NEC PE401H User manual

Entry Level
Installation Projector
PE Series
PE401H digital projector
A powerhouse projector packed
with essential features, the PE Series
projector is designed for conference
and classrooms.
Essential Features
for Ease of Use
• Bright images can be easily viewed in most
applications
• High contrast images (2000:1) from the latest Texas
Instruments DLP® engine featuring BrilliantColor™
technology with improved color accuracy
• Intuitive remote control provides one-touch source
changes and complete menu control
Versatile Features and
Powerful Performance
• Powerful 8-watt stereo speakers provide volume
needed for large rooms
• Built-in wall color correction presets provide for
adaptive color tone correction to display properly on
non-white surfaces
• Plug and Play setup and operation optimizes images
displayed from computers and video sources
• Flexible input panel, color-coded and clearly labeled
connects to computers, Blu-Ray players and other
sources using the VGA, Dual HDMI and composite
inputs
• Compact size and lightweight design simplifies
transport of projector
• AV mute and video image freeze allows you to control
the presentation and focus audience attention
Designed with
the Environment
in Mind
• Extended lamp life with ECO Mode™ technology
increases lamp life up to 3300 hours, while lowering
power consumption
• Power management enables projector to
automatically turn off when an incoming signal is
not detected from any of the inputs
• Auto Power On via the RGB (15-pin) input connector
when a signal is detected from a computer
• Carbon savings meter calculates the positive effects
of operating the projector in ECO Mode, which is
encouraged by an optional message at startup.
A green ECO Mode button on the remote control
makes the switch easy.
• Quick start (3 to 4 seconds) lets you begin
presenting in seconds while quick shutdown
(immediate power off with no cooling required after
shutdown) ensures efficient energy usage
When combined with active
shutter glasses (NP02GL),
3D Ready PE Series
projectors use DLP Link™
technology, developed
by Texas Instruments, to
create 3-D images.

NEC Display Solutions
500 Park Boulevard, Suite 1100
Itasca, IL 60143
866-NEC-MORE
ECO Mode is a trademark of NEC Display Solutions. BrilliantColor is a
trademark, and DLP and the DLP logo are registered trademarks of Texas
Instruments. HDMI, the HDMI logo and High-Definition Multimedia Interface
are trademarks or registered trademarks of HDMI Licensing LLC. All other
brand or product names are trademarks or registered trademarks of their
respective holders. Product specifications subject to change.
©2013 NEC Display Solutions of America, Inc. All rights reserved.
Rev. 06012013
ORDERING MODEL NUMBERS
NP-PE401H
UNIQUE FEATURES
BrilliantColor™ technology advanced video
processing from Texas Instruments delivers more
vibrant and realistic colors and blacks richer with
detail.
Intelligent Driving Scheme (IDS2) technology
has been adopted to extend the lamp life of the
projector up to 3300 hours in ECO Mode and
2500 hours normal.
ECO Mode technology extends lamp life, lowers
audible noise and reduces total cost of owner-
ship.
Built-in closed captioning enables decoding and
display of text information from a video.
Kensington lock slot enables security cable to
be attached to projector.
Filter-free design eliminates the hassle and time
spent monitoring and/or changing filters.
10-step image magnification with location
control.
WARRANTY
Registered owners receive a 3-year parts and
labor warranty, including the first year of Insta-
Care. The lamp is covered for one year or 500
hours, whichever comes first. InstaCare provides
the original owner one year of either limited 3
business day repair/return or next business day
exchange.
SHIPS WITH
Remote control, batteries, RGB cable, power
cord, user’s manual, product registration card
Specifications for PE401H
OPTICAL
Display Technology
Light Output (lumens)
Resolution
Native
Maximum
Contrast Ratio (up to)
Lamp Type
Lamp Life (up to)
Screen Size (diagonal)
Throw Ratio
Projection Distance
Projector Angle
Lens*
Zoom
Focus
F-number
Keystone Correction
0.65” DLP by Texas Instruments with BrilliantColor
4000 normal
1080p 1920 x 1080
UXGA 1600 x 1200
2000:1
330W AC
2500 hours normal / 3300 hours eco
40 to 200 in. / 1016 to 5080mm
1.6 - 2.72
3.9 to 43.3 ft. / 1.2 to 13.2m
14° wide / 12.7° tele
1 - 1.1
Manual
F=2.41 to 2.55, f=21.83 to 24mm
+/- 40°
SIGNAL COMPATIBILITY/
CONNECTIVITY
Scan Rate
Horizontal
Vertical
Supported Video Standards
SD/HD Video Signal Compatibility
PC Signal Compatibility
Macintosh Compatibility
Input/Output Terminals
RGB1 (analog)
RGB2 (digital)
RGB3 (digital)
Video 1
Audio 1
Audio
External Control
Sync Compatibility
15 - 100 kHz
50 - 120 Hz
NTSC, NTSC4.43, PAL-M, N, B, D, G H, I, SECAM
480i, 576i, 480p, 576p, 720p, 1080i, 1080p
VGA, SVGA, XGA, WXGA, WXGA+, SXGA, SXGA+, UXGA
Yes
15-pin, component video using ADP-CV1E adapter
HDMI w/ HDCP
HDMI w/ HDCP
RCA
1/8 in. stereo
8W stereo speakers
LAN, RS-232C (D-Sub 9pin), IR, USB-B (service only)
Separate Sync / Composite Sync / Sync on G
ELECTRICAL
Power Requirements
Input Current
Power Consumption
Normal Mode / ECO Mode /
Standby / Power Saving Mode
100 – 240V AC, 50/60 Hz
2.7A / 1.4A
410W / 310W / 6W / 0.5W
MECHANICAL
Installation Orientation
Dimensions (WxDxH)
Net Weight
Fan Noise
Regulations
Table/Front, Table/Rear
13.8 x 11.1 x 4.1 in. / 350 x 281 x 105mm
10.1 lbs. / 4.6 kg
36 dB normal / 31 dB eco
USA UL60950-1 FCC Part 15 Class B, Canada
CSA60950-1, NOM
ENVIRONMENTAL
Operational Temp
Humidity
Storage
41° – 104°F / 5° – 40°C
20-80% non-condensing
-4° – 122°F / -20° – 50°C
OPTIONAL ACCESSORIES
MP300CM
NP024LP
NP02GL
RMT-PJ32
SCP200
ADP-CV1E
PWRCRD-PJPX
RGBCBL-PJPX
NECEW1-MP
NECEW2-MP
ADVEXON1-MP
ADVEXON2-MP
Ceiling mount
Replacement lamp
Active shutter 3-D glasses
Replacement remote control
Lightweight adjustable suspended ceiling plate for
use with NEC ceiling mounts
Component video adapter converts component video
to D-sub 15-pin
Power cable
RGB cable
Extends term of parts and labor warranty to 3 years
Extends term of parts and labor warranty to 4 years
Extends term of InstaCare service program to 2 years
Extends term of InstaCare service program to 3 years
