Using this Guide ix
Using this Guide
The NEC Versa®6060 User’s Guide gives you the information you need to
maximize the use of your NEC Versa notebook computer. Read this guide to
familiarize yourself with your NEC Versa and its features. For specific
information see

Chapter 1, “Getting Started,” to acquaint yourself with system hardware.

Chapter 2, “Introducing the Software,” for a concise summary of the
applications loaded on your system.

Chapter 3, “Using Setup,” to customize your notebook’s parameter and
power management settings.

Chapter 4, “Using Your NEC Versa,” for an understanding of system
features and functionality. You’ll also master procedures for connecting
external options like headphone, microphone or speakers.

Chapter 5, “Using Multimedia,” for steps on integrating video and sound
clips into impressive presentations.

Chapter 6, “Traveling with Your NEC Versa,” lists valuable tips for
getting the most out of your system while on the road.

Chapter 7, “Solving Problems,” provides simple solutions to common
problems that may arise while operating your notebook.

Appendix A, “Setting Up a Healthy Work Environment,” provides
guidelines to help promote a healthy work setting.

Appendix B, “Specifications,” to review NEC Versa system specifica-
tions.
TEXT SETUP
To make this guide as easy to use as possible, text is set up in the following
ways.

Warnings, cautions, and notes have the following format:

x Using this Guide
!
WARNING
Warnings alert you to situations that could result in serious personal
injury or loss of life.
!
CAUTION
Cautions indicate situations that can damage the system hardware
or software.
NOTE
Notes give particularly important information about whatever
is being described.

Names of keys are printed as they appear on the keyboard, for example,
Ctrl, Alt, or Enter.

Text that you must type or keys that you must press are presented in bold
type. For example, type dir and press Enter.
RELATED DOCUMENTS
See the following documents for additional information on your NEC Versa
6060 notebook computer:

Your NEC Versa 6060 Quick Setup sheet.

Your NEC Versa 6060 Quick Reference card.
