECP)
EGA Enhanced Graphics Adapter
EPP Enhanced Parallel Port
EPROM erasable and programmable
ROM
F Fahrenheit
FAX facsimile transmission
FCC Federal Communications
Commission
FG frame ground
FM frequency modulation
FRU field-replaceable unit
GB gigabyte
GND ground
HEX hexadecimal
Hz hertz
IC integrated circuit
ID identification
IDE intelligent device electronics
in. inch
IPB illustrated parts breakdown
ISA Industry Standard
Architecture
I/O input/output
ips inches per second
IR infrared
IRQ interrupt request
K kilo (1024)
k kilo (1000)
KB kilobyte
kg kilogram
kHz kilohertz
lb pound
LED light-emitting diode
M mega
mA milliamps
max maximum
MB megabyte
MFM modified frequency
modulation
MHz megahertz
MIC microphone
MIDI musical instrument device
interface
MPC multimedia PC
mm millimeter
MPEG Motion Picture Experts
Group

xx Abbreviations
ms millisecond
NASC National Authorized Service
Center
NC not connected
NMI Non-maskable Interrupt
ns nanosecond
NSRC National Service Response
Center
PAL programmable array logic
PC personal computer
PCI Peripheral Component
Interconnect
PDA personal digital assistant
PFP plastic flat package
PIO parallel input/output
pixel picture element
PROM programmable ROM
RAM random-access memory
RAMDAC RAM digital-to-analog converter
RGB red green blue
ROM read-only memory
rpm revolutions per minute
R read
RTC real-time clock
R/W read/write
S slave
SCSI Small Computer System
Interface
SG signal ground
SIMM single inline memory module
SVGA Super Video Graphics Array
SW switch
TSC Technical Support Center
TTL transistor/transistor logic
tpi tracks per inch
V volt
Vac volts, alernating current
Vdc volts, direct current
VESA video electronics standards
association
VGA Video Graphics Array
VRAM video RAM
W watt
W write

Section 1
Technical Information
The PowerMate®P2166M/P2200M Series desktop and minitower systems come standard
with an Intel®Pentium™ multimedia extension (MMX™) processor, a 3 1/2-inch,
1.44 megabyte (MB) diskette drive, 256 kilobyte (KB) secondary cache, 16 MB or 32 MB
of random access memory (RAM), and 2 MB of synchronous graphics random access
memory (SGRAM).
The PowerMate P2200M system has a 200-MHz MMX processor and only comes in
minitower configurations. PowerMate P2166M systems include either a 166-MHz or
200-MHz MMX processor and come in minitower and desktop configurations.
PowerMate P2166M/P2200M Series system configurations are listed in Table 1-1 and
Table 1-2.
Table 1-1 PowerMate P2200M Minitower System
Configurations
Configurations Description
Non-multimedia 200-MHz Pentium MMX processor
3 1/2-inch diskette drive
2.0-GB hard disk
2 MB of SGRAM
16 MB of EDO RAM
256 KB secondary cache
Multimedia 200-MHz Pentium MMX processor
3 1/2-inch diskette drive
3.0-GB hard disk
Sixteen-speed CD-ROM reader
S
y
stem board w/audio
32 MB of EDO RAM
2 MB of SGRAM
256 KB secondar
y
cache
20-watt speakers
Microphone

Technical Information 1-2
Table 1-2 PowerMate P2166M System Configurations
Configurations Desktop Minitower
Non-multimedia 166-MHz Pentium MMX processor
3 1/2-inch diskette drive
2.0-GB hard disk
2 MB of SGRAM
16 MB of EDO RAM
256 KB secondary cache
166-MHz Pentium MMX processor
3 1/2-inch diskette drive
2.0-GB hard disk
2 MB of SGRAM
16 MB of EDO RAM
256 KB secondary cache
Multimedia 166- or 200-MHz Pentium MMX
processor
3 1/2-inch diskette drive
3.0-GB hard disk
Sixteen-speed CD-ROM reader
S
y
stem board w/audio
32 MB of EDO RAM
2 MB of SGRAM
256 KB secondar
y
cache
20 watt speakers
Microphone
166-MHz Pentium MMX processor
3 1/2-inch diskette drive
3.0 GB hard disk
Sixteen-speed CD-ROM reader
S
y
stem board w/audio
32 MB of EDO RAM
2 MB of SGRAM
256 KB secondar
y
cache
20 watt speakers
Microphone
Each system incorporates power management features and uses factory installed software to
enhance the hardware features. Systems come with the Windows®95 operating system pre-
installed (hot-loaded) on the hard disk.
The following paragraphs give an overview of the desktop and minitower systems.
Differences between systems are noted as they occur.

Technical Information 1-3
DESKTOP SYSTEM CHASSIS
The desktop chassis provides an enclosure for the system board, power supply, four
expansion slots, a five-connector PCI/ISA backboard, and four storage device slots. The
expansion slots include two 8-/16-bit ISA slots, one dedicated 32-bit PCI slot, and one
shared PCI/ISA (32-bit PCI or 8-/16-bit ISA) slot.
The four storage device slots accommodate up to three accessible devices and one internal
hard disk drive device. The accessible devices include the standard one-inch high 3 1/2-inch
1.44-MB diskette drive and up to two 1.6-inch high 5 1/4-inch storage devices. The non-
multimedia hard disk systems ship with an accessible 3 1/2-inch diskette drive and an
internal 3 1/2-inch hard disk drive, leaving two accessible 5 1/4-inch storage device slots
available for optional devices. The multimedia systems ship with an accessible 3 1/2-inch
diskette drive, an internal 3 1/2-inch hard disk drive, and an accessible 5 1/4-inch CD-ROM
reader, leaving one accessible 5 1/4-inch storage device slot available for an optional device.
Figure 1-1 shows front panel features and locations of the accessible storage devices in a
desktop system. Multimedia systems come with a CD-ROM reader installed in the top
accessible device slot.
Figure 1-1 Desktop System Controls and Storage Device Slots
